Manual Instruction
A026
Picture is for reference only.
Please refer to real object.
◆ Please read the manual carefully before assembling;
◆Preserve the manual properly for future reference;
◆The manual is for assembling and using reference only. Details will be
possibly improved and changed, including structure, appearance, packing,
functions, and etc. Please take the actual product as standard if something
different from the manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A026 and is the answer not in the manual?

Questions and answers

Related Manuals for Lean Cars A026

Summary of Contents for Lean Cars A026

  • Page 1 Manual Instruction A026 Picture is for reference only. Please refer to real object. ◆ Please read the manual carefully before assembling; ◆Preserve the manual properly for future reference; ◆The manual is for assembling and using reference only. Details will be possibly improved and changed, including structure, appearance, packing, functions, and etc.

  • Page 2: Before Assembling

    1. Before Assembling Warning! Choking Hazard: Small parts, Not for kids under 3 years. Dispose plastic bags carefully. It’s dangerous to kids. Adult assembly required.Use care when unpacking as components t o be assembled may pose small parts/sharp edge hazard. Check if the charger is in good state, including the wire, socket, and all details.
  • Page 3 4. Front & rear wheel, and rear view mirror assembling 前知 A. Assemble the front bumper firstly by putting shim, wheel, bushing, shim, wheel cover, and fix it by screws; B. Fix the motor, wheel, shim, wheel hub, shim and fix it by screws, then put on the wheel cover. C.
  • Page 4 5. Steer wheel assembling 前知 Install the steering pole, and connect the cables, then fix the steering wheel by screws. 6. Front bumper assembling Fix the front bumper onto the head part of the vehicle, and press tightly, fix it by six screws. 7.
  • Page 5 8. Chimney, luggage frame battery cables, hood assembling. A. Assemble the chimney firstly by 2 screws, install the chimney and rear luggage frame onto right position and press tightly; A. Connect the battery terminal to the ride on by red-red accordingly; B.
  • Page 6 9. Functions Sketch 1. Central Multifunctional Panel: see point 11. 2. Power Switch：Switch On/off the ride on 3. Horn and music button 4. Drive/reverse switch: switch to drive-neutral-reverse, 5. Speed switch 6. Pedal switch: pedal the switch to move,release to stop gradually. 7.
  • Page 7 10. Functions of Remote: Note：Use screwdriver to get screws off and open battery box，install 2 pc AAA 1.5V battery in, and fix it with screws. 1、 无刷马达 2、 差速器 The car is with remote priority function: while it is controlled by remote, the step switch does not work;...
  • Page 8 11. Central Multifunctional panel: 1. USB port 2. Light (no this function) 3. horn 4. MP3 port 5. VOL up 6. VOL down 7. PREV 8. NEXT 9. PLAY/PAUSE 10. Story 11. Power volume display 12. Music 13. Mobile Bingo connection Warning! ...
  • Page 9 Public road and other vehicles and walking people areas; 3. Where it’s possible to hit or hit the other things; 4. Other not safe areas. 5. Don’t drive in dark evening and night. 6. Don’t drive in rain or snow. Don’t drive if age or weight is not proper. 13.

  • Page 10: Charging Warnings

    15. Charging warnings: Inspect the charger carefully regularly to check if everything is OK. If there is somewhere with any problem, stop using is till repaired. The car is with self reset fuse. When its over loaded or used improperly,the fuse will Fuse: power off the car for 15-20 seconds ，and then to reset it.

  • Page 11: Troubleshooting

    17.Trouble Shooting Troubles Inspections Solutions Motor not 1. Check if fuse disconnected？ Yes, restart the car； rotating No, check the next； 2. Check if pedal switch in poor contact. No，repair the contact. Yes, check the next； 3. Check if motor terminal welded. No, connect it.
  • Page 12 Plastic bags and small parts inside may be dangerous. Keep away from the reach of children to avoid suffocation and other possible hazards. DISPOSAL OF BATTERIES: CONTAINS SEALED LEAD ACID BATTERY. BATTERY MUST BE RECYCLED. Dispose old batteries at an approved battery dumping station; Contact your local environmental protection agency office for additional information.
