- Page 1 Zalto Island Extractor instruction manual ZAL48CO | ZAL48BK | ZAL48SL Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk...
-
Page 2: Table Of Contents
CONTENTS WARNINGS ENVIRONMENTAL PROTECTION INSTALLATION REMOTE CONTROL OPERATION MODE TIMING MAINTENANCE Please keep this instruction manual for future reference Instruction manual ZAL48CO ZAL48SL ZAL48BK... -
Page 3: Warnings
WARNINGS The cooker surface and the inferior part of the cooker hood must be at a minimum distance of 65 cm. - The appliance is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure they do not play with the appliance. - Page 4 to oil and grease. Being highly inflammable, fried oil isespecially dangerous. Do not use uncovered electric grills. In order to avoid possible fire risk, all instructions for grease filter cleaning and for removing eventual grease deposits should be strictly followed. - Two persons are needed for the installation of this product.
- Page 5 - The electrical safety of this appliance can only be guaranteed when correctly earthed. It is essential that this standard safety requirement is met. If in any doubt please have the electrical installation tested by a qualified electrician. - Do not connect the appliance to the mains electricity supply by a multi-socket unit or an extension lead.
-
Page 6: Environmental Protection
Radio Equipment Directive (RED) 2014/53/EU This Declaration is issued under the sole responsibility of the manufacturer. Hereby, Caple declares that the radio equipment included in the product is in compliance with the RED directive 2014/53/EU. The full text of the EU Declaration of Conformity is available on our website www.caple.co.uk. -
Page 7: Installation
INSTALLATION The appliance is suitable for recirculation only, and cannot be vented externally. In recirculation mode the air and fumes conveyed by the appliance are cleaned both by a grease filter and by an active charcoal filter, and put again into circulation. At the beginning make sure that the package is intact and all the parts are unbroken, otherwise stop the installation and contact the dealer. - Page 8 Please keep this instruction manual for future reference Instruction manual ZAL48CO ZAL48SL ZAL48BK...
- Page 9 Please keep this instruction manual for future reference Instruction manual ZAL48CO ZAL48SL ZAL48BK...
- Page 10 Please keep this instruction manual for future reference Instruction manual ZAL48CO ZAL48SL ZAL48BK...
-
Page 11: Remote Control
REMOTE CONTROL Remote control used for the operation of island cooker hoods: At first ignition, keep pressed the lighting button for 5 seconds. Technical Data Alkaline battery powered : 12 V mod. 27 A Operating frequency : 433.92 Mhz Combinations : 32.768 Max. -
Page 12: Operation Mode
OPERATION MODE Standard configuration: Standard configuration requires all “cooker hoods radio control system” to be provided with the same transmission code. In the event two cooker hoods radio control system are installed in the same room or nearby, each system may affect the operation of the another. - Page 13 for 2 seconds. When Leds light on, press buttons (within 5 seconds). Leds flashing 6 times indicate the procedure is completed. WARNING: This operation deletes permanently the preset codes. Emergency button: In the event that the radio control does not work, use the emergency button to switch the appliance off.
-
Page 14: Timing
TIMING - As a result of the new EU65 “Energy label” and EU66 “ Ecodesign” regulations issued by the European Commission, which came into force as from January 1st, 2015 , our products have been adapted to comply with these new requirements - All of the models complying with the energy label requirements, are equipped with new electronics including a timer device for suction speeds control, when the air capacity exceeds 650m³/h.Internal motor models, with maximum air capacity... -
Page 15: Maintenance
- The active charcoal filter used in these hoods can be washed and re-used for up to a maximum 3 years. We recommend that these are replaced during this period. - To purchase replacement charcoal filters please visit www.caple.co.uk or call 0117 938 1900. - Page 16 Caple Service Fourth Way Avonmouth Bristol BS11 8DW t: 0117 938 7420 e: service@caple.co.uk www.caple.co.uk Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk...
