Echnical Specifications; 50 Hz - Danfoss MLM Series Application Manuallines

A G
PPLICATION UIDELINES

50 Hz

Model HP
MLZ015 2
MLZ019 2 ½
MLZ021 3
MLZ026 3 ½
MLZ030 4
MLZ038 5
MLZ042 5.5
MLZ045 6
MLZ048 7
MLZ058 7 ½
MLZ066 9
MLZ076 10
MLZ015 2
MLZ019 2 ½
MLZ021 3
MLZ026 3 ½
MLZ030 4
MLZ038 5
MLZ042 5.5
MLZ045 6
MLZ048 7
MLZ058 7 ½
MLZ066 9
MLZ076 10
MLZ/MLM015 2
MLZ/MLM019 2 ½
MLZ/MLM021 3
MLZ/MLM026 3 ½
MLZ/MLM030 4
MLZ/MLM038 5
MLZ/MLM042 5.5
MLZ/MLM045 6
MLZ/MLM048 7
MLZ/MLM058 7 ½
MLZ/MLM066 9
MLZ/MLM076 10
* at EN12900 conditions: To= -10°C, Tc= 45°C, RGT= 20°C, SC= 0K
** R507 performance data are nearly identical to R404A performance data
Motor voltage code 4: 400V/3~/50 Hz & 460V/3~/60 Hz
MLZ/MLM042: motor voltage code 5: 220-240V/1~/50 Hz
T

ECHNICAL SPECIFICATIONS

Nominal Power
cooling capacity * input *
W Btu/h kW
3300 11300 1.75
4500 15200 2.16
4700 16100 2.27
5900 20100 2.82
7100 24200 3.34
8500 28800 3.97
8900 30300 4.72
10200 34700 4.81
11100 37900 5.17
12800 43800 6.21
15200 51800 6.92
17300 59100 7.93
2000 7000 1.02
2600 9000 1.28
2800 9600 1.33
3400 11800 1.62
4200 14200 1.93
4900 16700 2.34
5300 18200 2.74
6000 20600 2.69
6400 21900 2.90
7700 26100 3.61
8900 30400 4.10
9900 33900 4.67
3300 11200 1.53
4300 14700 1.87
4600 15600 2.01
5700 19300 2.43
6800 23400 2.93
8100 27500 3.44
9100 31100 4.23
9300 31700 4.14
10600 36100 4.53
12300 42000 5.29
14100 48300 5.94
16600 56500 6.96
FRCC.PC.015.A4.02
Effi ciency *
Swept volume
COP EER
W/W Btu/h/W cm3/rev
1.89 6.44 33.8
2.06 7.05 43.5
2.08 7.08 46.2
2.09 7.12 57.1
2.12 7.25 68.8
2.13 7.27 81.0
1.88 6.43 93.1
2.11 7.21 98.6
2.14 7.32 107.5
2.07 7.05 126.0
2.19 7.49 148.8
2.18 7.46 162.4
2.01 6.87 33.8
2.05 7.01 43.5
2.11 7.20 46.2
2.13 7.26 57.1
2.16 7.38 68.8
2.09 7.13 81.0
1.95 6.64 93.1
2.24 7.66 98.6
2.21 7.54 107.5
2.12 7.25 126.0
2.17 7.41 148.8
2.13 7.25 162.4
2.15 7.35 33.8
2.30 7.84 43.5
2.27 7.75 46.2
2.33 7.96 57.1
2.33 7.97 68.8
2.34 7.98 81.0
2.16 7.36 93.1
2.24 7.66 98.6
2.33 7.97 107.5
2.33 7.94 126.0
2.38 8.13 148.8
2.38 8.12 162.4
Net weight
Displacement Oil charge
(with oil)
m3/h Litres kg
5.9 1.1 31
7.6 1.1 31
8.0 1.1 31
9.9 1.1 31
12.0 1.6 37
14.1 1.6 37
16.2 1.6 37
17.2 1.6 37
18.7 1.6 37
21.9 2.7 44
25.9 2.7 45
28.3 2.7 45
5.9 1.1 31
7.6 1.1 31
8.0 1.1 31
9.9 1.1 31
12.0 1.6 37
14.1 1.6 37
16.2 1.6 37
17.2 1.6 37
18.7 1.6 37
21.9 2.7 44
25.9 2.7 45
28.3 2.7 45
5.9 1.1 31
7.6 1.1 31
8.0 1.1 31
9.9 1.1 31
12.0 1.6 37
14.1 1.6 37
16.2 1.6 37
17.2 1.6 37
18.7 1.6 37
21.9 2.7 44
25.9 2.7 45
28.3 2.7 45
7
