Mercury 2002 Villager Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Table of Contents

10
20
58
74
83
108
108
108
109
4
10
15
20
39
50
53
58
63
74
76
77
83
85
87
89
90
99
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2002 Villager and is the answer not in the manual?

Questions and answers

Related Manuals for Mercury 2002 Villager

Summary of Contents for Mercury 2002 Villager

  • Page 1: Table Of Contents

    Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette (CD changer compatible) AM/FM stereo cassette with CD Rear seat controls CD changer Climate Controls Manual heating and air conditioning Electronic automatic temperature control Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control...
  • Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Transmission operation Vehicle loading Trailer towing Recreational towing Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing...
  • Page 3 Cleaning Maintenance and Specifications Hood Engine compartment Engine oil Battery Fuel information Air filter(s) Part numbers Refill capacities Lubricant specifications Engine data Vehicle dimensions Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.

  • Page 4: Introduction

    California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Mercury. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.

  • Page 5: Safety And Environment Protection

    Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available.

  • Page 6: Protecting The Environment

    Introduction Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

  • Page 7: Special Instructions

    Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. By operating other electronic equipment (e.g. mobile telephone without exterior aerial) electromagnetic fields can occur which can cause malfunctions of the vehicle electronics. Therefore you should observe the instructions of the equipment manufacturers.
  • Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based AdvanceTrac Hazard Warning Flasher Fuse Compartment Windshield Wash/Wipe Rear Window Defrost/Demist...
  • Page 9 Vehicle Symbol Glossary Power Window Lockout Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant Temperature Battery Battery Acid Fan Warning Maintain Correct Fluid Level Engine Air Filter Jack Low tire warning Introduction Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks...

  • Page 10: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.

  • Page 11: Brake System Warning

    Light turns on solid: Temporary malfunctions may cause the light to illuminate. Examples are: 1. The vehicle has run out of fuel. 2. Poor fuel quality or water in the fuel. 3. The fuel cap may not have been properly installed and securely tightened.

  • Page 12: Anti-Lock Brake System (Abs) (If Equipped)

    Instrument Cluster To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position (alternatively for some vehicles when the ignition is moved from the ON position to START position, the light will momentarily illuminate prior to reaching the START position).

  • Page 13: Cruise Set

    Instrument Cluster • Optional electronic instrument cluster Illuminates to confirm that the air bags are operational. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately. Charging system Illuminates when the battery is not charging properly.

  • Page 14: Turn Signals

    Instrument Cluster The “SET” light comes on when either the COAST/SET or RES/ACCEL controls are pressed. The “SET” light turns off when the cruise cancel control is pressed or the brake is applied. Both the “CRUISE” and “SET” lights turn off when the OFF control is pressed or the ignition is turned to the OFF position.

  • Page 15: Gauges

    Instrument Cluster High beams Illuminates when the high beam headlamps are turned on. Safety belt warning chime Sounds to remind you to fasten your safety belts. Headlamps on warning chime Sounds when the headlamps or parking lamps are on, the key is removed from the ignition and the driver’s door is opened.

  • Page 16: Engine Coolant Temperature Gauge

    Instrument Cluster Optional electronic instrument cluster gauges CRUISE ˚F ˚C MILES/BAL L/100 km OUTSIDE TEMP INST ECONOMY AVG. ECONOMY TO EMPTY BRAKE Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H”...

  • Page 17: Fuel Gauge

    • Optional electronic instrument cluster Fuel gauge Displays approximately how much fuel is in the fuel tank. The fuel gauge may vary slightly when the vehicle is in motion or on a grade. When refueling the vehicle from empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel.
  • Page 18 Instrument Cluster Speedometer Indicates the current vehicle speed. • Standard analog instrument cluster • Optional electronic instrument cluster Odometer Registers the total kilometers (miles) of the vehicle. • Standard analog instrument cluster • Optional electronic instrument cluster Refer to Electronic Message Center in the Driver controls chapter for information on how to switch the display from metric to English measurements.

  • Page 19: Trip Odometer

    Trip odometer Registers the kilometers (miles) of individual journeys. • Standard analog instrument cluster To reset, press and hold the control for one second. • Optional electronic instrument cluster Refer to Electronic Message Center in the Driver controls chapter for information on how to switch the display from Trip 1 and Trip 2 features on the electronic...

  • Page 20: Entertainment Systems

    Entertainment Systems AM/FM STEREO/CASSETTE (CD CHANGER COMPATIBLE) VOL - PUSH ON BASS TREB SEEK SCAN TUNE DISCS Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...

  • Page 21: Bass Adjust

    Entertainment Systems Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. BASS Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. TREB Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers.

  • Page 22: Scan Function

    Entertainment Systems Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Seek function The seek function control works in radio or CD changer mode. Seek function in radio mode • Press to find the next listenable station down the frequency band.
  • Page 23 Scan function in CD changer mode (if equipped) Press the SCAN control to hear a brief sampling of all selections on the CD. (The CD scans in a forward direction, wrapping back to the first track at the end of the CD.) To stop on a particular selection, press the SCAN control again.

  • Page 24: Setting The Clock

    Entertainment Systems 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected. Setting the clock Press CLK to toggle between listening frequencies and clock mode while in radio mode. To set the hour, press and hold the CLK control and press the SEEK control:...

  • Page 25: Tune Adjust

    Tune adjust The tune control works in radio and CD changer modes (if equipped). Tune adjust in radio mode • Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly.
  • Page 26 Entertainment Systems Automatic Music Search The Automatic Music Search feature allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection. To activate the feature, momentarily depress the TAPE AMS button. Then, press either REW (for the beginning of the current selection) or FF (to advance to the next selection).

  • Page 27: Fast Forward

    Fast forward The fast forward control works in tape and CD changer modes. To fast forward in tape mode, press the 1–2/FF control. Tape direction will automatically reverse when the end of the tape is reached. Press the SIDE/REW control to stop the fast forward of the tape.

  • Page 28: Dolby Noise Reduction

    Entertainment Systems Shuffle feature (if equipped) The shuffle feature operates in CD changer mode and plays all tracks on the current disc in random order. The shuffle feature continues to the next disc after all tracks are played. Press the SHUFFLE control to start this feature. Random order play will continue until the SHUFFLE control is pressed again.
  • Page 29 PREMIUM AM/FM CASSETTE (CD CHANGER COMPATIBLE) PUSH ON TAPE SEEK MUTE Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated. During the operation of any selected mode, lighting for the individual function controls will either illuminate or turn off.
  • Page 30 Entertainment Systems Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. Bass adjust The bass adjust control allows you to increase or decrease the audio...
  • Page 31 Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Seek function The seek function control works in radio, tape or CD changer mode (if equipped). Seek function in radio mode • Press to find the next listenable station down the frequency band.
  • Page 32 Entertainment Systems Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode. Scan function in tape mode Press the SCAN control to hear a short sampling of all selections on the tape.

  • Page 33: Autoset Memory Preset

    3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected. SIDE 1 . 2 Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations.
  • Page 34 Entertainment Systems Tune adjust The tune control works in radio or CD changer mode (if equipped). Tune adjust in radio mode • Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly.
  • Page 35 into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information.
  • Page 36 Entertainment Systems Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. Dolby noise reduction is manufactured under license from Dolby Laboratories Licensing Corporation.
  • Page 37 Radio Data System (RDS) feature When selected, the RDS (Radio Data System) function performs the following: • Displays the radio station call letters • Displays the type of music format (jazz, country, rock) • Searches for a particular type of music format by selecting the SEEK control •...
  • Page 38 Entertainment Systems • Use the SEL control to select the program type. With the feature on, use the SEEK or SCAN control to find the desired program type from the following selections: • Classic • Country • Info • Jazz •...

  • Page 39: Am/Fm Stereo Cassette With Cd

    SUPER SOUND AM/FM STEREO/CASSETTE/SINGLE CD PLAYER (CD CHANGER COMPATIBLE) VOL - PUSH ON DOLBY B NR SEEK TUNE SCAN BASS TREB SIDE 1-2 Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated.
  • Page 40 Entertainment Systems Turn control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. If you wish to maintain your preset volume level, turn the audio system off with the power control before switching off the ignition.
  • Page 41 Press the TREB control then press: • to decrease treble output and • to increase treble output. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control then press: • to shift sound to the left and •...
  • Page 42 Entertainment Systems Seek function The seek function control works in radio, tape or CD mode. Seek function in radio mode • Press to find the next listenable station down the frequency band. • Press to find the next listenable station up the frequency band.
  • Page 43 Scan function in CD mode Press the SCAN control to hear a short sampling of all selections on the CD. (The CD scans in a forward direction, wrapping back to the first track at the end of the CD.) To stop on a particular selection, press the control again.
  • Page 44 Entertainment Systems Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting autoset memory preset 1.
  • Page 45 • to decrease minutes and • to increase minutes. Tune adjust The tune control works in radio or CD mode. Tune adjust in radio mode • Press to move to the next frequency down the band (whether or not a listenable station is located there).
  • Page 46 Entertainment Systems Tape/CD/CD changer (if equipped) select • To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode, press the TAPE control. Press the button during rewind or fast forward to stop the rewind or fast forward function.
  • Page 47 Fast forward The fast forward control works in tape and CD modes. • In the tape mode, tape direction will automatically reverse when the end of the tape is reached. • In CD mode, pressing the control for less than three seconds results in slow forward action.

  • Page 48: Shuffle Feature

    Entertainment Systems Compression adjust Compression adjust brings soft and loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. Shuffle feature The shuffle feature operates in CD mode and plays all tracks on the current disc in random order.
  • Page 49 Press the RDS control. Use the SEL control to select ON or OFF to enable or disable the feature. RDS traffic announcement When set ON, this traffic feature will interrupt tape or CD play to play a traffic report broadcast from a FM RDS station.

  • Page 50: Rear Seat Controls

    Entertainment Systems • Rock • Soft • Top 40 RDS show RDS sends information with the FM broadcast, including: station name, station type, and/or radio text. To view this information: • With the RDS menu enabled, press the RDS control until SHOW is displayed. •...

  • Page 51: Adjusting The Volume

    ADJUSTING THE VOLUME Press the + control to increase volume. Press the — control to decrease volume. From the RSC, the speaker volume can not be set higher than the current volume radio setting. Once in headphone mode, the RSC volume controls will only change the headphone volume level (muting the speakers will not mute the headphones).

  • Page 52: Media Select

    Entertainment Systems MEDIA SELECT Push the MEDIA control to toggle between AM, FM1, FM2, tape, or CD changer (if equipped). MEMORY PRESET CONTROL Push the MEM control successively to allow rear sear passengers to scroll through the six memory presets in AM, FM1, or FM2. Push the MEM control in CD changer mode (if equipped) to advance to the next disc.

  • Page 53: Cd Changer

    Entertainment Systems CD CHANGER (IF EQUIPPED) The CD changer is located in the center console of your vehicle. 1. Slide the door to access the CD changer magazine. 2. Press EJECT to eject the magazine. 3. Turn the magazine (A) over. 4.
  • Page 54 Entertainment Systems If you pull too hard on the disc holder, the disc holder may come completely out of the magazine. If this happens, reinsert the disc holder back into the magazine while pressing on the lever (A). 5. Line up the CD with the groove of the disc holder.

  • Page 55: Cleaning Compact Discs

    The CD magazine may be inserted or ejected with the radio power on or off. ONLY use the magazine type supplied with the CD changer, other types will damage the unit. Keep the CD changer door closed. Coins and foreign objects will damage the CD player and void your audio system warranty.

  • Page 56: Radio Frequency Information

    Entertainment Systems CD units are designed to play commercially pressed 12 cm (4.75 in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.

  • Page 57: Radio Reception Factors

    RADIO RECEPTION FACTORS Three factors can affect radio reception: • Distance/strength. The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles). This range can be affected by “signal modulation.” Signal modulation is a process radio stations use to increase their strength/volume relative to other stations.

  • Page 58: Climate Controls

    Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM CLIMATE CONTROL SYSTEM Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode Selector Control Controls the direction of the airflow to the inside of the vehicle.

  • Page 59: Operating Tips

    The air condition operates in MAX A/C and when the A/C control is depressed. However, the air conditioning will only function if the outside temperature is about 4°C (40°F) or higher. Since the air conditioner removes considerable moisture from the air during operation, it is normal if clear water drips on the ground under the air conditioner drain while the system is working and even after you have stopped the vehicle.
  • Page 60 Climate Controls • To reduce humidity buildup inside the vehicle in warm weather conditions, don’t drive with the climate control system in the OFF position. • Under normal weather conditions, your vehicle’s climate control system should be left in any position other than the MAX A/C or OFF when the vehicle is parked.
  • Page 61 Climate Controls REAR PASSENGER AIR CONDITIONING SYSTEM (IF EQUIPPED) This system allows the rear seat occupants to adjust their air conditioning comfort level. The rear A/C fan speed control allows the rear passengers to control the volume of air that is distributed from the rear registers. REAR The rear seat A/C system is controlled from the main climate control system on the instrument panel.
  • Page 62 Climate Controls Turning the Rear A/C on 1. Set the main climate control rear fan control to Rear A/C; set the mode selector to any position (other than OFF), and depress the A/C control. OFF REAR A/C 1 2. Set the fan speed on the Rear A/C fan control to a number between 1–4 to regulate the airflow to the rear seat section.

  • Page 63: Electronic Automatic Temperature Control

    Climate Controls You can also set the Rear Fan Control on the main climate control system to Rear A/C and turn the Rear A/C Fan Control to 0. REAR For maximum cooling for the front seat passengers, set the rear fan switch to the OFF (0) position.

  • Page 64: Automatic Operation

    Climate Controls Turning the EATC system on OFF REAR 1 TEMP AUTOMATIC Press AUTOMATIC, any of the override controls or the fan speed control. The EATC system will only operate when the vehicle is running. Turning the EATC system off Press OFF.

  • Page 65: Temperature Selection

    Climate Controls If unusual conditions exist (i.e.-window fogging, etc.), the manual override controls allow you to select airflow locations and the fan control allows you to adjust fan speed as necessary. Temperature selection The display window indicates the ˚ selected temperature, function AUTO (AUTO or one of the override controls) and manual control of fan...
  • Page 66 Climate Controls The display will show indicate manual fan operation. To return to automatic fan operation, press AUTOMATIC. Manual override controls OFF REAR 1 TEMP AUTOMATIC The override controls allow you to: • manually control where the airflow is directed •...
  • Page 67 • (Defrost) - Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. If the temperature is about 4°C (40°F) or higher, the air conditioner will automatically dehumidify the air to reduce fogging. •...
  • Page 68 Climate Controls During periods of high humidity, vapor may be emitted from the air outlets when using the A/C system with outside air. This can be corrected by using MAX A/C to cool the vehicle. Rear seat heating Rear seat heating is provided through the floor ducts located under the front seats.
  • Page 69 • Do not place objects under the front seat that will interfere with the airflow to the rear seats. • Remove any snow, ice or leaves from the air intake area at the base of the windshield. • Do not place objects over the defroster outlets. These objects may block airflow and reduce visibility through your windshield.
  • Page 70 Climate Controls The rear A/C fan speed control allows rear passengers to control the volume of air that is distributed from the rear registers. REAR The rear seat A/C system is controlled from the main climate control system on the instrument panel. Ensure that the control is set to REAR A/C to engage the rear passenger compartment air conditioning system.
  • Page 71 Climate Controls Turning the Rear A/C on 1. Set the main climate control rear fan control to Rear A/C; set the mode selector to any position (other than OFF), and depress the A/C control. OFF REAR 1 TEMP AUTOMATIC 2. Set the fan speed on the Rear A/C fan control to a number between 1–4 to regulate the airflow to the rear seat section.

  • Page 72: Rear Window Defroster

    Climate Controls You can also turn the Rear Fan Control on the main climate control system to Rear A/C and turn the Rear A/C Fan Control to 0. REAR For maximum cooling for the front seat passengers, set the rear fan switch to the OFF (0) position.
  • Page 73 • Protects the climate control components from particle deposits The filter is located just in front of the windshield under the cowl grille on the passenger side of the vehicle. For more information, or to replace the filter, see your Ford, Lincoln or Mercury Dealer.

  • Page 74: Lights

    Lights HEADLAMP CONTROL Rotate the headlamp control clockwise to the first position to turn on the parking lamps. Rotate clockwise to the second position to also turn on the headlamps. Push the control to turn on the interior lamps. Push control again to turn off the interior lamps.

  • Page 75: High Beams

    High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel.

  • Page 76: Turn Signal Control

    Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. • In vehicles equipped with daytime running lights, use of the turn signals will shut off the highbeams in daytime driving. INTERIOR LAMPS Dome lamps The front dome lamp is located overhead between the driver and...

  • Page 77: Replacing Exterior Bulbs

    Lights Map lamps (if equipped) The map lamps are located on the overhead console and the side roof panels. Press the lamp lens to activate the lamps. BULBS Replacing exterior bulbs It is a good idea to check the operation of the following lights frequently: •...
  • Page 78 Lights Function Parking lamps (front) Headlamps License plate lamps High mount brakelamps Backup lamps Brakelamps Cornering lamps Side marker lamps Cargo liftgate lamp Dome lamps Turn signal lamps (front) Turn signal lamps (rear) Tail Lamps Personal reading lamps Stepwell lamps Glove compartment All replacement bulbs are clear in color except where noted.

  • Page 79: Replacing Headlamp Bulbs

    Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position, then open the hood. 2. Disconnect the electrical connector from the bulb by pulling rearward. 3. Remove the bulb retaining ring by rotating it counterclockwise (when viewed from the rear) to free it from the bulb socket, and slide the ring off the plastic base.
  • Page 80 Lights 1. With the flat side of the new bulb’s plastic base facing upward, insert the glass end of the bulb into the lamp assembly. Turn the bulb left or right to align the grooves in the plastic base with the tabs in the lamp assembly.

  • Page 81: Replacing High-Mount Brakelamp Bulbs

    Lights Replacing front turn signal lamp bulbs 1. Remove bulb socket by turning it counterclockwise, then slide it out of the lamp assembly. 2. Carefully pull bulb straight out of the socket and push in the new bulb. 3. To complete installation, follow removal procedure in the reverse order.

  • Page 82: Replacing License Plate Lamp Bulbs

    Lights Replacing tail lamp/backup/turn signal lamp bulbs 1. Open the liftgate to expose the lamp assemblies. 2. Remove the two screws from the lamp assembly. 3. Carefully remove the lamp assembly by pulling it rearward. 4. Rotate bulb socket counterclockwise and remove from lamp assembly.

  • Page 83: Driver Controls

    WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.

  • Page 84: Windshield Wiper Blades

    Driver Controls Press the washer control to activate the rear washer. The wiper will come on when the washer control is pressed, if it is not already on. Windshield wiper blades Check the wiper blades for wear at least twice a year or when they seem less effective.

  • Page 85: Changing The Wiper Blades

    Driver Controls Changing the wiper blades To replace the wiper blades: 1. Pull the wiper arm away from the windshield and lock into the service position. 2. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the...

  • Page 86: Illuminated Visor Mirror

    Driver Controls ILLUMINATED VISOR MIRROR To turn on the visor mirror lamps, lift the mirror cover. OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. Conversation mirror (if equipped) The conversation mirror allows the driver to view the rear seating area.

  • Page 87: Power Windows

    There are two auxiliary power points: • One is located on the instrument panel. • The second is located in the drivers side 2nd row trim panel. POWER WINDOWS • Press and hold the switch to open. • Pull up and hold the switch to close.
  • Page 88 Driver Controls One touch down • Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls except for the driver’s press the control.

  • Page 89: Power Side View Mirrors

    POWER SIDE VIEW MIRRORS The ignition must be in ACC or ON position to adjust the power side view mirrors. To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. 2. Move the control in the direction you wish to tilt the mirror.

  • Page 90: Speed Control

    Driver Controls SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not shift the gearshift lever into N (Neutral) with the speed control on.
  • Page 91 To set a speed • Press COAST/ SET. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.

  • Page 92: To Disengage Speed Control

    Driver Controls To set a lower set speed • Press and hold COAST/SET. Release the control when the desired speed is reached or • Press and release COAST/SET to operate the Tap-Down function. Each press will decrease the set speed by 1.6 km/h (1 mph) or •...

  • Page 93: Indicator Light

    • Press OFF. Pressing OFF will erase the previously programmed set speed. To return to a previously set speed • Press RES/ACCEL. For RES/ACCEL to operate, the vehicle speed must be faster than 48 km/h (30 mph). Indicator light • Standard analog instrument cluster The “CRUISE”...

  • Page 94: Steering Wheel Controls (If Equipped)

    Driver Controls STEERING WHEEL CONTROLS (IF EQUIPPED) These controls allow you to operate some audio control features. Audio control features In Radio mode: • Press NEXT to select the next preset station within the current radio band. In Tape mode: •...

  • Page 95: Homelink Universal Transceiver (If Equipped)

    • To close, press and hold the rear portion of the control. If the battery is disconnected, discharged, or a new battery is installed, the moon roof needs to be opened to the vent position to reset the moon roof positions. If you open and close the moon roof repeatedly, the moon roof motor may overheat and shut down for 45 seconds while the motor cools.
  • Page 96 Driver Controls Programming Do not program the HomeLink Universal Transceiver with the vehicle parked in the garage. Note: Your vehicle may require the ignition switch to be turned to the ACC position for programming and/or operation of the HomeLink . It is also recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for quicker training and accurate transmission of the radio-frequency signal.

  • Page 97: Gate Operator & Canadian Programming

    6. At the garage door opener receiver (motor-head unit) in the garage, locate the “learn” or “smart” button (usually near where the hanging antenna wire is attached to the unit). 7. Press and release the “learn” or “smart” button. (The name and color of the button may vary by manufacturer.) Note: There are 30 seconds in which to initiate step eight.

  • Page 98: Rolling Code Programming

    Driver Controls Operating the HomeLink Universal Transceiver To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.). For convenience, the hand-held transmitter of the device may also be used at any time.

  • Page 99: Erasing Homelink Buttons

    Erasing HomeLink buttons To erase the three programmed buttons (individual buttons cannot be erased): • Press and hold the two outer HomeLink buttons until the red indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds.
  • Page 100 Driver Controls You can select different features for the message center to display by using the message center controls located to the left of the instrument panel. Selectable features Select Press this control to select the following features: • OUTSIDE TEMP •...
  • Page 101 Message center functions Outside temp Press SELECT until the menu displays OUTSIDE TEMP. This will display the temperature of the air outside of your vehicle. The accurate temperature will be displayed after the vehicle has reached the outside temperature and is driven at speeds of 48 km/h (30 mph) or greater.

  • Page 102: Checking Your Highway Fuel Economy Using The Electronic Message Center Display

    Driver Controls Checking your highway fuel economy using the electronic message center display Use the following procedure will allow you to accurately monitor your actual highway fuel economy. This procedure requires the vehicle speed control system to be set to highway speeds and must be run only on suitable roadways where long distance speed control can be safely maintained.

  • Page 103: Positive Retention Floor Mat

    Driver Controls POSITIVE RETENTION FLOOR MAT Position the floor mat so that the eyelet is over the pointed end of the retention post. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. To remove the floor mat, reverse the installation procedure.
  • Page 104 Driver Controls Deactivating overdrive Press the Transmission Control Switch (TCS) located on the end of the gearshift lever. The O/D OFF indicator light will illuminate. The transaxle will operate in all gears except overdrive. To return to normal overdrive mode, press the Transmission Control Switch again.

  • Page 105: Cargo Area Features

    Cargo Area Features Rear Cargo net The cargo net helps stabilize lightweight objects in the cargo area. Attach the net to the anchors provided. The cargo restrained in the net must not exceed 22 kg (50 lbs.) or the net may not stay secured. The front and/or rear cargo nets are not designed to restrain objects during a collision or heavy braking.
  • Page 106 Driver Controls Front Cargo net (if equipped) The front cargo net can be used to hold small items between the front seats. To install the net, secure the hooks into the retainers located on the inboard base of the front seats. Parcel Shelf (if equipped) Your vehicle may be equipped with a 14 kg (30 lbs.) maximum capacity...

  • Page 107: Luggage Rack (If Equipped)

    All objects loaded on the cargo shelf MUST BE SECURED UNDER THE CARGO NET. The net is permanently attached to the cargo shelf. Do not load more than 14 kg (30 lbs.) on the parcel shelf. Do not load the parcel shelf through the liftgate glass. You MUST open the entire rear liftgate to gain access to the rear net retainers under the shelf.

  • Page 108: Locks And Security

    Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. POWER DOOR LOCKS Push control forward to unlock all UNLOCK...

  • Page 109: Remote Entry System

    Locks and Security Pull lock control out to engage the lock. Push control in to disengage childproof locks. REMOTE ENTRY SYSTEM This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 110: Unlocking The Doors

    Locks and Security Unlocking the doors Press this control to unlock the driver’s door. The interior lamps will illuminate and the parking and tail lamps will flash once. Press the control a second time within five seconds to unlock all doors.

  • Page 111: Replacing The Battery

    Replacing the battery The transmitter is powered by one coin type three-volt lithium battery. Typical operating range will allow you to be up to 10 meters (33 feet) away from your vehicle. A decrease in operating range can be caused by: •...

  • Page 112: Illuminated Entry

    Locks and Security Re-insert the key and turn to the ON position. Press any control on the first transmitter. The park lamps will flash twice to confirm the programming. To program additional (up to four) transmitters yourself, perform the following procedure. •...

  • Page 113: Arming The System

    Arming the system When unauthorized entry occurs, the system will flash headlamp lamps, tail lamps and the security indicator lamp, chirp the horn and disable the starting system. The system is ready to arm whenever the key is removed from the ignition.
  • Page 114 Locks and Security Disarming the anti-theft system Disarming an untriggered anti-theft system You can disarm the system by any of the following actions: • Unlock the doors by using your remote entry transmitter. • Unlock the doors with a key. Turn the key full travel (toward the rear of the vehicle) to make sure the alarm disarms.

  • Page 115: Seating And Safety Restraints

    Seating and Safety Restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
  • Page 116 Seating and Safety Restraints Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.

  • Page 117: Using The Manual Lumbar Support (If Equipped)

    Seating and Safety Restraints Using the manual lumbar support (if equipped) The lumbar control is located on the inboard side of the driver’s seat. Move the control up or down to adjust lumbar support. Adjusting the power seats (if equipped) The power seat controls are located on the outboard side of the seat.
  • Page 118 Seating and Safety Restraints • 6 way (driver seat) • 4 way (passenger seat) Rotate the vertical control to adjust the seatback. Memory seats and mirrors (if equipped) Some vehicles may only have the memory feature available for the seats. The memory seat control is located on the driver’s door panel.

  • Page 119: Rear Seats

    Seating and Safety Restraints 2. Press button 1 or 2 and hold for at least two seconds. The indicator light will stay on until the position is programmed. When the position has been programmed, the indicator light will flash three times. Repeat procedure for second position.
  • Page 120 Seating and Safety Restraints • 4 passenger vehicle (with third row seat in storage position) A. Cargo mat (if equipped) B. Narrow mats C. Sliding door mats, LH/RH • 5 passenger vehicle (second row seats removed) A. Cargo mat (if equipped) B.
  • Page 121 Seating and Safety Restraints B. Narrow mats • Two passenger vehicle (second row seats removed and third row seat stored in full forward position — if equipped with Rear Seat Entertainment System, the third row seat cannot be put into this position.) A.
  • Page 122 Seating and Safety Restraints Stowed cupholders The vehicle is equipped with cupholders that pull out from the 2nd row seat: • Bench seat - below center of the seat cushion • Bucket seat (driver’s side only) - inboard side of seat base Use only soft cups in the cupholder.
  • Page 123 Seating and Safety Restraints 2nd row bucket seats (if equipped) • Adjusting the left side bucket seat Pull control up to recline the seatback or fold the seatback flat. • Adjusting the right side (E-Z Entry Tip Slide) bucket seat The E-Z Entry Tip Slide seat allows for easier entry and exit to and from the 3rd row seat.
  • Page 124 Seating and Safety Restraints To exit the third row seat, pull up on the 3rd row access control. To return the seat to a seating position, move the seat rearward until the seat track locks. Then readjust the seatback. Lift handle to move the seat forward or backward.
  • Page 125 Seating and Safety Restraints Pull control up to flip seatback to a forward flat position. Adjusting 3rd row bench Pull control up to adjust seatback position. This control will also allow the seatback to be put in the forward flat position.
  • Page 126 Seating and Safety Restraints The entire seat can be moved to four seating positions and two storage positions. Before rearranging the seats, remove any floor mats that might be in the way, see Removable floor mats in this chapter for instructions on placement of floor mats.
  • Page 127 Seating and Safety Restraints To move the seat to another seating or storage position: 1. Lift control (A) to release the seat cushion and flip the cushion up. The seat cushion must be moved to the storage position before the seat can be moved along the track.
  • Page 128 Seating and Safety Restraints After sliding the seat, check to ensure that both sides of the seat are locked in position. This must be done before the vehicle is put into motion in order to prevent unintended movement of the seat. Every time you adjust any seat, check to be sure that it is properly latched in the lock position of both seat tracks.

  • Page 129: Safety Restraints

    Seating and Safety Restraints To install the seat: The bucket seats are not interchangeable due to the locations of the seat anchors on the floor of the vehicle. Each seat must be installed in its original position. 1. Position the seat in the vehicle. 2.

  • Page 130: Combination Lap And Shoulder Belts

    Seating and Safety Restraints In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.

  • Page 131: Vehicle Sensitive Mode

    Seating and Safety Restraints Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 8 km/h (5 mph) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers.

  • Page 132: How To Disengage The Automatic Locking Mode

    Seating and Safety Restraints • Grasp the shoulder portion and pull downward until the entire belt is extracted. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.

  • Page 133: Safety Belt Pretensioner

    Seating and Safety Restraints Safety belt pretensioner Your vehicle is equipped with safety belt pretensioners at the driver and front outboard passenger seating positions. The safety belt pretensioners are designed to activate only when the safety belts are fastened during certain frontal or near-frontal collisions. A safety belt pretensioner tightens the webbing of the lap and shoulder belts during a crash so that they fit more snugly.

  • Page 134: Lap Belts

    Seating and Safety Restraints Lap belts Adjusting the center lap belt The lap belt does not adjust automatically. The lap belt should fit snugly and as low as possible around the hips, not across the waist. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from).

  • Page 135: Safety Belt Warning Light And Indicator Chime

    Seating and Safety Restraints Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position...

  • Page 136: Air Bags

    Seating and Safety Restraints and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor and a qualified technician finds that the belts do not show damage and continue to operate properly, they do not need to be replaced.

  • Page 137: Important Supplemental Restraint System (Srs) Precautions

    Seating and Safety Restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim covering the air bag...

  • Page 138: Children And Air Bags

    Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame, bumper, front end body structure and tow hooks may affect the performance of the air bag sensors increasing the risk of injury.

  • Page 139: How Does The Air Bag Supplemental Restraint System Work

    Seating and Safety Restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation.

  • Page 140: Determining If The System Is Operational

    Seating and Safety Restraints If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.

  • Page 141: Important Child Restraint Precautions

    Seating and Safety Restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Air bag supplemental restraint system (SRS) in this chapter for special instructions about using air bags. Important child restraint precautions You are required by law to use safety restraints for children in the U.S.

  • Page 142: Child Booster Seats

    Seating and Safety Restraints Child booster seats Children outgrow a typical convertible or toddler seat when they weigh 40 pounds and are around 4 years of age. Although the lap/shoulder belt will provide some protection, these children are still too small for lap/shoulder belts to fit properly, which could increase the risk of serious injury.
  • Page 143 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...

  • Page 144: Safety Seats For Children

    Seating and Safety Restraints The importance of shoulder belts Using a booster without a shoulder belt increases the risk of a child’s head hitting a hard surface in a collision. For this reason, you should never use a booster seat with a lap belt only. It is best to use a booster seat with lap/shoulder belts in the back seat- the safest place for children to ride.
  • Page 145 Seating and Safety Restraints When installing a child safety seat: • Review and follow the information presented in the Air Bag Supplemental Restraint System section in this chapter. • Use the correct safety belt buckle for that seating position. • Insert the belt tongue into the proper buckle until you hear a snap and feel it latch.
  • Page 146 Seating and Safety Restraints Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
  • Page 147 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
  • Page 148 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.

  • Page 149: Attaching Safety Seats With Tether Straps

    Seating and Safety Restraints 5. Push down on the child seat while pulling on the loose end of the lap belt webbing to tighten the belt. 6. Before placing the child into the child seat, forcibly tilt the child seat from side to side and in forward direction to make sure that the seat is securely held in place.
  • Page 150 Seating and Safety Restraints Second row seats 1. Position the child safety seat on the seat cushion. 2. Route the child safety seat tether strap over the back of the seat, under the head restraint, and between the head restraint posts. If the top of the child seat hits the head restraint, try raising the head restraint to allow the child seat to...
  • Page 151 Seating and Safety Restraints 4. Rotate the tether strap. 5. Clip the tether strap to the seat tether slot bracket at the lower rear portion of the seatback. If the tether strap is clipped incorrectly (as shown) the child safety seat may not be retained properly in the event of a collision.

  • Page 152: Third Row Seats

    Seating and Safety Restraints 6. Rotate the tether strap clip. 7. Refer to the instructions in this section under Installing child safety seats in combination lap and shoulder belt seating positions to secure the child safety seat. 8. Tighten the child safety seat tether strap according to the manufacturer’s instructions.

  • Page 153: Attaching Safety Seats With Latch (Lower Anchors And Tethers For Children) Attachments For Child Seat Anchors

    Seating and Safety Restraints Attaching safety seats with LATCH (Lower Anchors and Tethers for CHildren) attachments for child seat anchors Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle. This type of child seat eliminates the need to use seat belts to attach the child seat.
  • Page 154 Seating and Safety Restraints The lower anchors for child seat installation are located at the rear section of the rear seat between the cushion and seat back. The LATCH anchors are below the locator symbols on the seat back. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments.

  • Page 155: Driving

    STARTING Positions of the ignition 1. OFF/LOCK, shuts off the engine and all accessories/locks the steering wheel, gearshift lever and allows key removal. 2. ACC, allows the electrical accessories such as the radio to operate while the engine is not running.

  • Page 156: Important Safety Precautions

    Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs higher than normal in order to warm the engine.

  • Page 157: Starting The Engine

    • steering wheel is turned when getting in or out of the vehicle RPM x 1000 CRUISE ˚F ˚C MILES/BAL L/100 km OUTSIDE TEMP INST ECONOMY AVG. ECONOMY TO EMPTY BRAKE Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced.

  • Page 158: Guarding Against Exhaust Fumes

    Driving seconds and try again. If the engine does not start in two attempts, Press the accelerator pedal all the way to floor and hold. Turn the key to START position. 4. When the engine starts, release the key, then release the accelerator pedal gradually as the engine speeds up.
  • Page 159 Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied. Such noises are usually heard during the first few brake applications in the morning;...

  • Page 160: Abs Warning Lamp

    Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the...
  • Page 161 The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released. Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park). The parking brake is not recommended to stop a moving vehicle.

  • Page 162: Automatic Transaxle Operation

    Driving • Uneven vehicle loading • High crown in center of road • High crosswinds • Wheels out of alignment • Loose or worn suspension components AUTOMATIC TRANSAXLE OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed.

  • Page 163: Understanding Gearshift Positions

    If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your dealer or a qualified service technician. Understanding gearshift positions Your automatic transaxle electronically controls the shift feel by using an adaptive learning strategy.
  • Page 164 Driving Overdrive — column mounted gearshift with O/D off switch The Overdrive position with the O/D R N D 2 1 OFF switch not depressed is the normal driving position for this automatic overdrive transaxle. When your vehicle cruises at a constant speed for any length of time, this fourth gear will increase your fuel economy.
  • Page 165 When to use D (Drive) or press the O/D OFF switch You will notice that there is only one drive position on your gearshift indicator (instead of Drive and Overdrive). However, you will find a control labeled OVERDRIVE located on the gearshift lever. Push in the switch and the O/D OFF light in the instrument cluster will illuminate.

  • Page 166: Driving With An Automatic Overdrive Transaxle

    Driving When parking, do not use the gearshift in place of the parking brake. Always set the parking brake fully and make sure that the gearshift is securely latched in Park (P). Turn off the ignition whenever you leave your vehicle. Never leave your vehicle unattended while it is running.

  • Page 167: Vehicle Loading

    Once through the water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes. Drying can be improved by moving your vehicle slowly while applying light pressure on the brake pedal. Driving through deep water where the transaxle is submerged may allow water into the transaxle and cause internal damage.

  • Page 168: Calculating The Load Your Vehicle Can Carry/Tow

    Driving Do not exceed the GVWR or the GAWR specified on the certification label. Do not use replacement tires with lower load carrying capacities than the originals because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the originals do not increase the GVWR and GAWR limitations.

  • Page 169: Trailer Towing

    TRAILER TOWING The trailer towing table shows the maximum allowable maximum GCWR and trailer weight. Maximum GCWR - kg (lbs.) 3628 ( 8000) Do not exceed the GVWR or the GAWR specified on the certification label. Towing trailers beyond the maximum recommended gross trailer weight could result in engine damage, transmission/axle damage, structural damage, loss of control, and personal injury.

  • Page 170: Preparing To Tow

    Driving Trailer Tow Prep Package (if equipped) The trailer tow prep package on your vehicle (if equipped) includes: • Heavy duty battery • Conventional size spare tire • Trailer tow module and jumper harness Using the jumper harness (if equipped) •...
  • Page 171 Do not attach safety chains to the bumper. Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications. The trailer brakes must meet local and Federal regulations. Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system.

  • Page 172: Recreational Towing

    Driving • Allow more distance for stopping with a trailer attached. • If you are driving down a long or steep hill, shift to a lower gear. Do not apply the brakes continuously, as they may overheat and become less effective. •...

  • Page 173: Roadside Emergencies

    In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Owner Information Guide in the glove compartment.

  • Page 174: Roadside Coverage Beyond Basic Warranty

    If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who need to obtain reimbursement information, call 1–800–665–2006.

  • Page 175: Fuses And Relays

    Roadside Emergencies The fuel pump shut-off switch is located in the driver’s foot well, behind the kick panel. The reset button (RED) for the fuel pump shut-off switch is accessible through an opening in the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1.

  • Page 176: Standard Fuse Amperage Rating And Color

    — — — — For fuses greater than 80A, please see your Ford or Lincoln Mercury Dealer. Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses.
  • Page 177 The fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating Corner Lamps Heated Seat 7.5A I/P Illum 7.5A Electron Tail Lamp Air Bag Audio Roadside Emergencies Passenger Compartment Fuse Panel Description Front Exterior Lamps Heated Seats (not available) Interior Panel Illumination Lamps Transaxle Control Module (TCM), Electronic Automatic Temperature Control (EATC)
  • Page 178 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating Eng Cont Room Lamp Mirror 7.5A Stop Lamp Cigar Lighter Hazard RR Pwr Plug Rear Blower Front Wiper Rear Blower Rear Wiper O2 Sensor 7.5A Audio/Video Turn Audio Amp Front Blower Eng Cont 7.5A Relays A/C Cont...

  • Page 179: Power Distribution Box

    Fuse/Relay Fuse Amp Location Rating Electron Rear Defog Front Blower Rear Defog — — Heated Mirror Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads.
  • Page 180 Roadside Emergencies USE SPECIFIED FUSES OR FUSIBLE LINKS ONLY 100A 140A MAIN The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating Fog Lamp 7.5A* FUEL PUMP 15A* 10A* 7.5A* 7.5A* ECCS 10A* — — — — 10A* 20A* 7.5A HORN...
  • Page 181 Fuse/Relay Fuse Amp Location Rating — — H/L RH 15A* HORN 15A* — — H/L LH 15A* — — — — 40A** — — PWR WND 30A** RAD FAN LO 20A** — — IGN SW 30A** — — RAD FAN 75A** FR BLW 65A**...

  • Page 182: Relay Box

    Roadside Emergencies Relay box The relay box is located in the engine compartment in front of the battery. The relays are coded as follows: Relay location Description Start Inhibit Relay Fuel Pump Relay Bulb Check Relay Fog Lamp Anti-theft Relay Horn Relay A/C Relay CHANGING THE TIRES...

  • Page 183: Temporary Spare Tire Information

    Temporary spare tire information Your vehicle may have a temporary or conventional size spare tire. The temporary spare tire for your vehicle is labeled as such. It is smaller than a regular tire and is designed for emergency use only. Replace this tire with a full-size tire as soon as possible.

  • Page 184: Removing The Spare Tire

    Roadside Emergencies Removing the spare tire 1. Open the liftgate, locate the U-shaped slits in the carpet, and flip up the piece of carpet to expose the hex nut. 2. Insert the lug nut wrench on the hex nut in cargo floor. 3.

  • Page 185: Tire Change Procedure

    2. Install the retainer through the wheel center and slide the wheel under the vehicle. 3. Turn the wrench clockwise until the tire is raised to its original position underneath the vehicle. The hex nut ratchets when the tire is raised to the stowed position.
  • Page 186 Roadside Emergencies 1. Park on a level surface, activate hazard flashers and set parking brake. PUSH RELEASE 2. Place gearshift lever in P (Park), turn engine OFF, and block the diagonally opposite wheel. 3. Remove the spare tire and jack assembly.
  • Page 187 Jacking notches are located approximately six inches rearward of the front wheels and twelve inches foward of the rear wheels. 6. Locate the jack notch closest to the tire you are changing, then place the jack on the frame rail directly behind the notch.

  • Page 188: Jump Starting

    Roadside Emergencies JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Batteries contain sulfuric acid which can burn skin, eyes, and clothing, if contacted.
  • Page 189 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
  • Page 190 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.

  • Page 191: Jump Starting

    Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
  • Page 192 Roadside Emergencies 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery.

  • Page 193: Wrecker Towing

    Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.

  • Page 194: Customer Assistance

    Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
  • Page 195 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) www.ford.ca In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: • Your telephone number (home and business).

  • Page 196: Ford Extended Service Plan

    Warranty expires. You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs. Ford ESP also offers reimbursement benefits for towing and rental coverage.

  • Page 197: The Dispute Settlement Board

    What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...

  • Page 198: Board Membership

    • A Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...

  • Page 199: Oral Presentations

    Customer Assistance Oral presentations If you would like to make an oral presentation, indicate YES to question 6 on the application. While it is your right to make an oral presentation before the Board, this is not a requirement and the Board will decide the case whether or not an oral presentation is made.

  • Page 200: Utilizing The Mediation/Arbitration

    Customer Assistance UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).

  • Page 201: Ordering Additional Owner's Literature

    Customer Assistance 1555 Fairlane Drive Fairlane Business Park #3 Allen Park, Michigan 48101 U.S.A. Telephone: (313) 594-4857 FAX: (313) 390-0804 If you are in another foreign country, contact the nearest Ford dealership. If the dealership employees cannot help you, they can direct you to the nearest Ford affiliate office.

  • Page 202: Reporting Safety Defects (U.s. Only)

    Customer Assistance California Civil Code Section 1793.22(b) presumes that the manufacturer has had a reasonable number of attempts to conform the vehicle to its applicable express warranties if, within the first 18 months of ownership of a new vehicle or the first 29 000 km (18 000 miles), whichever occurs first: 1.

  • Page 203: Cleaning

    WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.

  • Page 204: Paint Chips

    Cleaning PAINT CHIPS Your dealer has touch-up paint and sprays to match your vehicle’s color. Take your color code (printed on a sticker in the driver’s door jam) to your dealer to ensure you get the correct color. • Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips.

  • Page 205: Plastic (Non-Painted) Exterior Parts

    • Cover the highlighted areas to prevent water damage when cleaning the engine. • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your dealer.

  • Page 206: Windows And Wiper Blades

    Cleaning WINDOWS AND WIPER BLADES The windshield, rear window and wiper blades should be cleaned regularly. If the wiper does not wipe properly, substances on the windshield, rear window or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, tree sap, or other organic contamination.

  • Page 207: Leather Seats (If Equipped)

    INTERIOR For fabric, carpets, cloth seats and safety belts: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Ford Extra Strength Upholstery Cleaner (E8AZ-19523–AA). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).

  • Page 208: Ford, Lincoln And Mercury Car Care Products

    Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.

  • Page 209: Maintenance And Specifications

    Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.

  • Page 210: Opening The Hood

    Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.

  • Page 211: Engine Compartment

    Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.3L V6 engine 1. Power distribution box 2. Brake fluid reservoir 3. Air filter assembly 4. Battery 5. Relay box 6. Engine oil filler cap 7. Engine oil dipstick 8. Windshield washer fluid reservoir 9.

  • Page 212: Windshield Washer Fluid

    Maintenance and Specifications WINDSHIELD WASHER FLUID Windshield washer fluid Check the washer fluid whenever you stop for fuel. The reservoir is highlighted with a symbol. Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely.
  • Page 213 Maintenance and Specifications 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan. 3. Set the parking brake and ensure the gearshift is securely latched in P. 4. Open the hood. Protect yourself from engine heat. 5.

  • Page 214: Adding Engine Oil

    Maintenance and Specifications Adding engine oil 1. Check the engine oil. For instructions, refer to Checking the engine oil in this chapter. 2. If the engine oil level is not within the normal range, add only certified engine oil of the recommended viscosity. Remove the engine oil filler cap and use a funnel to pour the engine oil into the opening.

  • Page 215: Battery

    Maintenance and Specifications Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced. It is recommended you use the appropriate Motorcraft oil filter (or another brand meeting Ford specifications) for your engine application.
  • Page 216 Maintenance and Specifications When the battery is disconnected or a new battery installed, the transmission must learn its adaptive strategy. As a result of this, the transmission may shift firmly. This operation is considered normal and will fully update transmission operation to its optimum shift feel. Batteries normally produce explosive gases which can cause personal injury.

  • Page 217: Engine Coolant

    Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the scheduled maintenance guide.

  • Page 218: Adding Engine Coolant

    Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
  • Page 219 Maintenance and Specifications • DO NOT USE alcohol or methanol antifreeze or any engine coolants mixed with alcohol or methanol antifreeze. • DO NOT USE supplemental coolant additives in your vehicle. These additives may harm your engine’s cooling system. • DO NOT MIX recycled coolant and conventional coolant together in your vehicle.

  • Page 220: Recycled Engine Coolant

    Maintenance and Specifications If you must remove the radiator cap, follow these steps to avoid personal injury: 1. Before you remove the cap, turn the engine off and let it cool. 2. When the engine is cool, wrap a thick cloth around the cap. Slowly turn cap counterclockwise until pressure begins to release.

  • Page 221: What You Should Know About Automotive Fuels

    Maintenance and Specifications If you drive in extremely hot climates: • It is still necessary to maintain the coolant concentration above 40%. • NEVER decrease the coolant concentration below 40%. • Decreased engine coolant concentrations below 40% will decrease the corrosion protection characteristics of the engine coolant and may cause engine damage.
  • Page 222 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.

  • Page 223: Fuel Filler Cap

    Maintenance and Specifications Use the following guidelines to avoid static build-up when filling an ungrounded fuel container: • Place approved fuel container on the ground. • DO NOT fill a fuel container while it is in the vehicle (including the cargo area).

  • Page 224: Choosing The Right Fuel

    Maintenance and Specifications If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury.

  • Page 225: Cleaner Air

    Maintenance and Specifications Many of the world’s automakers issued the World-wide Fuel Charter that recommends gasoline specifications to provide improved performance and emission control system protection for your vehicle. Gasolines that meet the World-wide Fuel Charter should be used when available.

  • Page 226: Filling The Tank

    Maintenance and Specifications possible. Fuel expense, frequency of fill-ups or fuel gauge readings are NOT accurate as a measure of fuel economy. We do not recommend taking fuel economy measurements during the first 1 600 km (1 000 miles) of driving (engine break-in period). You will get a more accurate measurement after 3 000 km–5 000 km (2 000 miles-3 000 miles).

  • Page 227: Driving Style - Good Driving And Fuel Economy Habits

    Maintenance and Specifications 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading. 4. Subtract your initial odometer reading from the current odometer reading. 5. Follow one of the simple calculations in order to determine fuel economy: Multiply liters used by 100, then divide by total kilometers traveled.

  • Page 228: Maintenance

    Maintenance and Specifications • Resting your foot on the brake pedal while driving may reduce fuel economy. • Combine errands and minimize stop-and-go driving. Maintenance • Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy.

  • Page 229: Emission Control System

    Maintenance and Specifications EMISSION CONTROL SYSTEM Your vehicle is equipped with various emission control components and a catalytic converter which will enable your vehicle to comply with applicable exhaust emission standards. To make sure that the catalytic converter and other emission control components continue to work properly: •...

  • Page 230: Readiness For Inspection/Maintenance (I/M) Testing

    Maintenance and Specifications Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system. If your “Check Engine/Service Engine Soon” light is on, refer to the description in the Warning lights and chimes section of the Instrument Cluster chapter.

  • Page 231: Checking And Adding Power Steering Fluid

    Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be...

  • Page 232: Transmission Fluid

    Maintenance and Specifications 2. Visually inspect the fluid level. 3. If necessary, add brake fluid from a clean un-opened container until the level reaches MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specification ESA-M6C25–A.

  • Page 233: Low Fluid Level

    Maintenance and Specifications 1. Drive the vehicle 30 km (20 miles) or until it reaches normal operating temperature. 2. Park the vehicle on a level surface and engage the parking brake. 3. With the parking brake engaged and your foot on the brake pedal, start the engine and move the gearshift lever through all of the gear ranges.

  • Page 234: Adjusting Automatic Transmission Fluid Levels

    Maintenance and Specifications Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used. The type of fluid used is normally indicated on the dipstick and also in the Lubricant specifications section in this chapter. Use of a non-approved automatic transmission fluid may cause internal transaxle component damage.

  • Page 235: Information About Uniform Tire Quality Grading

    Maintenance and Specifications 4. Install a new air filter element. Be careful not to crimp the filter element edges between the air filter housing and cover. This could cause filter damage and allow unmetered air to enter the engine if not properly seated.

  • Page 236: Checking The Tire Pressure

    Maintenance and Specifications Traction AA A B C The traction grades, from highest to lowest are AA, A, B, and C. The grades represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete.
  • Page 237 Maintenance and Specifications Tire rotation Because your vehicle’s tires perform different jobs, they often wear differently. To make sure your tires wear evenly and last longer, rotate them as indicated in the scheduled maintenance guide. If you notice that the tires wear unevenly, have them checked. •...

  • Page 238: Snow Tires And Chains

    Maintenance and Specifications Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, “Touring”, etc.), as originally offered by Ford. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier for the driver to lose control and roll over.

  • Page 239: Part Numbers

    Maintenance and Specifications MOTORCRAFT PART NUMBERS Component Engine air filter element Cabin air filter Fuel filter Battery Oil filter PCV Valve Spark plugs Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. REFILL CAPACITIES Fluid Ford Part Name Engine oil (includes Motorcraft SAE 5W-30 filter change)

  • Page 240: Lubricant Specifications

    Maintenance and Specifications LUBRICANT SPECIFICATIONS Item Ford part name Brake fluid Motorcraft High Performance DOT 3 Motor Vehicle Brake Fluid Door Silicone weatherstrips Lubricant Engine coolant Motorcraft Premium Engine Coolant (green colored) Engine oil Motorcraft SAE 5W-30 Super Premium Motor Door latch, Multi-Purpose hood...

  • Page 241: Engine Data

    Maintenance and Specifications Item Ford part name Disc brake Motorcraft caliper rails Silicone Brake Caliper Grease and Dielectric Compound Constant Motorcraft CV velocity joints Joint Grease (High Temp.) Windshield Ultra-clear washer fluid Windshield Washer Concentrate DO NOT USE Motorcraft Extended Life Engine Coolant VC-2 (CXC-209 in Canada) meeting Ford specification WSS-M97B44–D (orange in color).

  • Page 242: Vehicle Dimensions

    Maintenance and Specifications VEHICLE DIMENSIONS Vehicle dimensions (1) Overall length (2) Overall width (3) Overall height (with luggage rack) (4) Wheelbase (5) Track - Front (5) Track - Rear mm (in) 4 933.4 (194.2) 1 902.5 (74.9) 1 780.5 (70.1) 2 849.9 (112.2) 1 610.4 (63.4) 1 610.4 (63.4)

  • Page 243: Certification Label

    Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.

  • Page 244: Vehicle Identification Number

    Maintenance and Specifications Vehicle identification number The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel and under the liftgate scuff plate at the bottom of the liftgate opening. (Please note that in the graphic XXXX is representative of your vehicle identification number.)

  • Page 245: Accessories

    FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln, Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
  • Page 246 Accessories Travel equipment Ash cup Auto headlamps with daytime running lights (DRL) Cargo box (rooftop luggage box) Cigarette lighter element Console Framed luggage covers HomeLink (in sun visor) Molded running boards Removable luggage basket Running boards, child step Soft luggage cover Track rider bars Track rider bar adaptors Trailer hitch (Class II)
  • Page 247 For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety compliance certification label).

  • Page 248: Index

    Index ABS (see Brakes) ...159 Accessory delay ...88 Air bag supplemental restraint system ...136–137 and child safety seats ...138 description ...137 disposal ...140 driver air bag ...139 indicator light ...12, 140 operation ...139 passenger air bag ...139 Air cleaner filter ...234, 239 Air conditioning automatic temperature control system ...63...
  • Page 249 in front seat ...146 in rear seat ...146, 148 tether anchorage hardware ...150 Cleaning your vehicle engine compartment ...204 exterior ...207 instrument panel ...206 interior ...207 plastic parts ...205 washing ...203 waxing ...203 wheels ...204 wiper blades ...206 woodtone trim ...205 Climate control (see Air conditioning or Heating) ...58, 63 Clock ...24, 33, 44...
  • Page 250 Index filter, specifications ...214, 239 recommendations ...214 refill capacities ...239 specifications ...240–241 Exhaust fumes ...158 Floor mats ...103 Fluid capacities ...239 Foglamps ...74 Fuel ...221 calculating fuel economy ...225 cap ...223 capacity ...239 choosing the right fuel ...224 comparisons with EPA fuel economy estimates ...228 detergent in fuel ...225 filling your vehicle with...
  • Page 251 Ignition ...155, 241–242 Infant seats (see Safety seats) ...144 Inspection/maintenance (I/M) testing ...230 Instrument panel cleaning ...206 cluster ...10 lighting up panel and interior ...75 Jack ...182 positioning ...182 storage ...182 Jump-starting your vehicle ...188 Keys key in ignition chime ...15 positions of the ignition ...155 Lamps autolamp system ...74...
  • Page 252 Index Oil (see Engine oil) ...212 Overdrive ...103, 166 Panic alarm feature, remote entry system ...110 Parking brake ...160 Parts (see Motorcraft parts) ...239 Power distribution box (see Fuses) ...179 Power door locks ...108 Power mirrors ...89 Power point ...86 Power steering ...161 fluid, checking and adding ...231 fluid, refill capacity ...239...
  • Page 253 changing ...182–183, 185 checking the pressure ...236 replacing ...237 rotating ...237 snow tires and chains ...238 tire grades ...236 treadwear ...235 Towing ...169 recreational towing ...172 trailer towing ...169 wrecker ...193 Transaxle fluid, refill capacities ...239 lubricant specifications ...241 Transmission ...162 fluid, checking and adding (automatic) ...232 lubricant specifications ...240...

Table of Contents
