Page 1 Keysight Advanced Power System - DC Power Supply N69100 Series Operating and Service Guide...
Page 3 Observe Environmental Conditions Provide Adequate Air Flow Moving Instruments Stacking Instruments Rack Mounting Accessories Single Unit Connections AC Mains Considerations Surge Protector Installation Power Cable Connections Output Connections Single Load Connections Multiple Load Connections Keysight N69100 Series Operating and Service Guide...
Page 4 Set the Slew Rate Set the Output Resistance Set the Output Bandwidth Set the Output Turn-On/Turn-Off Mode Enable the Output Parallel Operation Introduction Primary/Secondary Configuration Primary/Secondary Front Panel Display Primary/Secondary Programming Considerations Primary/Secondary Command Details Keysight N69100 Series Operating and Service Guide...
Page 5 Fault Output Inhibit Input Fault/Inhibit System Protection Output Couple Control System-Related Operations Instrument Identification Instrument State Storage Front Panel Display Front Panel Lock-Out Password Protection Clock Setup Priority Mode Tutorial Voltage Priority Current Priority Keysight N69100 Series Operating and Service Guide...
Page 6 TRIGger Subsystem VOLTage Subsystem Status Tutorial Status Registers Operation Status Group Questionable Status Groups Standard Event Status Group Status Byte Register Error and Output Queues Status Diagram Trigger Tutorial Trigger Sources Trigger Destinations Keysight N69100 Series Operating and Service Guide...
Page 7 Turn-on after Sanitization Sanitizing an Inoperative Instrument Calibration Switches Accessing the Calibration Switch Switch Functions Battery Replacement Disassembly Electrostatic Discharge (ESD) Precautions Tools Required Cover Disassembly Control Board Disassembly Constellation Board Disassembly Index Keysight N69100 Series Operating and Service Guide...
Page 8 Keysight Technologies as governed by United States and international copyright laws. In this document the terms “master” and “slave” have been replaced with “primary” and “secondary.”...
Page 9 Certification Keysight Technologies certifies that this product met its published specifications at time of shipment from the factory. Keysight Technologies further certifies that its calibration measurements are traceable to the United States National Institute of Standards and Technology, to the extent allowed...
Page 10 Interference- Causing Equipment Standard (ICES-001). The RCM mark is a registered trademark of the Australian Communications and Media Authority. Contains one or more of the 6 hazardous substances above the maximum concentration value (MCV), 40 Year EPUP. Keysight N69100 Series Operating and Service Guide...
Page 11 Failure to comply with these precautions or with specific warnings or instructions elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument. Keysight Technologies assumes no liability of the customer’s failure to comply with the requirements.
Page 12 To prevent electric shock, always disconnect the AC mains before cleaning. Use a dry cloth or one slightly dampened with water to clean the external case parts. Do not use detergent or chemical solvents. Do not attempt to clean internally. Keysight N69100 Series Operating and Service Guide...
Page 13 Legal and Safety Information In Case of Damage Instruments that are not functioning correctly, appear damaged or defective should be made inoperative and secured against unintended operation until they can be repaired by qualified service personnel. Keysight N69100 Series Operating and Service Guide...
Page 15 Keysight N69100 Series Operating and Service Guide Quick Reference Legal and Safety Information Introduction to the Instrument Front Panel Menu Reference Command Quick Reference Model Features and Options Specifications and Characteristics This document includes user, service, and programming information for the...
Page 16 Solid-state output disconnect switch for fast protection and smooth turn on/off transitions Single-quadrant operation provides current sourcing and limited sinking capability 10 kW and 20 kW rated models Measurement features 5.12 microsecond sample rate Real-time power measurements Amp-hour & Watt-hour measurement Keysight N69100 Series Operating and Service Guide...
Page 17 4. Navigation keys - Move the cursor to a menu item. Select the highlighted menu item. 5. Output keys - Turn the outputs on or off. Enter voltage or current. 6. Numeric Entry keys - Enter values. Arrow keys increment or decrement numeric settings. Keysight N69100 Series Operating and Service Guide...
Page 18 6. USB - USB interface connector. 7. LAN - 10/100/1000 Base-T Left LED indicates activity. Right LED indicates link integrity. 8. Primary/secondary - Connectors for grouping paralleled units. 9. Termination switches - Specifies primary/secondary termination types. Keysight N69100 Series Operating and Service Guide...
Page 19 Err = an error has occurred (press Error key to display error message) Lan = the LAN is connected and has been configured IO = there is activity on one of the remote interfaces Keysight N69100 Series Operating and Service Guide...
Page 20 The Backspace key deletes digits as it backspaces over them. The Enter key enters a value. If you exit a field without pressing the Enter key, the value is ignored. Press the Help key to get context sensitive help. Keysight N69100 Series Operating and Service Guide...
Page 21 Configures individual list step settings Reset Aborts the list and resets all list settings Repeat Specifies number of Arb repetitions, or continuous Arb Terminate Specifies Arb termination conditions Config Configures individual Arb settings Keysight N69100 Series Operating and Service Guide...
Page 22 Configures the screen saver and start-up meter view Lock Locks the front panel keys with a password Admin Login Enter a password to access the Admin functions Vprog Calibrates voltage programming Iprog Calibrates current programming and measurement Keysight N69100 Series Operating and Service Guide...
Page 23 Enables/disables USB, GPIB, and LAN services Sanitize Performs NISPOM secure erase of all user data Update Password protected firmware update Password Changes the admin password About Displays model, options, serial number, and firmware version Keysight N69100 Series Operating and Service Guide...
Page 24 Returns the minimum value :POWer [:DC]? Returns the averaged measurement. :MAXimum? Returns the maximum value :MINimum? Returns the minimum value :VOLTage [:DC]? Returns the averaged measurement. :ACDC? Returns the RMS measurement (AC + DC). Keysight N69100 Series Operating and Service Guide...
Page 25 Pauses additional command processing until all pending operations are complete. INITiate [:IMMediate] :ACQuire Initiates the measurement trigger system. :TRANsient Initiates the transient trigger system. :CONTinuous :TRANsient 0|OFF|1|ON Continuously initiates the transient trigger system. INSTrument :GROup :FUNCtion PRIMary/SECondary|NONE Sets the primary/secondary function Keysight N69100 Series Operating and Service Guide...
Page 26 Enables or disables the output. :COUPle [:STATe] 0|OFF|1|ON Enables or disables output coupling. :DOFFset <value> Sets a delay offset to synchronize coupled output state changes. :MAX :DOFFset? Returns the delay offset required for this instrument. Keysight N69100 Series Operating and Service Guide...
Page 27 Specifies the dwell time of each point in the Arb. :POINts? Returns the number of points in the Arb. :FUNCtion :TYPE CURRent|VOLTage Specifies either a voltage or current Arb. :TERMinate :LAST 0|OFF|1|ON Selects the output setting after the Arb ends. :VOLTage :CDWell Keysight N69100 Series Operating and Service Guide...
Page 28 Sets the state of the digital control port. :PIN<1-7> :FUNCtion <function> Sets pin function. DIO|DINPut|FAULt|INHibit|ONCouple|OFFCouple |TOUTput|TINPut :POLarity POSitive|NEGative Sets the pin polarity. :TOUTput :BUS [:ENABle] 0|OFF|1|ON Enables or disables BUS triggers on digital port pins. [SOURce:] Keysight N69100 Series Operating and Service Guide...
Page 29 [:AMPLitude] <value> Sets the output voltage when in voltage priority mode. :TRIGgered [:AMPLitude] <value> Sets the triggered output voltage. :BWIDth :RANGe 0 | 1 | 2 Sets the voltage compensation range. :LIMit [:POSitive] [:IMMediate] Keysight N69100 Series Operating and Service Guide...
Page 30 Clears all user memory and reboots the instrument. :SET <block data> Get and set the instrument state :TIME <hh>, <mm>, <ss> Sets the time of the system clock. :VERSion? Returns the SCPI version that the instrument complies with. Keysight N69100 Series Operating and Service Guide...
Page 31 Enables measurement triggers to be sent to a digital port pin. :ARB :SOURce <source> Selects the trigger source for arbitrary waveforms: BUS |EXTernal |IMMediate |PIN<1-7> :TRANsient [:IMMediate] Generates an immediate trigger. :SOURce <source> Selects the transient trigger source: BUS |EXTernal |IMMediate |PIN<1-7> Keysight N69100 Series Operating and Service Guide...
Page 32 Rack mount and slide kit - for mounting units in 19-inch EIA cabinets - models N6914xA only Keysight 1CP108A Rack mount flange kit with handles Keysight E3663AC Basic rail kit for system II Keysight instrument racks Keysight N69100 Series Operating and Service Guide...
Page 33 5 Time to recover to within the settling band following a step change from 40% to 90% and 90% to 40% of full load at Comp 0, with a 40 μs current rise and fall time Keysight N69100 Series Operating and Service Guide...
Page 34 5 ms Current up/down programming, comp 1 4 Rise/fall time 10% to 90% of step: 5 ms 5 ms 5 ms Settling time to 1% of step: 10 ms 10 ms 10 ms Keysight N69100 Series Operating and Service Guide...
Page 35 Typical low-level current = 2 mA @ 0 V (internal 2.2k pull-up) Typical high-level leakage current = 0.12 mA @ 16.5 VDC Pin 8: Pin 8 is common (internally connected to chassis ground) Keysight N69100 Series Operating and Service Guide...
Page 36 1 A sound pressure level of 80 dBA above a reference sound pressure of 20 μPa is at present regarded by many authorities as the threshold at which a hazard may be caused. Special means, such as the use of protective earpieces, can make a higher level non-hazardous to an operator. Keysight N69100 Series Operating and Service Guide...
Page 37 Source/Sink Efficiency (N69173A units, 380V=lowline, 480V=highline) 480V=highline) Power Factor (N69172A units, 380V=lowline, 480V=highline) Power Factor (N69173A units, 380V=lowline, 480V=highline) Total Harmonic Distortion (N69172A units, 380V=lowline, Total Harmonic Distortion (N69173A units, 380V=lowline, 480V=highline) 480V=highline) Keysight N69100 Series Operating and Service Guide...
Page 38 The following graphs show the small signal output impedance of the compensation modes for constant voltage (CV) and constant current (CC) operation. Output Impedance Amplitude (N69172A units) Output Impedance Phase (N69172A units) CV operation CV operation Keysight N69100 Series Operating and Service Guide...
Page 39 1 Quick Reference Output Impedance Amplitude (N69172A units) Output Impedance Phase (N69172A units) CC operation CC operation Output Impedance Amplitude (N69173A units) Output Impedance Phase (N69173A units) CV operation CV operation CC operation CC operation Keysight N69100 Series Operating and Service Guide...
Page 40 1 Quick Reference CV operation (N69143A units) CC operation (N69143A units) CV operation (N69145A units) CC operation (N69145A units) CV operation (N69146A units) CC operation (N69146A units) Keysight N69100 Series Operating and Service Guide...
Page 41 1. The output is stable in this region 2. The output may overshoot in this region 3. The output may be unstable in this region Inductive Load Boundary (N69143A units, Comp 0) Inductive Load Boundary (N69143A units, Comp 1) Keysight N69100 Series Operating and Service Guide...
Page 42 1 Quick Reference Inductive Load Boundary (N69145A units, Comp 0) Inductive Load Boundary (N69145A units, Comp 1) Inductive Load Boundary (N69146A units, Comp 0) Inductive Load Boundary (N69146A units, Comp 1) Keysight N69100 Series Operating and Service Guide...
Page 43 Capacitive Load Boundary (N69173A units, Comp 0-2 ) 1. The output is stable in this region 2. The output may overshoot in this region 3. The output may be unstable in this region Keysight N69100 Series Operating and Service Guide...
Page 44 1 Quick Reference Minimum ESR vs. DUT Capacitance (N69143A units, Comp 0-2) With local sensing and With remote sensing DUT directly connected to bus bars and load leads around 3 μH/1 mΩ Keysight N69100 Series Operating and Service Guide...
Page 45 1 Quick Reference Minimum ESR vs. DUT Capacitance (N69145A units, Comp 0-2) With local sensing and With remote sensing and DUT directly connected to bus bars load leads around 3 μH/1 mΩ Keysight N69100 Series Operating and Service Guide...
Page 46 1 Quick Reference Minimum ESR vs. DUT Capacitance (N69146A units, Comp 0-2) With local sensing and With remote sensing and DUT directly connected to bus bars load leads around 6 μH/2 mΩ Keysight N69100 Series Operating and Service Guide...
Page 47 DUT is a low AC impedance. The characteristic is valid when operating above 10% of the rated output of the unit. Programming Bandwidth Amplitude Programming Bandwidth Phase Voltage Programming Response (Comp 0-2) Current Programming Response Keysight N69100 Series Operating and Service Guide...
Page 48 The following graph plots the maximum permissible output peak-to-peak voltage that can safely be generated by the arbitrary waveform system at a specific frequency. The values are normalized in terms of full scale peak to peak voltage; therefore all models are represented. Keysight N69100 Series Operating and Service Guide...
Page 49 10 kW 12 mΩ N69172A 1000 V 333 V 0.78 V 20 A 60 A 20 kW 130 mΩ N69173A 2000 V 666 V 1.5 V 10 A 30 A 20 kW 500 mΩ Keysight N69100 Series Operating and Service Guide...
Page 50 1 Quick Reference Outline Diagram for 10 kW Models Keysight N69100 Series Operating and Service Guide...
Page 51 1 Quick Reference Outline Diagram for 20 kW Models Keysight N69100 Series Operating and Service Guide...
Page 53 Keysight N69100 Series Operating and Service Guide Installing the Instrument Before Installation or Use Single Unit Connections Multiple Unit Connections Interface Connections Heavy Weight Danger to hands and feet. To avoid personal injury and damage to the instrument, always use a sturdy cart or other suitable device to move the instrument.
Page 54 ESD cover with flange ESD cover for remote interface connections Bus bar connection kit Connection hardware for high voltage output bus bars Keysight 5067-6031 Calibration certificate Calibration certificate referenced to serial number None Keysight N69100 Series Operating and Service Guide...
Page 55 Do not lift or move the unit alone. Avoid moving the unit by hand. If unavoidable, lift only the unit’s chassis; do not lift the unit using the output terminals or front panel. Keysight N69100 Series Operating and Service Guide...
Page 56 Basic rail kit for system II Keysight instrument racks or similar design For Models N69172A and N69173A Accessory Description Keysight 1CP108A Rack mount flange kit with handles Keysight E3663AC Basic rail kit for system II Keysight instrument racks or similar design Keysight N69100 Series Operating and Service Guide...
Page 57 A gas-discharge tube is installed between the neutral connection and chassis ground. Several internal protection functions are used to safeguard the instrument against abnormal line conditions while also preventing AC mains islanding. The following conditions cause the instrument to shut down: Keysight N69100 Series Operating and Service Guide...
Page 58 Remove the three existing M5 bolts from the AC input assembly using the 8 mm Hex driver. Also remove the M3 screw in the chassis to the right of the ground stud using the T10 Torx driver. Keysight N69100 Series Operating and Service Guide...
Page 59 L2 I max L3 I max N69143A, N69145A, N68146A, 10 kW, 400-480 VAC without Neutral 19 A 19 A 19 A N69172A, N69173A 20 kW, 380-480 VAC with Neutral 36 A 36 A 36 A Keysight N69100 Series Operating and Service Guide...
Page 60 AC line filter assembly. If provided, do not connect the neutral wire. Tighten the terminal bolts to 23 in-lb (2.6 Nm). Note that on earlier units, the AC mains terminals have hex-nut terminal connections. Keysight N69100 Series Operating and Service Guide...
Page 61 For 10 AWG: WAGO 216-288 (Refer to manufacturer for details.) Connect the ground wire to the chassis stud located below the AC connector. The stud diameter is M5. Torque the M5 combination nut to 20 in-lbs. Keysight N69100 Series Operating and Service Guide...
Page 62 The following factors should be considered when wiring the load to the power supply: Load wire temperature, current carrying capacity, and voltage drop Load and sense wire insulation rating must be equivalent to the output voltage rating Load wire noise and impedance effect Keysight N69100 Series Operating and Service Guide...
Page 63 Single Load Connections 1. As shown in the following figure, terminate all load wires with wire terminal lugs securely attached. DO NOT use unterminated wires for load connections at the power supply. Keysight N69100 Series Operating and Service Guide...
Page 64 High Voltage Models - N69172A and N69173A Tightening torque for the 8.8 mm opening cannot exceed 10.8 Nm (8 lb-ft). Tightening torque for the 5.5 mm opening cannot exceed 4.8 Nm (3.5 lb-ft). Keysight N69100 Series Operating and Service Guide...
Page 65 If you are using local sensing and are connecting multiple loads to one output, connect each load to the output terminals using separate connecting wires as shown in the following figure. This minimizes mutual coupling effects and takes full advantage of the power supply's low output impedance. Keep Keysight N69100 Series Operating and Service Guide...
Page 66 Connect the unit for remote sensing by first removing the local sense cable between the sense and load terminals. Then make your sense and load connections as shown in the following figure. Note that the two center terminals of the sense connector in models N6917xA are not used. Keysight N69100 Series Operating and Service Guide...
Page 67 (see following table). protect Model resistor Model resistor protect protect N69143A 1.96 kΩ N69172A 60 kΩ N69145A 524 Ω N69173A 198 kΩ N69146A 524 Ω Keysight N69100 Series Operating and Service Guide...
Page 68 By setting the proper voltage slew rate when using an external capacitor, it may be possible to prevent mode crossover into constant current. Use the following formula to estimate the additional programming response time: Keysight N69100 Series Operating and Service Guide...
Page 69 DUT is of a resistive or high impedance nature and may have some local bypass capacitance near its own terminals. Remote sensing at the DUT terminals is recommended if accurate DC voltage regulation is required. Keysight N69100 Series Operating and Service Guide...
Page 70 Generally, a capacitor with low ESR in parallel with a capacitor with high ESR allows for good stability, minimized transient response voltage deviation, as well as good voltage noise filtering. Keysight N69100 Series Operating and Service Guide...
Page 71 DUT. After a short delay, the excessive current flow will cause over-current protection to engage - thereby disabling the output of the unit. Keysight N69100 Series Operating and Service Guide...
Page 72 Exposed bus bar surfaces must either be enclosed in a cabinet or insulated so that no accidental contact with lethal voltages can occur. Keysight N69100 Series Operating and Service Guide...
Page 73 Size the load cables according to the current rating of the unit. Plus cables should be bundled with minus cables. Although the drawing shows units side by side for clarity, they may also be stacked on top of each other. Keysight N69100 Series Operating and Service Guide...
Page 74 CAT6A cable as shown in the following figures. For further information about primary/secondary configurations, refer to Parallel Operation. Do not install units into a primary/secondary configuration that are not actively being used as part of the primary/secondary group. Keysight N69100 Series Operating and Service Guide...
Page 75 One reason is that exceeding the maximum float voltages ratings given in the characteristics tables is extremely dangerous and it is impossible to guarantee safe voltage balance when using bidirectional instruments in series. Keysight N69100 Series Operating and Service Guide...
Page 76 3. You can now use Interactive IO within the Connection Expert to communicate with your instru- ment, or you can program your instrument using the various programming environments. USB Connections The following figure illustrates a typical USB interface system. Keysight N69100 Series Operating and Service Guide...
Page 77 A private LAN is a network in which LAN-enabled instruments and computers are directly connected, and not connected to a site LAN. They are typically small, with no centrally-managed resources. The following figure illustrates a typical private LAN system. Keysight N69100 Series Operating and Service Guide...
Page 78 4. Output Couple configurable pins 5. Digital IO-configurable pins 6. Signal common Information on using the digital port is found under Programming the Digital Port. The electrical characteristics are described in the Common Characteristics tables. Keysight N69100 Series Operating and Service Guide...
Page 79 2. Connect the LAN, USB, GPIB cable, and digital IO wires (GPIB shown) to the appropriate rear panel connector. 3. Insert the cover tabs into the flange. Attach the ESD cover to the back of the unit using the two cap- tive cover screws. Keysight N69100 Series Operating and Service Guide...
Page 81 Keysight N69100 Series Operating and Service Guide Getting Started Using the Front Panel Remote Interface Configuration...
Page 82 AC power connected, and if it is green, the instrument is on. If a self-test error occurs, a message is displayed on the front panel. For other self- test errors, see Service and Maintenance for instructions on returning the instrument for service. Keysight N69100 Series Operating and Service Guide...
Page 83 Enter the desired setting using the numeric keypad. Then press Enter. If you make a mistake, either use the backspace key to delete the number, press Back to back out of the menu, or press Meter to return to meter mode. Keysight N69100 Series Operating and Service Guide...
Page 84 Enter. If you make a mistake, either use the backspace key to delete the number, press Back to back out of the menu, or press Meter to return to meter mode. Keysight N69100 Series Operating and Service Guide...
Page 85 Press the right arrow navigation key > to traverse the menu until the Protect command is highlighted. Press the Select key to access the Protect commands. Since the OVP command is already highlighted, press the Select key to access the OVP dialog. Keysight N69100 Series Operating and Service Guide...
Page 86 Press the Help key at the lowest menu level to display help information about the menu function controls. Whenever a limit is exceeded or any other invalid configuration is found, the instrument will display a message, including Error code information. Press Meter or Back to exit Help. Keysight N69100 Series Operating and Service Guide...
Page 87 This setting is non-volatile; it will not be changed by power cycling or *RST. Use the front panel menu to change the GPIB address: Keysight N69100 Series Operating and Service Guide...
Page 88 You can also reset the LAN to the as-shipped (default) settings. This returns ALL LAN settings to the as-shipped values and restarts networking. All default LAN settings are listed under Non-volatile Settings. Keysight N69100 Series Operating and Service Guide...
Page 89 "192.168.020.011" is actually equivalent to decimal "192.168.16.9" because ".020" is interpreted as "16" expressed in octal, and ".011" as "9". To avoid confusion, use only decimal values from 0 to 255, with no leading zeros. Keysight N69100 Series Operating and Service Guide...
Page 90 "192.168.020.011" is actually equivalent to decimal "192.168.16.9" because ".020" is interpreted as "16" expressed in octal, and ".011" as "9". To avoid confusion, use only decimal values from 0 to 255, with no leading zeros. Keysight N69100 Series Operating and Service Guide...
Page 91 The built-in Web interface only operates over the LAN. A Web browser is required to use the Web Interface. The Web interface is enabled when shipped. To launch the Web interface: Keysight N69100 Series Operating and Service Guide...
Page 92 IP address, and 5024 is the instrument’s telnet port. You should get a Telnet session box with a title indicating that you are connected to the power supply. Type the SCPI commands at the prompt. Keysight N69100 Series Operating and Service Guide...
Page 93 Not available Enable or disable the interfaces by checking or unchecking the following items: Enable LAN, Enable GPIB, and Enable USB If you cannot access the Admin menu, it may be password protected. Keysight N69100 Series Operating and Service Guide...
Page 95 Keysight N69100 Series Operating and Service Guide Using the DC Power System Programming the Output Parallel Operation Current Sinking Operation Programming Output Protection Programming Output Transients Sequencing the Output Making Measurements Programming the Digital Port System-Related Operations Priority Mode Tutorial...
Page 96 To specify current or voltage priority mode: FUNC CURR|VOLT Select Voltage or Current priority. Then press Select. When switching between modes, the output is turned off and the output settings revert to their power-on or RST values. Keysight N69100 Series Operating and Service Guide...
Page 97 This setting can be used to prevent crossover into current limit while up- and down- programming capacitive loads, or to limit programming response to a controlled rate. Use the Keysight N69100 Series Operating and Service Guide...
Page 98 Characteristics section illustrate the minimum ESR as a function of DUT capacitance to allow for stable operation. The Output Impedance graphs illustrate the effect that the compensation modes have on the small-signal output impedance. Keysight N69100 Series Operating and Service Guide...
Page 99 0 -100% of current step at Vout 5 ms 10 ms Front Panel Menu Reference SCPI Command Select Output\Advanced\Bandwidth\Current. To set the current compensation bandwidth: CURR:BWID:RANG 0 | 1 Select either 0, or 1. Keysight N69100 Series Operating and Service Guide...
Page 100 During a 1-cycle AC line dropout the unit may reboot. The output will remain off after reboot until the operator reinstates the previous settings, either by the front panel controls or using a computer program. This behavior is consistent with safe operating procedures. Keysight N69100 Series Operating and Service Guide...
Page 101 Configure one unit as the primary Configure the other units as secondary units with unique bus addresses Select the connection mode and auto-connect delay time Perform a one-time discovery on the primary - it saves the primary/secondary configuration Keysight N69100 Series Operating and Service Guide...
Page 102 After the secondary unit address configuration, run "Discover" on the primary unit to initiate communication with all secondary units. After initial discovery, the discovery process does not need to be run again unless the primary/secondary configuration changes. Keysight N69100 Series Operating and Service Guide...
Page 103 Set the positive current limit high to allow extra headroom for the up-programming transient dynamics. Transient dynamics are mainly a result of DUT capacitance charging currents. Note that the Keysight N69100 Series Operating and Service Guide...
Page 104 If a secondary unit goes into protection, the primary and the secondary unit on which the protection event occurred indicate the type of protection event. All other secondary units indicate PROT. Once the protection condition is corrected, clearing protection on the primary clears protection on all units. Keysight N69100 Series Operating and Service Guide...
Page 105 CSF can also be an initial indication of communication loss with the primary unit; which will transition to PSP. No secondary units discovered or 1 secondary discovered (if expecting multiple secondary units) Check that there are no duplicate secondary addresses. Error 332, Primary/Secondary Error Keysight N69100 Series Operating and Service Guide...
Page 106 PSP. Check that the primary/secondary CAT6A cables are installed correctly. This can also occur when changing the primary/secondary configuration. Always set the primary unit to None when changing primary/secondary configurations. Keysight N69100 Series Operating and Service Guide...
Page 107 AC mains. Refer to AC Mains Considerations for additional information. Keysight N69100 Series Operating and Service Guide...
Page 108 OT protection is always enabled. Note that If an over-temperature condition occurs on the AC input Keysight N69100 Series Operating and Service Guide...
Page 109 It minimizes the resulting peak current at the output terminals by comparing the actual output current to a fixed level of 105% of the unit's rated current. If the current exceeds this level, the unit will go into a latched protection. Keysight N69100 Series Operating and Service Guide...
Page 110 The delay can be programmed from 0 to 0.255 seconds. You can specify if the OCP delay timer is started by any transition of the output into current limit, or only at the end of a settings change in voltage, current, or output state. Keysight N69100 Series Operating and Service Guide...
Page 111 A watchdog protect can be cleared as described under Clear Output Protection. The watchdog delay can be programmed from 1 to 3600 seconds in 1-second increments. To enable the watchdog timer and specify a delay value, proceed as follows: Keysight N69100 Series Operating and Service Guide...
Page 112 Then, clear the protection function as follows: Front Panel Menu Reference SCPI Command Select Protect\Clear To clear a protection fault: OUTP:PROT:CLE Select Clear. The output is re-enabled once the output protection function is cleared. Keysight N69100 Series Operating and Service Guide...
Page 113 The transient trigger process is illustrated below. This applies to all transient types. The arrows on the right are specific to List transients. For an overview of the trigger system, refer to Trigger Overview. Keysight N69100 Series Operating and Service Guide...
Page 114 Triggers the transient as soon as it is INITiated. Pin<1-7> Selects a specific pin<n> that is configured as a Trigger Input on the digital control port. Use the following commands to select a trigger source: Keysight N69100 Series Operating and Service Guide...
Page 115 TRIG:TRAN Select Trigger to generate an immediate trigger signal regardless of the trigger source setting. Alternatively, if the trigger source is BUS, you can also program a *TRG or an IEEE-488 <get> command. Keysight N69100 Series Operating and Service Guide...
Page 116 In the front panel menu, you can only program the step level based on the priority mode that you are operating in - voltage or current priority. Keysight N69100 Series Operating and Service Guide...
Page 117 With a trigger-paced list, triggers that are received during the dwell period are ignored. You can set the list dwell time to zero ensure that no triggers are lost. Keysight N69100 Series Operating and Service Guide...
Page 118 To generate the voltage list shown in the figure, a list may include the following values: 9, 0, 6, 0, 3, 0: Keysight N69100 Series Operating and Service Guide...
Page 119 The number of dwell steps must equal the number of voltage steps. If a dwell list has only one value, that value will be applied to all steps in the list. Keysight N69100 Series Operating and Service Guide...
Page 120 Sending the INFinity parameter in the SCPI command makes the list repeat indefinitely. Front Panel Menu Reference SCPI Command Select Transient\List\Repeat. To program the list to repeat twice: LIST:COUN 2 Enter the number of list repetitions (2) and press Select. Keysight N69100 Series Operating and Service Guide...
Page 121 To enable the transient function, use: VOLT:MODE ARB In voltage priority mode select Voltage mode. In current priority mode select Current mode. In the CURR:MODE ARB dropdown list, select Arb. Then press Select. Keysight N69100 Series Operating and Service Guide...
Page 122 To return the output to the pre-Arb state: ARB:TERM:LAST OFF Select either Return to Start, or Stop at Last Step and press Select. To keep the output at the Arb end point: ARB:TERM:LAST ON Keysight N69100 Series Operating and Service Guide...
Page 123 OnCouple and OffCouple signals to enable and disable the output. These signals provide an additional level of control when sequencing the output on individual and multiple units. The following figure illustrates the programming path when using the OnCouple and OffCouple signals to control the output. Keysight N69100 Series Operating and Service Guide...
Page 124 Front Panel Menu Reference SCPI Command Select Output\Sequence\Couple. Program a turn-on delay: OUTP:DEL:RISE .02 Specify the Turn-on delay in seconds. Repeat for each instrument. Repeat for each additional unit. Keysight N69100 Series Operating and Service Guide...
Page 125 Enter the delay offset value of the Use the delay offset of the slowest unit to specify slowest unit in the Delay offset field in milliseconds. Then the common delay offset press Select. OUTP:COUP:DOFF <value> Keysight N69100 Series Operating and Service Guide...
Page 126 If you wish to program a voltage turn-off slew rate, you must set the slew rate and program the output voltage to zero before you send the output off command. Keysight N69100 Series Operating and Service Guide...
Page 127 When a protection event is detected, the power supply immediately opens the solid-state output switch. This typically takes less than 50 μs following the initial detection. Turn-On/Turn-Off Flowchart Keysight N69100 Series Operating and Service Guide...
Page 128 To set the number of power line cycles to 10: SENS:SWE:NPLC 10 Enter the number of power line cycles in the NPLC field. Then press Select. The AC line frequency is detected automatically for SENSe:SWEep:NPLC. Keysight N69100 Series Operating and Service Guide...
Page 129 The bin containing the most data points below the 50% point is the low bin. The average of all the data points in the low bin is returned as the Low level. If no low bin Keysight N69100 Series Operating and Service Guide...
Page 130 The following figure illustrates the measurement acquisition process. This process applies to both measurement triggers and external data logging. For an overview of the trigger system, refer to Trigger Overview. Keysight N69100 Series Operating and Service Guide...
Page 131 When the unit is turned on, the trigger system is in the idle state. In this state, the trigger system is disabled, ignoring all triggers. The INITiate commands enable the trigger system to receive triggers. Keysight N69100 Series Operating and Service Guide...
Page 132 After a trigger is received and the measurement completes, the trigger system will return to the idle state. Once the measurement completes, FETCh queries can retrieve the most recent measurement data without initiating a new measurement or altering the data in the measurement buffer. Keysight N69100 Series Operating and Service Guide...
Page 133 NOT complete. When the MEAS_active bit is false, you can retrieve the measurement. Refer to Status Tutorial for more information. Front Panel Menu Reference SCPI Command Select Measure\Control. To query the MEAS_active bit (bit 5): The Trig state field indicates "Idle". STAT:OPER:COND? Keysight N69100 Series Operating and Service Guide...
Page 134 A trigger input pin can be selected as the source for measurement and transient trigger signals. See TRIGger- :ACQuire:SOURce TRIGger:TRANsient:SOURce TOUTput A trigger output pin will generate output triggers from any subsystem that has been configured to output trigger signals. Common Applies only to pin 8. Connected to ground. Keysight N69100 Series Operating and Service Guide...
Page 135 In the Polarity field, select either Positive or Negative. To configure pins 1 through 7 as “0000111”: To send data to the pins, select DIG:OUTP:DATA 7 System\IO\DigPort\Data. Select the Data Out field and enter the binary word. Keysight N69100 Series Operating and Service Guide...
Page 136 In the Function field, select either the Trig In or Trig Out DIG:PIN2:FUNC TINP function. To select the pin polarity: In the Polarity field, select either Positive or Negative. DIG:PIN1:POL POS DIG:PIN2:POL POS Keysight N69100 Series Operating and Service Guide...
Page 137 In the Polarity field, select either Positive or Negative. DIG:PIN3:POL POS Select Protect\Inhibit. To specify the Inhibit mode: Select either Latching or Live. OUTP:INH:MODE LATC OUTP:INH:MODE LIVE To disable the Inhibit signal, select Off. OUTP:INH:MODE OFF Keysight N69100 Series Operating and Service Guide...
Page 138 2. Set the delay offset of each individual unit to match the longest delay offset of the group. 3. Connect and configure the digital connector pins of the sequenced units as shown below. Keysight N69100 Series Operating and Service Guide...
Page 139 Repeat commands for units 2 and 3. Once configured and enabled, turning the output on or off on any coupled unit will cause all coupled units to turn on or off according to their user-programmed delays. Keysight N69100 Series Operating and Service Guide...
Page 140 However, you can configure the power supply to use the settings you have stored in memory location 0 at power-on. Front Panel Menu Reference SCPI Command Select States\PowerOn. OUTP:PON:STAT RCL0 Select Recall State 0. Then press Select. Keysight N69100 Series Operating and Service Guide...
Page 141 This parameter is saved in non-volatile memory. Therefore, the front panel remains locked even after AC power is cycled. Front Panel Menu Reference SCPI Command Select System\Preferences\Lock Not available In the dialog box, enter the password to unlock the front panel. Then select Lock. Keysight N69100 Series Operating and Service Guide...
Page 142 Enter the date in the Month, Day and Year fields. Enter the time in the Hour, Minute, and Second fields. To set the time: Press Select to set the date and time. SYSTem:TIME 20,30,0 Keysight N69100 Series Operating and Service Guide...
Page 143 A LIM+ (positive current limit)status is set to indicate that a current limit has been reached. These conditions are annunciated by CL+ on the front panel. Keysight N69100 Series Operating and Service Guide...
Page 144 This condition is annunciated by VL+ on the front panel. For additional information on priority mode operation during output turn-on/turn- off, refer to Turn-On Turn-Off Behavior. Keysight N69100 Series Operating and Service Guide...
Page 145 Keysight N69100 Series Operating and Service Guide SCPI Programming Reference Related Software SCPI Introduction Commands by Subsystem Status Tutorial Trigger Tutorial Reset State SCPI Error Messages...
Page 146 Keysight Developer Network at www.keysight.com/find/adn. Interface Documentation For detailed information about interface connections, refer to the Keysight Technologies USB/LAN/GPIB Interfaces Connectivity Guide, included with the Keysight IO Libraries Suite. Or you can download the guide from the Web at www.keysight.com/find/connectivity.
Page 147 A portion of the OUTPut subsystem is shown below to illustrate the tree system. Note that some [optional] commands have been included for clarity. OUTPut [:STATe] OFF|0|ON|1 :DELay :FALL <value>|MIN|MAX :RISE <value>|MIN|MAX :INHibit :MODE LATChing|LIVE|OFF Keysight N69100 Series Operating and Service Guide...
Page 148 In the following example, the optional startindex and points parameters must be separated with a comma. Note the space between CURRent? and the first parameter. FETCh:CURRent? [< start_index >, < points >] Keysight N69100 Series Operating and Service Guide...
Page 149 A vertical bar ( | ) separates multiple parameter choices for a given command string. For example, LATChing|LIVE|OFF in the OUTPut:INHibit command indicates that you can specify "LATChing", "LIVE", or "OFF". The bar is not sent with the command string. Keysight N69100 Series Operating and Service Guide...
Page 150 "OFF" or "0". For a true condition, the instrument will accept "ON" or "1". When you query a Boolean setting, the instrument will always return "0" or "1". The following command requires a Boolean parameter: DISPlay OFF|0|ON|1 Keysight N69100 Series Operating and Service Guide...
Page 151 The instrument returns to the trigger idle state. The instrument's input and output buffers are cleared. The instrument is prepared to accept a new command string. The ABORt command is the recommended method to terminate an instrument operation. Keysight N69100 Series Operating and Service Guide...
Page 152 5 SCPI Programming Reference Commands by Subsystem ABORt CALibrate DISPlay FETCh FORMat HCOPy IEEE-488 Common INITiate INSTrument MEASure OUTPut SENSe [SOURce:] CURRent DIGital FUNCtion LIST POWer STEP VOLTage STATus SYSTem TRIGger Keysight N69100 Series Operating and Service Guide...
Page 153 Operation Status registers. Note that this command does not turn off continuous triggers if INITiate:CONTinuous:TRANsient ON has been programmed. In this case, first turn off continuous triggers before sending the ABORt command. Parameter Typical Return (none) (none) Aborts the triggered measurement: ABOR:ACQ Keysight N69100 Series Operating and Service Guide...
Page 154 Specifies the dwell time of each point in the Arb. Values are in seconds and are rounded to the nearest 10.24-microsecond increment. Current and voltage Arbs share settings, so setting this parameter for a current Arb changes the voltage dwell value and vice versa. Keysight N69100 Series Operating and Service Guide...
Page 155 When OFF (0), and also when the Arb is aborted, the output returns to the settings that were in effect before the Arb started. Parameter Typical Return 0|OFF|1|ON, *RST OFF 0 or 1 Terminate with the output at the last Arb value: ARB:TERM:LAST ON Keysight N69100 Series Operating and Service Guide...
Page 156 Typical Return Numeric value (none) Specify calibration value 0.0237: CAL:DATA 2.37E-2 CALibrate:DATE <"date"> CALibrate:DATE? Enters the calibration date in nonvolatile memory. Enter any ASCII string up to 15 characters. The query returns the date. Keysight N69100 Series Operating and Service Guide...
Page 157 This setting is non-volatile; it will not be changed by power cycling or *RST. CALibrate:SAVE Saves the calibration constants in non-volatile memory. Do this at the end of the calibration to avoid losing changes. Parameter Typical Return (none) (none) Store calibration constants into non-volatile memory: CAL:SAVE Keysight N69100 Series Operating and Service Guide...
Page 158 Calibrates the local voltage programming and measurement. The value selects the range to calibrate. Parameter Typical Return The maximum voltage of the output range. (none) Calibrates the voltage of the 20 V range: CAL:VOLT 20 Keysight N69100 Series Operating and Service Guide...
Page 159 Sets the current limit when in voltage priority mode. Units are in amperes. The maximum value depends on the current rating of the unit. Parameter Typical Return 0 to 102% of rating, *RST 1.02% of rating <current limit> Sets the current limit to 2 A: CURR:LIM 2 Keysight N69100 Series Operating and Service Guide...
Page 160 CCTRans starts the over-current delay timer by any transition of the output into current limit mode. Parameter Typical Return SCHange|CCTRans, *RST SCHange SCH or CCTR Selects the CCTRans delay mode: CURR:PROT:DEL:STAR CCTR Keysight N69100 Series Operating and Service Guide...
Page 161 The CURRent:SLEW:MAX command is coupled to the CURRent:SLEW command. If CURRent:SLEW sets the rate to MAX or INFinity, CURRent:SLEW:MAX is enabled. If the slew rate is set to any other value, CURRent:SLEW:MAX is disabled. Keysight N69100 Series Operating and Service Guide...
Page 162 Pin 3 functions as an inhibit input. ONCouple Pins 4 -7 synchronize the output On state. OFFCouple Pins 4 -7 synchronize the output Off state. TINPut A trigger input function. TOUTput A trigger output function Keysight N69100 Series Operating and Service Guide...
Page 163 Enable BUS triggered signals on the digital pins: DIG:TOUT:BUS ON The query returns 0 (OFF) if the trigger signal will NOT be generated with a BUS trigger command, and 1(ON) if a trigger signal will be generated with a BUS trigger command. Keysight N69100 Series Operating and Service Guide...
Page 164 To display voltage and power: DISP:VIEW METER_VP DISPlay:SAVer[:STATe] 0|OFF|1|ON DISPlay:SAVer[:STATe]? Turns the front panel screen saver on or off. Parameter Typical Return 0|OFF|1|ON, *RST OFF 0 or 1 Turns the front panel screen saver on: DISP:SAV ON Keysight N69100 Series Operating and Service Guide...
Page 165 FETCh[:SCALar]:VOLTage:HIGH? Returns the High level of a pulse waveform. Values returned are either in amperes, or volts. See Additional Measurements. Parameter Typical Return (none) <HIGH value> Returns the measured high level current FETC:CURR:HIGH? Keysight N69100 Series Operating and Service Guide...
Page 166 IGNORE_OVLD parameter is sent, the accumulated measurement will be returned even if some samples were outside of the measurement range. Parameter Typical Return IGNORE_OVLD ignore overload measurements <amp-hours> <watt-hours> Returns the amp-hour measurement FETC:AHO? Returns the watt-hour measurement FETC:WHO? Keysight N69100 Series Operating and Service Guide...
Page 167 (little-endian). Parameter Typical Return NORMal|SWAPped, *RST NORMal NORM or SWAP Sets the data transfer to Swapped: FORM:BORD SWAP The byte order is used when fetching real data from SCPI measurements. Keysight N69100 Series Operating and Service Guide...
Page 168 Refer to Priority Mode Tutorial for more information. Parameter Typical Return CURRent|VOLTage, *RST VOLTage CURR or VOLT Sets the output regulation to current priority: FUNC CURR Keysight N69100 Series Operating and Service Guide...
Page 169 Returns the image in GIF format: HCOP:SDUM:DATA? GIF HCOPy:SDUMp:DATA:FORMat BMP|GIF|PNG HCOPy:SDUMp:DATA:FORMat? Specifies the format for front panel images returned. Parameter Typical Return BMP|GIF|PNG, *RST PNG BMP, GIF, or PNG Specify GIF as the image format: HCOP:SDUM:DATA:FORM GIF Keysight N69100 Series Operating and Service Guide...
Page 170 Event status event query. Reads and clears the event register for the Standard Event Status group. The event register is a read-only register, which latches all standard events. Refer to Status Tutorial for more information. Keysight N69100 Series Operating and Service Guide...
Page 171 The difference between *OPC and *OPC? is that *OPC? returns "1" to the output buffer when the current operation completes. *OPC? Returns a 1 to the output buffer when all pending operations complete. The response is delayed until all pending operations complete. Keysight N69100 Series Operating and Service Guide...
Page 172 Reset the instrument: *RST *RST forces the ABORt commands. This cancels any measurement or transient actions presently in process. It resets the WTG-meas, MEAS-active, WTG-tran, and TRAN-active bits in the Oper- ation Status registers. Keysight N69100 Series Operating and Service Guide...
Page 173 Output Queue MAV bit. The Status Byte is a read-only register and the bits are not cleared when it is read. Refer to Status Tutorial for more information. Parameter Typical Return (none) <bit value> Read status byte: *STB? Keysight N69100 Series Operating and Service Guide...
Page 174 Pauses additional command processing until all pending operations are complete. See for more information. Parameter Typical Return (none) (none) Wait until all pending operations complete. *WAI *WAI can only be aborted by sending the instrument a Device Clear command. Keysight N69100 Series Operating and Service Guide...
Page 175 With initiate continuous disabled, the output trigger system must be initiated for each trigger using the INITiate:TRANsient command. ABORt:TRANsient does not turn off continuous triggers if INITiate:CONTinuous:TRANsient ON has been programmed. In this case, first turn off continuous triggers before sending the ABORt com- mand. Keysight N69100 Series Operating and Service Guide...
Page 176 Set the delay after power-on before the primary unit attempts to connect to secondary units. This only applies if the connect mode is set to AUTO. This setting is saved in-volatile memory. Parameter Typical Return 0 to 120 seconds Configures the connection delay for 10 seconds INST:GRO:PRIM:CONN:DEL 10 Keysight N69100 Series Operating and Service Guide...
Page 177 Sets the secondary unit's bus address. Each secondary unit in a primary/secondary group must have a unique bus address or bus communication will fail. This setting is saved in non-volatile memory. Parameter Typical Return 1 - 9 Set the secondary unit's address to 1 INST:GRO:SEC:ADDR 1 Keysight N69100 Series Operating and Service Guide...
Page 178 Dwell times can be programmed from 0 through 262.144 seconds with the following resolution: Range in seconds Resolution 0 - 0.262144 1 microsecond 0.262144 - 2.62144 10 microseconds 2.62144 - 26.2144 100 microseconds 26.2144 - 262.144 1 millisecond Keysight N69100 Series Operating and Service Guide...
Page 179 When OFF (0), and also when the list is aborted, the output returns to the settings that were in effect before the list started. Parameter Typical Return 0|OFF|1|ON, *RST OFF 0 or 1 Terminate with the output at the last step value: LIST:TERM:LAST ON Keysight N69100 Series Operating and Service Guide...
Page 180 Parameter Typical Return 0|OFF|1|ON 0 or 1 To generate triggers at the beginning of the second step of a 3-step list: LIST:TOUT:BOST OFF,ON,OFF Keysight N69100 Series Operating and Service Guide...
Page 181 To blink the front panel LXI indicator: LXI:IDENT ON LXI:MDNS[:STATe] 0|OFF|1|ON LXI:MDNS[:STATe]? Sets the MDNS state on or off. Parameter Typical Return 0|OFF|1|ON, *RST OFF 0 or 1 To set the MDNS state on: LXI:MDNS ON Keysight N69100 Series Operating and Service Guide...
Page 182 Initiates, triggers, and returns the High level of a pulse waveform. Values returned are either in amperes, or volts. See Additional Measurements. Parameter Typical Return (none) <HIGH value> Returns the measured high level current MEAS:CURR:HIGH? Keysight N69100 Series Operating and Service Guide...
Page 183 Parameter Typical Return (none) <MIN value>, <MAX value> Returns the measured maximum current MEAS:CURR:MAX? Returns the measured minimum voltage MEAS:VOLT:MIN? Returns the measured maximum power MEAS:POW:MAX? Keysight N69100 Series Operating and Service Guide...
Page 184 This value must be the largest delay offset of the synchronized group. Use OUTPut:COUPle:MAX:DOFFset? to query the delay offset for each unit. The largest value returned must be specified as the common delay offset for each unit. Keysight N69100 Series Operating and Service Guide...
Page 185 1.03E–2 to 1.023E–1 100 microseconds 1.03E+2 to 1.023E+3 1 second Note that both Rise and Fall commands use the same resolution; which is determined by whichever delay time (fall or rise) is the longest. Keysight N69100 Series Operating and Service Guide...
Page 186 Sets the turn-off state to low impedance: OUTP:TMOD:OFF LOWZ The turn-on/turn-off setting only applies when the instrument is operating in voltage priority mode. In current priority mode, the turn-on/turn-off behavior is always high impedance. Keysight N69100 Series Operating and Service Guide...
Page 187 Resets the latched protection. This clears the latched protection status that disables the output when a protection condition occurs (see Programming Output Protection). Parameter Typical Return (none) (none) Clears the latched protection status: OUTP:PROT:CLE Keysight N69100 Series Operating and Service Guide...
Page 188 NOT reset by activity on the front panel - the output will still shut down after the time period has elapsed. Programmed values can range from 1 to 3600 seconds in 1 second increments. Keysight N69100 Series Operating and Service Guide...
Page 189 5 SCPI Programming Reference POWer Query [SOURce:]POWer:LIMit? Returns the power limit of the instrument in Watts, either 5 kW or 10 kW. Parameter Typical Return None 20,000 Return the power limit: POWer:LIMit? Keysight N69100 Series Operating and Service Guide...
Page 190 Changing the NPLC changes the number of points and time interval setting. Parameter Typical Return 0.0003072 to 1,258,290,000,000, *RST 1 <NPLC value> Specifies 100 power line cycles: SENS:SWE:NPLC 100 Keysight N69100 Series Operating and Service Guide...
Page 191 Because SOURce subsystem commands are often used without the optional SOURce keyword, these commands are listed by their individual subsystems, below: Subsystems and Commands Using the Optional [SOURce:] Keyword CURRent DIGital FUNCtion LIST POWer:LIMit STEP:TOUTput VOLTage Keysight N69100 Series Operating and Service Guide...
Page 192 The condition register bits reflect the current condition. If a condition goes away, the cor- responding bit is cleared. *RST clears this register, other than those bits where the condition still exists after *RST. Keysight N69100 Series Operating and Service Guide...
Page 193 If the same bits in both NTR and PTR registers are set to 0, then no transition of that bit at the Oper- ation Condition register can set the corresponding bit in the Operation Event register. The value returned is the binary-weighted sum of all enabled bits in the register. Keysight N69100 Series Operating and Service Guide...
Page 194 The condition register bits reflect the current condition. If a condition goes away, the cor- responding bit is cleared. *RST clears this register, other than those bits where the condition still exists after *RST. Keysight N69100 Series Operating and Service Guide...
Page 195 If the same bits in both NTR and PTR registers are set to 0, then no transition of that bit at the Ques- tionable Condition register can set the corresponding bit in the Questionable Event register. The value returned is the binary-weighted sum of all enabled bits in the register. Keysight N69100 Series Operating and Service Guide...
Page 196 Specifies whether a trigger out is generated when a transient step occurs. A trigger is generated when the state is on (true). Parameter Typical Return 0|OFF|1|ON, *RST OFF 0 or 1 Sets the step trigger signal to ON: STEP:TOUT ON Keysight N69100 Series Operating and Service Guide...
Page 197 The remote/local instrument state can also be set by other interface commands over the GPIB and some other I/O interface. When multiple remote programming interfaces are active, the interface with the most recently changed remote/local state determines the instrument’s remote/local state. Keysight N69100 Series Operating and Service Guide...
Page 198 255 characters. For a list of error codes and message strings, see SCPI Error Messages. SYSTem:PASSword:FPANel:RESet Resets the front panel lockout password to zero. This command does not reset the calibration password. Parameter Typical Return (none) <+0,"No error"> Resets the front panel password: SYST:PASS:FPAN:RES Keysight N69100 Series Operating and Service Guide...
Page 199 Sets the time of the system clock. Specify hours (0 to 23), minutes (0 to 59), and seconds (0 to 59). The real time clock is only used in conjunction with the BenchVue Power Control and Analysis software. Parameter Typical Return <hh>,<mm>,<ss> <hh,mm,ss> Set the clock to 8:30 PM: SYST:TIME2018,06,30 Keysight N69100 Series Operating and Service Guide...
Page 200 Typical Return (none) <"version"> Return the SCPI version: SYST:VERS? The command returns a string in the form "YYYY.V", where YYYY represents the year of the version and V represents a version for that year. Keysight N69100 Series Operating and Service Guide...
Page 201 Enables measurement triggers to be sent to a digital port pin. The digital port pin must be configured as trigger output before it can be used as a trigger source (see External Trigger I/O). Parameter Typical Return 0|OFF|1|ON, *RST OFF 0 or 1 Enable sending measurement triggers to digital pins: TRIG:ACQ:TOUT ON Keysight N69100 Series Operating and Service Guide...
Page 202 BUS | EXTernal | IMMediate | PIN<1-7> *RST BUS BUS, EXT, IMM, PIN<n> Select digital port pin 1 as the Arb trigger source: TRIG:ARB:SOUR PIN1 Select digital port pin 1 as the transient trigger source: TRIG:TRAN:SOUR PIN1 Keysight N69100 Series Operating and Service Guide...
Page 203 0 | 1 | 2, *RST 0 0, 1, or 2 Sets the voltage bandwidth to comp 1: VOLT:BWID:RANG 1 [SOURce:]VOLTage:LIMit[:POSitive][:IMMediate][:AMPLitude] <value>|MIN|MAX [SOURce:]VOLTage:LIMit[:POSitive][:IMMediate][:AMPLitude]? [MIN|MAX] Sets the voltage limit when in current priority mode. Units are in volts. Keysight N69100 Series Operating and Service Guide...
Page 204 Specifies an output resistance of 0.5 ohms: VOLT:RES 0.5 When units are connected in parallel, the maximum output resistance is reduced. The pro- grammable resistance for a single unit must be divided by the total number of paralleled units. Keysight N69100 Series Operating and Service Guide...
Page 205 The VOLTage:SLEW:MAX command is coupled to the VOLTage:SLEW command. If VOLTage:SLEW sets the rate to MAX or INFinity, VOLTage:SLEW:MAX is enabled. If the slew rate is set to any other value, VOLTage:SLEW:MAX is disabled. Keysight N69100 Series Operating and Service Guide...
Page 206 PTR/NTR, Event, and Enable register. The outputs of the Operation Status register group are logically- ORed into the OPERation summary bit (7) of the Status Byte register. Refer to Status Diagram. The following table describes the Operation Status register bit assignments. Keysight N69100 Series Operating and Service Guide...
Page 207 Output is disabled by an external INHibit signal 1024 Output is unregulated PROT 2048 Output is disabled by a watchdog timer protection 4096 Output is disabled by excessive output dynamic protection 13-15 not used not used 0 is returned Keysight N69100 Series Operating and Service Guide...
Page 208 Error Messages Command A command syntax error occurred. Error Messages not used not used 0 is returned Power On Power has been cycled since the last time the event register was read or cleared. Keysight N69100 Series Operating and Service Guide...
Page 209 The Output Queue is a first-in, first-out (FIFO) data register that stores messages until the controller reads them. Whenever the queue holds messages, it sets the MAV bit (4) of the Status Byte register. Keysight N69100 Series Operating and Service Guide...
Page 210 5 SCPI Programming Reference Status Diagram Keysight N69100 Series Operating and Service Guide...
Page 211 Sends the trigger to the designated transient (STEP, BOST, EOST) Acquisition system Sends the trigger to the acquisition system (TOUT) Starts the arbitrary waveform. Note that the waveform must first be enabled and initiated. See Programming Output Transients. Keysight N69100 Series Operating and Service Guide...
Page 212 5 SCPI Programming Reference Trigger Diagram Keysight N69100 Series Operating and Service Guide...
Page 213 ARB:CURRent:CDWell:DWELl 0.001 ARB:FUNCtion:SHAPe ARB:FUNCtion:TYPE VOLTage ARB:TERMinate:LAST ARB:VOLTage:CDWell:DWELl 0.001 CALibrate:STATe CURRent CURRent:LIMit 1.02% of rating CURRent:MODE FIXed CURRent:PROTection:DELay 20 ms CURRent:PROTection:DELay:STARt SCHange CURRent:PROTection:STATe CURRent:SLEW CURRent:SLEW:MAXimum DIGital:OUTPut:DATA DIGital:TOUTput:BUS DISPlay DIGital:OUTPut:DATA DIGital:TOUTPut:BUS FORMat:DATA ASCII FORMat:BORDer NORMal Keysight N69100 Series Operating and Service Guide...
Page 214 1 step set to OFF LIST:VOLTage 1 step set to 0.1% of rating LXI:IDENtify LXI:MDNS OUTPut OUTPut:DELay:FALL OUTPut:DELay:RISE OUTPut:PROTection:WDOG OUTPut:PROTection:WDOG:DELay RESistance RESistance:STATe SENSe:CURRent:RANGe:AUTO SENSe:FUNCtion:CURRent SENSe:FUNCtion:VOLTage SENSe:SWEep:NPLCycles STEP:TOUTput TRIGger:ACQuire:SOURce TRIGger:ACQuire:TOUTput TRIGger:ARB:SOURce TRIGger:TRANsient:SOURce VOLTage 0.1% of rating Keysight N69100 Series Operating and Service Guide...
Page 215 DIGital:PIN<all>:POLarity POSitive DISPlay:VIEW METER_VI INSTrument:GROup:FUNCtion NONE INSTrument:GROup:SECondary:ADDRess OUTPut:COUPle OUTPut:COUPle:DOFFset OUTPut:INHibit:MODE OUTPut:PON:STATe Front Panel as-shipped settings Front panel lockout password Disabled Firmware update password protected Disabled GPIB address GPIB interface Enabled LAN interface Enabled Keysight N69100 Series Operating and Service Guide...
Page 216 LAN service - VXI-11 Enabled LAN service - Telnet Enabled LAN service - mDNS Enabled LAN service - Web server Enabled LAN service - sockets Enabled Web password Blank (web password is disabled) Keysight N69100 Series Operating and Service Guide...
Page 217 Calibration is not enabled. The instrument will not accept calibration commands. 102 Calibration password is incorrect The calibration password is incorrect. 103 Calibration is inhibited by switch setting Calibration mode is locked out by the calibration switch. 104 Bad sequence of calibration commands Keysight N69100 Series Operating and Service Guide...
Page 218 A selftest failure has occurred. See selftest failure list for details. 203 Compatibility function not implemented The requested compatibility function is not available. 204 NVRAM checksum error A checksum error has occurred in the instrument’s nonvolatile random access memory. 205 NVRAM full Keysight N69100 Series Operating and Service Guide...
Page 219 308 This setting cannot be changed while transient trigger is initiated Setting cannot be changed while the instrument is waiting for or executing a trigger sequence. 309 Cannot initiate, voltage and current in fixed mode Keysight N69100 Series Operating and Service Guide...
Page 220 Generic syntax error. -101 Invalid character An invalid character was found in the command string. -102 Syntax error Invalid syntax was found in the command string. Check for blank spaces. -103 Invalid separator Keysight N69100 Series Operating and Service Guide...
Page 221 The mantissa of a numeric parameter contained more than 255 digits, excluding leading zeros. -128 Numeric data not allowed A numeric parameter was received but a character string was expected. -130 Suffix error Keysight N69100 Series Operating and Service Guide...
Page 222 -168 Block data not allowed Data was sent in arbitrary block format but is not allowed for this command. Execution Errors (these errors set Standard Event Status register bit #4) -200 Execution error Keysight N69100 Series Operating and Service Guide...
Page 223 The command could not be executed because of a hardware problem with the instrument. -241 Hardware missing The command could not be executed because of missing hardware, such as an option. Query Errors (these errors set Standard Event Status register bit #2) -400 Query Error Keysight N69100 Series Operating and Service Guide...
Page 224 -430 Query DEADLOCKED A condition causing a deadlocked query error occurred. -440 Query UNTERMINATED after indefinite response A query was received in the same program message after a query indicating an indefinite response was executed. Keysight N69100 Series Operating and Service Guide...
Page 225 Keysight N69100 Series Operating and Service Guide Verification and Calibration Test Equipment and Setups Performance Verification Instrument Calibration Test Record Forms...
Page 226 V, C Differential Amplifier Bandwidth: 20 MHz LeCroy 1855A, DA1850A, or equivalent Differential Probe 10:1/100:1 selectable LeCroy DXC100A, or equivalent Terminations 50Ω BNC termination V=Verification; C=Calibration Dependent on rating of model being tested Keysight N69100 Series Operating and Service Guide...
Page 227 "Wait" statements can be used in the test program if the test system is faster than the unit under test. Keysight N69100 Series Operating and Service Guide...
Page 228 The performance verification tests are recommended as acceptance tests when you first receive the instrument. The acceptance test results should be compared against the instrument specifications. Keysight Technologies recommends that you repeat the performance verification tests at every calibration interval. This ensures that the instrument will remain within specifications for the next calibration interval and provides the best long-term stability.
Page 229 6 Verification and Calibration If the instrument fails any of the tests or if abnormal test results are obtained, try calibrating the unit. If calibration is unsuccessful, return the unit to a Keysight Technologies Service Center. Refer to the Recommended Test Equipment and Setups section for a list of the equipment and test setups required for verification.
Page 230 6 Verification and Calibration Models N69172A and N69173A Keysight N69100 Series Operating and Service Guide...
Page 231 “CV Load Effect”. Turn the output on. The output status of the unit under test should be “CV”. If it isn’t, adjust the load so that the output current drops slightly. Keysight N69100 Series Operating and Service Guide...
Page 232 A). Connect the RP79xxA load unit to the output terminals. Step 2. Turn on the unit under test and program the instrument settings as described in the test record form under “Transient Response”. Keysight N69100 Series Operating and Service Guide...
Page 233 Also, record the current reading measured by the instrument over the interface. The readings should be within the limits specified in the test record form under “Current Programming & Readback, High Current”. Keysight N69100 Series Operating and Service Guide...
Page 234 10% of its rated current, and has a -CL status. Divide the voltage drop (DMM reading) across the current shunt by the shunt resistance to convert to amps and record this value. The readings should be within the limits specified in the test record form under “Current Sink Tests”. Keysight N69100 Series Operating and Service Guide...
Page 235 Once started, you must complete each calibration section in its entirety. As each calibration sec- tion is completed, the instrument calculates new calibration constants and begins using them. These constants are not saved in nonvolatile memory until a SAVE command is explicitly given. Keysight N69100 Series Operating and Service Guide...
Page 236 Voltage and current programming and measurement accuracy specifications can be extended to a three-year period calibration interval by multiplying (or increasing) the one-year calibration accuracy specifications shown in the verification Test Record Forms by a factor of three. Calibration Setups Keysight N69100 Series Operating and Service Guide...
Page 237 Measure the output voltage with the DMM and enter the data. Front Panel Menu Reference SCPI Command Display shows: “Enter P2 measured data”. Enter the data CAL:LEV P2 from the external DMM. Press Enter when done. Press *OPC? Back to finish. CAL:DATA <data> Keysight N69100 Series Operating and Service Guide...
Page 238 Save Calibration and Log Out Front Panel Menu Reference SCPI Command Select System\Admin\Cal\Save. To save calibration data: Select Save to save all calibration data. CAL:SAVE Select System\Admin\Logout To exit calibration mode: to exit calibration mode. CAL:STAT OFF Keysight N69100 Series Operating and Service Guide...
Page 239 Voltage priority: 10 V, -816 A CC Load Effect: Current priority: 20.4 V, 400 A Voltage priority: 20 V, -408 A 10% of current rating (Isink): Voltage priority: 0 V, 0 A Voltage priority: 10 V, 800 A Keysight N69100 Series Operating and Service Guide...
Page 240 Voltage priority: 40 V, -255 A CC Load Effect: Current priority: 80.8 V, 125 A Voltage priority: 80 V, -127.5 A 10% of current rating (Isink): Voltage priority: 0 V, 0 A Voltage priority: 40 V, 250 A Keysight N69100 Series Operating and Service Guide...
Page 241 Voltage priority: 80 V, -127.5 A CC Load Effect: Current priority: 161.6 V, 62.5 A Voltage priority: 160 V, -63.75 A 10% of current rating (Isink): Voltage priority: 0 V, 0 A Voltage priority: 80 V, 125 A Keysight N69100 Series Operating and Service Guide...
Page 242 10% of Current Rating (Isink): Voltage priority: 0 V, 0 A Voltage priority: 333 V, 60 A Equipment damage. The LeCroy DXC100A probe is limited to 500 V. Only connect for CV Ripple and Noise test. Keysight N69100 Series Operating and Service Guide...
Page 243 10% of Current Rating (Isink): Voltage priority: 0 V, 0 A Voltage priority: 666 V, 30 A Equipment damage. The LeCroy DXC100A probe is limited to 500 V. Only connect for CV Ripple and Noise test. Keysight N69100 Series Operating and Service Guide...
Page 245 Keysight N69100 Series Operating and Service Guide Service and Maintenance Introduction Self-Test Procedure Firmware Update Instrument Sanitize Calibration Switches Battery Replacemsnt Disassembly...
Page 246 7 Service and Maintenance Introduction Repair Service Available If your instrument fails during the warranty period, Keysight Technologies will repair or replace it under the terms of your warranty. After your warranty expires, Keysight offers repair services at competitive prices.
Page 247 SHOCK HAZARD To prevent electric shock, disconnect the AC mains before cleaning. Clean the outside of the instrument with a soft, lint-free, slightly damp cloth. Do not use detergent. Disassembly is not required or recommended for cleaning. Keysight N69100 Series Operating and Service Guide...
Page 248 If 0, self-test passed. If 1, self-test failed. on. Press the Error key to display the list of errors. If self test-fails, use SYSTem:ERRor? to view the self-test error. For a list of errors, see SCPI Error Messages. Keysight N69100 Series Operating and Service Guide...
Page 249 SCPI Command Select System\Admin\Update Not available Check the Must log in as admin box. This requires a user to log into the Admin menu before the firmware update utility performs a firmware update. Keysight N69100 Series Operating and Service Guide...
Page 250 If the instrument is no longer functioning and you are unable to use the sanitization procedure described above, you must physically remove the P600 board from the instrument and destroy it. Refer to Disassembly. Keysight N69100 Series Operating and Service Guide...
Page 251 The admin/calibration password is reset to 0 when the instrument is first powered on. Use this setting if you have forgotten the password. Inhibit Calibration All calibration commands are disabled. This is useful where access is guarded by instru- ment seals. Keysight N69100 Series Operating and Service Guide...
Page 252 2. Remove the Control board as described under Disassembly. 3. The battery is located on the Constellation board under the ribbon cable. 4. To access the battery, release the ribbon cables by pulling up on the locking tab. Keysight N69100 Series Operating and Service Guide...
Page 253 8. Replace the Control board and top cover when finished. When reassembling, torque all screws to 9 in-lbs. 9. Reset the date and time (see Clock Setup). Keysight N69100 Series Operating and Service Guide...
Page 254 2. Remove the 7 flat-head screws located on the top, the 10 flat-head screws along the sides, and the 3 pan-head screws on the back (see figure below). Place the screws in a container so that you do not lose them. 3. Remove the instrument cover. Keysight N69100 Series Operating and Service Guide...
Page 255 Constellation board assembly. 1. Remove the three screws along the side of the chassis that attach the Constellation board. Place the screws in a container so that you do not lose them. Keysight N69100 Series Operating and Service Guide...
Page 256 3. To access the P600 board, use a T8 Torx driver to remove the four heatsink screws. You can now remove the P600 board from its socket. Remove 4 heatsink screws to remove the P600 board 4. When reassembling, torque all screws to 9 in-lbs. Keysight N69100 Series Operating and Service Guide...
Page 257 CLS 170, 217 sharing 101 AC mains Command sinking 107 considerations 57 quick reference 24 CURRent Subsyetem 159 Accessories 32 separators 148 Air flow 55 subsystems 152 DC offset 86 Amp-hour terminators 148 Keysight N69100 Series Operating and Service Guide...
Page 258 Inductive load Message Available 173 ESR? 170 boundary 41 Models 32 INITiate Subsystem 175 Factory reset 172, 213 Inspect 54 Non-volatile settings 215 Features 16 Instrument identification 140 FETCh Subsystem 165 Instrument Sanitize 250 Keysight N69100 Series Operating and Service Guide...
Page 259 REFerence 24 protection 110 digital port 134 Regenerative Over-voltage 85 priority 96 operation 17, 57, 107 protection 110 protection 108 Remote interface 87 resistance 98 Repackaging for slew rate 97 shipment 246 transients 113 Keysight N69100 Series Operating and Service Guide...
Page 260 DC Offset voltage 86 Test record forms 239 output current 84 Transient Voltage output voltage 83 Deviation 70 over-voltage 85 TRG 174 SOURce Subsyatem 191 Trigger Specificatons 33 diagram 212 SRE 173 tutorial 211 Stacking 56 Keysight N69100 Series Operating and Service Guide...
