Page 1
Manual Instruction A021 24V YSA021A ◆ Please read the manual carefully before assembling; ◆ Preserve the manual properly for future reference; ◆The manual is for assembling and using reference only. Details will be possibly improved and changed, including structure, appearance, packing, functions, and etc. Please take the...
1. Before Assembling Warning! Choking Hazard: Small parts, Not for kids under 6 years. Dispose plastic bags carefully. It’s dangerous to kids. Adult assembly required.Use care when unpacking as components to be assembled may p ose small parts/sharp edge hazard. ...
Page 3
4. Front Wheel Assembling 前知 Fix the front wheel onto the axle, and tighten the screws. (left & right) 5. Rear Wheel Assembling Fix onto the rear axle, and assemble the wheels with tightening screws from both sides. 6 . Steer pole and wheel Wheel Assembling Install the steering pole after fixing the steering wheel.
Page 4
Rear View Mirrors, Windshield, Seat Assembling A. Insert the rear view mirrors onto c the car and press it till its locked Put the windshield onto right buckle hole, press it heavily till locked. C. Put the seats onto right position and fix them by screws.
Page 5
8. Hood Open & close, Battery Connecting A. The hood could be opened and closed by a wrench or key of the car. B. Hold the hood by supporting poles.
Page 6
C. Connect the battery terminals with right colors accordingly. 9. Functions Sketch A 1. Central Multifunctional Panel: see point 11. 2. Power Switch:Switch On/off the ride on 3. Speed Switch: switch to shift speed 4. Drive/reverse switch:switch to drive-neutral-reverse, 5. Light Switch: switch on/off the car light 6.
Page 8
2. Power off Switch sprint 5. Holzer pedal Switch 3. Left brake adjustment 6.pedal brake back moving spring 12. Central Multifunctional panel: USB port Light (no this function for this version) horn MP3 port VOL up VOL down PREV NEXT PLAY/PAUSE Story Power volume display...
Page 9
3. Where it’s possible to hit or hit the other things; 4. Other not safe areas. 5. Don’t drive in dark evening and night. 6. Don’t drive in rain or snow. Don’t drive if age or weight is not proper. 14.
16. Charging warnings: Portable charging Inspect the charger carefully regularly to check if everything is OK. OCKET If there is somewhere with any problem, stop using is till repaired. Fuse: The car is with self reset fuse. When its over loaded or used improperly,the fuse will power off the car for 15-20 seconds,and then to reset it.
18. Trouble Shooting Troubles Inspections Solutions Motor not 1. Check if fuse disconnected? Yes, restart the car; rotating No, check the next; 2. Check if pedal switch in poor contact. No,repair the contact. Yes, check the next; 3. Check if motor terminal welded. No, connect it.
Page 12
Plastic bags and small parts inside may be dangerous. Keep away from the reach of children to avoid suffocation and other possible hazards. DISPOSAL OF BATTERIES: CONTAINS SEALED LEAD ACID BATTERY. BATTERY MUST BE RECYCLED. Dispose old batteries at an approved battery dumping station; Contact your local environmental protection agency office for additional information.
Page 13
Execution Standard: EN71 ‐1: EN71-1:2014+A1:2018 for mechanical and physical properties; EN71-2: 2011+A1:2014 flammability test; EN71-3:2013+A2: 2017 for migration of certain elements; EN62115:2005+A12:2015 on safety of electric toy Excluding clause Excluding Annex E & Annex ZC & Annex; U.S. ASTM F963-17 For Physical And Mechanical Tests Excluding Section 4.25, 5.15, 6.5, 6.6, 7.2; U.S.
