Xenosys L2S14C User Manual page 14

D. Turn on light & Intensity change
Battery Alarm LED
1. Press the power ON/OFF button of the control unit to turn on.
① Check the light comes from LED lens module.
② Check the battery alarm LED. (LED shows the remaining time of the battery)
③ If fully charged battery is installed, battery alarm LED shows Green. During the
battery is running out, it shows in the turn of Green→Orange→Red→blinking Red.
We recommend changing battery when hearing 3 times "beep" sound and "blinking
Red". After 2 to 5 minutes of "blinking Red" sign, the power will shut down
automatically.
Caution – Please exchange with fully charged battery or recharge when hearing
"beep" sound and only a few moments light come which means the battery is not
charged.
2. Turn the intensity change knob and there will "beep" sound come to change desired
brightness level. There is no "beep" sound when it reaches to minimum or maximum
level. Turn right side for brighter level and turn left for dimmer level.
Brightness
Brightness (lx)
@WD400mm
3. Adjust LED lens module up-down or left-right to locate the desired position. External
LED lens module's temperature will go up to 42℃ (max.) during usage, so be careful.
4. After finishing the usage, press the power ON/OFF button to turn off.
Portable LED Headlight System (L2S14C)
LLM1482
Min. 4,000
Max. 22,000
Power ON/OFF button &
Intensity Change knob
Type
LLM1474 LLM1466
5,000 6,000
25,000 32,000
14
Operating Time
(hr)
More than 27
More than 4
