K-143
98666 00143
8
Specifications:
Recommended Motors:
Parts List
Required to complete: 5 minute epoxy,
120/220 sandpaper, masking tape, finishing
filler/paint.
7
Length: 31"
Diameter 2.6"
Weight: 15oz
Recovery: 30" Nylon Chute
Motor Mount: 29mm
Features: Vinyl Decals
Fins: 1/8" Plywood
CG: 20.25" from nose tip
Single Use
F20J-7
1200'
F23J-7
990'
F25W-6 1430'
F26J-6
1190'
G38FJ-7 1750'
G40W-7 2010'
1.
(1) Molded nose cone
2.
(1) pre-slotted body tube
3.
(2) Centering rings
4.
(1) 29mm motor tube
5.
(8) laser-cut fins
6.
(1) Kevlar® shock cord section
7.
(1) Nylon shock cord section
8.
(1) 9"x9" flameproof chute protector
9.
(1) 30" Nylon chute
10. (2) ¼" launch lugs
11. (1) Vinyl decal
RMS
E16W-4 510'
F40W-7 1540'
G33J-7
1950'
™
Advertisement
Table of Contents
Related Manuals for Madcow Rocketry Martian Transport
Summary of Contents for Madcow Rocketry Martian Transport
- Page 1 ™ Specifications: Length: 31” Diameter 2.6” Weight: 15oz Recovery: 30” Nylon Chute Motor Mount: 29mm Features: Vinyl Decals Fins: 1/8” Plywood CG: 20.25” from nose tip Recommended Motors: Single Use F20J-7 1200’ E16W-4 510’ F23J-7 990’ F40W-7 1540’ F25W-6 1430’ G33J-7 1950’...
- Page 2 Make sure you have the motor assembly facing the right way! (The shock cord goes over the forward centering ring) Spread some more epoxy on the inside edge of the body tube before sliding the rear centering ring into the body tube. ©2009 MadCow Rocketry™ Martian Transport™ Assembly...
- Page 3 1/2” from the aft end of the body tube. Site down both launch lugs and make sure they are both aligned. If you have a ¼” launch rod, you can use this to ensure that both lugs are aligned properly. Martian Transport™ Assembly ©2007 MadCow Rocketry™...
- Page 4 IMPORTANT: In no event shall Madcow Rocketry be liable for any direct, indirect, punitive, incidental, special consequential damages whatsoever arising out of or connected with the use or misuse of it’s products.
