- Page 1 L2S14C (Portable LED Headlight System) User Manual Optical & Medical Device System Engineering XENOSYS CO., LTD. 2, Venture-ro, 100 beon-gil, Yeonsu-gu, Incheon 406-840, Korea TEL. 82-32-875-9811~2 FAX. 82-32-875-9813 www.xenosys.co.kr / sales@xenosys.co.kr...
-
Page 2: Table Of Contents
COMPONENTS ..........................8 FUNCTIONS ............................ 9 OPERATING INSTRUCTION ......................12 BASIC TROUBLESHOOTING ......................18 SPECIFICATIONS .......................... 19 ELECTROMAGNETIC COMPATIBILITY ..................22 TRANSPORTATION ........................22 STORAGE ............................23 CLEANING INSTRUCTION ......................24 SERVICE & WARRANTY ....................... 24 Portable LED Headlight System (L2S14C) www.xenosys.co.kr... -
Page 3: Introduction
The external figure of product is like below pictures. Please refer to components on page 8 ~ 9. Left-side View Front View Rear View Table A describes features of L2S14C and detail specifications are described from page 19 to 21. Model Power Spectrum... -
Page 4: Safety & Precautions
4. Do not touch the power cord with wet hand which may cause electric shock or equipment damage. 5. Do not use L2S14C with connecting directly to the battery pack during the operation or medical practice. Portable LED Headlight System (L2S14C) - Page 5 4. LED optic outside emits heat, so be careful on touching. 5. Do not look directly into LED lens module or some one’s eyes to avoid the risk of permanent eye damage. Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
- Page 6 1. Do not connect any metallic objects between the cradle connector and battery. This may cause the defective on the charger and charger cradle. 2. Use only the charger which is provided by Xenosys on the phone jack. This may cause the defective on the charger and charger cradle.
-
Page 7: Features
FEATURES 1. Operating Principle L2S14C adopts the way to deliver DC voltage from the battery to LED device through STEP-Down circuit and generate light speed through the lens. Even though battery voltage is reduced, L2S14C allows LED to provide consistent brightness. -
Page 8: Components
⑤ Charger (LCH14) ⑥ DC Power Supply (BPM010S05) ⑦ Power Cord 2. Optional ⑧ Anti-curing Filter ⑨ LED Lens Module (LLM1474) ⑩ LED Lens Module (LLM1466) (Only for LLM1474, LLM1482) ⑪ Headband Cloth Pad (Expendables) Portable LED Headlight System (L2S14C) www.xenosys.co.kr... -
Page 9: Functions
Field of View: Ø66 mm @WD400mm Optional ⑪ Headband Cloth Pad Expendables (2 kind / 3 pieces for 1set) Optional FUNCTIONS 1. Main Body (Control Unit) ① Top View Isometric View ② Front View Bottom View Portable LED Headlight System (L2S14C) www.xenosys.co.kr... - Page 10 Warning – Do not connect ANY OTHER charger with Ø3.5 phone jack; it will cause severe damage to main body. This will be excluded from the under warranty and get charged. Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
- Page 11 ② 3 types of LED Lens Module available (Choose one) Class Type Feature (Field of View) Reference Standard LLM1482 Ø82mm@WD400mm Basic Option 1 LLM1474 Ø74mm@WD400mm Option 2 LLM1466 Ø66mm@WD400mm Charger (LCH14) Top View ① Isometric View Front View Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
-
Page 12: Operating Instruction
L2S14C from the over-voltage. Please check if its Xenosys supplied charger and the serial number. If it’s Xenosys supplied one, then stop using and contact the distributor (dealer) or the manufacturer. If not, make sure to use Xenosys DC5V power supply. - Page 13 2. Store LED light in the place free from the air with pressure, temperature, humidity, wind, ray of light, dirt, salinity, and ion. 3. Store L2S14C in the place free from the declination, shack, and shock. 4. Store L2S14C in the place free from gas, smoke, and chemical fluid.
- Page 14 3. Adjust LED lens module up-down or left-right to locate the desired position. External LED lens module’s temperature will go up to 42℃ (max.) during usage, so be careful. 4. After finishing the usage, press the power ON/OFF button to turn off. Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
- Page 15 Step 2: Push to the ① bottom of the cradle Step 1: Push to the direction of terminal ‘-’ and Step 2 4. Check the battery installation: Turn the battery to check the exchange. (Finish exchanging) Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
- Page 16 2. Adjust ② Head diameter adjustment knob to fix the headband in stable. 3. Move ③ Height adjustment bar which is installed LED lens module to fit. 4. Adjust the right position to see the surgery or wound spot properly. Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
- Page 17 (+) screw which is inside of headband (the opposite side of the knob) and loose the screw up to 0.5 ~ 1 pitch to counterclockwise direction to maintain proper operation. 2. Headband cloth pad is expendables. We recommend changing them in case of too much pollution. (Optional) Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
-
Page 18: Basic Troubleshooting
Discharging time is too fast charged. (Check the battery charged, we recommend alarm LED) exchanging with new battery as it is expendables. Check the cable which is Contact distributor Light flickers intermittently connected to main unit. manufacturer Portable LED Headlight System (L2S14C) www.xenosys.co.kr... -
Page 19: Specifications
① Size: Variable measurement Minimum 170mm ⅹ 160mm (A ⅹ B) ~ Maximum 220mm ⅹ 200mm (A ⅹ B) ② Weight: 300 g B. Charger (LCH14) ① Size: Refer to the below photo ② Weight: 23 g Portable LED Headlight System (L2S14C) www.xenosys.co.kr... - Page 20 C. Battery Pack ① Size: Refer to the below ② Weight: 47 g D. DC Power Supply ① Size: 95(L)x53(W)x33(H) [mm] ② Weight: 176 g E. Power Cord ① Length: 1.8 m ② Weight: 90 g Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
- Page 21 DC3.7V Battery Pack 2600mAh Li-ion Input: AC100~240, 50-60Hz, 0.3A DC Power Supply Output: DC5V Dimension & Weight of Total Package External Figures W 410 x H 320 x T 180 (mm) Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
-
Page 22: Electromagnetic Compatibility
2. Load L2S14C boxes up and down evenly by handcart and any vehicle trunk to transport. 3. When you carry L2S14C by hand, hold it with two hands firmly and disconnect charger, and power cord from the main-body for safe transportation. -
Page 23: Storage
② Store the battery with separated from the main body in case of long-time no use. ③ Recommend to keep it in the dry condition with ambient temperature range of +15℃ ~ +25℃. Keep away from too hot or extremely cold places. Portable LED Headlight System (L2S14C) www.xenosys.co.kr... -
Page 24: Cleaning Instruction
1. This service & warranty statement applies to all countries to the extent that there is no special warranty rule. 2. All services & warranty should be provided by Xenosys Co., Ltd. or authorized personnel by Xenosys Co., Ltd. 3. Warranty becomes effective from the sales date for material, production defective, or defect under the normal use. - Page 25 9. If there is any defect happens which cannot be handled by troubleshooting in this manual, return it to the manufacturer. Then Xenosys will take care of it. If the qualified engineer determines that the defect comes from the abuse or improper use, warranty will not be applied.
- Page 26 XENOSYS CO., LTD. #2, Venture-ro, 100 beon-gil, Yeonsu-gu, Incheon 406-840, Korea TEL. 032-875-9811~2 FAX. 032-875-9813 sales@xenosys.co.kr www.xenosys.co.kr / Portable LED Headlight System (L2S14C) www.xenosys.co.kr...
