CHILDREN’S ELECTRIC MOTORCYCLE Owner’s Manual with Assembly Instructions Styles and colo(u)rs may vary. Made in China. The owner’s manual contains important safety information as well as assembly, use and maintenance instructions. The Ride-on Car must be assembled by an adult who has read and understands the instructions in this manual.
Page 2
SPECIFICATIONS: Battery 6V4AH*1 Charger 6V500mA Suitable age: 37-96 months Load Capacity: Under 30kg Speed: 3km/h Size of car: 106 x 64 x 51 CM Power way: Charging type Charge time: 8-12 hours VER: SMS-JT5158-EN-190105...
Parts List │ 2 Q’ty (pcs) PART PART NAME REMARKS Vehicle body Seat Front fork Face guard Front fender Absorber tube Side wheel Front wheel Wheel cover Brake Foot plate Foot plate axle Front axle Ø4x12 screw Ø10 lock nut Ø10 washer Ø8 lock nut M10X190 bolt...
Before Assembly │ 4 WARNING! • CHOKING HAZARD - Small parts. Not suitable for children under 36 months. The product contains small parts, keep children away when assembling. • ADULT ASSEMBLY REQUIRED. • Always remove protective material and poly bags and dispose before assembly. •...
Page 6
Attach the Faceguard & Front fender │ 5 1. Fit the Face guard to the front fork tubes. 2. Insert four Ø4x12 screws and tighten the screws with a screwdriver. Front Fork Tubes 3. Fit the front fender to the front fork. 4.
Page 7
Attach the shock absorber tubes & brakes │ 6 1. Slide the absorber tubes onto the front fork tubes. 2. Slide the brakes to the front fork tubes. Front Fork Tubes...
Attach the Front Wheel │ 7 Front fork assembly Tools required: Socket spanner x2 Rear axle 1.Tighten a Ø10 lock nut to the end of the front axle. 2. Slide a Ø10 washer onto the front axle. 3. Insert the front axle through the hole on the front fork, slide a wheel cover to the front axle.
Page 9
Attach the Side Wheel │ 8 Bottom View Spanner Turn the vehicle body downside up. 1. Fit the side wheel to the vehicle body. 2. Tighten two Ø8 lock nuts to secure it with a spanner.
Page 10
Attach the Foot Plates │ 9 1. Tighten a Ø10 lock nut onto one end of the foot plate axle with a socket spanner. 2. Slide a foot plate (larger end out)onto the foot plate alxe. Insert the foot plate axle into the hole on the vehicle body, ensure the square end of the foot plate inserted into the groove on the vehicle body.
Page 11
Attach the Handle Bar Assembly │ 10 Handle bar assembly Sound unit connectors Bottom View Socket Socket spanner spanner Power supply connectors 1. Plug the sound unit connectors into each other. Plug the power supply connectors into each other. 2. Fit the handle bar assembly to the vehicle body. 3.
Connect the Power Supply │ 11 Top View 1. Remove the screw on the top of the seat with a screwdriver, and lift to remove 2. Plug the red wire connector on the vehicle body into the terminal on battery. Replace the seat.
Page 13
Safety │ 12 WARNING! PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. DIRECT ADULT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • This toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.
Page 14
Use Your Ride-on │ 13 1. Power Switch: Turns the vehicle on and off. 2. Forward button: ● To move the product forward, press the button down. ● To brake or slow down, release pressure from the button. MP3 PLAYER (IF EQUIPPED) A.
Page 15
Charging │ 14 ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! WARNING! • PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or the charger with another brand. Using another battery or charger may cause a fire or explosion. - Do not use the battery or charger for any other product.
Charging │ 15 • If your ride-on with a the magnitude of voltage Digital voltmeter(IF EQUIPPED), will tell you how much power is remaining in the battery when you must recharge the battery. Make sure the vehicle is stop! BATTERY MAGNITUDE OF VOLTAGE BATTERY STATE ≥...
Battery Replacement & Fuse │ 16 The battery features a thermal fuse with a rest fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded. The fuse will reset and power will be restored after the unit is turned OFF for 20 seconds and then turned ON again.
Troubleshooting Guide │ 17 Possible Cause Solution Problem Vehicle does not run Battery low on power Recharge battery. Thermal fuse has tripped Reset fuse, see <Fuse> Check that the battery connectors are firmly plugged Battery connector or wires into each other. If wires are loose around the motor are loose contact your distributor please.
Page 19
Maintaining │ 18 • It is parents' responsibility to check main parts of the toy before using, Must regularly examine for potential hazard, such as the battery, charge,cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed.
Page 20
Our products are suitable for ASTM F963; GB6675; EN71 and EN62115 standard.
