3ware
®
Serial ATA RAID Controller
Supports the 9550SX Models
PN 720-0126-02
November 2005

Advertisement

Table of Contents
loading

Related Manuals for 3Ware 9550SXU-16ML

Summary of Contents for 3Ware 9550SXU-16ML

  • Page 1 3ware ® Serial ATA RAID Controller Supports the 9550SX Models PN 720-0126-02 November 2005...
  • Page 2 AMCC, 215 Moffett Park Drive, Sunnyvale, CA 94089. Trademarks 3ware®, Escalade®, and 3DM® are all registered trademarks of AMCC. The 3ware logo, 3BM, StorSwitch, TwinStor, and R5 Fusion are all trademarks of AMCC. All other trademarks herein are property of their respective owners. Disclaimer...

  • Page 3: Table Of Contents

    3DM 2 (3ware Disk Manager) ........11 3ware CLI (Command Line Interface) ....... . . 11 Monitoring, Maintenance, and Troubleshooting Features .
  • Page 4 Chapter 6. 3ware Disk Manager (3DM 2) ....... . .
  • Page 5 Rebuilding Units through 3BM ........183 www.3ware.com...
  • Page 6 Updating the 3ware Driver Under Red Hat ......203 Updating the 3ware Driver Under SuSE ......204 Updating the 3ware Driver Under FreeBSD .

  • Page 7: About This Guide

    BIOS level (3ware BIOS Manager 2, or 3BM 2) and one that runs in a browser (3ware Disk Manager 2, or 3DM 2). You can also perform many tasks at the command line, using 3ware’s Command Line Interface (CLI).
  • Page 8 C. Warranty, Technical Support, and Service Description Provides a summary of the steps required to install and set up your 3ware RAID controller. Provides step-by-step instructions for configuring RAID units if you have just installed the controller. Describes how to install drivers for the 3ware controller if you have just installed and configured it.

  • Page 9: Conventions

    In the sections that describe using 3DM, current controller is used to refer to the controller which is currently selected in this drop-down list. Unit refers to one or more disks configured through 3ware to be treated by the operating system as a single drive. Also known as an array. Array and unit are used interchangeably throughout this manual.
  • Page 10 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 11: Chapter 1. Introducing The 3Ware® 9000 Series Controller

    Introducing the 3ware® 9000 Series Controller 3ware 9550SX controllers are part of the AMCC 3ware 9000 Series Serial ATA family of controllers. This chapter introduces the features and concepts of the 9000 series as a whole, and the 9550SX in particular. It includes the following sections: “Product Features”...

  • Page 12: What's New With The 3Ware 9550Sx Controllers

    Chapter 1. Introducing the 3ware® 9000 Series Controller What’s New with the 3ware 9550SX Controllers Enhancements and changes in version 9.3 of the software for the 3ware 9000 series controllers include the following features and benefits for the 9550SX models.
  • Page 13 Other Requirements Adequate air flow and cooling Adequate power supply for drives 3DM 2 (3ware Disk Manager) displays information in a browser. It requires the following: Internet Explorer 5.5 and later or Mozilla 1.2 or later JavaScript must be enabled...

  • Page 14: Understanding Raid Concepts And Levels

    When you work with 3ware software, “unit” is the term used to refer to an array of disks that is configured and managed through the 3ware software.

  • Page 15: Available Raid Configurations

    The stripe size is configurable in the 3ware BIOS Manager (3BM) and in the 3ware Disk Manager (3DM 2). Requires a minimum of two drives.
  • Page 16 Fault tolerance is a basic requirement for mission critical systems like web and database servers. 3ware uses a patented technology, TwinStor®, on RAID 1 arrays for improved performance during sequential read operations. With TwinStor technology, read performance is twice the speed of a single drive during sequential read operation.
  • Page 17 RAID 50 array, up to one drive in each RAID 5 set can fail and the array will continue to function. Please note that if two or more drives in a RAID 5 set fail, then all of the data will be lost. www.3ware.com...

  • Page 18: Determining What Raid Level To Use

    Chapter 1. Introducing the 3ware® 9000 Series Controller Single Disk A single drive that has been configured as a unit through 3ware software. (3BM, 3DM 2, or CLI). Like disks in other RAID configurations, single disks contain 3ware Disk Control Block (DCB) information and are seen by the OS as available units.
  • Page 19 Through drive coercion, the capacity used for each drive is rounded down so that drives from differing manufacturers are more likely to be able to be used www.3ware.com Understanding RAID Concepts and Levels Depending on the number of drives, a RAID 50 may contain from 2 to 4 subunits.

  • Page 20: 3Ware Tools For Configuration And Management

    3ware Tools for Configuration and Management 3ware software tools lets you easily configure the drives attached to your 3ware RAID controller, specifying which drives should be used together as a RAID unit and the type of RAID configuration you want, and designating hot spares for use if a drive degrades.

  • Page 21: 3Bm (3Ware Bios Manager)

    3DM can be used locally (on the system that contains the 9000) or remotely (on a system connected via a network to the system containing the 9000). For details about working with 3DM, see “3ware Disk Manager (3DM 2)” on page 65.

  • Page 22: Monitoring, Maintenance, And Troubleshooting Features

    Write Cache 3DM 2 and CLI. When write cache is enabled, data will be stored in system cache, 3ware controller cache, and drive cache before the data is committed to disk. This allows the system to process multiple write commands at the same time, thus improving performance. However when data is stored in cache, it could be lost if a power failure occurred.
  • Page 23 Battery Backup Unit (BBU) installed, the cache stored on the 3ware controller can be restored. StorSave Profiles performance that is desired for a unit when write cache is enabled (9550SX controllers only). For more information, see “Setting the StorSave Profile for a Unit” on page 139.
  • Page 24 Chapter 1. Introducing the 3ware® 9000 Series Controller 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 25: Chapter 2. Getting Started With Your 3Ware Raid Controller

    Physically Install the Controller and Drives To install your controller and drives, follow the instructions in the 3ware 9550SX Serial ATA RAID Controller Quick Install Guide. If you do not have a...
  • Page 26 Driver and Firmware” on page 190. Set Up Management and Maintenance Features 3ware RAID controllers come with software that include a number of features to help you manage and maintain the controller and your configured units. The default settings for these features allow you to begin using your newly configured units right away.
  • Page 27 Background Task Settings Verify Task Schedules Follow Verify Task Schedule Rebuild Task Schedules Follow Rebuild Task Schedule Self-test Task Schedules Follow Self-test Task Schedule www.3ware.com Default Value Where to Change Enabled 3BM, 3DM, CLI Disabled 3BM, 3DM, CLI 2048 3BM, CLI...
  • Page 28 Chapter 2. Getting Started with Your 3ware RAID Controller 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 29: Chapter 3. First-Time Raid Configuration Using 3Bm

    If you will install the operating system on and boot from a unit managed through the new 3ware RAID controller, follow the steps in this chapter to use the 3ware BIOS Manager (3BM) to configure the unit and install the driver.
  • Page 30 Port1 Port2 Figure 5. 3ware BIOS Screen Press Alt-3 immediately to bring up the 3ware BIOS Manager (3BM). Normally your 3ware configuration remains on-screen for just a few seconds. However, if a unit has degraded, the screen indicates the problem and remains on your screen longer.
  • Page 31 Figure 8. Asterisks Next to Selected Drives After all drives for the unit are selected, use the Tab to move to the Create Unit button and press Enter. The Create Disk Array screen appears (see Figure 9). www.3ware.com Basic Steps for Creating a Unit...
  • Page 32 In general, use smaller stripe sizes for sequential access (such as video access) and larger stripe sizes for random access (such as a database). Striping size is not applicable for RAID 1, because it is a 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 33 3BM will ask you to confirm that you want enable write cache. The unit is not actually created and no data is overwritten until you have finished making all your changes and press F8. www.3ware.com Basic Steps for Creating a Unit...
  • Page 34 Once you have booted to the operating system, initialization of the RAID 5 or RAID 50 unit will begin after a delay of up to ten minutes. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 35: Specifying A Hot Spare

    In the list of Available Drives, highlight the drive to use. Type s to specify that the selected drive will be the hot spare. You’ll see the words “Hot Spare” appear next to the drive in the Available Drives list. Figure 13. Hot Spare Indicated www.3ware.com Specifying a Hot Spare...

  • Page 36: Leaving Individual Drives As Jbods

    3ware RAID controller should precede them in boot order. If you will install your OS on a disk or unit attached to the 3ware RAID controller, specify the controller as the boot device. (Note that if you configured more than one unit, the drive(s) specified as Unit 0 will be treated as the boot disk.)

  • Page 37: What Next

    What Next? The final steps in setting up your RAID units are to load the 3ware driver and make the units available to your operating system. For details, turn to Chapter 4, “Driver Installation.” After installing the driver, you may also want to install 3ware’s browser-based Disk Management tool, 3DM 2, or the 3ware Command Line Interface (CLI).
  • Page 38 Chapter 3. First-Time RAID Configuration Using 3BM 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 39: Chapter 4. Driver Installation

    Driver Installation The final steps in setting up your RAID units are to load the 3ware driver and make the units available to your operating system. If the unit you have created will be your system's boot device, you install the driver for the controller as you install the operating system.

  • Page 40: Driver Installation Under Windows

    2003 64-bit for AMD Opteron or Intel EM64T is also supported. It is recommended that you upgrade to the latest service pack available. A drive or unit managed by the 3ware RAID controller may be configured to be your system’s boot device. Or, you can use another device as your boot device, such as a disk attached to the motherboard.

  • Page 41: Creating A 3Ware Driver Diskette

    Creating a 3ware Driver Diskette If you are installing Windows on a new unit or drive managed by the 3ware RAID controller, you must create a 3ware driver diskette. To create a driver diskette Insert the 3ware software CD into your system.

  • Page 42: Installing The Driver On A System That Boots From A Different Device

    Installing the Driver on a System that Boots from a Different Device If you are installing the 3ware RAID controller on a system that already has the operating system installed on another drive, follow the instructions in this section, depending on the version of Windows installed on your system: “To install the 3ware driver under Windows 2000”...
  • Page 43 When the Install Hardware Device Drivers screen appears (Figure 16), click Next and follow the prompts on the screen to install the second driver. Figure 16. Install Hardware Device Drivers www.3ware.com Driver Installation Under Windows...
  • Page 44 Plug and Play device, and brings up the Found New Hardware Wizard. This wizard guides you in installing the 3ware driver (see Figure 18). Note that you will see screens for the installation of two drivers during this process.
  • Page 45 When the Welcome to the Found New Hardware Wizard screen appears again (Figure 20), click Next and follow the prompts on the screen to install the second driver. Figure 20. Welcome to the Found New Hardware Wizard www.3ware.com Driver Installation Under Windows...
  • Page 46 Figure 21. Completing Found New Hardware Wizard After the driver has been installed, continue with the instructions below under “Making Units Managed by a 3ware Controller Available to Windows” on page 37. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 47: Making Units Managed By A 3Ware Controller Available To Windows

    Making Units Managed by a 3ware Controller Available to Windows After the 3ware driver has been installed, you need to partition and format the new units or disks. Remove the driver diskette or CD, reboot the system, and log in as the system administrator.

  • Page 48: Driver Installation Under Linux

    You can download that guide from: www.3ware.com/support/userdocs.asp A drive or unit managed by the 3ware RAID controller may be configured to be your system's boot device. Or, you can use another device as your boot device, such as a disk attached to the motherboard.

  • Page 49: Obtaining 3Ware Linux Drivers

    RedHat, SuSE, and other versions of Linux. Be Sure to Use the Correct Drivers The Linux 3w-9xxx drivers included on the 3ware CD are for 3ware 9550SX and 9500S series controllers. 3ware 7/8000 series controllers use a Linux driver labeled 3w-xxxx. The drivers for the 9000 series controllers and the 7/8000 series controllers are not interchangeable, but can be used together when both controller types are installed in the same system.

  • Page 50: Driver Installation Under Red Hat Linux Or Fedora Core 4

    Hat Linux is already installed on another drive.) Creating a Red Hat Linux Driver Diskette If you are installing Linux on the new drive or unit managed by the 3ware RAID controller, you must create a 3ware driver diskette. If Linux is already installed on another device, you may install the 3ware driver from either the 3ware software CD-ROM or make a driver diskette.
  • Page 51 In the 3ware Driver & Firmware Disk Images menu, click the button for the driver disk you want to create. A confirmation window opens. Insert a blank diskette into a drive and click the Yes button to begin creating the driver floppy diskette.
  • Page 52 If asked for what type of media, select Local CD-ROM since you are installing from the Red Hat CD-ROM. Installing the 3ware Driver on a Red Hat Linux System that Boots From a Different Device The steps for installing the 3ware driver vary slightly, depending on your specific installation requirements.
  • Page 53 For Bigmem kernels: For Hugemem kernels: For IA32E kernels: To install the 3ware driver and update the RAM disk Log in as root and open a console window. Mount the CD which contains the 3ware driver. To mount the CD, type:...
  • Page 54 The output should be similar to: Added linux * Reboot. The 3ware driver will be loaded from the ram disk automatically at boot time. To install the 3ware driver and load the driver manually instead of using a RAM disk Log in as root and open a console window.

  • Page 55: Driver Installation Under Suse Linux

    Creating a SuSE Linux Driver Diskette If you are installing Linux on the new drive or unit managed by the 3ware RAID controller, you must create a 3ware driver diskette. If Linux is already installed on another device, you may install the 3ware driver from the 3ware software CD-ROM.
  • Page 56 Chapter 4. Driver Installation Insert the 3ware Linux driver installation diskette. Click OK and continue with the installation. Installing the 3ware Driver on a SuSE Linux System that Boots from a Different Device Log in as root. Edit /etc/sysconfig/kernel following line: INITRD_MODULES="reiserfs 3w-9xxx"...

  • Page 57: Compiling A 3Ware Driver For Linux

    If you are using a Linux distribution for which there is not a compiled driver available from 3ware, you can copy the source from the 3ware software CD or download the source from the 3ware website and compile a new driver. For more information, see 3ware knowledgebase article 14546 http://www.3ware.com/KB/article.aspx?id=14546.

  • Page 58: Driver Installation Under Freebsd

    RAID Controller Quick Install Guide from: support/userdocs.asp A drive or unit managed by the 3ware RAID controller may be configured to be your system's boot device. Or, you can use another device as your boot device, such as a disk attached to the motherboard.

  • Page 59: Installing The Driver Under Freebsd

    “Installing the Driver while Installing FreeBSD on the 3ware RAID Controller” on page 49 “Installing the 3ware Driver on a FreeBSD System that Boots from a Different Device” on page 52 Installing the Driver while Installing FreeBSD on the 3ware RAID...
  • Page 60 Boot with the FreeBSD CD-ROM or diskette. In the sysinstall menu, select Configure > Load KLD module. Note: insert an MS-DOS floppy with the 3ware driver, the floppy drive. If you do not insert it immediately, the sysinstall may fail to recognize the floppy drive.
  • Page 61 For example, if the configuration file is GENERIC, type cp GENERIC custom. Edit the custom file and add the lines shown below under RAID controllers device twa # 3ware Escalade 9000 series Save the file. Change to the following directory: cd /sys/conf Edit the file "files.i386"...
  • Page 62 To make the driver part of the kernel Create the directory mkdir /sys/dev/twa Copy the 3ware driver source file archive (twa.tgz) to the directory you created in step 1. Unpack the 3ware driver source files. cd /sys/dev/twa ; tar -xzvf twa.tgz Change the kernel build infrastructure to include the 3ware driver sources.
  • Page 63 TWA_DEBUG=<number from 0 to 10> Specifying 0 in the above line prints no debug messages, whereas specifying 10 prints a LOT of debug messages. www.3ware.com Driver Installation Under FreeBSD " and add the lines shown below files.i386...
  • Page 64 Chapter 4. Driver Installation 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 65: Chapter 5. 3Ware Bios Manager 2 (3Bm 2)

    3ware BIOS Manager 2 (3BM 2) This section describes the basics of using 3ware BIOS Manager 2 (3BM 2), one of the tools you can use to configure and maintain the units connected to your 3ware 9550SX RAID controller. For information about doing particular tasks in 3BM, refer to the later sections in this guide.
  • Page 66 Chapter 5. 3ware BIOS Manager 2 (3BM 2) Press Alt-3 immediately to bring up the 3ware BIOS Manager (3BM). Normally your 3ware configuration remains on-screen for just a few seconds. However, if a unit has degraded, the screen indicates the problem and remains on your screen longer.

  • Page 67: Exiting The 3Bm Configuration Utility

    Although similar to 3BM, some screens and features are different for the 7000/8000-series. For detailed information, see the version of the 3ware Escalade ATA RAID Controller User Guide that supports the 7000 and 8000 series controllers. If you have two 9000 controllers that have different versions of the BIOS installed, they will also appear in different BIOS summaries, and will launch different versions of 3BM.

  • Page 68: Working In The 3Bm Screens

    3ware 7000/8000-series controller, and contain data that needs to be updated before your 3ware 9000 series controller can use them. (If you want to move a unit from a 7/8000 controller to the 9000 controller, you must convert the drives first.
  • Page 69 Delete Unit Maintain Unit Settings Information Specify (or unspecify) a drive as a hot spare www.3ware.com Working in the 3BM Screens Use these keys Up and Down Arrow Keys Left and Right Arrow Keys Tab and Shift+Tab Enter or the Spacebar...
  • Page 70 Chapter 5. 3ware BIOS Manager 2 (3BM 2) Table 5: Working in 3BM 2 To do this Return to starting values for this session in the 3ware BIOS Manager Rescan the controller and update the status of units and drives...

  • Page 71: Adjusting Bios Loading Settings

    PCI controllers and do not need to boot from the units. Note: BIOS for all controllers for one time only by pressing Alt-B. This is useful to temporarily boot from a non-3ware device without having to change the system’s boot order. www.3ware.com Adjusting BIOS Loading Settings Specifies what level of detail to display on the start-up .
  • Page 72 Chapter 5. 3ware BIOS Manager 2 (3BM 2) To change BIOS settings On the main 3BM screen, Tab to Settings and press Enter. On the pop-up menu, select BIOS and press Enter. The BIOS Options Settings screen appears. Figure 27. BIOS Option Settings Screen Tab through the options and make the desired changes.

  • Page 73: Displaying Controller Information

    You can get help with using 3BM while you are in the BIOS manager. Press F1 or Alt-F1 at any time. A description of the basic 3BM tasks appears. When you’re finished using help, press Esc to close the help window. www.3ware.com Displaying Controller Information Enter...
  • Page 74 Chapter 5. 3ware BIOS Manager 2 (3BM 2) 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 75: Chapter 6. 3Ware Disk Manager (3Dm 2)

    Note: for use in the OpenSSL Toolkit (http://www.openssl.org/). 3ware Disk Manager 2 (3DM 2) allows you to manage and view the status of 3ware RAID controllers and associated drives. 3DM runs as a service under Microsoft Windows, and as a daemon under Linux. When it is running, you can use your browser to view status and perform administrative tasks locally or remotely.

  • Page 76: Browser Requirements For 3Dm

    888, use the following line: pref(“network.security.ports.banned.override”, “888”) This file is located at: /usr/lib/mozilla/defaults/pref/all.js Because 3DM may be viewed in different browsers, the For security reasons, some web browsers do not allow 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 77: Installing 3Dm

    Installing 3DM 3DM 2 can be installed from the main 3ware CD that came with your 3ware RAID controller. You can also download the current version from the website at http://www.3ware.com/support/download.asp. 3DM must be installed on the system in which the controller is installed. 3DM does not have to be installed on remote systems in order to remotely manage a 3ware controller.
  • Page 78 You may enter multiple e-mail addresses, separating each entry with a comma (,). If you do not want email alerts to be sent to anyone, in these fields and click Next to go on to the next None” <file server name> 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 79 To do so, click View Certificate and then click Install Certificate. Figure 31. Security Alert dialog box When the first 3DM screen appears in your browser, log in as Administrator and use the default password, www.3ware.com Installing 3DM 3ware...

  • Page 80: Uninstalling 3Dm Under Microsoft Windows

    3, substituting your installation directory. If you are installing for FreeBSD, replace To start the installation Insert the 3ware software installation CD-ROM for Linux into the CD- ROM drive. Mount the CD-ROM disk: mount /dev/cdrom /mnt...
  • Page 81 (default is yes) If you want to be able to use 3DM for remote administration, change this to No. Change the directory and then eject the CD-ROM disk when finished: cd /home eject cdrom www.3ware.com Installing 3DM...

  • Page 82: Uninstalling 3Dm Under Linux Or Freebsd

    Chapter 6. 3ware Disk Manager (3DM 2) Uninstalling 3DM under Linux or FreeBSD To uninstall 3DM for Linux or FreeBSD Insert the 3ware software installation CD-ROM into the CD-ROM drive. Mount the CD-ROM disk: mount /dev/cdrom /mnt Change the directory and run the uninstall script: (For FreeBSD, replace “linux”...

  • Page 83: Starting 3Dm And Logging In

    3DM runs as a service under Windows, and as a daemon under Linux. It is a good idea to leave 3DM running on the system that contains your 3ware RAID controller. That way email alerts can be sent by 3DM, and administrators can manage the controller remotely, if remote administration is enabled.

  • Page 84: Viewing 3Dm Remotely Via A Standard Web Browser

    Viewing 3DM Remotely via a Standard Web Browser When remote administration is enabled, you can use 3DM to check status and administer your 3ware RAID controller from a browser on any computer, over an internet connection. You do not need to install the 3DM software on the remote computer.

  • Page 85: Working With The 3Dm Screens

    The main area of the page provides summary or detail information about your 3ware RAID controller and the resources connected to it. As you work in 3DM, the Messages area just below the menu bar displays information about the results of commands you have selected.

  • Page 86: 3Dm Menus

    3DM will use for listening. Help lets you access information about using 3DM, and provides access to an electronic copy of this User Guide. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 87: Viewing Information About Different Controllers In 3Dm

    Throughout these instructions, current controller is used to If you click Refresh on the browser window, you will be Description Provides basic information about each 3ware RAID controller in your system. To see this page, click Summary in the menu bar.
  • Page 88 Shows the status of a Battery Backup Unit (BBU), if one is installed, and allows you to test the battery. Monitor > Battery To view this page, choose Backup on the menu bar. 3ware 9550SX Serial ATA RAID Controller User Guide on the...

  • Page 89: Setting Up 3Dm Preferences

    User access level allows the user to view pages within 3DM. These passwords work independently of each other. The default password for both the User and Administrator is “3ware”. Passwords are case sensitive. You can only change passwords if you are logged in as Administrator. If you change the Administrator password, you will be automatically logged out, and must log back in with the new password.

  • Page 90: Managing E-Mail Event Notification

    Event notification can only occur while 3DM is running, so it is recommended that 3DM be left running on the system that contains the 3ware RAID controller.

  • Page 91: Enabling And Disabling Remote Access

    In the Remote Access section of the 3DM 2 Settings Page, select either Enabled or Disabled in the Allow Remote Connections field. The page refreshes, and a message at the top of the screen confirms that remote access has been enabled or disabled. www.3ware.com Setting Up 3DM Preferences...

  • Page 92: Setting The Incoming Port

    Setting the Frequency of Page Refreshes Since the status of the drives attached to your 3ware RAID controller can change while you are viewing information about them in 3DM, it’s important to refresh the page information regularly. That way you can be assured that the information you see in 3DM is current.

  • Page 93: 3Dm 2 Reference

    Unit Information Page Unit Details Page Drive Information Page Drive Details Window Controller Settings Page Scheduling Page Maintenance Page Alarms Page Battery Backup Page 3DM 2 Settings Page Controller Summary Page Figure 34. Controller Summary Page www.3ware.com 3DM 2 Reference...
  • Page 94 The Summary page appears after you first logon to 3DM, and when you click the Summary link in the menu bar. The Summary page provides basic information about each 3ware RAID controller in your system. To see details about the units in a controller, click the link in the ID column.

  • Page 95: Controller Details Page

    Download Error Log: Click on this link to download the firmware error log to your computer. This feature is important when contacting AMCC for support with your controller. It will help AMCC identify the problem you encountered. www.3ware.com 3DM 2 Reference...

  • Page 96: Unit Information Page

    RAID 5, RAID 10, RAID 50, Single Disk, JBOD, or Spare. For details about each of the RAID levels, see “Understanding RAID Concepts and Levels” on page 4. The logical capacity (size) of the unit. Capacity. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 97: Unit Details Page

    Information page. Because it is a sub-page of Unit Information, the page title in the menu bar continues to display “Unit Information” even when you view www.3ware.com 3DM 2 displays the capacity (in MBytes or GBytes) the 3DM 2 Reference...
  • Page 98 If the Type is Disk, Single Disk, JBOD, or Spare, the port to which the Port #. drive is connected is shown. For multiple drive units, the port numbers are shown in the subunits section. The port number is a link to the Drive Information page. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 99: Drive Information Page

    The unit the drive belongs to, if applicable. Unit. Status. The status of the drive: OK, Not Supported, Read Timeout, Read Failure, Orphan, DCB Data Check, Unsupp DCB, Unconv DCB, Offline JBOD, Not Present, Device Error, SMART Failure, ECC Error, or Drive www.3ware.com 3DM 2 Reference...

  • Page 100: Drive Details Window

    This Drive Details window shows some Extra Drive Information, including NCQ and SATA Link Speed support, and the SMART data for the drive. In most cases, the status of the drive will not correspond to 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 101 SMART Data SMART data is displayed as hex values. Consult your disk drive manufacturer for information on how to interpret the SMART data. The SMART data meaning varies by disk drive manufacturer and model. www.3ware.com...

  • Page 102: Controller Settings Page

    The five radio buttons let you set the ratio at which background tasks are performed in comparison to I/O. The furthest left buttons set the firmware to the fastest settings for background tasks settings. This means, maximum 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 103 For 9500S controllers, a Disable Write Cache on Unit Degrade setting can be set in 3ware BIOS Manager (3BM). You can see if this setting is enabled in the Other Controller Settings field at the bottom of this Controller Settings page.
  • Page 104 “Naming a Unit” on page 149. The policy Continue on Source Error During Rebuild is The 9550SX, like the 9500S, supports StorSave. For the If the write cache setting is disabled for a unit, the StorSave 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 105 After the unit is rebuilt, the write cache will be re-enabled automatically. (This option does not apply to 9550SX controllers; it is integrated into the StorSave policy.) www.3ware.com Number of drives that will spin up at the The delay time (in seconds) between drive groups Indicates whether unconfigured disks drives are not exported to the operating system.

  • Page 106: Scheduling Page

    3DM Version 1.x. You can also use the CLI in conjunction with the operating system schedulers. For detailed information, see the 3ware KnowledgeBase article 12290, on the website at http://www.3ware.com/kb/.
  • Page 107 The UDMA mode can become downgraded in the event that cable CRC errors are encountered, requiring multiple retries to read sectors. In severe cases, the www.3ware.com Scheduling of these tasks is only available on the 9000- Only the checked tasks will be run during the scheduled...

  • Page 108: Maintenance Page

    Alarm. Maintenance Page Figure 42. Maintenance Page The Maintenance page appears when you choose Management > Maintenance from the menu bar. This test checks to see whether SMART 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 109 In 9000-series controllers, rescan checks all ports. It checks empty ports for newly plugged in drives. If those drives were previously part of a 3ware RAID configuration and they still have valid DCB (Disk Configuration Block) information on them, the controller tries to piece them back together into a working unit.
  • Page 110 The percentage complete can be active or paused. To see whether this task is currently active or paused, click on the unit number to display the Unit Information page, which has that information. In 8000-series controllers, only JBOD units can be removed 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 111 I/O. While a unit is verifying, the status changes to Verifying and a Stop Verify link appears in the right-most column of the Unit Maintenance table. www.3ware.com Physically removing drives which are not in hotswap 3DM 2 Reference...
  • Page 112 RAID 10 with four drives. If the unit has not previously been initialized and you click Once migration of a unit is started, it cannot be cancelled. 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 113 Information about the unit remains intact on the drives. This allows the drive or drives to be reassembled into a unit again on this controller, or if moved to another controller. www.3ware.com Before you click Remove Unit, make sure the unit you 3DM 2 Reference...
  • Page 114 Physically removing drives which are not in hotswap Before you click Delete Unit, make sure the unit you are When a unit is deleted, the data will be permanently Physically removing drives which are not in hotswap 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 115 Figure 44. Configuring a RAID 50 with 12 Drives You can enter a name for the unit. Name. The drop-down list of stripe sizes lists the possible stripe sizes for the Stripe. configuration you selected in the RAID level drop-down. www.3ware.com...
  • Page 116 Three profiles are available: Protection, Balanced, and Performance. For additional information, see “Setting the StorSave Profile for a Unit” on page 139. If the configuration window disappears while you are 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 117: Alarms Page

    CLI, but not both. Whichever issues an alarms command first determines which can see alarm data. For more information about any of the alarms that appear on the Alarms page, see “AEN Messages” on page 214. www.3ware.com 3DM 2 Reference...

  • Page 118: Battery Backup Page

    Note: 9550SX controllers in the Fall of 2005. Battery Backup Unit. Indicates the BBU firmware version. Firmware. Battery Backup Unit capability will be available for the Indicates whether the BBU is present. 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 119 “Charging” the next time the system is powered on. This indicates the BBU is not able to backup the 3ware RAID controller. When the BBU is in the charging state, write caching is disabled automatically on all units attached to the controller.
  • Page 120 This is the amount of time that the battery backup unit can protect the data in the 3ware RAID controller's cache memory. This field is set to zero at the start of a new test and is updated after the test completes. A capacity of zero will also show if the BBU is disconnected and then reconnected.

  • Page 121: 3Dm 2 Settings Page

    This field determines whether e-mail notification is Enabled or Send E-mail. Disabled. Specifies the type of events for which notifications should be sent. Notify On. A severity of Information will send e-mails for all alarms, a severity of www.3ware.com 3DM 2 Reference...
  • Page 122 Enter the new password. Enter the new password a second time, to be sure Saves password changes. Displays how frequently pages in 3DM will be This field enables or disables the ability for users and 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 123 If you change this port, make sure the port you specify is not being used. Failure to do so will cause 3DM to stop responding and you will have to restart it by hand. Saves a new port number. Change Port button. www.3ware.com...
  • Page 124 Chapter 6. 3ware Disk Manager (3DM 2) 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 125: Chapter 7. Configuring Your Controller

    To see details about a particular controller in 3DM Start 3DM and log in. The 3DM Controller Summary page appears, listing all the 3ware controllers installed in your system. The right-most column of the list shows the status of each controller.
  • Page 126 When you have more than one controller installed, information about each one will be shown, sequentially. Press Alt-3 to bring up the 3ware BIOS Manager (3BM). Note: want to work with, press Ctrl-Alt-Del to restart your computer and try again Tab to Information and press Enter.

  • Page 127: Viewing And Setting Controller Policies

    This policy can only be set and only shows in 3BM. Auto-Carving. disabled. When it is enabled, any unit larger than a specified size (known www.3ware.com Viewing and Setting Controller Policies This setting indicates whether Spinup allows drives to be powered-up into the...

  • Page 128: Viewing Controller Policies

    Table 4, “Initial Default Settings for Policies,” on page 17. To view controller policies in 3DM Choose Management > Controller Settings from the menu bar. Figure 48. 3DM Controller Settings Page Determines whether the Auto-Rebuild policy is enabled or 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 129: Exporting Jbod Disks

    Figure 49. 3BM Policy Control Screen Exporting JBOD Disks By default, JBOD disks (unconfigured disks) connected to the 3ware RAID controller are not exported to the operating system. This means that any drives you leave unconfigured are not seen by the operating system, and cannot be used for storage.

  • Page 130: Enabling And Setting Up Staggered Spinup

    Tab to the OK button and press Enter. You will notice a short delay as 3BM makes the policy changes. If you enable the Export JBOD Disks option, the controller 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 131: Disabling Write Cache On Unit Degrade

    RAID layer (using some redundancy) on top of the 3ware RAID configuration. In case of a second drive failure, the software RAID layer can still provide redundancy since no data was lost.
  • Page 132 Figure 50. Auto-Carve policy in 3BM In CLI, use the command tw_cli /cx set autocarve=on. For more information, see the 3ware 9000 Series Serial ATA RAID Controller CLI Guide. Create a new unit or migrate an existing unit to include the drives you want to use.

  • Page 133: Setting The Auto-Rebuild Policy

    Using the 3ware CLI, use the command the size for volumes The size can be between 1024Gb and 2048Gb For more information, see the 3ware 9000 Series Serial ATA RAID Controller CLI Guide. Setting the Auto-Rebuild Policy For 9550SX controllers, the Auto-Rebuild policy determines how the controller firmware will attempt to rebuild degraded units.
  • Page 134 You can enable or disable the Auto-Rebuild policy through 3DM, 3BM, or the CLI. For how to change this setting through CLI, see 3ware 9000 Series Serial ATA RAID Controller CLI Guide. To enable Auto-Rebuild through 3BM On the main 3BM screen, Tab to Settings and press Enter.

  • Page 135: Chapter 8. Configuring Units

    Configuring Units A unit is any configured disk or array of disks connected to your 3ware RAID controller. This section includes instructions for performing the following configuration tasks: Creating a New Unit Creating a Hot Spare Enabling and Disabling the Unit Write Cache...
  • Page 136 For details, see “Changing An Existing Configuration” on page 144. Note: unit managed through the new 3ware RAID controller, Chapter 3, “First-Time RAID Configuration Using 3BM,” provides step-by- step instructions.

  • Page 137: Creating A Unit Through 3Dm

    You can also have 3DM rescan the controller, if you have added drives or units. For information about working in 3DM, see “3ware Disk Manager (3DM 2)” on page 65. www.3ware.com...
  • Page 138 (For details about this screen, see “Maintenance Page” on page 98.) Click Create Unit. A window like the one shown here shows the drives you selected, and lets you specify configuration settings. 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 139 Rebuild. You can also set the StorSave policy. Click Ok. The new unit will appear in the Unit Maintenance list at the top of the page and the operating system will be notified of the new unit. www.3ware.com Creating a New Unit...

  • Page 140: Creating A Unit Through 3Bm

    Units” on page 133. Creating a Unit through 3BM In 3BM, configuration tasks start from the main 3ware BIOS Manager screen shown in Figure 54. From this screen you can configure new units, delete existing ones, or perform maintenance tasks.
  • Page 141 Enter. Tip: You can also press Alt-C to choose Create Unit. On the 3ware Disk Array screen, make sure that the proper drives are listed (see Figure 56 for an example for RAID 5). Figure 56. Create Disk Array Display (Optional) Press Enter and type a name for the unit;...
  • Page 142 If you made changes to units on more than one controller, the details about changes about to be made may extend beyond one screen. In this case, you use the PgUp and PgDn keys to bring more information into view. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 143: Ordering Units In 3Bm

    Partition and format the new arrays or disks using the Administrative Tools from the Start menu: Choose Computer Management from the Administrative Tools menu. www.3ware.com For RAID 5 units with 5 or more disks, and RAID 50 units Creating a New Unit...
  • Page 144 Partition the unit: fdisk -BI /dev/da0; disklabel /dev/da0 | disklabel -B -R -r da0 Create or make the file system: newfs /dev/da0c You can also use sysinstall to format and partition the unit. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 145: Creating A Hot Spare

    For example, one drive might be 122 GB, and the other 123 GB, even though both are sold and marketed as “120 GB drives”. 3ware drive coercion uses the same capacity for both of these drives so that one could replace the other.

  • Page 146: Specifying A Hot Spare Through 3Bm

    3BM will notify you. If the drive you designated as a spare is not large enough 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 147: Enabling And Disabling The Unit Write Cache

    (JBOD). If the StorSave Profile is “protect” and a unit has degraded, write cache cannot be enabled. Do not use Windows Control Panel to enable or disable cache on 3ware RAID units. www.3ware.com Enabling and Disabling the Unit Write Cache...

  • Page 148: Enabling And Disabling The Unit Write Cache Through 3Dm

    In the Configure Disk Array screen, Tab to the field Write Cache Settings. Figure 61. Unit Write Cache State in 3BM The current setting—Enabled or Disabled—is shown. (The initial default setting is for write cache to be enabled.) 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 149: Setting The Storsave Profile For A Unit

    FUA (Force Unit Access) Enabled Write Journaling Enabled Disable Cache on Degrade www.3ware.com Setting the StorSave Profile for a Unit Enter to select it. If the write cache setting is disabled for a unit, the StorSave Balanced More data protection...
  • Page 150 . FUA commands are a way that the RAID . Write journaling tracks the writing of data to disk and . In the event that a unit degrades, the 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 151: Setting The Storsave Profile Through 3Dm

    (usually server-type applications). When enabled, reordering to be done on the drive, itself. www.3ware.com Enabling or Disabling Queuing for a Unit NCQ can improve performance; it causes command can result in...
  • Page 152 Chapter 8. Configuring Units In order to make use of NCQ, the feature must be enabled at both the drive and the controller. You can enable support for NCQ in the 3ware 9550SX controller on a per-unit basis, as described below.

  • Page 153: Setting Other Unit Policies Through 3Dm

    The page refreshes, and a message at the top confirms the change you have made (Figure 62). Figure 62. Setting Unit Policies in 3DM Note: units. www.3ware.com Setting Other Unit Policies through 3DM You can also set some of these policies when you create...

  • Page 154: Changing An Existing Configuration

    You can also use RLM to change the stripe size of a unit. These changes can be made using 3DM2 or the CLI. Instructions for using migrate in 3DM2 are described below. For information about CLI, see 3ware 9000 Series Serial ATA RAID Controller CLI Guide.

  • Page 155: Changing Raid Level

    For example, a four-drive RAID 5 with a 64KB stripe size can be migrated to a four-drive RAID 5 with 256KB stripe size. The steps below describe how to change a RAID level in 3DM2. www.3ware.com Changing An Existing Configuration Destination...

  • Page 156: Expanding Unit Capacity

    RAID 1 can only have two drives, if you add a drive to either, the RAID level must be changed.) It is important that you allow migration to complete You can only migrate a unit to a RAID level that has the 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 157: Informing The Operating System Of Changed Configuration

    Then turn to Step 4 under “Informing the Operating System of Changed Configuration” on page 147. Inform the operating system of the change, as described below. Note: information, see the 3ware 9000 Series Serial ATA RAID Controller CLI Guide. Informing the Operating System of Changed Configuration After you change the configuration of a unit, you must inform the operating system of the change, and you may need to re-partition the unit.
  • Page 158 In Linux and FreeBSD, the tools to expand the partition and file system can vary, depending on the kernel version and file system that you are using. Please consult your Linux/FreeBSD documentation and the 3ware Knowledgebase for more information. This step can only be done after the system has completed <enter>.

  • Page 159: Naming A Unit

    Tab to the OK button and press Enter to select it. You return to the main 3BM screen. When you are finished making changes, press F8 to save them and exit 3BM. www.3ware.com If you want to cancel your change before saving it, click Naming a Unit...

  • Page 160: Deleting A Unit

    “Unsupported DCB,” indicating that they were previously part of a unit on a 3ware 7000/8000 series controller, they must be deleted before you use them. (If you want to move a unit from a 7/8000 controller to the 9000 controller, you must convert the drives first.
  • Page 161 Configuration information associating the drives with the unit is deleted, and the individual drives appear in the Available Drives list (Figure 65). You can now use them as part of another unit, or designate them as Spares, for use in a rebuild. www.3ware.com Deleting a Unit...

  • Page 162: Deleting A Unit Through 3Bm

    If you want to delete an incomplete drive or unusable Any data on the unit will be lost once the unit is 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 163 Remember: The unit is not actually deleted and no data is overwritten until you press the F8 key to save your changes, or press Esc and select Yes when asked if you want to save. Press F8 to save your changes, or press Esc and then Yes. www.3ware.com Deleting a Unit...

  • Page 164: Removing A Unit

    You can also remove a drive, if you want to force a degrade If you do not have hot swap carriers, you do not need to If a unit is not unmounted and you remove 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 165: Removing A Unit Through 3Bm

    Enter to select it. An asterisk appears in the left-most column to indicate that the unit is selected. www.3ware.com Even though removing a unit is supported in 3BM, you can Physically removing drives which are not in hot Removing a Unit...

  • Page 166: Moving A Unit From One Controller To Another

    Moving a Unit from One Controller to Another After you have configured a unit on a 3ware 9000 series controller (9500S or 9550SX), you can move it to a different 3ware 9000 series controller, and retain the configuration on the new controller. This is referred to as “array roaming.”...

  • Page 167: Unlocking Drives Configured On A 9500S Controller

    When drives are configured into a unit on a 9500S controller, they become locked for use with 9500S series controllers. If you want to use these drives on an older 3ware controller, a non-3ware controller, or connect them directly to a motherboard ATA controller, you must first unlock them.

  • Page 168: Moving Legacy Jbod Units To A 9000 Controller

    Install the 9000 controller and attach the drives to the 9000 board, as described earlier in this section. Reboot the system and enter the 3ware 9000 series BIOS (3BM) by pressing Alt-3. Enable the Export JBOD policy on the Policy screen.

  • Page 169: Moving Units From A 9500S To A 9550Sx Controller

    Attach the drives to the 9000 board. Reboot the system and enter the 3ware 9000 series BIOS (3BM) by pressing Alt-3. Enable the Export JBOD policy on the Policy screen. Press the F8 or Esc key to save and exit.

  • Page 170: Adding A Drive Through 3Dm

    In 3DM, choose Management > Maintenance. On the Maintenance Page, click Rescan Controller. command. If you have a 9550SX controller, when you add a drive to Physically adding a drive without a hotswap carrier and 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 171: Removing A Drive

    If you have a hot-swap carrier and want to physically remove a drive from your system without powering it down, you must first remove it through the 3ware software. This is required for 3ware controllers before the 9550SX model, and recommended for the 9550SX models.
  • Page 172 When 3DM asks you to confirm that you want to remove the drive, click You can now remove the drive from your system. If you removed a drive that was part of a unit, the unit may become degraded, as shown in (Figure 68). 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 173: Rescanning The Controller

    For more details about how the Rescan feature works, see the information in the Reference section, under “Maintenance Page” on page 98. To rescan the controller through 3DM In 3DM, choose Management > Maintenance. www.3ware.com Rescanning the Controller...
  • Page 174 To rescan the controller through 3BM From the main 3BM screen, press Alt-r. You are warned that any configuration changes you have made in 3BM will be lost. Type for Yes. The controller is rescanned. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 175: Chapter 9. Maintaining Units

    In addition, 3ware BIOS Manager (3BM) and 3ware Disk Manager (3DM) provide tools to let you check unit and drive status, and manually start background maintenance tasks. 3DM also lets you review alarms and errors and schedule background maintenance tasks.
  • Page 176 “Controller Summary Page” on page 83 “Controller Details Page” on page 85 “Unit Information Page” on page 86 “Unit Details Page” on page 87 “Drive Information Page” on page 89 “Drive Details Window” on page 90 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 177: Reviewing Alarms And Errors

    The Alarms page in 3DM shows a log of all events (also called Asynchronous Event Notifications, or AENs) that have occurred on units. These events include alarms that occur when the 3ware RAID controller requires attention, such as when a disk unit becomes degraded and is no longer fault tolerant.

  • Page 178: Downloading An Error Log

    You can download an error log containing information from the firmware log. This can be useful when troubleshooting certain types of problems. For example, you might want to send the saved file to 3ware Customer Support for assistance when troubleshooting.

  • Page 179: About Background Tasks

    Although you can use the unit while it is being initialized in the background, initialization does slow I/O performance until completed. You can adjust how much initialization will slow performance by setting the rate at which it www.3ware.com About Background Tasks That is, if...

  • Page 180: Initialization Of Different Raid Types

    RAID 1 and RAID 10 units do not need to be initialized when they are created to be fault tolerant and are immediately available for use with full performance when created. Units that do not need to be immediately initialized for full 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 181: Auto Initialization After Power Failure

    Performance? Auto Initialization After Power Failure The 3ware controller detects and handles power failures. This mechanism is intended to ensure that redundant units have consistent data and parity. When a redundant unit is unexpectedly shutdown, there is a possibility some data and parity may be inconsistent.

  • Page 182: About Rebuilds

    This allows you to insert a new drive to use in the rebuild process. With the 3ware 9000 series controller, rebuilds on multiple units can take place simultaneously. About Verification...
  • Page 183 How Errors Are Handled Verification makes use of the same error checking and error repair techniques used during ordinary use of drives configured through 3ware RAID controllers. When verification encounters an error, the controller typically retries the command.

  • Page 184: About Migration

    For more information about migration, see “Changing An Existing Configuration” on page 144. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 185: About Self-Tests

    After you select one of the radio buttons, the page refreshes, and a message at the top confirms the change you have made. For more information about these settings, see the reference section, “Controller Settings Page” on page 92. www.3ware.com About Background Tasks...

  • Page 186: Scheduling Background Tasks

    Migration receives higher priority than all other background tasks. 3ware 9000-series RAID controllers can work on multiple units at the same time. This means that if you have both a redundant unit and a non-redundant unit, the verification of the redundant unit and the media scan of the non- redundant unit will occur at the same time.

  • Page 187: Viewing Current Task Schedules

    The Scheduling Page appears, showing the schedule for Rebuild Tasks. (Migration and initialization tasks follow the Rebuild Task schedule.) To view Verify Tasks or Self-test Tasks, select it from the drop-down list at the top of the page. www.3ware.com Scheduling Background Tasks...

  • Page 188: Turning On Or Off Use Of A Task Schedule

    Tasks column. For more information, see “Selecting Self-tests to be Performed” on page 180. When you first use 3DM, daily schedules exist with 24 hour 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 189: Removing A Task Schedule

    Scroll to the section of the Scheduling page that shows the task you want to add. In the fields at the bottom of the section, select the Day, Time, and Duration for the task. www.3ware.com Scheduling Background Tasks...

  • Page 190: Selecting Self-Tests To Be Performed

    To disable self-tests you must either remove all schedule times, or uncheck the tests listed in the Tasks column. The scheduled tasks can be added in any order. For example These tasks will only be run during scheduled times if they 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 191: Rebuilding Units

    This will cause uncorrectable blocks to be rewritten, but the data may be incorrect. It is recommended that you execute a file system check when the rebuild completes. www.3ware.com If a rebuild fails, check the Alarms page for the reason. If Rebuilding Units...

  • Page 192: Rebuilding A Unit Through 3Dm

    Note: Remove Drive link on the Maintenance page to remove the drive from the unit. If you need to cancel a rebuild, you can do so by using the 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 193: Rebuilding Units Through 3Bm

    A red message box informs you that the unit is degraded, and suggests some possible approaches. Figure 71 shows an example of a degraded- array message. Figure 71. Degraded Disk Array Warning Message Press a key to continue. www.3ware.com Rebuilding Units...
  • Page 194 Tab to the Maintain Unit button and press Enter. Select Rebuild from the pop-up menu and press Enter. Figure 72. Rebuild Option on the Maintain Menu The Rebuild Disk Array screen displays. 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 195: Cancelling A Rebuild And Restarting It With A Different Drive

    Press F8 to save your changes and exit 3BM. The unit will begin rebuilding about ten minutes after the operating system finishes loading and the 3ware driver has loaded. Cancelling a Rebuild and Restarting It with a Different Drive When you start a rebuild from 3BM, you cannot cancel from within the 3BM interface.

  • Page 196: Verifying Units

    You can manually start a verify through either 3DM or 3BM. as described below. ) is logged and the entire unit is If the unit has not previously been initialized and you 3ware 9550SX Serial ATA RAID Controller User Guide ) is posted to “Verify...

  • Page 197: Verifying A Unit Through 3Dm

    An asterisk appears in the left-most column to indicate that it is selected. Tab to the Maintain Unit button and press Enter. On the pop-up menu, select Verify and press Enter. Verification of the selected unit starts immediately. Figure 74. Verifying a Unit www.3ware.com Verifying Units...

  • Page 198: Locating A Drive By Blinking Its Led

    You can issue the command to blink the LED through 3DM and through the CLI. For details about using the CLI, see 3ware 9000 Series Serial ATA RAID Controller CLI Guide. To blink the LED for a drive Choose Information >...

  • Page 199: Chapter 10. Maintaining Your Controller

    Information” on page 63) Using the CLI you can see both the driver and firmware versions (see 3ware 9000 Series Serial ATA RAID Controller CLI Guide) Under Linux, you can also type the following command if you have a 2.4...

  • Page 200: Updating The Driver And Firmware

    Under Windows, you can follow the first 8 steps under “Updating the 3ware Driver Under Windows XP” on page 196. You can also use the 3ware Command Line Interface to check the version. For more information, see 3ware 9000 Series Serial ATA RAID Controller CLI Guide.

  • Page 201: Updating The 3Ware Driver And Firmware Under Windows

    Windows Device Manager. Note: system. Restarting is always required if you update the firmware. In addition, if you boot from a unit on a 3ware RAID controller, updating the driver will require that you restart the system. www.3ware.com...
  • Page 202 Chapter 10. Maintaining Your Controller To update the 3ware driver and firmware using the update utility Download and extract the driver files, as described on page 190. Backup any critical data prior to updating the 3ware driver. Log in to your system as system administrator.
  • Page 203 Figure 77. Update Utility Showing Drivers Already Current If the firmware image is not found with the driver files, you will see an error message, and the 3ware Driver/Firmware Update dialog box will show only the Driver as available. Figure 78. Error Message When the Firmware Image is Missing www.3ware.com...
  • Page 204 Doing so will render the controller unusable. If you have multiple controllers in your system, your screen Do not power off the system while the firmware is 3ware 9550SX Serial ATA RAID Controller User Guide Only the driver is available, because the firmware image was not found.

  • Page 205: Using The Update Utility With Multiple Controllers

    To update the firmware on multiple controllers Follow steps 1 through 5 above, under “Updating the 3ware Driver and Firmware Under Windows” on page 191. www.3ware.com...

  • Page 206: Updating The 3Ware Driver Under Windows Xp

    Firmware Under Windows.” Updating the 3ware Driver Under Windows XP If you prefer, you can update the 3ware driver through the Windows Device Driver Manager, instead of using the Update Utility described above. To update the 3ware driver under Windows XP (Note that during this process, you will step through driver installation wizards twice.)
  • Page 207 Click on the Hardware tab and then click on the Device Manager tab. Open the SCSI and RAID Controllers selection. Locate and double-click on the applicable 3ware Serial ATA RAID Controller. The 3ware 9000 Series ATA RAID Controller Properties dialog box appears.
  • Page 208 12 When you reach the Hardware Update Wizard screen shown in Figure 83, select “Install from a list or specific location (Advanced)” and then click Next. Figure 83. Upgrade/Install Device Driver Wizard 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 209 Next. Figure 84. Search for Driver Screen 14 When the Select the Device Driver screen appears (Figure 85), click the Have Disk… button. Figure 85. Select the Device Driver Screen www.3ware.com Updating the Driver and Firmware...
  • Page 210 The wizard begins installing the driver. You will see a progress box during installation. 17 If the Digital Signature Not Found screen appears, click Yes to continue and follow the instructions to complete the driver installation. 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 211 Figure 88. Found New Hardware Screen 20 Choose “No, not this time” and click Next. At the next screen, leave the selection as “Install the software automatically.” Click Next and follow the prompts on the screen. www.3ware.com Updating the Driver and Firmware...
  • Page 212 Chapter 10. Maintaining Your Controller 21 When the second Completing the Found New Hardware screen appears, click Finish. Figure 89. Completing Found New Hardware Wizard 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 213: Updating The 3Ware Driver Under Red Hat

    Updating the 3ware Driver Under Red Hat Download and extract the driver, as described on page 190. Backup any critical data prior to updating the 3ware driver. Change the directory to the location with the extracted driver. Copy the files to the appropriate directory.

  • Page 214: Updating The 3Ware Driver Under Suse

    Download and extract the driver, as described on page 190. Backup any critical data prior to updating the 3ware driver. Change the directory to the location with the extracted driver. Copy the files to the appropriate directory.

  • Page 215: Updating The 3Ware Driver Under Freebsd

    If you are using lilo, use lilo to update to the boot loader. You should see a printout of kernels that are able to boot on this system after running lilo. 10 Reboot, if booted from the 3ware controller. Otherwise, continue with step 11. The driver is now updated.

  • Page 216: Updating The Firmware Under Linux And Freebsd

    Updating the Firmware Under Linux and FreeBSD Download and extract the firmware, as described on page 190. Backup any critical data prior to updating the 3ware firmware. Change the directory to the location with the extracted files, which include tw_update.

  • Page 217: Viewing Battery Information

    The Battery Backup Unit (BBU) is an add-on card that can be attached to a 3ware 9000 RAID controller to supply power from a battery pack in the event of a system power loss. This allows the controller to use write-caching for optimal performance and to preserve data in the event of a system power failure.

  • Page 218: Testing Battery Capacity

    "LOW". This is part of the battery test. After the voltage drops to a point, it will start charging again, and the status will change to “Charging.” Eventually, the battery voltage will say “OK” again. 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 219 To test the battery in a BBU in 3BM At the main 3BM screen, tab to the BBU button and press Enter. Tab to Test Battery Capacity and press Enter. Figure 92. Battery Backup Information Screen in 3BM www.3ware.com Testing Battery Capacity...
  • Page 220 Chapter 10. Maintaining Your Controller 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 221: Chapter 11. Troubleshooting

    Before Contacting Customer Support Three screens in 3DM 2 provide controller version and status information that can be helpful when contacting 3ware Customer Support with questions or for troubleshooting: Controller Summary, Unit Details, and Unit Information. You can copy and paste the information from these screens into an email using the system clipboard.

  • Page 222: Problems And Solutions

    3ware. If you have a different type of motherboard available, you may want to test the controller in it to see if the 3ware BIOS screen appears. Q2: Need to boot from a non-3ware device without changing the boot order.

  • Page 223: Problems In 3Dm

    Remember that deleting a RAID unit overwrites any exist- ing data on the member drives. Problems in 3DM Q6: A 3ware RAID controller does not show in the list of controllers. You may not have the most recent driver for your controller (7000/8000, 9000).

  • Page 224: Aen Messages

    Chapter 11. Troubleshooting AEN Messages AEN (asynchronous event notifications) are messages issued by the 3ware RAID controller when an error is detected such or when an action is completed. These are summarized in Table 10. Descriptions of each are provided at the end of the table.
  • Page 225 Drive not supported 032h Spare capacity too small for some units 033h Migration started 034h Migration failed 035h Migration done 036h Verify fixed data/parity mismatch 037h SO-DIMM not compatible 038h SO-DIMM not detected 039h Buffer ECC error corrected www.3ware.com AEN Messages...
  • Page 226 Battery health check started 052h Battery health check completed 053h Battery capacity test is overdue 055h Battery charging started 056h Battery charging completed 057h Battery charging fault 058h Battery capacity is below warning level 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 227: Aen Error Message Details

    AEN Error Message Details 001h Controller reset occurred The 3ware RAID controller has detected a soft reset from the device driver. If the 3ware RAID controller fails to respond to the device driver within a reasonable amount of time, the device driver may issue a soft reset to the 3ware RAID controller and retry the command packet.
  • Page 228 008h Unclean shutdown detected The 3ware RAID controller has the ability to detect if the system has been shutdown via the standard shutdown mechanism of the operating system (clean shutdown). If the system loses power or is reset without going through the normal shutdown procedure, it is possible that the data on a redundant array may be out of synchronization.
  • Page 229 One such drive failure is when the drive indicates back to the 3ware RAID controller that it was unable to complete a command. If the drive returns an error to the 3ware RAID controller, the user is notified by this AEN.
  • Page 230 Chapter 11. Troubleshooting attached to the 3ware RAID controller is monitored daily. If a failure of any drive is determined to be likely, the user is notified by this AEN. 3ware recommends that you replace any drive that has the SMART attribute exceeded.
  • Page 231 At this point, the 3ware RAID controller has a good copy of the requested data in its cache memory. It will then use this data to force the failing drive to reallocate the bad sector, which essentially repairs the sector.
  • Page 232 The DCB format expected by the 3ware RAID controller and the DCB that is written on the drive must be compatible. If an array that was created on a very old 3ware product is connected to a newer 3ware RAID controller, this AEN is posted and the 3ware RAID controller rejects the drive.
  • Page 233 02Eh Replacement drive capacity too small The 3ware RAID controller notifies the user by this AEN when the replacement drive capacity is smaller than required. The replacement drive must be equal to or greater capacity than the drive it's replacing.
  • Page 234 Chapter 11. Troubleshooting 030h Drive not supported 3ware 8000 and 9000 series Serial ATA Controller only support UltraDMA- 100/133 drives when using the parallel to serial ATA converter. This AEN indicates that an unsupported drive was detected during rollcall or a hot add.
  • Page 235 176. 03Fh Flash file system error detected The 3ware RAID controller stores some configuration parameters as files in its flash memory. This AEN will be sent when a corrupted flash file system is found on the controller during boot-up. A further attempt will be made to repair the flash file system.
  • Page 236 If the voltage is below the warning threshold, this AEN will be posted to the user. When this event happens, the Battery Backup Unit is still able to backup the 3ware RAID controller, but the user should replace the battery.
  • Page 237 If the temperature is below a warning threshold, this AEN will be posted to the user. When this event happens, the Battery Backup Unit is still able to backup the 3ware RAID controller but the user should replace the battery pack.
  • Page 238 This AEN is posted when the Battery Backup Unit starts a battery test. The test estimates the battery capacity in hours, which is how long the Battery Backup Unit can back up the 3ware RAID controller. This test performs a full battery charge/discharge/re-charge cycle and may take up to 20 hours to complete.
  • Page 239 The Battery Backup Unit periodically evaluates the health of the battery and its ability to backup the 3ware RAID controller in case of a power failure. This AEN is posted when the result of the health test is below the warning...
  • Page 240 The Battery Backup Unit periodically evaluates the health of the battery and its ability to backup the 3ware RAID controller in case of a power failure. This AEN is posted when the result of the health test is below the fault threshold.

  • Page 241: Chapter A. Glossary

    (RAID 1, RAID 5, RAID 10, RAID 50). . Command Line Interface. The 3ware CLI is a text program, rather than a GUI (graphical user interface), for Windows, Linux, and FreeBSD. It has the same functionality as 3DM, and can be used to view, maintain, and manage 3ware controllers, disks, and units.
  • Page 242 RAID level. The array will appear to the operating system as a single unit. Overwrites any existing unit configuration data on the drives. Disk configuration block. This is 3ware proprietary RAID table DCB. information that is written to disk drives that are in a RAID unit, single disk, or spare.
  • Page 243 An unconfigured single drive. The acronym is derived from “just a JBOD. bunch of disks.” Note that earlier versions of the 3ware RAID controller exported JBODs to the OS. By default, this is not the case in 9000-series controllers. However, a policy in 3BM can be set that allows JBODs to be seen by the OS.
  • Page 244 . To generate data on a new drive after it is put into service Duplication of data on another drive or drives, so that it is The process of making a drive unavailable to the 3ware 9550SX Serial ATA RAID Controller User Guide...
  • Page 245 For RAID 5 and RAID 50, a verify will calculate RAID 5 parity and compare it to what is written on the disk drive. www.3ware.com The process of making a unit unavailable to the The process of using an existing unit of...
  • Page 246 Appendix A. Glossary 3ware 9550SX Serial ATA RAID Controller User Guide...

  • Page 247: Chapter B. Compliance And Conformity Statements

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC radio frequency emission limits, use shielded cables and connectors between all parts of the computer system. www.3ware.com...

  • Page 248: Microsoft Windows Hardware Quality Lab (Whql)

    Since the certification process may lag behind the release of the drivers, please refer to our WEB site at www.3ware.com for current certification information. European Community Conformity...

  • Page 249: Chapter C. Warranty, Technical Support, And Service

    30 days from the date of purchase. For detailed terms and conditions, please see the Limited Hardware Warranty and Software License Agreement at our website: http://www.3ware.com/support/rma_form.asp AMCC warranty service is provided by returning the defective product to AMCC.

  • Page 250: Exclusions

    (transit time not included). Advanced replacement is available with a credit card number with authorization in the amount equaling the then current list price of the 3ware Serial ATA RAID Controller, including shipping costs. As soon as practicable thereafter, AMCC will ship the advanced replacement to you at the address of your choosing.

  • Page 251: Amcc Technical Support And Services

    AMCC Technical Support and Services Product information, Frequently Asked Questions, software upgrades, driver files and other support are available through the AMCC World Wide Web site at http://www.3ware.com. AMCC’s 3ware software library is accessible at: http://www.3ware.com/support/download.asp Web-based software downloads feature upgrading multiple switches simultaneously.
