- Page 1 Washing Machine Model: WWF8025DQWA WWF7025EQWA...
-
Page 2: Table Of Contents
CUSTOMER CARE AND SERVICE We recommend the use of original spare parts.When contacting Service, ensure that you have the following data available. The information can be found on the rating plate. Model, PNC, Serial Number. Warning / Caution-Safety information. General information and tips Environmental information. - Page 3 CONTENTS WASHING HINTS 6.1 Sorting The Laundry ....................19 6.2 Temperatures ....................... 19 6.3 Before Loading The Laundry ..................19 6.4 Maximum Loads ......................19 6.5 Removing Stains ......................19 6.6 Detergents Type And Quantity Of Detergent ..............20 INTERNATIONAL WASH CODE SYMBOLS ..............
-
Page 4: Safety Information
SAFETY INFORMATION 1.1 Conditions Of Use This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working ● environtment; farm houses; ● by clients in hotels, motels, and other residential type ●... -
Page 5: General Safety
Young children should be supervised to ensure that ● they do not play with the appliance. The packaging components (e.g. plastic film, ● polystyrene) can be dangerous to children - danger of suffocation! Keep them out of children’s reach. Keep all detergents in a safe place out of children’s ●... -
Page 6: Installation
1.4 Installation 1.5 Use ● ● This appliance is heavy. Care should This appliance is designed for be taken when moving it. domestic use. It must not be used for purposes other than those for which ● When unpacking the appliance, check it was designed. -
Page 7: Product Description 2.1 Parts
PRODUCT DESCRIPTION 2.1 Parts Detergent/Softener Dispenser Worktop Control Panel Door Emergency Door Opening Front Feet (Level Adjustment) Water Drain Hose Water Inlet Hose Rear Feet (Level Adjustment) Mains Cable Transit Bolts Transit Bolts, Hose Support CAUTION ! All transit bolts (3 pcs) must be removed before using the appliance. -
Page 8: Control Panel
CONTROL PANEL 3.1 Control Panel Description On/Off Button Program Touchpad Temp Touchpad Child Lock Option Spin Touchpad Extra Rinse Option Option Touchpad Start/Pause Touchpad Delay End Touchpad Display LED Icon Pause to add clothes status icon Door Lock status icon Extra Rinse status icon Delay End status icon Woolmark Apparel Care... -
Page 9: Program Description
Energy Saver 40°C, 60°C decrease the energy consumption. The time of the washing program is extended. 3.3 Maximum Load Maximum Load (kg) Program WWF8025DQWA WWF7025EQWA 8.0 kg Whites 7.0 kg 4.0 kg 3.5 kg Colours 1.5 kg... -
Page 10: Program Options Compatibility
3.4 Program Options Compatibility Option Program Quick Soak Rinse & Drain & Extra Vapour Delay End Spin Spin Rinse Whites Colours Quick 15 ... - Page 11 Vapour Touchpad Soak Select this option to add approximately This option allows you to soak heavily 30 minutes of tumbling in vapour during soiled clothes and stained items at the the wash cycle. Vapour helps open fabric beginning of the wash before main fibers up to allow laundry additives to washing phase.
- Page 12 Rinse & Spin Machine will drain remaining soak water and starts filling with fresh With this option you can perform only the water for the main wash. last rinse of a selected washing program. Extra Rinse and No Spin can also be NOTE selected with this option.
-
Page 13: Settings
3.6 Setting Extra Rinse Option ( Enabling/Disabling End-Of-Wash Buzzer This option is recommended for people who are allergic to detergents, and in This setting permits you to either enable areas where the water is very soft. Use or disable the buzzer at the end of the this option to add two rinse phases to a program. -
Page 14: Start/Pause ( ) And Add Clothes ( ) Touchpad
Start/Pause ( ), Pause to add clothes ( This touchpad has 2 functions: Start/Pause ( Pause to add clothes ( After you have selected the desired You can only add clothes if add program and options, press this clothes “ ”... -
Page 15: Daily Use
DAILY USE 5.1 Loading The Laundry Using Detergent And Additives Turn the water tap on. IMPORTANT: Please read Connect the main plug to the main “Detergents Type and socket. Quantity of Detergent”on Press the On/Off button to switch the page 20 before use. machine ON. -
Page 16: Options Setting
If required, pour fabric softener into Position up: for powder detergent the compartment marked “ ”. (factory setting). Position down: for liquid detergent. NOTE: Measure out the detergent and the The amount used must not exceed fabric softener; the “MAX” mark in the drawer. Pull out the dispenser drawer until it If you use thick softeners it is stops. -
Page 17: Starting A Cycle ( )
5.7 Changing The Options If an option is not compatible with the wash program selected, symbol “ ” It is possible to change only some option will flash on display along with buzzer after the program has started. sound. Press the touchpad Start/Pause. The If you want to decrease washing time, indicator will start flashing. -
Page 18: When The Washing Program Is Completed, But There Is Water In The Drum
Keep the door partly open, to prevent Press the “On/Off” button to deactivate the mildew and odours. the appliance. Turn off the water tap. NOTE: After approximately 18 hours, if you do NOTE: not press Start/Pause touchpad, the At the end of the program, the time appliance will drain and spin automati- remaining can suddenly decrease from 7 cally (except for “Wool”... -
Page 19: Washing Hints
WASHING HINTS 6.1 Sorting The Laundry Never wash whites and coloureds together. Whites may lose their Follow the wash code symbols on each “whiteness” in the wash. garment label and the manufacturer’s New coloured items may run in the first washing instructions. -
Page 20: Detergents Type And Quantity Of Detergent
Mould stains: treat with bleach, rinse The choice and quantity of detergent will well (whites and fast coloureds only). depend on ; Grass: soap lightly and treat with bleach type of fabric (delicates, woollens, (whites and fast coloureds only). cottons, etc.) ; the colour of clothes ;... -
Page 21: International Wash Code Symbols
INTERNATIONAL WASH CODE SYMBOLS These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic Max. wash Max. wash Max. wash Max. wash DO NOT temperature temperature temperature temperature Hand wash wash wash at all 95 °C... -
Page 22: Maintenance Wash
8.4 Maintenance Wash With the use of low temperature washes it is possible to get a build up of residues inside the drum. We recommend that a maintenance wash be performed on a regular basis. To run a maintenance wash: The drum should be empty of laundry. -
Page 23: Cleaning The Drawer Bottom
8.7 Cleaning The Drawer Bottom After washing cycle finish, residues of 3. Clean the dispenser with an old softener and water may remain in the toothbrush under the water tap. softener dispenser. It is recommended to clean the bottom of softener dispenser regularly to remove any residue. -
Page 24: Cleaning The Water Inlet Filter
8.8 Cleaning The Water Inlet Filter If your water is very hard or contains traces of lime deposit, the water inlet filter may become clogged. It is therefore a good idea to clean it from time to time. To clean the water inlet filters: Close the water tap. -
Page 25: Troubleshooting
TROUBLESHOOTING 9.1 Possible Failures Alarm Code: The appliance does not fill with water Certain problems are due to lack of properly. simple maintenance or oversights, which can be solved easily without calling out an The appliance does not drain the water. engineer. - Page 26 Malfunction Possible Cause Solution Too much detergent or unsuitable Reduce detergent quantity and detergent (creates too much foam) use correct type of detergent has been used. (refer page 20). Check whether there are any leaks There is water from one of the inlet hose fittings. It Check the water inlet hose on the floor: is not always easy to see this as...
-
Page 27: Emergency Door Opening
Malfunction Possible Cause Solution The electronic unbalance detection device has cut in because the laundry is not evenly distributed in the drum. The laundry is Spinning starts Pause the machine and redistributed by reverse rotation of the drum. late or the redistribute laundry This may happen several times before the machine does... -
Page 28: Technical Data
220-240 V~ / 50 Hz Total power absorbed 2000 W Minimum fuse protection 10 A Water supply pressure (Maximum / Minimum) 0.8 MPa / 0.05 MPa Program WWF8025DQWA WWF7025EQWA Whites 8.0 kg 7.0 kg Colours 4.0 kg 3.5 kg Quick 15 1.5 kg... -
Page 29: Installation
INSTALLATION 11.1 Unpacking Open the door. Remove the CAUTION! polystyrene All transit bolts and packing must be piece from removed before using the appliance. the door seal You are advised to keep all transit and all the devices so that they can be refitted if items from the machine ever has to be transport- the drum. -
Page 30: Positioning
7. Remove the power supply cable and the 11.2 Positioning drain and inlet hoses from the hose holders «B» on the rear of the appliance. It is important that your washing machine stands firm and leveled on the floor to ensure correct operation. -
Page 31: Water Inlet
When the washing machine is levelled, Loosen the ring nut to angle the hose to try to rock it from corner to corner. If it the left or right depending on the position does rock, adjust the legs again until it is of your water tap. -
Page 32: Electrical Connection
Directly into a drain pipe, at a height of not less than 60 cm and not more than 90 cm. Max. 90 cm Min. 60 cm The end of the drain hose must always be ventilated, i.e. the inside diameter of the drain pipe must be larger than the outside diameter of the drain hose. -
Page 33: Environment Concerns
When the appliance is installed, the power supply cable must be easily accessible. If this appliance is supplied from a cord extension set or electrical portable outlet device, the cord extension set or electrical portable device must be positioned so that it is not subject to splashing or ingress of moisture. -
Page 34: Warranty
(b)‘ASC’ means Electrolux’ authorised serviced centres; power supply; (vi) incomplete or improper installation; (c)Westinghouse’ means Electrolux Home Products Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341 in (vii) incorrect, improper or inappropriate operation; respect of Appliances purchased in Australia and Electrolux (NZ) (viii) insect or vermin infestation;... - Page 35 Notes.
