CHILDREN ELECTRIC CAR
CHILDREN ELECTRIC CAR
Criteria of product operation:
GB 6675.1-2014 GB 6675.2-2014 GB 6675.3-2014 GB 6675.4-2014
GB 19865-2005 GB 5296.5-2006
Installation and Operation Instruction
EN 71 EN 62115
ASTM F963 CPSIA
Picture is for reference only, and the product is subject to practicality.
Advertisement
Related Manuals for Lean Cars HC-8988
Summary of Contents for Lean Cars HC-8988
- Page 1 CHILDREN ELECTRIC CAR CHILDREN ELECTRIC CAR Criteria of product operation: GB 6675.1-2014 GB 6675.2-2014 GB 6675.3-2014 GB 6675.4-2014 GB 19865-2005 GB 5296.5-2006 Installation and Operation Instruction EN 71 EN 62115 ASTM F963 CPSIA Picture is for reference only, and the product is subject to practicality.
- Page 2 Would you please to read this specification carefully before installation in order to avoid operating errors or damages. Make sure that the baby will be safe. The user should safekeeping the specification. Specification Car type HC-8988 Storage battery 12V7AH *1 /12V 10AH *1 Electric motor 12V 30W*4(drive) 12V8W*1(turn)
-
Page 3: Kind Reminder
Kind reminder ▪ Small parts. Not suitable for children under 36 months！ Do not drove the car in the water. Do not put the water or liquid on the car. ▪ Products should be adult assembly！Before the assembly screw Do not drove the car in the room to protect children and furniture. split pin and other dangerous sharp tip! ▪... -
Page 4: Installation Steps
Installation Steps： 1.Adjust the front axle a.After the adjustment, insert a 5*12MM Front axle configuration diagram screw into the hole at the joint of the steering disc and lock it with M5 locknut to ensure that the steering joint can Front axle assembly adjustment diagram rotate easily from left to right After the adjustment, insert a 5*12MM screw... - Page 5 5.Install the steering wheel a.Firstly connect the steering wheel wire to dashboard wire. b.Then insert steering wheel into the dashboard hole position ,align the steering rod hole with the steering wheel hole, insert ¢5 bolt and tight with nut. (Referring to Picture5) 6.
- Page 6 e. High-low speed switch - When manual for driving，Children can adjust the Charging socket 9.Power connection speed by themself. a.Firstly open the hood , f.Go forward/ Stop/ Back forward switch-When manual for driving，children connect the power plug-in, can control to go forward or backward when they step on the foot pedal. and turn on the power （Referring to Picture10) switch on the dashboard,...
