- Page 1 WWF9024M5WA WWF8024M5WA Washing Machine User Manual...
-
Page 2: Table Of Contents
Failure to strictly adhere to the requirements in this manual may result in personal injury, property damage and affect your ability to make a claim under the Westinghouse manufacturer’s warranty provided with your product. Products must be used, installed and operated in accordance with this manual. - Page 3 ENGLISH BEFORE FIRST USE ....................... 16 DAILY USE 5.1 Loading The Laundry ....................17 5.2 Using Detergent And Additives ..................17 ......................18 5.3 Options Setting ....................19 5.4 Starting A Cycle ( .................... 19 5.5 Interruption Of A Program ....................
-
Page 4: Safety Information
SAFETY INFORMATION 1.1 Conditions Of Use This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environtment; farm houses; by clients in hotels, motels, and other residential type environments;... -
Page 5: Child Safety
ENGLISH 1.2 Child Safety This washing machine is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the appliance. The packaging components (e.g. plastic film, polystyrene) can be dangerous to children - danger of suffocation! Keep them out of children’s reach. -
Page 6: General Safety
1.3 General Safety 1.4 Installation This appliance is heavy. Care should It is dangerous to alter the specifica- tions or attempt to modify this product be taken when moving it. in any way. When unpacking the appliance, check During high temperature wash that it is not damaged. -
Page 7: Use
ENGLISH 1.5 Use Only wash fabrics which are designed to be machine washed. Follow the instructions on each garment label. Do not overload the appliance. See the relevant section in the user manual. Before washing, ensure that all pockets are empty and buttons and zips are fastened. -
Page 8: Product Description
PRODUCT DESCRIPTION 2.1 Parts Worktop Detergent/Softener Control Panel Dispenser (see page 10) (see page 17) Door Cabinet Drain Pump Filter Front Panel (see page 25) Level Adjustment Feet (Front) Mains Cable Transit Bolts Transit Bolts & Hose Support... -
Page 9: Accessories
ENGLISH Detergent/Softener Dispenser Transit Bolt (when remove) (For more informations, see page 17, 24) Softener Main Wash Prewash Door (when open) (for more informations, see page 17) Transit bolts must be removed before using the appliance. Drum Lifter Stainless Steel 2.2 Accessories Washing Drum Plastic Caps... -
Page 10: Control Panel
CONTROL PANEL 3.1 Control Panel Description Program Selector Knob Start/Pause and Add Clothes Touchpad Temperature Selection Touchpad Time Saver Touchpad On/Off Button Delay End Touchpad Spin Selection Touchpad Display Plus Hygiene Touchpad Save Favourite Program Option Prewash Touchpad... -
Page 11: Program Chart
11 11 ENGLISH 3.2 Program Chart Program; Max. Max. Load Type of load and soil level Temperature Spin (Dry range Speed Clothes) Max. Cotton; 1200 White and coloured cotton. (Adjust wash time according to soil level. See Time Saver table on Cold to 90°C page 13) Max. -
Page 12: Program Options Compatibility
Favourite – – Recall you favourite program. Maximum capacity depended on the model of the Washing Machine (see defined on model: WWF9024M5WA 9 kg the control panel). WWF8024M5WA 8 kg Eco Cotton Program with 40degC option selected is recommended for a full load of normally soiled cotton and is the Energy and Water rating label program. -
Page 13: Options
13 1 3 ENGLISH 3.4 Options Delay End ( ) Touchpad Before you start the program, this option Temperature Touchpad makes it possible to define the end of the washing program from minimum of 1 hour Press this touchpad repeatedly to to maximum of 20 hours. - Page 14 Plus Hygiene Touchpad Prewash ( ) Touchpad Select this option to add approximately Select this option if you wish your laundry 30 minutes of tumbling in vapour after to be pre-washed before the main wash. the rinse cycle. The indicator of this Use this option for heavy soil.
-
Page 15: Settings
ENGLISH 15 15 3.5 Settings Save Favourite ( ) Program To deactivate the function, press and hold “Prewash” touchpad about Program settings that are frequently used 2 seconds until the display shows the can be saved (e.g. Cotton, 60°C, 1200 icon “... -
Page 16: Start/Pause ( ) And Add Clothes ( ) Touchpad
3.6 Start/Pause ( ) and Add Clothes ( Add Clothes ( ) Touchpad You can only add clothes when the icon “ ” shown on the This touchpad has 2 functions: display. Start/Pause ( To add clothes: Pressing the “Start/Pause”... -
Page 17: Daily Use
ENGLISH DAILY USE 5.1 Loading The Laundry 5.2 Using Detergent And Additives Turn the water tap on. Please read “Detergents Type Connect the main plug to the main and Quantity of Detergent”on socket. page 22 before use. Press the On/Off button to turn on the Detergent Dispenser Drawer washing machine. -
Page 18: Options Setting
NOTE: When you use the NOTE liquid detergent The softener amount used must Do not use gelatinous or thick not exceed the “MAX” mark in the liquid detergents. drawer. Do not put more liquid than the If you use thick softeners it is maximum level. -
Page 19: Starting A Cycle ( )
ENGLISH 5.4 Starting A Cycle ( 5.7 Changing The Options To start a program, press the Start/Pause It may be possible to change some of the touchpad. The corresponding pilot light options after a wash program has started. will stop flashing and a default program Press the touchpad Start/Pause. -
Page 20: When The Washing Program Is Completed, But There Is Water In The Drum
NOTE NOTE After approximately 18 hours, if you do At the end of the program, the time not press Start/Pause touchpad, the remaining can suddenly decrease from appliance will drain and spin automatically 7 minutes or less to 0 due to the (except for “Wool”... -
Page 21: Washing Hints
21 21 ENGLISH WASHING HINTS 6.1 Sorting The Laundry Wash bras, pantyhose and other delicates in a Follow the wash code symbols on each mesh laundry bag, garment label and the manufacturer’s which you can purchase washing instructions. Sort the laundry as from your supermarket. -
Page 22: Detergents Type And Quantity Of Detergent
Oil based paint: moisten with benzine Low sudsing detergents designed for stain remover, lay the garment on a soft front load washing machines are labelled cloth and dab the stain; treat several “Front Loading”, “high efficiency”, “HE”, times. -
Page 23: International Wash Code Symbols
23 23 ENGLISH Not enough detergent causes: the washload to turn grey, greasy clothes. Too much detergent causes: sudsing, reduced washing effect, inadequate rinsing. Use less detergent if: you are washing a small load, the laundry is lightly soiled, large amounts of foam during washing. INTERNATIONAL WASH CODE SYMBOLS These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. -
Page 24: Care And Cleaning
CARE AND CLEANING WARNING! To run a maintenance wash: The drum should be empty of laundry. You must DISCONNECT the appliance from the electricity supply, before you can Select the “Tub Clean” program. carry out any cleaning or maintenance Press Start/Pause to start the program. -
Page 25: Cleaning The Drawer Recess
25 2 5 ENGLISH Flush it out under a tap to remove any WARNING! traces of accumulated powder. 1. Disconnect the mains plug from the mains socket. 2. Do not remove the filter while the appliance is operating. Do not clean the drain pump if the water in the appliance is hot. - Page 26 3. When the container is full of water, 5. Remove fluff and objects from the put the drainage duct back again and pump (if there are any). empty the container. Do step 2, 3 again and again until no more water flows out from the drain pump.
-
Page 27: Cleaning The Water Inlet Filter
27 27 ENGLISH Put the filter back into the housing Clean the filter in the inlet hose with with exposed section facing up. a stiff brush. Make sure that you correctly tighten the filter to prevent leakages. Guide Remove the inlet hose behind the appliance. -
Page 28: Frost Precautions
8.9 Frost Precautions If the appliance is installed in an area where the temperature can be less than 0 °C, remove the remaining water from the inlet hose and the drain pump. Emergency Drain Disconnect the main plug from the main socket. -
Page 29: Troubleshooting
ENGLISH TROUBLESHOOTING 9.1 Possible Failures Alarm Code: Certain problems are due to lack of The appliance does not fill simple maintenance or oversights, which with water properly. can be solved easily without calling out The appliance does not drain an engineer. Before contacting your local the water. - Page 30 Malfunction Possible cause Solution The drain hose is squashed or Check the drain hose kinked. (Error code: connection. The drain pump is clogged. Clean the drain filter. Machine (Error code: does not empty and/or The option “Rinse Hold”...
- Page 31 ENGLISH 31 31 Malfunction Possible cause Solution The laundry is not evenly Pause the machine and distributed in the drum. redistribute laundry manually. Machine vibrates or There is very little laundry in the Load more laundry. is noisy: drum. Unstable floors eg. wooden floors. Refer to relevant paragraph in “Positioning”...
-
Page 32: Emergency Door Opening
NOTE If you are unable to identify or solve the problem, contact our service centre. Before calling service centre, make a Scan QR code PNC : Mod : S/N : note of the model, serial number and Made in Thailand... -
Page 33: Technical Data
Favourite Spin speed (Maximum / Minimum) 1200 rpm / 400 rpm 1) Maximum capacity depended on the model of the Washing Machine (see defined on the control panel). model: WWF9024M5WA 9 kg WWF8024M5WA 8 kg INSTALLATION Use gloves. Remove the external film. - Page 34 Remove the cardboard top. Put one of the polystyrene packaging elements on the floor behind the Remove the polystyrene packaging appliance. Carefully put down the materials. appliance with the rear side on it. Remove the plastic bag which cover Make sure not to damage the hoses.
-
Page 35: Positioning
Remove the three transit bolts. 11. Pull out the plastic spacers. 11.2 Positioning It is important that your machine stands firm and leveled on the floor to ensure correct operation. The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to avoid restricting the machine door. -
Page 36: Water Inlet
11.3 Water Inlet Loosen or tighten the feet to adjust the level. A correct adjustment of the Connect the water inlet hose to a tap appliance level prevents vibration, noise with 3/4” BSP thread. and the movement of the appliance when in operation. - Page 37 ENGLISH 37 37 In a sink, drain pipe branch. Fitting Hose Guide This branch must be above the trap so that the bend is at least 60 cm above Pull apart to the ground. Hose bend insert hose. Guide hose Max.
-
Page 38: Electrical Connection
11.5 Electrical Connection This machine is designed to operate CAUTION! on a 220-240 V, single-phase, 50 Hz Connect the machine to an supply. earthed socket outlet. “An incorrect power supply may void The manufacturer declines any your warranty.”... - Page 40 www.westinghouse.co.nz...
