① DC5V connection jack: The phone jack which is connected to the plug of DC power
supply.
Warning – Do not use non-Xenosys supplied power supply. This will cause severe
damage to the cradle & main body which is also excluded from the under warranty and
get charged.
6. DC Power Supply
① Charging Plug: Provide the power to DC5V connection jack of the charger.
Warning – Do not use any other device randomly which may cause the defective reason.
In case of using non-Xenosys-supplied charger with higher voltage (over 5V), the main unit
will shut down the power supply and stop the all operation after "beep" sound. It is a security
circuit to protect L2S14C from the over-voltage. Please check if its Xenosys supplied charger
and the serial number. If it's Xenosys supplied one, then stop using and contact the distributor
(dealer) or the manufacturer. If not, make sure to use Xenosys DC5V power supply.
A. Preparation before usage
1. Check components
Components are shown on page 8~9. They can differ from the picture and replace or
delete with new parts for better performance.
Portable LED Headlight System (L2S14C)

OPERATING INSTRUCTION

12
