Xenosys L2S14C User Manual page 17

①, ② Adjustment Knob
Warning
1. In case of ① Depth of head adjustment knob or ② Head diameter adjustment knob
operating is loose, remove the cloth pad first. Then use the screw driver to lock the clockwise
direction of (+) screw which is inside of headband (the opposite side of the knob) and loose
the screw up to 0.5 ~ 1 pitch to counterclockwise direction to maintain proper operation.
2. Headband cloth pad is expendables. We recommend changing them in case of too much
pollution. (Optional)
Portable LED Headlight System (L2S14C)
(+) Screw
17 www.xenosys.co.kr
