Page 1 PONTIAC 4 EONNEVILLE OWNER'S MANUAL...
Page 2: Table Of Contents
Pontiac Bonneville Introduction Part Part Part Part Part Part Part Part P a r t 9 Printed in USA This to Use & Seats Restraint Systems & Features Controls Comfort Controls Your Driving and the Road Problems on the Road &...
Page 3 Note to Canadian Owners For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Pontiac Division whenever it appears in this manual. For Canadian Owners Who Prefer a French Language Manual: Aux proprietaires canadiens: Vous pouvez vous procurer un exemplaire de ce guide en franGais chez votre concessionaire ou au DGN Marketing Services Ltd., 1500 Bonhill Rd., Mississauga, Ontario L5T 1C7.
Page 4: How To Use This Manual
Part 8: Customer Assistance Information This part tells you how to contact Pontiac for assistance and how to get service publications. It also gives you information on “Reporting Safety Defects” on page 269.
Page 5: Vehicle Damage Warnings
Safety Warnings and Symbols You will find a number of safety cautions in this book. We use a box with gray background and the word CAUTION to tell you about things that could hurt you i: you were to ignore the warning. [n the gray caution area, we tell you what the hazard is.
Page 6 Vehicle Symbols These are some of the symbols you may find on your vehicle. For example, These symbols these symbols are important are used on an for you and original battery: your passengers whenever your vehicle is CAUTION driven: POSSIBLE INJURY DOOR LOCK UNLOCK...
Page 7: Passling
Notes...
Page 8: Restraint Systems
H e r e YOU’II find information about the seats in your Pontiac and how to use your safety belts properly You can also learn about some things you should do with safety belts Seats ..........
Page 9: Seats And Restraint Systems
& Seats Restraint Systems Seats and Seat Controls This section tells you about the seats-how to adjust them-and also about reclining seatbacks and head restraints. Manual Front Seat Move the control lever under the front of the seat to unlock it. Slide the seat to where you want it.
Page 10 Adjustable Support Seat (OPTION) On some models, you’ll find the controls on the center console. Slide the selector switch to “L” or to choose the front “R’ seat you want to adjust. Adjusts the seat forward or back. Adjusts the seat up or down. ‘...
Page 11: Head Restraints
& Seats Restraint Systems Head Restraints Slide the head restraint up or down so that the top of the restraint is closest the top of your ears. This position reduces the chance of a neck injury in a crash. On some models, you can also adjust the head restraint by tilting the pad forward or rearward.
Page 12: Safety Belts: They're For Everyone
Safety Belts: They’re For Everyone This part of the manual tells you how to use safety belts properly. It also tells you some things you should not do with safety belts And it explains the Supplemental Inflatable Restraint, or “air bag” system. This figure lights up as a reminder to buckle up.
Page 13: Why Safety Belts Work
& Seats Restraint Systems Why Safety Belts Work When you ride in or on anything, you go as fast as goes. For example, if the bike is going 10 mph (16 km/h), so is the child. When the bike hits the block, stops.
Page 14 Get it up to speed. Then stop the vehicle. the simplest vehicle. Suppose it’s Take The rider doesn’t stop. seat on wheels. just a l 3 . ,...
Page 15 & Seats Restraint Systems Why Safety Belts Work (COrV7y The person keeps going until stopped by something. In a real vehicle, it could be the windshield 0.14 or the instrument panel or the safety belts! With safety belts, you slow down as the vehicle does.
Page 16: Here Are Questions Many People Ask About Safety Belts And The Answers
Here Are Questions Many People Ask About Safety Belts and the Answers Won’t I be trapped in the vehicle after an accident if I’m wearing a safety belt? You could be whether you’re wearing a safety belt not. But you can easily unbuckle a safety belt, even if you’re upside down.
Page 17: Driver Position
And there are different rules for smaller children and babies. If a child will be riding in your Pontiac, see the section located later in this part called “Children.’’ Follow those rules for everyone’s protection.
Page 18 Pick up the latch plate and pull the belt across you. Don’t let it get twisted. 4. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure it is secure. If the belt isn’t long enough, see “Safety Belt Extender”...
Page 19 & Seats Restraint Systems Lap-Shoulder Belt (CONK) To move it up or down, squeeze the release handle. When you release the handle, try to move it down a little to make sure it has locked into position. You can move the adjuster up from a lower position by pushing the bottom of the release handle.
Page 20 What’s wrong with this? The belt is buckled in the wrong place. What’s wrong with this? The shoulder belt is worn under the worn arm, It should be over the shoulder at all times. Q: What’s wrong with this? The belt is twisted across the body.
Page 21: Supplemental Inflatable Restraint System (Air Bags)
Supplemental Inflatable Restraint System (Air Bags) This section explains the Supplemental Inflatable Restraint (SIR), or “air bag,” system. Your Pontiac has an air bag for both the driver and the right-front passenger.
Page 22 Here are the most important things to know:...
Page 23 & Seats Restraint Systems INFLATABLE RESTRAINT 9ir Bag Readiness Light ’here is an air bag readiness light on the xtrument panel, which shows INFLATABLE RESTRAINT”. The ystem checks for electrical malfunctions, nd the light tells you if there is a problem. ’ou will see this light flash for a few xonds when you turn your ignition to, Run”...
Page 24: Part
impacts where the inflation would provide no occupant protection benefit. It is possible that in a crash, only one of the two air bags in your Bonneville will deploy. This is rare, but can happen in a crash just severe enough to make an air bag inflate.
Page 25: Part
Servicing Your Air Bag-Equipped Pontiac Air bags affect how your Pontiac should be serviced. There are parts of the air bag system in several places around xour vehicle. You don’t want the system to inflate while someone is working on your vehicle.
Page 26: Part
The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it’s more likely that the fetus won’t be hurt in a crash. For pregnant women, as for anyone, the key to making safety belts effective is wearing them properly.
Page 27: Part
& Seats Restraint Certter Passenger Position (CONK) When you sit a center seating position, you have a lap safety belt, which has no retractor. To make the belt longer, tilt the latch plate and pull along the belt. Systems T o make the belt shorter, pull its free end 1 s shown until the belt is snug.
Page 29: Part
& Seats Restraint Systems The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you'd be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen.
Page 30: Smaller Children And Babies
Children Everyone in a vehicle needs protection! That includes infants and all children smaller than adult size. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.
Page 31: Where To Put The Restraint
& Seats Restraint Systems Smaller Children and Babies (CONT) ChiZd Restraints Be sure to follow the instructions.for the restraint. You may find these instructions on the restraint itself or in a booklet, or both. These restraints use the belt system in your vehicle, but the child also has to be secured within the restraint to help reduce the chance of personal injury.
Page 32: Top Strap
If your child restraint has a top strap, it should be anchored. If you need to have an anchor installed, you can ask your Pontiac dealer to put it in for you. If you want to install an anchor yourself, your dealer can tell you how to do it.
Page 33 & Seats Restraint Systems Securing a Child Restraint in a Rear Outside Position You’ll be using the lap-shoulder belt. See the earlier section about the top sfrap if the child restraint has one. 1. Put the restraint on the seat. Follow the instructions for the child restraint.
Page 34: Securing A Child Restraint In A Center Seat Position
6. To tighten the belt, feed the lap belt into the retractor while you push down on the child restraint. Push and pull the child restraint in different directions to be sure it is secure. To remove the child restraint, just unbuckle the vehicle’s safety belt and let go back all the way.
Page 35 & Seats Restraint Systems Securing a Child Restraint in a Center Seat Position (CONT.) See the earlier section about the top strap if the child restraint has one. 1. Make the belt as long as possible by tilting the latch plate and pulling it along the belt.
Page 36 7. Push and pull the child restraint in different directions to be sure it is secure. If the child restraint isn’t secure, turn the latch plate over and buckle it again. Then see if it is secure. If it isn’t, secure the restraint in a different place in the vehicle and contact the child restraint maker for their advice about how to attach the...
Page 37 & Seats Restraint Systems Securing a Child Restraint in the Right Front Seat (CONT.) You’ll be using the lap-shoulder belt. See the earlier section about the top strap if the child restraint has one. 1. Because your vehicle has a right-front passenger’s air bag, always move the seat as far back as it will go before securing a front-facing child restraint.
Page 38: Larger Children
7. To tighten the belt, feed the lap belt back into the retractor while you push down on the child restraint. ’ 8. Push and pull the child restraint in different directions to be sure it is secure. To remove the child restraint, just unbuckle the vehicle’s safety belt and let it go back all the way.
Page 39 & Seats Restraint Systems Larger Children (CONK) Children who aren’t buckled up can strike other people who are. What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? Move the child toward the center of the vehicle, but sure that the...
Page 40: Safety Belt Extender
Wherever the child sits, the lap portion of the belt should be worn low and snug on the hips, just touching the child’s thighs. This applies belt force to the child’s pelvic bones in a crash. Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it.
Page 41 & Restraint Systems Seats What’s wrong with this? The belt is torn. Torn or frayed belts may not protect you in a crash. They can rip apart under impact forces. If a belt is torn or frayed, get a new one right away. .
Page 42 Part...
Page 43: Features And Controls
If your ignition keys don’t have plugs or the tag, go to your Pontiac dealer for the correct key code if you need a new ignition key. There are 15 alternative PASS-Key@ blanks, to help discourage theft.
Page 44: Door Locks
Door Locks There are several ways to lock and unlock your vehicle. From the Outside: Use your door key or Remote Keyless Entry, if your vehicle has this option. If you have the Theft Deterrent System, you will also unlock and lock all doors when you unlock or lock either front door with your key if the ignition is off.
Page 45: Controls
“Universal Theft Deterrent” later in this section. ..a44 Remote Keyless Entry (OPTION) If your Pontiac has this option, you can lock and unlock your doors or unlock your trunk from up to 30 feet m) away using the key chain transmitter supplied with your vehicle.
Page 46: Matching Transmitter(S) To Your Vehicle
this time. All doors, including the fuel filler door, will lock when “LOCK” is pressed. The trunk will unlock when the opened trunk symbol is pressed, but only when the ignition is off. Press any button to illuminate the interior lights (see “Illuminated Entry System’’...
Page 47: Rear Door Security Locks
& Features Controls Rear Door Security Locks Your Pontiac is equipped with rear door security locks that help prevent passengers from opening the rear doors of your car from the inside. To use one of these locks: 1. Move the lever all the way up to the “ENGAGED”...
Page 48: Parking At Night
When you park your Pontiac and open the driver’s door, you’ll hear a tone reminding you to remove your key from the ignition and take it with you. Always do this.
Page 49 & Features Controls Your vehicle is equipped with the PASS-Key’II (Personalized Automotive Security System) theft deterrent system. PASS-Key’II is a passive theft deterrent system. This means you don’t have to do anything different to arm or disarm the system. It works when you insert or remove the key from the ignition.
Page 50: Universal Theft Deterrent
Roadside Assistance Program at 1-800-ROADSIDE, or 1-800-762-3743. Universal Theft Deterrent -(OPTION) If your Pontiac has this option, it has a theft deterrent alarm system. With this system, the “SECURITY” light will flash as you open the door (if your ignition is off).
Page 51: Trunk Lock
& Features Controls Universal Theft Deterrent ( o m o N ) (CONI) To Stop the Alarm: If you set off the alarm by accident, unlock any door with your key. You can also turn off the alarm by pressing the “UNLOCK”...
Page 52: Remote Trunk Release
Remote Trunk Release (OPTION) Press the trunk release button located below the driver’s door armrest to release the trunk lid. The ignition may be on or off and the transaxle must be in “P” (Park). The system also works with the Remote Keyless Entry System.
Page 53: Glove Box
There’s a special shelf inside for storing this manual. New Vehicle “Break-In” NOTICE: Your modern Pontiac doesn’t need an elaborate “break-in.” But will perform better in the long run if you follow these guidelines: Don’t drive at any one...
Page 54: Starting Your Engine
To restart when you’re already loving, use “N” (Neutral) only. NOTICE: Don’t try to shift to “P” (Park) if your Pontiac is moving. If you do, you could damage the transaxle. Shift to “P” (Park) only when your vehicle is stopped.
Page 55: Driving Through Deep Standing Water
If you ever have to have your vehicle towed, see the part of this manual that tells how to do it without damaging your vehicle. See “Towing Your Pontiac” in the Index. Driving Through Deep Standing Water NOTICE:...
Page 56: Engine Coolant Heater (Engine Block Heater)
Instead of trying to list everything here, we ask that you contact a Pontiac dealer in the area where you'll be parking your vehicle. The dealer can give you the best advice for that particular area.
Page 57: Shifting The Automatic Transaxle
& Features Controls Shifting the Automatic Transaxle Your automatic transaxle may have a shift lever located on the console between the seats or on the steering column. Both are shown in this section. There are several different positions for your shift lever. In this manual, these are referred to by the commonly used symbols in the right column below: Park...
Page 58 Ensure the shift lever is fully in “P” (Park) range before starting the engine. Your Pontiac has a brake-transaxle shift interlock. You have to fully apply your regular brakes before you can shift from (Park) when the ignition key is in the “P,’...
Page 59 & Features Controls Reverse (CONT.) To rock your vehicle back and forth to get out of snow, ice or sand without damaging your transaxle, see “If You’re Stuck: In Sand, Mud, Ice or Snow” in the Index. Neutral N (Neutral): In this position, your engine doesn’t connect with the wheels.
Page 60: Forward Gears
NOTICE: Damage to your transaxle caused by shifting out of “P” (Park) or “N” (Neutral) with the engine racing isn’t covered by your warranty. Forward Gears Automatic Overdrive: This position for normal driving. If you need more power for passing, and you’re: Going less than about 35 mph (56 km/h), push your accelerator pedal about halfway down.
Page 61 & Features Controls Forward Gears (CONT) D (Third Gear): , but you This is like never go into Overdrive. Here are some times you might choose “D’ instead of When driving on hilly, winding roads When towing a trailer, so there is less shifting between gears When going down a steep hill 2 (Second Gear): This position gives you...
Page 62: Parking Brake
Computer Command Ride (OPTION SSEBSEi) Vehicles equipped with Computer Command Ride provide improved passenger ride comfort under a variety of road and driving conditions. For normal driving conditions, press the “TOURING RIDE” button to get a more refined comfortable ride. When driving conditions require improved handling, press the “PERFORM RIDE”...
Page 63: Steering Column Shift Lever
& Features Controls Parking Brake (CONT.) To Release the Parking Brake: This vehicle has a “push to release” park brake pedal. Hold the regular brake pedal down with your right foot and push the park brake pedal with your left foot. This will unlock the pedal.
Page 64: Console Shift Lever
Move the shift lever into (Park) “P,’ position like this: Pull the lever toward you. Move the lever up as far as it will go. Move the ignition key to “LOCK” 4. Remove the key and take with you. If you can walk away from your vehicle with the ignition key in your hand, your vehicle is in “P”...
Page 65: Leaving Your Vehicle With The Engine Running
(Park). “P’ Shifting o f “P” (Park) Your Pontiac has a brake-transaxle shift interlock. You have to fully a & your regular brakes before you can shift from “P” (Park) when the ignition is in the “On”...
Page 66: Parking Over Things That Burn
1. Turn the key to “Off”. Open and close the driver’s door to turn off the Retained Accessory Power Feature. 2. Apply and hold the brake until the end of Step 4. Shift to “N” (Neutral). 4. Start the vehicle and then shift to the drive gear you want.
Page 67 & Features Controls Engine Exhaust (CONT.) - . . 6 6 Running Your Engine While You’re Parked It’s better not to park with the engine running. But if you ever have to, here are some things to know. Follow the proper steps to be sure your vehicle won’t move.
Page 68: Tilt Wheel
Horn You can sound the horn by pressing the horn symbols on your steering wheel. Tilt Wheel tilt steering wheel allows you to adjust he steering wheel before you drive. Ir' o u can also raise it to the highest level tc give your legs more room when you exit tnd enter the vehicle.
Page 69: Turn Signal And Lane Change Indicator
& Features Controls Turn Signall Multifunction Lever The lever on the left side of the steering column includes your: Turn Signal and Lane Change Indicator Windshield Wipers Windshield Washer Headlight Washers (SSE and SSEi only) Cruise Control (Option) Headlight High-Low Beam Turn Signal and Lane Change Indicator The turn signal has two upward (for...
Page 70: Windshield Wipers
If a, bulb is burned out, replace it to help avoid an accident. If the green arrows don’t go on at all when you signal a turn, check the fuse (see “Fuses & Circuit Breakers” in the Index) and for burned-out bulbs.
Page 71: Windshield Washer
& Features Controls Windshield Wipers (CONT) Heavy snow or ice can overload your wiper motor. A circuit breaker will stop the motor until it cools. Clear away snow or ice to prevent an overload. Keep in mind that damaged wiper blades may prevent you from seeing well enough to drive safely.
Page 72 NOTICE: When using concentrated washer fluid, follow the manufacturer’s instructions for adding water. Don’t mix water with ready-to-use washer fluid. Water can cause the solution to freeze and damage your washer fluid tank and other parts of the washer system. Also, water doesn’t clean as well as washer fluid.
Page 73: Cruise Control (Option)
& Features Controls Cruise Control (OPTION) (CONK) When you apply your brakes, the Cruise Control shuts off. To Set Cruise Control 1. Move the Cruise Control switch to “ON”. 2. Get up to the speed you want. Push in the “SE.T” button at the end of the lever and release it.
Page 74 To Resume a Set Speed Suppose you set your Cruise Control at a desired speed and then you apply the brake. This, of course, shuts off the Cruise Control. But you don’t need to reset it. Once you’re going about 25 mph (40 km/h) or more, can move the Cruise Control switch from “ON”...
Page 75: Light Controls
& Features Controls Passing Another Vehicle While Using Cruise Control Use the accelerator pedal to increase your speed. When you take your foot off the pedal, your vehicle will slow down cruise control speed you set earlier. Using Cruise Control on Hills How well your Cruise Control will work on hills depends upon your speed, load,...
Page 76: Operation Of Lights
Taillights Instrument Panel Lights Push the switch in all the way to turn all the lights off. Operation of Lights Although your vehicle’s lighting system (headlights, parking lights, fog lamps, side marker lights and taillights) meets all applicable federal lighting requirements, certain states and provinces may apply their own lighting regulations that may require special attention before you...
Page 77: Headlight High-Low Beam Changer
& Features Controls Headlight High-Low Beam Changer change the headlights from low beam to high or high low, pull the turn signal lever all the way toward you. Then release it. When the high beams are on, this blue also light on the instrument panel will be on.
Page 78: Fog Lights
The Twilight Sentinel Does Two Things: First, depending on how dark it becomes outside, the Twilight Sentinel turns your headlights on automatically, when they’re needed. Avoid covering the sensor located near the windshield, by the defroster outlet-otherwise your headlights will stay on.
Page 79: Rear Reading Lights
Features Controls Rear Reading Lights These overhead lights and the interior courtesy lights will come on when you open the doors. To turn on the reading light when the door is closed, slide the switch up. Slide it down to turn off the light. Inside Manual DaylNight Rearview Mirror...
Page 80: Power Remote Control Mirrors
keep the photocells operating well, occasionally clean them with a cotton swab and glass cleaner. Manual Remote Control Mirror The outside rearview mirror should be adjusted so you can just see the side of your vehicle when you are sitting in a comfortable driving position.
Page 81: Card Holder
& Features Controls Card Holder The front doors on some vehicles have a card holder for convenient storage of business cards or parking lot ticket stubs. The card holder has space for up to five regular business cards. Sun Visors To block out glare, you can swing down the visors.
Page 82 Express Open Sunroof (OPTION) Your express open sunroof provides an airy, spacious feel to your vehicle’s interior and can also increase ventilation. It includes a sliding glass panel and a sliding sunshade. The control switch will work only when the ignition is on or during Retained Accessory Power, if you have that option.
Page 83: Storage Armrest
& Features Controls Storage Armrest (OPTION) Console Shift Models: Press the button at the front edge to open the armrest storage area for cassette tapes, gloves, etc. A cup holder flips forward for use. There’s also a bin for storage underneath the armrest storage area.
Page 84: Rear Storage Compartment
Rear Storage Compartment Lift the rear of the armrest to reveal the storage space. Pull down the interior door to access the trunk for storing long objects. Ashtrays Lift the cover to reveal the front ashtray. To clean the ashtray, lift it out by pulling on the snuffer.
Page 85 Features Controls Ashtrays (CONT.) On models without a console, there’s an ashtray/cup holder under the instrument panel. To clean the ashtray, lift it out by pulling up on the tabs on either side. It snaps back into place. To open the rear ashtrays, lift the cover. NOTICE: Don’t put papers and other things that burn into your ashtrays.
Page 86: Sunglasses Storage
NOTICE: Don’t hold a cigarette lighter in with your hand while it is heating. If you won’t be able to back away from the heating element when it’s ready. That can make it overheat, damaging the lighter and the heating element.
Page 87 & Features Controls...
Page 88: The Instrument Panel-Your Information System
The Instrument Panel-Your Information System Your instrument panel is designed to let you know at a glance how your vehicle is running. You’ll know how fast you’re going, how much fuel you’re using, and many other things you’ll need to drive safely and economically;...
Page 89 Instrument Panel Clusters Your Pontiac is equipped with one of these instrument panel clusters, which includes indicator warning lights and gages that are explained on the following pages. Be sure to read about those that apply to the instrument panel cluster for your vehicle.
Page 90 8 9 . . .
Page 91: Speedometer And Odometer
Driver Information Center on vehicles so equipped. Tamper Resistant Odometer Your Pontiac has a tamper resistant odometer. If you see silver lines between the numbers, you’ll know that someone has probably tried to turn it back, so the numbers may not be true.
Page 92: Warning Lights, Gages And Indicators
Information System that works along with the warning lights and gages. See “Driver Information System” in the Index. Warning Lights Your Pontiac has some of the warning light systems shown here. The symbols are explained on the following pages. SYSTEMS...
Page 93: Engine Coolant Temperature Warning Light
& Features Controls SYSTEMS MONITOR (-J[=zFz] [HeURlTY][-)) Warning Lights (CONT.) # . . 9 2 I - ] DRIVER INFORMATION LAMP CHECK OIL LEVEL WASHER FLUID LOW COOLANT CHECK QAQES m o o DOOR AJAR TRUNK TURN SIONAL BACK U P TAIL BRAKE LAMP MILES TRIP...
Page 94: Low Coolant Warning Light
HOT COOLANT CAN BURN YOU BADLY! In “Problems on the Road”, this manual shows what to do. See “Engine Overheating” in the Index. Some clusters with gages do not have a coolant temperature warning light. In those clusters a “CHECK GAGES” warning light will alert you of a potential coolant heating problem.
Page 95 Features Controls i - ) XI Warning Light ’ you have a problem with your oil, this ght may stay on after you start your ngine, or come on when you are driving. ‘his may indicate that oil is not going lrough your engine quickly enough to eep it cool.
Page 96 CHECK LEVEL :heck Oil Level Warning Light (OPTION) ’his light indicates when the engine oil :vel is 1 to 1 1/2 quarts (0.95 L to 1.4 L) 3w. The light will go on for one to three econds when the ignition is turned to the Run”...
Page 97: Battery Warning Light
& Features Controls Battery Warning Light (CONT.) If you must drive a short distance with the light on, be certain to turn off all your accessories, such as the radio and climate control system. Some clusters with gages do not have a battery warning light.
Page 99: Anti-Lock Brake System Warning Light
Then start the engine again to reset the system. If the light still stays on, or comes on again while you’re driving, your Pontiac needs service. If the regular brake system warning light isn’t on, you still have brakes, but you don’t have anti-lock brakes.
Page 100 Gages Your Pontiac may have many of the following gages. Be sure to read about the mes that came with your vehicle. 9 9 0 . .
Page 101 & Features Controls CHECK GAGES >heck Gages Warning Jght (OPTION) ‘his light will come on briefly when you re starting the engine. If the light comes n and stays on while you are driving, heck your gages for fuel, coolant :mperature, oil pressure or voltage.
Page 102: Engine Coolant Temperature Gage
H 2 a Engine Coolant Temperature Gage This gage shows the engine coolant temperature. If the gage pointer moves into the red area, your engine is too hot! The “CHECK GAGES” light will go on and a warning chime will sound, if you have this option.
Page 103 & Features Controls Oi/ Pressure Gage (OPTION) (CONK) Driving your vehicle with low oil pressure can cause extensive engine damage. NOTICE: Damage to your engine from neglected oil problems can be costly and is not covered by your warranty..Voltmeter (omoN) Vhen the engine is running, the gage hows the condition of the charging...
Page 105: Driver Information Center
& Features Controls Driver Information Center (CONI) Brake Lamp and Center High Mounted Back-up Lamp Tail Lamp/Turn/Side MarkerLicense If a bulb is out, you will see a message, such as “PARK LAMP’, and you will also see where the problem is on the vehicle outline.
Page 106 SECURITY You’ll get a “DOOR AJAR’ message if a door is not fully dosed. The vehicle outline will show you which door it is. You will also get a “HOOD AJAR” or “TRUNK AJAR” message if the hood or the trunk isn’t fully closed.
Page 107: Electronic Compass
& Features Controls Electronic Compass (CONI) CHOOSING YOUR ZONE NUMBER Locate your zone number on the map above. If your number is different than the one shown when you turn the key on, follow the steps under “Changing Your Zone Number”. If you live on the line, you can pick the zone area you are most likely to drive (In Alaska use Zone 9 or IO.
Page 108: Head-Up Display
[MODE) Release the “MODE” button. The heading display will start to rotate. 4. Drive the car in small circles. Don’t drive faster than 10 mph. 5. Drive in circles until the “CALIBRATE’ light goes out. It usually takes I to 5 circles. 6.
Page 109 & Features Controls Head-Up Display (OPTION) (CONI) When you sit straight in your seat, the HUD image will appear directly in front of the driver. When the ignition key is turned to “Run”, all possible HUD images will come on and look like this.
Page 110 Slide the “ADJUST” (image height) control all the way up, raising the image as far as possible. Then slide the HUD image height control down so the image is as low as possible but in full view. 4. Slide the dimmer control downward until the HUD image is no brighter than necessary.
Page 111 & Features Controls Care of the Head-Up Display (CONT.) If You Can’t See the HUD Image When the Ignition is On: Are the headlights on? Is anything covering the HUD unit? Is the HUD dimmer control far enough up? Is the HUD image adjusted to the proper height? Still no HUD image? Check the fuse in the fuse panel.
Page 112 I n this part you’ll find out how to operate the comfort control systems and audio systems offered with your Pontiac Be sure to read about the Radio particular system supplied with your ..........
Page 113: Comfort Controls
Comfort Controls Standard Climate Control The air conditioner and heater work best if you keep your windows closed while using them. Selects the force of air you want. The fan is always running unless the mode control is moved to “OFF”. Temperature Control: The center control regulates the temperature of the air coming through the system.
Page 114 Non-Air Conditioning Settings (Vent): This setting brings in the outside air and directs it to the upper portion of your body through the instrument panel outlets. ’N (Heat): This setting directs warmed air through the heater ducts. Some warm air is diverted to the windshield to minimize fogging.
Page 115: Rear Window Defogger
Comfort Controls Defogging Windows With Standard Climate Control (CONT.) To defog the side windows, move the mode control to and the fan control F f l to “HIGH”. Aim the side vents toward the side windows. For increased air flow to the side vents.
Page 117: Comfort Controls & Audio Systems
Comfort Controls & Audio Systems Electronic Climate Control (OPTION) When the engine is cold, the “AUTO’ blower is delayed/reduced until warm air is available. Immediately selecting 90°F farenheit will NOT get the car warmer any sooner than selecting 75 “AUTO”. The “DEFROST” blower speed starts low to reduce windshield fogging from any snow on the hood as you start driving.
Page 118 not be able to if it’s very warm or cold outside. ECON: Use in cold or cool weather. This saves fuel because the air conditioner compressor doesn’t run. But this setting doesn’t remove humidity from the air. (Defrost): Press this to remove fog or ice from the windshield.
Page 119 & Audio Systems Flow-Through Ventilation System Your Pontiac's flow-through ventilation system supplies outside air into the vehicle when it is moving. Outside air will also enter the vehicle when the heate or the air conditioning fan is running.
Page 120 This helps air to circulate throughout your vehicle. r-,ldio Systems The following pages describe the audio systems available for your Pontiac, and how to get the best performance from them. Please read about the system in your vehicle.
Page 121: Setting The Clock
Comfort Controls Audio Systems (CONT.) NOTICE: c ’ Before you add any sound equipment to your vehicle like a tape player, CB radio, mobile telephone or two-way radio sure you can add what you want. If you can, it’s very important to do properly.
Page 122: Am/Fm Stereo Radio
AM/FM Stereo Radio The digital display indicates information on time or radio station frequency, the “AM” or “FM” radio band, whether the station is in stereo, and other functions. Upper Knob (PWR/VOLUME) This knob does three things: Rotate to turn the system on and off. Rotate to control the volume.
Page 123 Comfort Controls - - . & Audio Systems AM/FM Stereo Radios With Optional Features Your Pontiac may have an AM/FM radio equipped with a combination of optional features: Graphic equalizer. Cassette tape player. Compact disc player. THEFTLOCK@.
Page 124 The standard features on these radios operate identically. This section explains the standard features first, followed by an explanation of each optional feature. 1 2 3 . . .
Page 125 Comfort Controls AM/FM Stereo Radios With Optional Features (CONT.) Digital Display: Indicates information on time or radio frequency, the “AM” or “FM” radio band, whether the station is in stereo, and other radio functions. POWER: With the ignition on, push the “POWER”...
Page 126 Equalizer: Boost the bass, emphasize a voice song, brighten the treble your equalizer gives you the freedom to adjust seven separate frequencies of sound to your individual taste. Move a lever up to emphasize a frequency, move down to de-emphasize. Start the levers in the with middle position, then adjust each lever as...
Page 127 Comfort Controls & Audio Systems AM/FM Stereo Radios With Optional Features: (CONE) ’’A NEXT Press “NEXT” or “SEEK search for the next selection on the tape. There must be a gap of at least four seconds between selections on the tape in order for the tape player to stop.
Page 128 If “ERR” (Error) appears in the display and the disc ejects, the disc cannot play temporarily. Check to see i f The disc is upside down. The disc is dirty, scratched or wet. There may be too much moisture in the air (wait about one hour and try again).
Page 129 Comfort Controls AM/FM Stereo Radios with Optional Features: (CONT) FWD (Forward): Press and hold “FWD” to rapidly advance the disc. The radio display will show the time into the track during fast forward operation. EJECT Press “EJECT” to remove the disc.
Page 130 4. Press the “4” buttons together. “1” and Hold them down until shows on “---” the display. Next you will use the secret code number which you have written down. Press the “MIN” button and “000” will appear on the display. 6.
Page 131 Comfort Controls & Audio Systems Radio THEFTLOCK8 Feature (CONI) Press “AMEM” and this time the display will show “SEC”, indicating that your radio is secure, The “THEFTLOCKO” indicator light located below the “TUNE” knob will flash when the ignition is off. .
Page 132 “InOP’ (inoperative). If you forget your code or cannot unlock the radio, contact your Pontiac dealer for assistance. To disable THEFTLOCKO, you simply follow these steps: 1. Turn the ignition to the “Accessory”...
Page 133: Gain Control
Comfort Controls & Audio Systems Steering Wheel Controls for Audio System (CONK) SEEK: Press to seek and stop on the next station higher or lower on the radio band. When listening to a cassette tape or compact disc, you can change to the previous or next selection by pressing the “SEEK”...
Page 134: Understanding Radio Reception
Insert the cassette at least 3 times to ensure thorough cleaning. A scrubbing action cleaning cassette is available through your Pontiac dealership. You may also choose a non-scrubbing action, wet-type cleaner which uses a cassette with a fabric belt to clean the tape head.
Page 135: Care Of Your Compact Discs
Comfort Controls Cassettes are subject to wear and the sound quality may degrade over time. Always verify that the cassette tape is in good condition before obtaining service on your tape player. Please note that cassette tape adapter kits for portable CD players will not work in your cassette player.
Page 136: Power Antenna Mast Care
Power Antenna Mast Care Your power antenna will look its best and work well if it’s cleaned from time to time. To Clean the Antenna Mast: 1. Turn on the ignition and radio to raise the antenna to full mast extension. 2.
Page 137 Notes...
Page 138: Your Driving And The Road
Your ....Defensive Driving DrunkenDriving 'Control of a Vehicle Bmking Anti-LackBrakes SteeringTips Steering in Emergencies Passling DrivingatNight I)rivin>g in the Rain ............City Driving .
Page 139: Defensive Driving
The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your Pontiac: Buckle up. (See “Safety Belts’’ in the Index.) Defensive driving really means “be ready for anything.” On city streets, rural roads, or freeways, means “always expect the...
Page 140 According to the American Medical Association, a 180-pound (82 kg) person who drinks three 12-ounce (355 ml) bottles of beer in an hour will end up witk a BAC of about 0.06 percent. The person would reach the same BAC by drinking three 4-ounce 120 ml) glasses of wine or three mixed drinks if each had 1-1/2...
Page 141 Driving the Road Your Drunken Driving (CONT.) But it’s very important to keep in mind that the ability to drive is affected well below a BAC of 0.10 percent. Research shows that the driving skills of many people are impaired at a BAC approaching 0.05 percent, and that the effects are worse at night.
Page 142: Control Of A Vehicle
You have three systems that make your vehicle go where you want it to go. They are the brakes, the steering and the accelerator. All three systems have to do their work at the places where the tires meet the road. Sometimes, as when you’re driving on snow o r ice, it’s easy to ask more of those control systems than the tires and road...
Page 143: Anti-Lackbrakes
Driving and the Road Your Anti-Lock Brakes (ABS) Your Pontiac has an advanced electronic braking system that will help prevent skidding. ANTILOCK This light on the instrument panel will go on when you start your vehicle. When you start your vehicle and begin to drive away, you may hear a momentary motor or clicking noise.
Page 144: Traction Control System
You can steer around the obstacle while braking hard. As you brake, your computer keeps receiving updates on wheel speed and controls braking pressure accordingly. Remember: Anti-lock doesn‘t change the time you need to get your foot up to the brake pedal.
Page 145: Braking In Emergencies
Your Driving and the Road Traction Control System (OPTION) (CONI) snow. See “Rocking Your Vehicle” in the Index.) To turn the system off, press the “TRACTION CONTROL” button. The “TRACTION OFF” warning light will come on and stay on. If the system is limiting wheel spin when you press the button, the system won’t turn off right away.
Page 146: Steering In Emergencies
But sometimes you can’t; there isn’t room. That’s the time for evasive action steering around the problem. Your Pontiac can perform very well in emergencies like these. First apply your brakes. It is better to remove as much speed as you can from a possible collision.
Page 147: Off-Road Recovery
Your Driving and the Road Off-Road Recovery You may find sometime that your right wheels have dropped off the edge of a road onto the shoulder while you’re driving. If the level of the shoulder is only slight1 below the pavement, recovery should be fairly easy.
Page 148: Loss Of Control
“overdriving” those conditions. But skids are always possible. The three types of skids correspond to your Pontiac’s three control systems. In the braking skid your wheels aren’t rolling. In the steering or cornering skid, too much speed or steering in a curve causes tires to slip and lose cornering force.
Page 149: Drivingatnight
Your Driving and the Road Skidding (CONI) Of course, traction is reduced when water, snow, ice, gravel, or other material is on the road. For safety, you’ll want to slow down and adjust your driving to these conditions. It is important to slow down on slippery surfaces because stopping distance will be longer and vehicle control more limited.
Page 150: I)Rivin>G In The Rain
You can be temporarily blinded by approaching lights. It can take a second or two, or even several seconds, for your eyes to readjust to the dark. When you are from faced with severe glare (as a driver who doesn’t lower the high beams, or a vehicle with misaimed headlights), slow down a little.
Page 151: Some Other Rainy Weather Tips
Your Driving and the Road Driving in the Rain (CONX) Driving too fast through large water puddles or even going through some car washes can cause problems, too. The water may affect your brakes. Try to avoid puddles. But if you can’t, try to slow down before you hit them.
Page 152: City Driving
city Driving One of the biggest problems with city streets is the amount of traffic on them. You’ll want to watch out for what the other drivers are doing and pay attention to traffic signals. Here are ways to increase your safety in city driving: Know the best way to get to where you are going.
Page 153: Before Leaving On A Long Trip
If it needs service, have it done before starting out. Of course, you’ll find experienced and able service experts in Pontiac dealerships all across North America. They’ll be ready and willing to help if you need it.
Page 155: Hillandmountainroads
Driving and the Road Your Hill and Mountain Roads (CONK) Know how to go down hills. The most important thing to know is this: let your engine do some of the slowing down. Shift to a lower gear when you go down a steep or long hill.
Page 156: Driving On Snow Or Ice
Have your Pontiac in good shape for winter. Be sure your engine coolant mix is correct. You may want to put winter emergency supplies in your trunk. Include an ice scraper, a small brush or broom, a supply of windshield washer...
Page 157: If You're Caught In A Blizzard
Your Driving and the Road Driving on Snow or Ice (CONT.) What’s the worst time for this? “Wet ice.” Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all.
Page 158 Put on extra clothing or wrap a blanket around you. If you have no blankets or extra clothing, make body insulators from newspapers, burlap bags, rags, floor mats anything you can wrap around yourself or tuck under your clothing to keep warm. You can run the engine to keep warm, but be careful.
Page 159: If You're Stuck In Deep Snow
Pontiac dealer for important information about towing a trailer with your vehicle. Your Pontiac can tow a trailer if it is equipped with proper trailer towing equipment. To identify what the vehicle trailering capacity is for your vehicle, you should read the information in “Weight of...
Page 160: If You Do Decide To Pull A Trailer
You can ask your dealer for our trailering information or advice, or you can write us at: Customer Assistance Center Pontiac Division One Pontiac Plaza Pontiac, MI 48340-2952 In Canada, write to: General Motors of Canada Limited, Customer Assistance Center...
Page 161: Weight Of The Trailer Tongue
Your Driving and the Road Weight of the Trailer Tongue The tongue load (A) of any trailer is an important weight to measure because it affects the total capacity weight of your vehicle. The capacity weight includes the curb weight of the vehicle, any cargo you may carry in it, and the people who will be riding in the vehicle.
Page 162: Safety Chains
The bumpers on yaur vehicfe are not intended for hitches. Do not attach rental hitches or other bumper-type hitches to them. Use only frame-mounted hitch that does not attach to the bumper. Safety Chains You should always attach chains- between your vehicle and your trailer.
Page 163 Your Driving and the Road Driving with a Trailer (CONT.) Following Distance Stay at least twice as far behind the vehicle ahead as you would when driving your vehicle without a trailer. This can help you avoid situations that require heavy braking and sudden turns.
Page 164: Maintenance When Trailer Towing
Parking on Hills You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to move. People can be injured, and both your vehicle and the trailer can be damaged.
Page 165 Notes 1 4 4...
Page 166 about H e r e you'^^ find what to some problems that can occur road ..........Hazard Warning Flashers .
Page 167: Problems On The Road
Problems on the Road Hazard Warning Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lights will flash on and off. ’ress the button in to make your front and ear turn signal lights flash on and off.
Page 168: Jump Starting
Jump Starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your Pontiac. But please follow the steps below to do it safely. NOTICE: Remember that ignoring these steps could result in costly damage to your vehicle that wouldn’t be...
Page 169 Problems on the Road To Jump Start Your Pontiac: (CONK) You could be injured if the vehicles roll. Set the parking brake firmly on each vehicle. Put an automatic transaxle in “P” (Park) or a manual transaxle in “N” (Neutral).
Page 170 Connect the red positive cable to the positive terminal of the vehicle with the dead battery. Use a remote positive terminal if the vehicle has one. There may be a red plastic cover over the positive cable end; remove it before attaching the jumper cable.
Page 171 Towing Your Pontiac Try to have a GM dealer or a professional towing service tow your Pontiac. The usual towing equipment is: (A) Sling-type tow truck (B) Wheel-lift (C) Car carrier...
Page 172 Before you do anything, turn on the hazard warning flashers. When you call, tell the towing service: That, if you have the SSE or SSEi model, your vehicle cannot be towed from the front with sling-type equipment. That your vehicle has front-wheel drive.
Page 173 (EXCEPT SSE & SSEi) Before hooking up to a tow truck, be sure to read all the information on “Towing Your Pontiac” earlier in this section. 1. Attach T-hook chains into the bottom slots in the cradle behind the front wheels, on both sides.
Page 174 (SSE & SSEi Only) Before hooking up to a tow truck, be sure to read all the information on “Towing Your Pontiac” earlier in this section. Attach T-hook chains into the slots just behind the front wheels on both sides.
Page 175 Problems on the Road Towing from the Front-Vehicle Hook-up (SSE & SSEi Only) (CONT.) Attach a separate safety chain around the outboard end of each control arm. NOTICE: Towing a vehicle over rough surfaces could damage a vehicle. Damage can occur from vehicle to ground or vehicle to wheel-lift equipment.
Page 176 Rear-Vehicle tiook=up (ALL) Before hooking up to a tow truck, be sure to read all the information on “Towing Your Pontiac” earlier in this section. Attach T-hook chains on both sides in the slotted holes in the floor pan support rails...
Page 177: If Steam Is Coming From Your Engine
Problems on the Road Engine Overheating You will find a coolant temperature gage or a warning light about a hot engine on your Pontiac’s instrument panel. See “Coolant Temperature Gage” and “Coolant Temperature Warning Light” in the Index. If Steam Is Coming From...
Page 178: If No Steam Is Coming From Your Engine
If No Steam Is Coming From Your Engine If you get the overheat warning but see or hear no steam, the problem may not be too serious. Sometimes the engine can get a little too hot when you: Climb a long hill on a hot day. Stop after high speed driving.
Page 179 Problems on the Ro,ad Cooling System (CONT.) If the coolant inside the coolant recovery tank is boiling, don’t do anything else until it cools down. The coolant level should be at or above the “FULL COLD’ mark. If it isn’t, you may have a leak in the radiator hoses, heater hoses, radiator, water pump or somewhere else in the cooling system.
Page 180 NOTICE: In cold weather, water can freeze and crack the engine, radiator, heater core and other parts. Use the recommended coolant. When the coolant in the coolant recovery tank is at or above the “FULL COLD’ mark, start your vehicle. If the overheat warning continues, there’s one more thing you can try.
Page 181: How To Add Coolant To The Radiator
Problems on the Road How to Add Coolant to the Radiator: 1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot. Turn the pressure cap slowly to the left until it first stops.
Page 182 4. Then fill the coolant recovery tank to the “FULL COLD” mark. 5. Put the cap back on the coolant recovery tank, but leave the radiator pressure cap off. 6. Start the engine and let it run until can feel the upper radiator hose getting hot.
Page 183: Air Inflator System
Problems on the Road How to Add Coolant to the Radiator: (CONT.) 8. Then replace the pressure cap. At any time during this procedure if coolant begins to flow out of the filler neck, reinstall the pressure cap. Be sure the arrows on the pressure cap line up like this.
Page 184: Changing A Flat Tire
Changing a Flat Tire If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on your hazard warning flashers. The following steps will tell you how to use the jack and change a tire. Please read all twenty steps in this section before beginning to change your tire(s).
Page 185 Road Problems on the Changing a Flat Tire (CONI) 1. Turn the center retainer bolt on the spare tire cover counterclockwise to remove it, then lift the tire cover. 2. Remove the spare tire from the trunk..Open the jack storage cover by twisting the knob turn...
Page 186 If you have steel wheels with full plastic wheel covers, loosen each nut cap using the wheel wrench. Note: Nut caps are captured in the cover and will not remove completely. If you have aluminum wheels with metal nut caps remove them. If you have aluminum wheels in which the center cover hides the wheel nuts, remove the center cover...
Page 187 Problems on the Road Changing a Flat Tire (CONT.) Attach the wheel wrench to the jack, and rotate the wrench clockwise to raise the jack head a few inches. 7. Near each wheel well is a notch in the frame into which to put the jack head. The front notch is 10 inches back fron the front wheel well.
Page 188 9. If your wheel has the special locking lug nut, use the special adapter supplied with your vehicle to remove the locking wheel nut by turning counterclockwise. 1O.Use the wheel wrench to loosen the wheel nuts, but don't remove them. .Raise the vehicle by rotating tbe wheel wrench clockwise on thejack shaft.
Page 189 Problems on the Road Changing Flat Tire (CONT.) NOTICE: Raising your vehicle with the jack inlproperly positioned will damage the vehicle or may allow the vehicle fdl off the jack. Be sure to fit the jack lift head into the proper location before raising your vehicle.
Page 190 15. Replace the wheel nuts with the rounded end of the nuts toward the wheel. Make sure each wheel stud is centered in each wheel hole while tightening the nuts. Tighten each nut by hand until the wheel is held flat against the hub.
Page 191 the Road Problems Changing a Flat Tire (CONT.) Don't try to put the wheel cover on the compact spare tire. It won't fit. Store the wheel cover in the trunk until you have replaced the compact spare tire with a regular tire.
Page 192: Compact Spare Tire
1 8 ~ . When re-installing the center cover, do not use a hammer or mallet, as they could damage the cover. 19. Store the flat tire as far forward in the trunk as possible. Store the jack and wheel wrench in their compartment in the trunk.
Page 193 If that doesn’t get you out after a few tries, you may need to be towed out. If you do need to be towed out, see “Towing Your Pontiac” in the Index.
Page 195: Appearance Care
Pontiac Service Manual. It tells you much more about how to service your Pontiac than this manual can. To order the proper service manual, see “Service Publications” in the Index. Your vehicle has an air bag system.
Page 196 Fuel The 8th digit of your Vehicle Identification Number (VIN) shows the code letter for your engine. You will find the VIN at the top left of your instrument panel. (See “Vehicle Identification Number” in the Index.) 3800 Engine (Code L): Use regular unleaded gasoline rated at 87 octane or higher.
Page 197: Gasolines For Cleaner Air
& Service Appearance Care MTBE is “methyl tertiary-butyl ether.” Fuel that is no more than 15% MTBE is fine for your vehicle. Ethanol is ethyl or grain alcohol. Properly-blended fuel that is no more than 10% ethanol is fine for your vehicle Methanol is methyl or wood alcohol.
Page 198: Filling Your Tank
You can also write us at the following address for advice. Just tell us where you’re going and give your Vehicle Identification Number (VIN). General Motors Overseas Distribution Corporation, North American Export Sales (NAES) 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7 Fuel Door Lock (omohf)
Page 199: Service And Appearance Care
Be careful not to spill gasoline. Clean gasoline from painted surfaces as soon as possible. See “Cleaning the Outside of Your Pontiac” in the Index. When you put the cap back on, turn it to the right until you hear at least three clicks.
Page 200: Checking Things Under The Hood
Checking Things Under the Hood The following sections tell you how to check fluids, lubricants and important parts under the hood. Hood Release To open the hood, first pull the hood release handle inside the vehicle. Then go to the front of the vehic1e':and pull up on the underhood release.
Page 201 & Appearance Care Service Before closing the hood, be sure all the filler caps are on properly. Then just pull the hood down and close firmly. Underhood Light Your parking lights or headlights must be on for the underhood light to function when you open the'hood..
Page 202 3800 Engine (CODE L) When you open the hood, you'll see: Engine Coolant Recovery Tank 2. Power Steering Fluid Reservoir Automatic Transaxle Fluid Dipstick 4. Brake Fluid Reservoir Windshield Washer Fluid Reservoir Air Cleaner 7. Engine Oil Dipstick Engine Oil Fill Cap Radiator Pressure Cap Battery ;...
Page 203 & Service Appearance Care 3800 SC Engine (CODE I ) When you open the hood, you’ll see: 1. Engine Coolant Recovery Tank 2. Automatic Transaxle Fluid Dipstick Power Steering Fluid Reservoir 4. Brake Fluid Reservoir 5. Windshield Washer Fluid Reservoir 6.
Page 204 ~~~~ Engine Accessory Belt The 3800 (L27) engine uses an engine accessory belt. This diagram shows the features connected by the belt routing. See “Maintenance Schedule’’ in the Index for when to check the belt. A. Power Steering B. Crank C.
Page 205: Supercharger Oil
& Service Appearance Care tngine Accessory Belt ‘he Supercharged 3800 engine uses two ccessory drive belts. One belt drives the enerator and the power steering pump. ‘he second belt drives the supercharger, oolant pump and air conditioning ompressor. Each belt has its own msioner and idler pulley.
Page 206 WIRING HARNESS SHIELD Remove the wiring harness shield. Clean the area around the oil fill plug before removing it. Remove the oil fill plug using a 3/16 Allen wrench. The oil level is correct when just reaches the bottom of the threads of the inspection hole.
Page 207: What Kind Of Oil To Use
& Service Appearance Care When to Add Oil If the oil is at or below the ADD line, then you’ll need to add some oil. But you must use the right kind. This section explains what kind of oil to use. For crankcase capacity, see “Capacities and Specifications”...
Page 208 Recommended SAE Viscosity Grade Engine Oils For best fuel economy and cold starting, select the lowest SAE viscosity grade oil for the expected temperature range. LOOK FOR ONE OF THESE LABELS WEATHER SAE 1 OW-30 PREFERRED SAE 5W-30 IF NEITHER SAE 5W-30 NOR SAE 1OW-30 GRADE OILS ARE AVAILABLE, SAE 30 GRADE MAY BE USED AT TEMPERATURES ABOVE 40 DEGREES F (4 DEGREES C).
Page 209: Engine Oil Additives
.208 Engine Oil Additives Don‘t add anything to your oil. Your Pontiac dealer is ready to advise if you [hink something should be added. When to Change Engine See if any one of these is true for you: Most trips are less than 4 miles (6 km).
Page 210: Air Cleaner
Used oil can be a real threat to the environment. If you change your own oil, be sure to drain all free-flowing oil from the filter before disposal. Don’t ever dispose of oil by putting it in the trash, pouring it on the ground, into sewers, or into streams or bodies of water.
Page 211 & Service Appearance Care Air Cleaner (CONT.) 2. Unscrew the clamp on the air intake hose where the hose attaches to the throttle body near the top of the engine. Detach the hose from the throttle body, then pull back the rear of the housing cover.
Page 212: Automatic Transaxle Fluid
Schedule to determine when to. change your fluid. See “Scheduled Maintenance Services” in the Index. How to Check : j ! Because this operation can be a little difficult, you may choose to have this done at a Pontiac Dealership Service Department. b . .
Page 213 & Service Appearance Care (cow.) How to Check If you do it yourself, be sure to follow all the instructions here, or you could get a false reading on the dipstick. NOTICE: Too much or too little fluid can damage your transaxle. Too much can mean that some of the fluid could come out and fall on hot engine parts or exhaust system...
Page 214: How To Add Fluid
1 . 0 ~ . If you have a problem with engine overheating, see “Engine Overheating” in the Index. The proper coolant for your Pontiac will: Give freezing protection down to -34°F (-37°C). Give boiling protection up to ,262”F 128 “C).
Page 215: Adding Coolant
& Service Appearance Care Engine Coolant (CONT.) What to Use Use a mixture of one-half clean water (preferably distilled) and one-half antifreeze that meets “GM Specification 1825-M,” which won’t damage aluminum parts. You can also use a recycled coolant conforming to GM Specification 1825-M with a complete coolant flush and refill.
Page 216: Radiator Pressure Cap
LOW COOLANT If this light comes on, it means you're lo\ on coolant. I'o Add C,oolant [f you need more coolant, add the proper mix at the coolant recovery tank. Add coolant mix at the recovery tank, but be careful not to spill it. Radiator Pressure Cap NOTICE: Your radiator cap is a 15 psi...
Page 217: What To Add
& Service Appearance Care Thermostat Engine coolant temperature is controlled by a thermostat in the engine coolant system. The thermostat stops the flow of coolant through the radiator until the coolant reaches a preset temperature. When you replace your thermostat, an AC@ thermostat is recommended.
Page 218: Windshield Washer Fluid
Windshield Washer Fluid To Add Open the cap labeled “WASHER FLUID ONLY.” Add washer fluid until the bottle is full. NOTICE: When using concentrated washer fluid, follow the manufacturer’s instructions for adding water. Don’t mix water with ready-to-use washer fluid. Water can cause the solution to freeze and damage your washer fluid tank and other...
Page 219: Brake Master Cylinder
If you do, wash it off immediately. See “Appearance Care” in the Index. Brake Wear Your Pontiac has front disc brakes and rear drum brakes. Disc brake pads have built-in wear indicators that make a high-pitched warning sound when the brake pads are worn and new pads are needed.
Page 220: Brake Pedal Travel
Vehicles we design and test have top-quality GM brake parts in them, as your Pontiac does when it is new. When you replace parts of your braking system for example, when your brake linings...
Page 221: Vehicle Storage
& Service Appearance Care Battery Every new Pontiac has a Delco Freedom@ battery. You never have to add water to one of these. When it’s time for a new battery, we recommend a Delco Freedom@ battery. Get one that has the catalog number shown on the original battery’s label.
Page 222: Taillight Bulb Replacement
Twist the bulb assembly 1/6 turn and pull out the bulb assembly. 4. Unclip the bulb assembly from the wiring harness and replace the bulb assembly. Reverse steps 1-3 to replace the bulb assembly and headlight housing. Make sure the tab is locked into (“A”) the slot (“B”) in the radiator support...
Page 223: Windshield Wiper Blade Replacement
:og Light Bulb qeplacement F you have fog lights, don’t change your lg light bulbs unless you have the proper iming equipment. See your Pontiac ealer if you have any further questions. .222 Windshield Wiper Blade Replacement Replacement blades come in different types and are removed in different ways.
Page 224 The other label is the Certification label, found on the rear edge of the driver’s door. It tells you the gross weight capacity of your vehicle, called the GVWR (Gross Vehicle Weight Rating). The GVWR includes the weight of the v,ehicle, all occupants, fuel and cargo.
Page 225 These tires are warranted by the tire manufacturers and their warranties are delivered with every new Pontiac. If your spare tire is a different brand than your road tires, you will have a tire warranty folder from each of these manufacturers.
Page 226 When to Check Check your tires once a month or more. Don’t forget your compact spare tire. It should be at 60 psi (420 kPa). How to Check Use a good quality pocket-type gage to check tire pressure. Simply looking at the tires will.not tell you the pressure, especially if you have radial tires which may look properly inflated even if...
Page 227: Buying New Tires
& Service, Appearance Care When It’s Time for New Tires One way to tell when it’s time for new tires is to check the treadwear indicators, which will appear when your tires have only 2/32 inch (1.6 mm) or less of tread remaining, You need a new tire i f You can see the indicators at three or...
Page 228: Uniform Tire Quality Grading
Uniform Tire Quality Grading The following information relates to the system developed by the United States National Highway Traffic Safety Administration which grades tires by treadwear, traction and temperature performance. (This applies only to vehicles sold in the United States.) Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire...
Page 229: Wheel Replacement
If the wheel leaks air, replace it (except some aluminum wheels, which can sometimes be repaired). See your Pontiac dealer if these conditions exist. Your dealer will know the kind of wheel you need.
Page 230 Some are dangerous if you breathe their fumes in a closed space. When you use anything from a container to clean your Pontiac, be sure to follow the manufacturer’s warnings and instructions. And always open your doors or windows when you’re cleaning the inside.
Page 231 Use a vacuum cleaner often to get rid of dust and loose dirt. Wipe vinyl or leather with a clean, damp cloth. Your Pontiac dealer has two GM cleaners, a solvent-type spot lifter and a foam-type powdered cleaner. They will clean normal spots and stains very well.
Page 232: Cleaning Vinyl
Spec/al Cleaning Problems Greasy or Oily Stains Such as grease, oil, butter, margarine, shoe polish, coffee with cream, chewing gum, cosmetic creams, vegetable oils, wax crayon, tar and asphalt. Carefully scrape off excess stain. Follow the solvent-type instructions described earlier. Shoe polish, wax crayon, tar and asphalt will stain if left on a vehicle seat fabric.
Page 233 & Service Appearance Care Cleaning the Top of the Instrument Panel Use only mild soap and water to clean the top surfaces of the instrument panel. Sprays containing silicones or waxes may cause annoying reflections in the windshield and even make it difficult to see through the windshield under certain conditions.
Page 234: Cleaning The Outside Of Your Pontiac
High pressure vehicle washes may cause water to enter your vehicle. Finish Care Occasional waxing or mild polishing of your Pontiac may be necessary to remove residue from the paint finish. You can get GM approved cleaning products from your dealer. (See “Appearance Care and Materials”...
Page 235: Sheet Metal Damage
& Service Appearance Care Weatherstrips Silicone grease on weatherstrips will make them last longer, seal better, and not stick or squeak. Apply silicone grease with a clean cloth at least every six months. During very cold, damp weather more frequent application may be required.
Page 236: Finish Damage
Although no defect in the paint job causes this, Pontiac will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000...
Page 237 (0.473L) Not recommended for pigskin suede leather. See Your General Motors Dealers for These Products. See Your Maintenance Schedule for Other Products. You can get these from your Pontiac dealer. DESCRIPTION Magic Mirror Creme Wax Spray-A-Squeak Silicone Grease Tar and Road Oil Remover...
Page 238: Engine Identification
Vehicle Identification Number (VZN) This is the legal identifier for your Pontiac. It appears on a plate in the front corner of the instrument panel, on the driver’s side. You can see it if you look through the windshield from outside your vehicle.
Page 239: Fuses And Circuit Breakers
& Service Appearance Care Fuses & Circuit Breakers The wiring circuits in your vehicle are protected from short circuits by a combination of fuses and circuit breakers. The main fuse panel is located to the left of the steering wheel, under the instrument panel.
Page 240 Left Side Fuse Panel Ratin Position (AMPKJ Circuit Breaker-Power Windows, Sunroof Not Used Power Seats-Circuit Brakes Not Used Not Used Crank Signal-Air VATS Position Ratin Circuitry R AMP^^ Spare Not Used Interior Lamps Ignition (Run), Automatic A/C Control Courtesy Lights, Power Mirrors Not Used Not Used...
Page 241 & Service Appearance Care Right Side Fuse Panel Additional fuses are located the relay center, on the far right side, below the instrument panel. You must remove the sound insulator on the right side of the passenger foot well to replace these fuses Replacing these fuses is difficult.
Page 242 Maxifuse/Relay Center To check the fuses in this underhood fuse center, turn the two knobs 1/4 turn counterclockwise and loosen the metal wing nut on the passenger side of the cover. Then remove the cover. The inside of the cover has a chart that explains the features and controls governed by each fuse and relay.
Page 243: Capacities And Specifications
Not all air conditioning refiigerants are the same. I f the air conditioning sys- tem in your vehicle needs refrigerant, be sure the proper refrigerant is used. I f you’re not sure, ask your Pontiac dealer.. For additional information, see your “Warranty and Owner Assistunce Information” booklet.
Page 244: Engine Specifications
Engine Specifications 3800 Tuned Port Injection and 3800 Supercharged Engines ..VIN Engine Code (Tuned Port) VIN Engine Code (Supercharged) ......Type .
Page 245: Replacement Bulbs
& Service Appearance Care Replacement Bulbs OUTSIDE LIGHTS Halogen Headlights LowBeam HighBeam Front Lights Park/Turn Side Marker Taillights Taillights Stoplights RearTurn Rear Side Marker Back-up Lights Center High-Mounted Stop Light License Plate Light FogLight Trunk Light Underhood Light ..244 BULB 9006...
Page 246 Replacement Bulbs (CONI) INSIDE LIGHTS Door Lights Front Courtesy/Reading Lights Rail Courtesy/Reading Lights Glove Compartment Light Visor Vanity Light Hush Panel (Lower Floor Lighting) Ash Tray BULB 12V 8W Festoon 7065 245.
Page 247 Notes...
Page 248: Maintenance Schedule
Have you purchased the GM Protection Plan? The Plan supplements your new vehicle warranties See your Pontiac dealer for details Introduction A Word About Maintenance Your Vehicle and the Environment How This Part is Organized Scheduled Maintenance Services...
Page 249: Your Vehicle And The Environment
So please read this part and note how you drive. If you have any questions on how to keep your vehicle in good condition, see your Pontiac dealer, the place many GM owners choose to have their maintenance work done. Your dealer can be relied upon to use proper parts and practices.
Page 250: Section A: Scheduled Maintenance Services
Using Your Maintenance Schedule This section tells you the maintenance services you should have done and when you should schedule them. Your Pontiac dealer knows your vehicle best and wants you to be happy with it. If you go to your dealer for your service needs, you’ll know that GM-trained and supported service people will perform the work using genuine GM parts.
Page 251 Maintenance Schedule Scheduled Maintenance Services Schedule I Follow Schedule I if your car is MAINLY driven under one or more of the following conditions: When most trips are less than 4 miles (6 kilometers). When most trips are less than When most trips include extended idling and/or frequent low-speed operation as in stop-and-go traffic.
Page 252 The services shown in this schedule up to 48,000 miles (80 000 km) should be performed after 48.000 miles at the same intervals.
Page 253 Maintenance Schedule Scheduled Maintenance Services Schedule I1 Follow Schedule I1 ONLY if none of the driving conditions specified in Schedule I apply. TO BE SERVICED (See “Explanation of Scheduled Maintenance Services” following Schedules I and 11) Item No. Engine Oil &...
Page 254 TO BE SERVICED (See “Explanation of Scheduled Maintenance Services” following Schedules I and 1 1 ) Item No. 6. Transaxle Service 7. Spark Plug Replacement” 8. Spark Plug Wire Inspection*? 9. Supercharger Oil Check 10. Air Cleaner Filter Replacement* 11. Fuel Tank, Cap &...
Page 255: Maintenance Schedule
Maintenance Schedule Explanation of Scheduled Maintenance Services Following are explanations of the services listed in Schedule I and Schedule 11. The proper fluids and lubricants to use are listed in Section D. Make sure whoever services your vehicle uses these. All parts should be replaced and all necessary repairs done before you or anyone else drives the vehicle.
Page 256 Transaxle Service Change both the fluid and filter every 15,000 miles (25 000 km) if the vehicle is mainly driven under one or more of these conditions: In heavy city traffic where the outside temperature regularly reaches 90°F (32 “C) or higher. In hilly or mountainous terrain.
Page 257: Section B: Owner Checks And Services
Maintenance Schedule Section B: Owner Checks and Services Listed below are owner checks and services which should be performed at the intervals specified to help ensure the safety, dependability and emission control performance of your vehicle. Be sure any necessary repairs are completed at once. Whenever any fluids or lubricants are added to your vehicle, make sure they are the proper ones, as shown in Section D.
Page 258 i t Least Once a Month WHAT TO DO SERVICE Tire Inflation Check tire inflation. Make sure they are inflated to the pressures specified Tire-Loading Information label located on the rear edge of the driver’s door. See “Tires” in the Index for further details. Cassette Deck Clean cassette deck.
Page 259 CHECK OR WHAT TO DO SERVICE Brake-Transaxle Shift Interlock BTSI (Automatic hnsaxle) 1. Before you start, be sure you have enough room around the vehicle. It should be parked on a level surface. 2. Firmly apply the parking brake (see “Parking Brake”...
Page 260 CHECK OR WHAT TO DO SERVICE Parking Brake and 4utomatic “P” I‘ransaxle :Park) Mechanism Check Park on a fairly steep hill, with the vehicle facing downhill. Keeping your foot on the regular brake, set the parking brake. check the parking brake: With the engine running and transaxle in “N”...
Page 261: Section C: Periodic Maintenance Inspections
Maintenance Schedule Section C: Periodic Maintenance Inspections Listed below are inspections and services which should be performed at least twice a year (for instance, each spring and fall). You should let your GM dealer’s service department or other qualified service center do these jobs. Make sure any necessary repairs are completed at once.
Page 262: Section D: Recommended Fluids And Lubricants
CHECK OR WHAT TO DO SERVICE Brake System Inspect the complete [nspection brake lines and hoses for proper hookup, binding, leaks, chafing, etc. Inspect disc brake pads for wear and rotors for surface Also inspect drum brake wear and cracks. Inspect other brake parts, including cylinders, calipers, parking brake, etc.
Page 263 Maintenance Schedule USAGE FLUIDILUBRICANT Parking Brake Chassis lubricant (GM Part No. Guides 1052497 or equivalent) or lubricant meeting requirements of NLGI Grade 2, Category LB or GC-LB. Power Steering GM Hydraulic Power Steering Fluid System (GM Part No. 1052884 or equivalent). Automatic DEXRONa- IIE or DEXRONs- I11 Transaxle...
Page 264: Maintenance Record
Section E: Maintenance Record After the scheduled services are performed, record the date, odometer reading and who performed the service in the columns indicated. When completing the Maintenance SERVICED BY Performed column, insert the numbers from the Schedule Schedule I1 maintenance charts which correspond to the maintenance performed.
Page 265 Maintenance Schedule Maintenance Record ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING .264...
Page 266: Customer Assistance Information
H e r e you find out to contact Pontiac if you need assistance This part also tells you to obtain service publications and to report any safety defects Customer Assistance Information ........
Page 267: Customer Satisfaction Procedure
Customer Assistance Information Customer Satisfaction Procedure 'our satisfaction and goodwill are nportant to your dealer and Pontiac. iormally, any hncern with the sales .ansaction or the operation of your ehicle will be resolved by your dealer's )ales or Service Departments.
Page 268: Customer Assistance For The Hearing Or Speech Impaired
We encourage you to call the toll free number listed previously in order to give your inquiry prompt attention. However, if you wish to write Pontiac, write to: United States Pontiac Division Customer Assistance Center One Pontiac Plaza Pontiac, MI 48340...
Page 269 AUTO LINE, but you may contact the BBB at any time. The BBB will attempt to resolve the complaint serving as an intermediary between you and Pontiac. If this mediation is unsuccessful, an informal hearing will be scheduled where eligible customers may present their case to an impartial third-party arbitrator.
Page 270 REPORTZNG SAFETY DEFECTS TO THE UNITED STATES GOVERNMENT If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying General Motors.
Page 271: Reporting Safety Defects To General Motors
Pontiac Roadside Assistance Program Security While You Travel 1 -800-ROADSIDE 1-800-762-3743 As the proud owner of a new Pontiac vehicle, you are automatically enrolled in the Pontiac Roadside Assistance Program This value-added service is intended to provide you with peace of mind as you drive in the city or travel the open road.
Page 272: Canadian Roadside Assistance
Pontiac reserves the right to limit services or reimbursement to an owner or driver when in Pontiac’s judgement the claims become obsessive in frequency or type of occurrence. For prompt and efficient assistance when calling, please provide the following information to the advisor:...
Page 273 Customer Assistance Information Individual PSP’s If you don’t want to buy all the PSP’s issued by Pontiac for all models in that model year, you can buy individual PSP’s, such as those which may pertain to a particular model. To do this, you will first need to see our index of PSP’s.
Page 274 1994 PONTIAC SERVICE PUBLICATIONS ORDERING INFORMATION The following publications covering the operation in this book and mailinn with vour check, monev order or credit card information to Helm. Incormrated (address listed below). CURRENT PUBLICATIONS FOR 1994 PONTIAC BONNEVILLE PRODUCT SERVICE PUBLICATIONS...
Page 276 PONTIAC SERVICE PUBLICATIONS ORDER FORM NOTE: Please complete form below (Print or Type) and MAIL TO: PUBLICATION FORM NUMBER DESCRIPTION S-9410-H 10260950 10260958 NOTE: Dealers and Companies please also the name of the person whose attention the shipment should be sent.
Page 278 PONTIAC SERVICE PUBLICATIONS ORDER FORM NOTE: Please comDlete form below (Print or Twe) and MAIL TO: (Monday-Friday 8:OO A.M.-6:00 P.M. EST) PUBLICATION FORM NUMBER ITEM DESCRIPTION S-9410-H Service Manual 10260950 Owner’s Manual In-Portfolio 10260958 NAME) (CUSTOMER P.O. ADDRESS-NO (STREET NUMBERS) ’...
Page 280 Index ... . . Warning Light ....Accessory Outlet Adding ....Brake Fluid Electrical Equipment 120.
Page 281 Glass ..... . Head-Up Display ... . 107 ..Inside of Your Pontiac ..Outside of Your Pontiac Power Antenna .
Page 282 Electrical Equipment....Adding 85. 120. 237 Electronic Climate Control ..Electronic Compass ... . . 105 Emergencies.
Page 283 Index Gear Positions (see “Shifting the Transaxle”) Gearshift Lever (see “Shifting the Transaxle”) ..... GloveBox Graphic Equalizer (see “Audio Systems”) Halogen Bulb Replacement 220.
Page 284 ... Long Distance Driving ....Low Battery ..Low Coolant Warning Light .
Page 285 Index ....ieplacing Tires ....Zeplacing Wheels ..ieporting Safety Defects .
Page 286 ....Towing a Trailer ... . Towing Your Pontiac ....Traction Control Traction Control System .
Page 287 ..Malfunction Indicator Lamp 94. 95 ... Service Engine Soon ..Traction Control System ....Washer.
Page 288 Notes 287.
Page 289: Service Station Information
Service Station Information Hood Release See Page 199 Engine Oil See Page 205 Windshield Washer Fluid See Page 217 Automatic Transaxle Fluid See Page 211 Cold Tire Pressure See Tire-Loading Information label on inside edge of driver’s door. See Page 224 Fuel Capacity 18 U.S.

Pontiac 1994 Bonneville Owner's Manual

4 Part Driving and the Road Your

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pontiac 1994 Bonneville

Summary of Contents for Pontiac 1994 Bonneville
