BATTERY POWERED RIDE-ON
BATTERY POWERED RIDE-ON
Type without roof
Styles and colo(u)rs may vary.
Made in China.
The owner's manual contains important safety information as well as assembly, use and
maintenance instructions.
The Ride-on Car must be assembled by an adult who has read and understands the
instructions in this manual.
Keep the package away from children and dispose of properly before use.
Keep this manual for future reference.
UTV
Owner's Manual
with Assembly Instructions
Type with roof

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UTV and is the answer not in the manual?

Questions and answers

Related Manuals for Lean Cars UTV

Summary of Contents for Lean Cars UTV

  • Page 1 BATTERY POWERED RIDE-ON BATTERY POWERED RIDE-ON Type without roof Type with roof Owner’s Manual with Assembly Instructions Styles and colo(u)rs may vary. Made in China. The owner’s manual contains important safety information as well as assembly, use and maintenance instructions. The Ride-on Car must be assembled by an adult who has read and understands the instructions in this manual.
  • Page 2 About Your New Ride-On │ 1 On the purchase of your new Ride-On. This ride-on will provide your child with many miles of riding of enjoyment. To help assure you and your rider a safe ride we ask you to please read this manual carefully, and keep it for future reference.

  • Page 3: User Notice

    User Notice │ 2 WARNING! • CHOKING HAZARD - Small parts. Not suitable for children under 36 months. The product contains small parts, keep children away when assembling. • ADULT ASSEMBLY REQUIRED. • Always remove protective material and poly bags and dispose before assembly.

  • Page 4: Parts Diagram

    Parts Diagram │ 3 HINT: Some parts shown are assembled on both sides of vehicle Type without roof Type with roof 6 27...

  • Page 5: Parts List

    Parts List │ 4 Q’ty (pcs) PART REMARKS PART NAME without roof with roof Vehicle body Rear wheel 2WD 1 PC labeled “R”, the other one labeled “L” Front wheel Ø12 washer Lock nut Hubcap rear axle Steering wheel M5x35 machine screw Placed on the steering wheel Ø5 nut Placed on the steering wheel...
  • Page 6 Attach the Front Bumper & Rear Axle │ 5 Rear Bottom View 1. Insert the tabs on the front bumper into the holes in the front of the vehicle, push until you hear it “click” into place. • Turn the vehicle body downside up. Cut off the plastic tie on the front axle with scissors.

  • Page 7: Attach The Rear Wheels

    Attach the Rear Wheels │ 6 Rear Bottom View 1. Slide the rear wheel onto the rear axle, ensure the driver on the wheel match up with the gear box. 2. Slide a Ø12 washer onto the rear axle. 3. Tighten a lock nut to the end of the front axle with a spanner. •...
  • Page 8 Reset the Front Axle │ 7 M6x16 machine screw Steering column Steering linkage Front axle plate Ø6 washer Ø6 lock nut Steering linkage Front axle plate Front Bottom View Cut off the plastic tie on the front axle with scissors. 7-1.

  • Page 9: Attach The Front Wheels

    Attach the Front Wheels │ 8 Front Bottom View Remove all the parts from the front axle. 1. Slide a Ø12 washer onto the front axle. 2. Slide a front wheel onto the front alxe. 3. Slide a Ø12 washer onto the front axle. 4.

  • Page 10: Attach The Steering Wheel

    Attach the Steering Wheel │ 9 HINT: If the steering wheel of your vehicle equipped with the sound function, please follow the steps 1-4 to add the batteries (Not Included), and refer to the battery information on page 2. 1. With a screwdriver remove the screw on the battery cover located in the center of the steering wheel.
  • Page 11 Attach the Cargo Basket & Connect the Power Supply │ 10 1. Fit the cargo basket to the bonnet. 2. Insert four Ø4x16 screws and tighten. 3. Plug the battery connector into the vehicle connector. Battery connector Vehicle connector Top View...

  • Page 12: Attach The Seat

    Attach the Seat │ 11 1. Fit the seat back to the seat. 2. Fit the seat assembly to the vehicle body. 3. Insert two M5x16 machine screws through the seat and into the vehicle, and tighten with a screwdriver. 4.
  • Page 13 Attach the Rear Rollbar │ 12 HINT: The follow steps only for the type without roof. 1. Fit the rear rollbar support to the each end of the rear rollbar linkage. 2. Insert a Ø4x16 screw and tighten on each side. 3.
  • Page 14 Attach the Front Rollbar │ 13 HINT: The follow steps only for the type without roof. 1. Insert the front rollbar into the holes in the top side of the vehicle body. Push until you hear it “click” into place. Type without roof completed.
  • Page 15 Attach the Roof(1) │ 14 HINT: The follow steps only for the type with roof. “R” marked “L” marked “R” marked “L” marked HINT: The roof, roof beams, roof front supports and roof rear supports are marked “L” and “R”, aslo they are designed to assemble together in only one way. Please follow the guides: L to L, R to R.
  • Page 16 Attach the Roof(2) │ 15 HINT: The follow steps only for the type with roof. 1. Fit the roof assembly to the vehicle body. 2. Insert a Ø4x16 screw through the both roof front supports and into the bonnet, and tighten with a screwdriver.
  • Page 17 Use Your Ride-on │ 16 1. Power button: Turns the vehicle on and off. 2. Low speed forward/reverse shifter: Changes the direction that vehicle moves from forward to reverse. ● To move the vehicle forward, shift the lever to top position. ●...
  • Page 18 Using the High Speed │ 17 IMPORTANT ● The High Speed Protective cover must be removed by an adult. ● Before remove the HIGH SPEED protective cover: Make sure your child knows how to steer, how to start and stop the product and knows the rules for safe driving.

  • Page 20: Battery Disposal

    Charging │ 18 WARNING! • ONLY an adult is allowed charge and recharge the battery! • This product with Charging Protection: when charging, all functions will be cut off. • The POWER SWITCH must be turned in OFF position when charging. •...

  • Page 21: Troubleshooting Guide

    Troubleshooting Guide │ 19 Possible Cause Solution Problem Vehicle does not run Battery low on power Recharge battery. Thermal fuse has tripped Reset fuse, see <Fuse> Check that the battery connectors are firmly plugged Battery connector or wires into each other. If wires are loose around the motor are loose contact your distributor please.
  • Page 22 Maintaining │ 20 • It is parents' responsibility to check main parts of the toy before using, Must regularly examine for potential hazard, such as the battery, charge, cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed.
