DMX Protocol

3 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
4 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
6 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel 1 - Color presets
F Color presets
Control-channel 2 - White
F White (0=off, 255=100% white)
Control-channel 3 - Dimmer
F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 1 - Red
F Red (0=off, 255=100% red)
Control-channel 2 - Green
F Green (0=off, 255=100% green)
Control-channel 3 - Blue
F Blue (0=off, 255=100% blue)
Control-channel 4 - White
F White (0=off, 255=100% white)
Control-channel 1 - Red
F Red (0=off, 255=100% red)
Control-channel 2 - Green
F Green (0=off, 255=100% green)
39/44
