  • Page 1 DS-S555-3X3 46" - 55" 900 lb (117 - 140 cm) (409 kg) 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 2 WARNING ENG - This product is designed to be installed on solid concrete. Hardware is included for solid concrete installation. Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
  • Page 3 This page intentionally left blank. 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 4 Parts (Before beginning, make sure you have all parts shown below). Parts List Description Part # pedestal 147-T1426 column 146-T1131 extension 145-T1778 cover 145-T1809 side support bracket 145-T1807 vertical support bracket 145-T1806 left adaptor bracket 146-1609 right adaptor bracket 146-1608 computer cover 145-T1930 computer shelf...
  • Page 5 K ( 3 ) I ( 1 ) J ( 1 ) computer cover dual cross computer shelf support L ( 2 ) M ( 4 ) cord extension O ( 3 ) bracket adaptor cross support CC (6) M8 x 20mm N ( 4 ) P ( 6 ) Q ( 112 )
  • Page 6 AA (4) Do not fully tighten hardware Q (4) U (2) TOP VIEW 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 7 TIGHTEN CONNECTING HARDWARE 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 8 1/8" 1/8" Q (6) (3mm) (3mm) R (4) F (3) TIGHTEN CONNECTING HARDWARE 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 9 S (4) M (2) N (2) TIGHTEN CONNECTING HARDWARE TOP VIEW 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 10 WARNING ENG - When installing Peerless mounts on a concrete floor, the floor must be at least 8" thick with a minimum compressive strength of 2000 psi. Never attach concrete expansion anchors to concrete covered with plaster, drywall, or other finishing material. 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 11 Drill mounting holes into supporting surface (3" (76mm) minimum depth required). 3/8" Align base. Mark mounting holes. (10mm) 3" 3/8" (76mm) (10mm) 55.00" (1397mm) 3/8" (10mm) Align base. Install using concrete anchors provided. BB (8) ENG Maximum 35 ft • lb (47 N.M.). 55.00"...
  • Page 12 R (2) CC (2) Q (4) P (2) Q (4) R (4) 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 13 TIGHTEN CONNECTING HARDWARE Tighten. Tighten. Cross supports must center on columns. 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 14 TIGHTEN CONNECTING HARDWARE Tighten. Tighten. Cross supports must center on colmuns. 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 15 TIGHTEN CONNECTING HARDWARE Tighten. Tighten. Cross supports must center on columns. 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 16 Q (2) R (2) E (4) R (8) Q (8) 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 17 11-1 Center adaptor brackets vertically on back of screen. 11-2 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 18 12-1 "LOCKED" POSITION Must hang displays on bottom row first. Secure pin in "locked" position. 12-2 "LOCKED" POSITION Must hang displays on middle row second. Secure pin in "locked" position. 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 19 12-3 "LOCKED" POSITION Must hang displays on top row last. Secure pin in "locked" position. 12-4 Optional: Insert M5 x 10mm type-F socket pin screws (T) to lock latches. "LOCKED" POSITION 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 20 Display adjustment TILT FORWARD SIDE SIDE SIDE TILT BACKWARD TILT RIGHT TILT LEFT SIDE DOWN ROTATE LEFT ROTATE RIGHT 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 21 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 22 15-1 1/8" (3mm) T (2) 15-2 TIGHTEN CONNECTING HARDWARE 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 23 Route cables through cord brackets. 2014-07-30 #:009-9089-7 (2020-01-14)
  • Page 24 (from date of the original installation of the product). At its option, Peerless-AV will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.
