Lincoln 2000 Continental Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Before driving
Starting and driving
Servicing
All rights reserved. Reproduction by any means, electronic or mechanical including
photocopying, recording or by any information storage and retrieval system or translation
in whole or part is not permitted without written authorization from Ford Motor Company.
Ford may change the contents without notice and without incurring obligation.
Copyright © 1999 Ford Motor Company
Contents
2
6
22
92
120
125
141
162
209
214
225
226
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000 Continental and is the answer not in the manual?

Questions and answers

Carla
August 5, 2025

Where is the pull chord for opening fuel door located in 2000 Lincoln continental. I know it is in the trunk but where and what does it look like?

0

Related Manuals for Lincoln 2000 Continental

Summary of Contents for Lincoln 2000 Continental

  • Page 1: Table Of Contents

    Before driving Introduction Instrumentation Controls and features Seating and safety restraints Starting and driving Starting Driving Roadside emergencies Servicing Maintenance and care Capacities and specifications Customer assistance Reporting safety defects Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.

  • Page 2: Introduction

    Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning Engine exhaust, some if its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer, or birth defects or other reproductive harm. ICONS Indicates a safety alert.

  • Page 3: Breaking-In Your Vehicle

    Introduction WARNINGS Warnings provide information which may reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment. BREAKING-IN YOUR VEHICLE There are no particular breaking-in rules for your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is necessary to give the moving parts a chance to break in.
  • Page 4 Introduction These are some of the symbols you may see on your vehicle. Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Power Windows Front/Rear...
  • Page 5 Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Vehicle Symbol Glossary Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant Temperature Battery Battery Acid...

  • Page 6: Instrumentation

    Instrumentation Headlamp control (pg. 22) Turn signal and wiper/washer control (pg. 48) LIGHTS AUTO LAMP Instrument panel Auto lamp dimmer switch (pg. 23) (pg. 23) Instrument cluster (pg. 8) – TURN ON HEAD LAMPS FILL ON RIGHT RPMx1000 SERVICE ENGINE SOON BRAKE Speed control...

  • Page 7: Climate Control System

    Electronic sound system controls* (pg. 48) Message Center (pg. 14) SYSTEM DRIVER ID MENU SELECT VEHICLE HANDLING TRIP DISPLAY RESET DTE ECON BASS TREB FADE PUSH ON TAPE SEEK TUNE SCAN AUTO MUTE SIDE 1 2 COMP AUTO BACK BACK BOTH BOTH Heated seat control...

  • Page 8: Warning Lights And Chimes

    Instrumentation WARNING LIGHTS AND CHIMES – TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON BRAKE Service engine soon Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II).
  • Page 9 These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the gas cap. After three driving cycles without these or any other temporary malfunctions present, the Service Engine Soon light should turn off.
  • Page 10 Instrumentation Brake system warning Momentarily illuminates when the ignition is turned to the ON position. Also illuminates if the BRAKE parking brake is engaged. If the brake warning lamp does not illuminate at these times, seek service immediately. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately.
  • Page 11 Turn on headlamps (if equipped) Illuminates to remind the driver to turn the headlamps on when: the daytime running lamps are on (if equipped) the autolamps are off the autolamp sensor determines it is night time Charging system Illuminates when the ignition is turned to the ON position and the engine is off.
  • Page 12 Instrumentation Supplemental restraint system (SRS) warning chime For information on the SRS warning chime, refer to the Seating and safety restraints chapter. Key-in-ignition warning chime Sounds when the key is left in the ignition in the OFF/LOCK or ACC position and the driver’s door is opened. Headlamps on warning chime Sounds when the headlamps or parking lamps are on, the ignition is off (and the key is not in the ignition) and the driver’s door is opened.
  • Page 13 Speedometer Indicates the current vehicle speed. Odometer The odometer is located in the message center. It registers the total kilometers (miles) of the vehicle. Pressing the E/M control (if equipped) will alternate between English (miles) and Metric (kilometers) measurements. Tachometer Indicates the engine speed in revolutions per minute.
  • Page 14 Instrumentation This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level the gauge indication will not be accurate. ELECTRONIC MESSAGE CENTER The electronic message center only works when the ignition is in the ON position.
  • Page 15 Basic operation of Memory Profile System In order for the system to be able to store or recall an individual’s seat and mirror position preferences, the Memory Profile must first recognize who will be driving the vehicle. Drivers may identify themselves to the system one of two ways: Pressing the unlock control on the appropriate remote...
  • Page 16 Instrumentation If Memory position 1 or Memory position 2 wishes to make temporary changes to their seat or outside mirror positions without affecting their preferred positions they may do so by: Using the switch on the back of the remote transmitter to turn the Memory Profile System OFF prior to pressing the unlock control on the remote transmitter or...
  • Page 17 fuel level distance to empty traction control ride control System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems. The message center will display the last selected feature if there are no more warning messages. This allows you to use the full functionality of the message center after you acknowledge the warning by pressing the RESET control and clearing the warning message.
  • Page 18 Instrumentation Gear Display Data ERR Brake Lamp Out Check Traction Control Check Ride Control Trunk Ajar Check Steering Assist Low Washer Fluid Air Leveling Disabled Tail Lamp Out Check FRT Turn Lamps Turn on Headlamps Warning messages that have been reset are divided into two categories: They will reappear on the display ten minutes from the reset.
  • Page 19 MENU Press this control to change various convenience settings throughout the vehicle. Each press of the MENU control will display the following: Traction control (returns to “ON” everytime vehicle is started). Express window (completely goes down with one touch on the power switch).
  • Page 20 Instrumentation TRIP Press this control to display the first of two trip odometers. Press it again to display the second trip odometer. To reset the displayed trip odometer, press the RESET control. DISPLAY Press this control to turn the message center display off. Press it again to turn the display on.
  • Page 21 The DTE function will flash for 5 seconds and sound a tone for 1 second when you have approximately: 40 km (25 miles) 16 km (10 miles) DTE is calculated using a running average fuel economy initialized by the factory. This value is not the same as the average fuel economy display. The running average fuel economy is based on more than 800 kilometers (500 miles) of driving history, and is reinitialized if the battery is disconnected.

  • Page 22: Controls And Features

    Controls and features HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps only. Rotate to the second position to also turn on the headlamps. The exterior lamps will illuminate when the ignition is ON and the windshield wiper control is in the interval, LO or HI position.
  • Page 23 Flash to pass Pull toward you to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation. Push up to brighten. Push down to dim. AUTOLAMP CONTROL The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.

  • Page 24: Climate Control System

    Controls and features CLIMATE CONTROL SYSTEM Electronic Automatic Temperature Control (EATC) system The EATC system will maintain a selected temperature and automatically control airflow. You can override automatic operation with any of the override controls, the fan speed control or the steering wheel controls (if equipped).
  • Page 25 Controls and features If unusual conditions exist (i.e.-window fogging, etc.), the manual override controls allow you to select airflow locations and the fan control allows you to adjust fan speed as necessary. Temperature selection The display window indicates the ˚ selected temperature, function (AUTO or one of the override controls) and manual control of fan...
  • Page 26 Controls and features Fan speed ( When AUTO is pressed, fan speed is adjusted automatically for existing conditions. You can override fan speed at any time. To control fan speed manually, press the fan control or the steering wheel fan speed control to cancel automatic AUTO fan speed operation.
  • Page 27 Controls and features MAX A/C-Uses recirculated air to cool the vehicle. The temperature will display 16°C (60°F). To exit, press AUTOMATIC or any other override controls. MAX A/C is noisier than normal A/C but more economical and will cool the inside of the vehicle faster. Airflow is from the instrument panel registers.
  • Page 28 Controls and features Displaying outside temperature Press EXT to display the outside air temperature. It will be displayed until EXT is pressed again. If the selected temperature is changed while the outside temperature is displayed, the new temperature will be displayed for four seconds after it is changed, then the outside temperature will return to the window.
  • Page 29 If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open. This will force most of the hot, stale air out of the vehicle. Then operate the air conditioner as you would normally.

  • Page 30: Using Your Audio System

    Controls and features CLOCK Press to increase the time displayed. Press to decrease the time displayed. USING YOUR AUDIO SYSTEM Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated.
  • Page 31 High Level Audio System with AM/FM Stereo/Cassette (Radio Controlled CD Changer Compatible) PUSH ON TAPE MUTE Premium AM/FM Stereo/Cassette/Alpine Audio System (Radio Controlled CD Changer Compatible) PUSH ON TAPE MUTE Your vehicle is equipped with a delayed accessory feature. This feature enables the audio playing media to continue playing up to 10 minutes after the ignition has been turned off, or until a door is opened.
  • Page 32 Controls and features Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
  • Page 33 to increase volume compensation to decrease or shut off the volume compensation AM/FM select The AM/FM select control works in radio, tape and CD modes (if equipped). AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations.
  • Page 34 Controls and features Press to select the next disc in the CD changer. Hold the control to fast-forward through the remaining discs. Seek function The seek function control works in radio, tape or CD mode (if equipped). Seek function in radio mode Press to find the next listenable station down the...
  • Page 35 Controls and features Scan function in tape mode Press the SCAN control to hear a short sampling of all selections on the tape. (The tape scans in a forward direction. At the end of the tape’s first side, direction automatically reverses to the opposite side of the tape.) To stop on a particular selection, press the control again.
  • Page 36 Controls and features 3. When the first six strong stations are filled, the station stored in memory preset control 1 will start playing. If there are less than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available.
  • Page 37 Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Tape/CD select (if equipped) To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode, press the TAPE control. Press the button during rewind or fast forward to stop the rewind or fast forward function.
  • Page 38 Controls and features In CD mode, pressing the REW control for less than three seconds results in slow rewind. Pressing the control for more than three seconds results in fast rewind. Fast forward The fast forward control works in tape and CD modes (if equipped). In the tape mode, tape direction will automatically reverse when the end of the tape is reached.
  • Page 39 Compression feature Compression adjust brings soft and loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. Shuffle feature The shuffle feature operates in CD mode and plays all tracks on the current disc in random order.
  • Page 40 Controls and features Traffic Press the RDS control until TRAFFIC is displayed. Use the SEL control to select ON or OFF. With the feature on, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting RDS data).
  • Page 41 Show RDS sends information with the FM broadcast: station name, station type, and/or radio text. With RDS activated, press the RDS control until SHOW is displayed. Use the SEL control to select (program) TYPE, (station) NAME or NONE (no text displayed). Mute mode Press the control to mute the playing media.
  • Page 42 Controls and features Press the DSP control until one of the following appears: ALL SEATS DRIVER SEAT REAR SEATS Use the SELECT control to change the equalization to the desired mode. CD changer (if equipped) Your CD changer is either located in the passenger’s footwell area or in the center console.
  • Page 43 Controls and features 1. Pull the lever to remove a CD tray from the magazine. 2. Insert one disc into each CD tray of the magazine (up to 6 discs). Ensure that the label side is facing If you pull too hard on the disc holder, the disc holder may come completely out of the magazine.
  • Page 44 Controls and features 5. Slide the door to the left to close. Use only compact discs containing this mark. The magazine does not need to be full for the changer to operate. Radio power must be turned on to play the CDs in the changer. The magazine may be stored in the glove compartment when not being used.
  • Page 45 A disc with format and dimensions not within industry standards is inserted. Cleaning compact discs Inspect all discs for contamination before playing. If necessary, clean discs only with an approved CD cleaner and wipe from the center out to the edge. Do not use circular motion. CD and CD changer care Handle discs by their edges only.

  • Page 46: Positions Of The Ignition

    Controls and features Radio reception factors Three factors can affect radio reception: Distance/strength. The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles). This range can be affected by “signal modulation.” Signal modulation is a process radio stations use to increase their strength/volume relative to other stations.

  • Page 47: Key System

    5. START, cranks the engine. Release the key as soon as the engine starts. Refer to the Securilock chapter for more information on Securilock KEY SYSTEM The vehicle is equipped with a master key and valet key lock system. The master key will actuate doors, trunk, glove box, ignition and remote trunk release.
  • Page 48 Controls and features TURN SIGNAL CONTROL Push down to activate the left turn signal. Push up to activate the right turn signal. Cornering lamps When the turn signal is used and the headlamps are on, the cornering lamps will light either the right or left side depending on the direction of the turn.
  • Page 49 In Tape mode: Press MEM/NEXT to listen to the next selection on the tape. In CD mode: Press MEM/NEXT to listen to the next track on the disc. In any mode: Press VOL up or down to adjust the volume. Climate control features Press TEMP up or down to adjust temperature.
  • Page 50 Controls and features To turn speed control off Press OFF or Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased. When the OFF control is pressed, the message “SPEED CONTROL OFF” will appear for 5 seconds in your message center.
  • Page 51 Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved. To set a higher set speed Press and hold SET ACCEL. Release the control when the desired vehicle speed is reached Press and release SET ACCEL. Each press will increase the set speed by 1.6 km/h (1 mph) if (E) English is selected or 2 km/h...
  • Page 52 Controls and features Depress the brake pedal. When the desired vehicle speed is reached, press SET ACCEL. When the COAST or SET ACCEL control is pressed and released, the message “SPEED CONTROL SET” will appear for 5 seconds in your message center.

  • Page 53: Tilt Steering

    Controls and features TILT STEERING Pull the tilt steering control toward you to move the steering wheel up or down. Hold the control while adjusting the wheel to the desired position, then release the control. Never adjust the steering wheel when the vehicle is moving. INTERIOR LAMPS Map lamps To turn on the map lamps, press the...
  • Page 54 OFF. With the ignition key in the ACC or ON position, the reading lamp can be turned on by pressing the rocker control. LINCOLN RESCU SYSTEM (IF EQUIPPED) Lincoln RESCU runs a self-test when you start your vehicle. During this test, the Lincoln RESCU...
  • Page 55 It is important that you understand the limitations of your Lincoln RESCU System prior to initiating an activation. See Lincoln RESCU System Limitations later in this chapter for details. The RESCU system can be activated in three ways: 1. By pressing the Information control.
  • Page 56 General description Lincoln’s Remote Emergency Satellite Cellular Unit (RESCU) is designed to expedite roadside, emergency or information assistance to motorists who are uncertain of their location and/or are uncertain of whom to contact for assistance.
  • Page 57 There may be charges incurred for certain services. Upon receiving an Emergency Activation (by pressing the emergency control or via an air bag activation) the Lincoln Security Response Center relays details of the situation and the location of the vehicle to the appropriate authorities and establishes a three-way phone call.
  • Page 58 Activation and deactivation When either of the two Lincoln RESCU controls are pressed, or the air bags are deployed (this will activate the system as an emergency automatically), a warning light, located in the overhead console, will begin to flash and status messages will be displayed on the vehicle’s...
  • Page 59 Refer to your cellular phone user’s manual for further information. Message center interface During an activation, Lincoln RESCU communicates with the vehicle’s message center. Status messages describing the sequence of the steps being executed are displayed, allowing you to visually follow the activation process.
  • Page 60 Location data retransmit capability During an activation, the Lincoln Security Response Center operator has the capability to initiate a retransmission of the electronic data message. This may be necessary to ensure a more precise determination of vehicle location or to track a vehicle that is moving.
  • Page 61 Inoperative if battery discharged or disconnected Lincoln RESCU is powered by the vehicle’s battery and will not operate if the battery is discharged or disconnected. Inoperative if cellular phone is not installed in the vehicle interface Lincoln RESCU utilizes your vehicle’s cellular phone and will not operate...
  • Page 62 (PIN). In this situation, the user is required to enter the PIN with any phone calls made over the network. The PIN feature is not compatible with the Lincoln RESCU System. At the time your phone is activated, ask your carrier to assign you a phone number that does not require a personal identification number.
  • Page 63 Contact you dealer for assistance if you are unsure if a particular cellular feature is compatible with your Lincoln RESCU System. Potential limitations if activated outside home cellular region At the time you receive your vehicle (or shortly after), you will need to select a cellular carrier and activate your phone.
  • Page 64 You will be responsible, however, for any charges imposed by your cellular phone carrier for the 1–800 phone call to the Lincoln Security Response Center. After your initial service period expires, you will be required to pay a monitoring fee if you elect to continue emergency and roadside assistance.

  • Page 65: Homelink Universal Transceiver (If Equipped)

    MOON ROOF (IF EQUIPPED) To open the moon roof: Press and hold the control forward to raise the moon roof to the vent position (when the glass panel is closed). Press the control rearward to fully open the moon roof. To close the moon roof: Press the control forward.
  • Page 66 Controls and features Do not use the HomeLink Universal Transceiver with any garage door opener that lacks safety stop and reverse features as required by U.S. federal safety standards (this includes any garage door opener model manufactured before April 1, 1982). A garage door which cannot detect an object, signaling the door to stop and reverse, does not meet current U.S.
  • Page 67 Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting after two seconds which may not be long enough to program the HomeLink Universal Transceiver. To program your hand-held transmitters: continue to hold the button on the HomeLink Universal Transceiver.
  • Page 68 Controls and features 1. Locate the training button on the garage door motor head unit. Refer to the garage door opener manual or call 1–800–355–3515 or on the Internet at HomeLink.jci.com. if there is difficulty locating the training button. 2. Press the training button on the garage door motor head unit (which will activate the “training”...

  • Page 69: Electronic Compass (If Equipped)

    Controls and features 3. Press and hold the hand-held transmitter button. 4. The HomeLink indicator light will flash, first slowly and then rapidly. When the indicator light begins to flash rapidly, release both buttons. The previous device has now been erased and the new device can be activated by pushing the HomeLink button that has just been programmed.
  • Page 70 Controls and features Compass zone adjustment The compass in the mirror is set in ZONE eight at the factory. It may be necessary to adjust the compass if you live outside zone eight or during a long distance trip. 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map.
  • Page 71 With moon roof: 1. Press and hold the Auto-Dimming control to toggle the Compass display ON/OFF, then release. 2. Press and hold both map light buttons, between 5 and 8 seconds, until the ZONE number appears in the display, then release. The display should show the current zone number.
  • Page 72 Controls and features With moon roof: 1. Start the vehicle. 2. Press and hold both map light buttons for over 8 seconds, until the letter “C” appears in the display, then release. 3. Drive the vehicle slowly (less than 8 km/h [5 mph]) in circles until the letter “C”...

  • Page 73: Automatic Dimming Rearview Mirror

    4. Continue to press until your zone number is shown in the mirror display, then release. 5. The display will show all segments, then return to normal compass mode within ten seconds. Compass calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines.

  • Page 74: Power Door Locks

    Controls and features With moon roof: Press the control to turn the mirror on or off. The mirror will automatically return to the normal state whenever the vehicle is placed in R (reverse)(when the mirror is on) to ensure a bright clear view when backing up.

  • Page 75: Power Windows

    POWER WINDOWS Press and pull the rocker switches to open and close windows. Press the top portion of the rocker switch to open. Pull the top portion of the rocker switch to close. Express down To make the driver window open fully without holding the window control, press and quickly release the driver window control.

  • Page 76: Power Side View Mirrors

    Controls and features Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls except for the driver’s press the control. Press the control again to restore the window controls. Accessory delay With accessory delay, the window switches may be used for up to ten minutes after the ignition switch is turned to the OFF position or until...
  • Page 77 Controls and features Heated outside mirrors Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.

  • Page 78: Fuel Door Release

    Controls and features FUEL DOOR RELEASE Your vehicle is equipped with a locking fuel door. To open the door, press the control located on the door. Fuel filler door override release If the remote release is inoperative, open the trunk, then pull the override release handle located inside the trunk on the passenger side to open the fuel filler door.

  • Page 79: Perimeter Alarm System (If Equipped)

    Cupholder Compact disc changer (if equipped) Ashtray and lighter Use only soft cups in the cupholder. Hard objects can injure you in a collision. POSITIVE RETENTION FLOOR MAT Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in.
  • Page 80 Controls and features The system is ready to arm whenever the ignition is turned OFF. Any of the following actions will prearm the alarm system: Lock the doors with the remote transmitter (doors opened or closed). The horn will chirp to confirm that the control was pressed.

  • Page 81: Remote Entry System

    Unlock the doors by using your keyless entry keypad. Unlock the doors with a key. Turn the key full travel (toward the front of the vehicle) to make sure the alarm disarms. Turn ignition to ACC or ON. REMOTE ENTRY SYSTEM The remote entry system allows you to lock or unlock all vehicle doors without a key.
  • Page 82 Controls and features This process will arm your anti-theft system (if equipped). For more information on arming the anti-theft system, refer to Perimeter alarm system in this chapter. Opening the trunk Press the control once to open the trunk. Ensure that the trunk is closed and latched before driving your vehicle.
  • Page 83 weather conditions nearby radio towers structures around the vehicle other vehicles parked next to the vehicle To replace the battery: 1. Twist a thin coin between the two halves of the transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART.
  • Page 84 Controls and features All transmitters must be reprogrammed at the same time. Illuminated entry The interior lamps illuminate when the remote entry system is used to unlock the door(s) or sound the personal alarm. The system automatically turns off after 25 seconds or when the ignition is turned to the RUN or ACC position.

  • Page 85: Keyless Entry System

    The system can be deactivated by switching the transmitter to OFF. KEYLESS ENTRY SYSTEM With the keyless entry keypad, you can: lock or unlock the vehicle doors without using the key. arm and disarm the perimeter alarm system (if equipped) reprogram remote entry transmitters.
  • Page 86 Controls and features Programming your own entry code 1. Enter the factory-set code (keypad will illuminate when pressed). 2. Press the 1/2 control within five seconds of step 1. 3. Enter your personal 5–digit code. Enter each digit within five seconds of the previous one.
  • Page 87 Unlocking the doors and releasing the trunk with the keyless entry system To unlock the driver door, enter either the factory-set code or personal code (each digit pressed within 5 seconds of prior digit). The interior lamps will illuminate. To unlock all doors, enter the factory-set code or personal code (driver door unlocks) and press 3/4 within five seconds.
  • Page 88 Controls and features Autolock The autolock feature will lock all of the doors when: all vehicle doors are fully closed the ignition key is turned to the ON position the vehicle is in a forward gear and you exceed 5 km/h (3 mph). The autolock feature repeats when: the ignition key remains in the ON position a door is opened and then closed...
  • Page 89 PATS ignition key may cause vehicle starting concern and record DTC’s under certain conditions. If present, you need to keep these objects from touching the PATS ignition key while starting the engine. These objects and devices cannot damage the PATS ignition key, but can cause a momentary concern if they are too close to the key during engine start.
  • Page 90 Controls and features Procedure to program spare SecuriLock New SecuriLock keys must have the correct mechanical key cut for your vehicle. Conventional (non-SecuriLock ) keys cannot be programmed to your vehicle. You will need to have two previously programmed SecuriLock the new unprogrammed SecuriLock procedure.

  • Page 91: Interior Luggage Compartment Release (If Equipped)

    INTERIOR LUGGAGE COMPARTMENT RELEASE (IF EQUIPPED) Your vehicle is equipped with a mechanical interior luggage compartment release handle that provides a means of escape for children and adults in the event they become locked inside the luggage compartment. Adults are advised to familiarize themselves with the operation and location of the release handle.

  • Page 92: Seating And Safety Restraints

    Seating and safety restraints SEATING Adjustable head restraints Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
  • Page 93 Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision.
  • Page 94 Seating and safety restraints Press to move the rear portion of the seat cushion up or down. Heated seats (if equipped) To operate the heated seats: Slide the control to BACK to heat the seatback only. Slide the control to BOTH to heat the seatback and the seat cushion.
  • Page 95 Easy access/easy out feature This feature automatically moves the driver’s seat backward when: the transmission is in N (Neutral) or P (Park) the key is removed from the ignition cylinder The seat will move 5cm (2 inches) forward (to the original position) when: the transmission is in N (Neutral) or P (Park) the key is placed in the ignition cylinder...
  • Page 96 Seating and safety restraints In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
  • Page 97 The front outboard and rear safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
  • Page 98 Seating and safety restraints Grasp the shoulder portion and pull downward until the entire belt is extracted. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
  • Page 99 Position the shoulder belt height adjusters so that the belt rests across the middle of your shoulder. Failure to adjust the safety belt properly could reduce the effectiveness of the seat belt and increase the risk of injury in a collision. Lap belts Adjusting the front center seat lap belt (if equipped) The lap belt does not adjust automatically.
  • Page 100 Seating and safety restraints Use only extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended.
  • Page 101 If... The driver’s safety belt is not buckled before the vehicle has reached at least 5 km/h (3 mph) and 1-2 minutes have elapsed since the ignition switch has been turned to ON... The driver’s safety belt is buckled while the safety belt indicator light is illuminated and the safety belt warning chime is sounding...
  • Page 102 Seating and safety restraints Reasons given... Traffic is light Belts wrinkle my clothes The people I’m with don’t wear belts I have an air bag I’d rather be thrown clear Do not sit on top of a buckled safety belt to avoid the Belt Minder chime.
  • Page 103 all vehicle doors are closed the driver’s safety belt is unbuckled the parklamps/headlamps are in OFF position (If vehicle is equipped with Autolamps, this will not affect the procedure.) To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle.

  • Page 104: Air Bag Supplemental Restraint System (Srs)

    Seating and safety restraints Safety belt maintenance Inspect the safety belt systems periodically to make sure they work properly and are not damaged. Inspect the safety belts to make sure there are no nicks, wears or cuts, replacing if necessary. All safety belt assemblies, including retractors, buckles, front seat belt buckle assemblies, buckle support assemblies (slide bar-if equipped), shoulder belt height adjusters (if equipped), shoulder belt guide on seatback (if...
  • Page 105 collision including information about the air bag system and impact severity. This information will assist Ford in the servicing of your vehicle and may help Ford better understand real world collisions and further improve the safety of future vehicles. Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and...
  • Page 106 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Modifications to the front end of the vehicle, including frame, bumper, front end body structure and tow hooks may effect the performance of the air bag sensors increasing the risk of injury.
  • Page 107 Seating and safety restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation.
  • Page 108 Seating and safety restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the air bag is inflated, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
  • Page 109 Do not attempt to service, repair, or modify the air bag Supplemental Restraint System, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS is provided.
  • Page 110 Seating and safety restraints How does the side air bag system work? The side air bag system consists of the following: An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks.
  • Page 111 Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with the vehicle service manual.

  • Page 112: Safety Restraints For Children

    Seating and safety restraints Disposal of air bags and air bag equipped vehicles (including pretensioners) For disposal of air bags or air bag equipped vehicles, see your local dealership or qualified technician. Air bags MUST BE disposed of by qualified personnel. SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children.

  • Page 113: Safety Seats For Children

    neck, the child should wear the lap and shoulder belt. Moving the child closer to the center of the vehicle may help provide a good shoulder belt fit. Do not leave children, unreliable adults, or pets unattended in your vehicle. To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all Federal motor vehicle...
  • Page 114 Seating and safety restraints When installing a child safety seat: Review and follow the information presented in the Air Bag Supplemental Restraint System section in this chapter. Use the correct safety belt buckle for that seating position. Insert the belt tongue into the proper buckle until you hear a snap and feel it latch.
  • Page 115 Installing child safety seats in combination lap and shoulder belt seating positions 1. Position the child safety seat in a seat with a combination lap and shoulder belt. An air bag can kill or injure a child in a child seat. If you must use a forward-facing child seat in the front seat, move seat all the way back.
  • Page 116 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
  • Page 117 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
  • Page 118 Seating and safety restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
  • Page 119 6. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the child safety seat. 7. Tighten the child safety seat tether strap according to the manufacturer’s instructions.

  • Page 120: Starting

    Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
  • Page 121 2. Make sure the headlamps and vehicle accessories are off. Make sure the parking brake is set. Make sure the gearshift is in P (Park). 3. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely.

  • Page 122: Starting The Engine

    Starting – TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON BRAKE Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced. If the driver’s safety belt is fastened, the STARTING THE ENGINE 1.
  • Page 123 recommended if you live in a region where temperatures reach -23°C (-10°F) or below. For best results, plug the heater in at least three hours before starting the vehicle. Using the heater for longer than three hours will not harm the engine, so the heater can be plugged in the night before starting the vehicle.
  • Page 124 Starting Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch). Adjust the heating or air conditioning (if equipped) to bring in fresh air. Improve vehicle ventilation by keeping all air inlet vents clear of snow, leaves and other debris.

  • Page 125: Driving

    Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
  • Page 126 Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the...

  • Page 127: Traction Control

    Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn off the ignition whenever you leave your vehicle. The parking brake is not recommended to stop a moving vehicle. However, if the normal brakes fail, the parking brake can be used to stop your vehicle in an emergency.
  • Page 128 Driving reduction is realized via the fully electronic spark and fuel injection systems. This process is very sensitive to driving conditions and very fast acting. The front wheels “search” for optimum traction several times a second and adjustments are made accordingly. The Traction Control of available traction on slippery surfaces.

  • Page 129: Air Suspension System

    If the steering wanders or pulls, the condition could be caused by any of the following: underinflated tire(s) on any wheel(s) high crown in center of road high crosswinds wheels out of alignment loose or worn components in steering linkage Speed sensitive steering The steering in your vehicle is speed sensitive.

  • Page 130: Automatic Transaxle Operation

    Driving The air suspension shut-off switch is located on the left side of the trunk. If this switch is in the OFF position, the rear air suspension will not operate. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle.
  • Page 131 on the accelerator in each gear. Do not rock the vehicle for more than a few minutes, because it could damage the vehicle. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transaxle may occur. Do not rock the vehicle for more than a few minutes or damage to the transaxle and tires may occur or the engine may overheat.
  • Page 132 Driving Understanding gearshift positions P (Park) Always come to a complete stop before shifting into P (Park). Make sure the gearshift lever is securely latched in P (Park). This locks the transaxle and prevent the front wheels from rotating. Always set the parking brake fully and make sure the gearshift is securely latched in P (Park).
  • Page 133 Driving N (Neutral) With the gearshift lever in the N (Neutral) position, the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. D (Overdrive) The overdrive position is the normal driving position for an automatic overdrive transaxle.
  • Page 134 Driving When to use 3 (Third) 3 (Third) eliminates the needless shifting back and forth between third and fourth gears that your vehicle may do when driving on hilly terrain. It also gives more engine braking than overdrive to slow your vehicle on downgrades.

  • Page 135: Driving Through Water

    When parking, do not use the gearshift in place of the parking brake. Always set the parking brake fully and make sure that the gearshift is securely latched in Park (P). Turn off the ignition whenever you leave your vehicle. Never leave your vehicle unattended while it is running.
  • Page 136 Driving GAWR (Gross Axle Weight Rating): Carrying capacity for each axle system. The GAWR is specific to each vehicle and is listed on the Safety Compliance Label on the driver’s door pillar. GCW (Gross Combined Weight): The combined weight of the towing vehicle (including passengers and cargo) and the trailer.

  • Page 137: Trailer Towing

    38°C [100°F]) Your vehicle does not come from the factory fully equipped to tow. However, you can contact your local Lincoln dealer to get the proper towing equipment. Do not tow a trailer until your vehicle has been driven at least 3 200 km (2 000 miles).
  • Page 138 Driving Do not exceed the GVWR or the GAWR specified on the certification label. Towing trailers beyond the maximum recommended gross trailer weight could result in engine damage, transmission/axle damage, structural damage, loss of control, and personal injury. Preparing to tow Use the proper equipment for towing a trailer, and make sure it is properly attached to your vehicle.
  • Page 139 Do not connect a trailer’s lighting system directly to your vehicle’s lighting system. To get the proper equipment for hooking up your trailer’s lamps, see your Lincoln Mercury dealer. Be sure to follow their instructions carefully. If you do not install trailer lights correctly, you may cause damage to the vehicle’s lighting system or other vehicle systems.
  • Page 140 Driving Vehicles with trailers should not be parked on a grade. If you must park on a grade, place wheel chocks under the trailer’s wheels. Recreational towing Follow these guidelines for your specific powertrain combination to tow your vehicle with all four wheels on the ground (such as behind a recreational vehicle).

  • Page 141: Getting Roadside Assistance

    In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, it is found in the Roadside Assistance book in the glove compartment.

  • Page 142: Hazard Flasher

    In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. HAZARD FLASHER Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc.

  • Page 143: Fuses And Relays

    2. Check the fuel system for leaks. 3. If no fuel leak is apparent, reset the fuel pump shut-off switch by pushing in on the reset button. 4. Turn the ignition to the ON position. Pause for a few seconds and return the key to the OFF position.
  • Page 144 Roadside emergencies Standard fuse amperage rating and color Fuse Mini Rating Fuses Grey Violet Pink 7.5A Brown Blue Yellow Natural Green — — — — — Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal.
  • Page 145 The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating Roadside emergencies Passenger Compartment Fuse Panel Description Lighting Control Module: Anti-Theft Indicator Lamp, PWM Dimming Output, Illumination Lamps for Microphone, RR and LR Door Ashtrays, Heated Seat Switches, Rear Defrost Control Switch, EATC Control Panel, Message Center Switches, Speed Control Switches, Cigar Lighter, Console and Ashtray...
  • Page 146 Roadside emergencies Fuse/Relay Fuse Amp Location Rating — — —— Passenger Compartment Fuse Panel Description Virtual Image Instrument Cluster, Lighting Control Module (LCM RUN/START Sense), Autolamp Light Sensor Virtual Image Instrument Cluster, RF Park/Turn Lamp Power Point Fuel Filler Door Release Switch, Trunk Lid Relay Air Bag Diagnostic Monitor, EATC Module, Blower Motor Relay...
  • Page 147 Fuse/Relay Fuse Amp Location Rating — — — — Roadside emergencies Passenger Compartment Fuse Panel Description Lighting Control Module (LCM): Right Headlamp Virtual Image Instrument Cluster, EATC Module Not Used Shift Lock Actuator, Vehicle Dynamic Module, Virtual Image Instrument Cluster, Rear Window Defrost, Heated Seat Switch Assembly, Low Tire Pressure Module Radio...
  • Page 148 Roadside emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating Passenger Compartment Fuse Panel Description Lighting Control Module: Anti-Theft Indicator Lamp, PWM Dimming Output, Illumination Lamps for Microphone, RR and LR Door Ashtrays, Heated Seat Switches, Rear Defrost Control Switch, EATC Control Panel, Message Center Switches, Speed Control Switches, Cigar Lighter, Console and Ashtray...
  • Page 149 Fuse/Relay Fuse Amp Location Rating — — — —— Roadside emergencies Passenger Compartment Fuse Panel Description Virtual Image Instrument Cluster, Lighting Control Module (LCM RUN/START Sense), Autolamp Light Sensor Virtual Image Instrument Cluster, RF Park/Turn Lamp Power Point Fuel Filler Door Release Switch, Trunk Lid Relay Air Bag Diagnostic Monitor, EATC Module, Blower Motor Relay...
  • Page 150 Roadside emergencies Fuse/Relay Fuse Amp Location Rating — — — — — Passenger Compartment Fuse Panel Description Lighting Control Module (LCM): Right Headlamp Virtual Image Instrument Cluster, EATC Module Not Used Shift Lock Actuator, Vehicle Dynamic Module, Virtual Image Instrument Cluster, Rear Window Defrost Radio Heated Mirrors...
  • Page 151 Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. Always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.

  • Page 152: Changing The Tires

    Roadside emergencies Fuse/Relay Fuse Amp Location Rating 40A** 60A** 60A** 60A** 60A** 40A** 60A** 30A* 20A* 30A* 30A* — 20A* 15A* 30A* — — * Mini Fuses ** Maxi Fuses Auxiliary relay box The auxiliary relay box is located in the engine compartment. The auxiliary relay box contains the high and low speed cooling fan relays.
  • Page 153 Tire change procedure To prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed.
  • Page 154 Roadside emergencies 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. Refer to Anti-theft lug nuts for information on removing anti-theft lug nuts. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your...
  • Page 155 (not the dealer) to get a replacement key. If the lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln/Mercury dealer who has access to the master set of keys. Do not use an impact wrench with the anti-theft key.

  • Page 156: Jump Starting Your Vehicle

    Roadside emergencies 3. Turn the wrench in a counterclockwise direction to remove the lug nut. To install the anti-theft lug nut: 1. Insert the key over the locking lug nut. 2. Place the lug nut wrench over the lug nut key and apply pressure on the key with the wrench.
  • Page 157 Roadside emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
  • Page 158 Roadside emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
  • Page 159 Roadside emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
  • Page 160 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.

  • Page 161: Wrecker Towing

    Roadside emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed by wheel lift or flatbed equipment.

  • Page 162: Maintenance And Care

    Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a Scheduled Maintenance Guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide necessary parts and service.

  • Page 163: Opening The Hood

    Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2.

  • Page 164: Identifying Components In The Engine Compartment

    Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.6L DOHC V8 engine 1. Automatic transmission fluid dipstick 2. Brake fluid reservoir 3. Battery 4. Air filter assembly 5. Engine oil dipstick 6. Engine oil filler cap 7. Power steering fluid reservoir 8.

  • Page 165: Engine Oil

    ENGINE OIL Checking the engine oil Refer to the Scheduled Maintenance Guide for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
  • Page 166 Maintenance and care If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range. Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7.
  • Page 167 Maintenance and care Engine oil and filter recommendations Look for this certification trademark. Use SAE 5W-30 motor oil certified for gasoline engines by the American Petroleum Institute (API). Motor oil displaying the API certification trademark will meet all requirements for your vehicle’s engine. Ford oil specification is WSS-M2C153-G.
  • Page 168 Maintenance and care BRAKE FLUID Checking and adding brake fluid Brake fluid should be checked and refilled as needed. Refer to the Scheduled Maintenance Guide for the service interval schedules. 1. Clean the reservoir cap before removal to prevent dirt or water from entering the reservoir.

  • Page 169: Engine Coolant

    WINDSHIELD WASHER FLUID Checking and adding washer fluid Check the washer fluid whenever you stop for fuel. The reservoir is highlighted with a If the level is low, add enough fluid to fill the reservoir. In very cold weather, do not fill the reservoir all the way.
  • Page 170 Maintenance and care The engine coolant must be maintained at the correct fluid level and concentration to work properly. If the engine coolant fluid level and concentration is not maintained correctly, damage to the engine and cooling system may result. When the engine is cold, check the level of the engine coolant in the reservoir.
  • Page 171 Automotive fluids are not interchangeable; do not use engine coolant, antifreeze or windshield washer fluid outside of its specified function and vehicle location. Adding engine coolant Use only Ford Premium Engine Coolant E2FZ-19549-AA (in Canada, Motorcraft CXC-10) or a premium engine coolant that meets Ford specification ESE-M97B44-A.
  • Page 172 Maintenance and care Plain water may be added in an emergency, but you must replace it with a 50/50 mixture of engine coolant and distilled water as soon as possible. Check the coolant level in the reservoir before you drive your vehicle the next few times (with the engine cool).
  • Page 173 Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in the Capacities and specifications chapter. Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter. Severe climates If you drive in extremely cold climates (less than –36°...

  • Page 174: Checking And Adding Power Steering Fluid

    Maintenance and care CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the Scheduled Maintenance Guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
  • Page 175 Maintenance and care Automatic transmission fluid expands when warmed. To obtain an accurate fluid check, drive the vehicle until it is warmed up (approximately 30 km [20 miles]). If your vehicle has been operated for an extended period at high speeds, in city traffic during hot weather or pulling a trailer, the vehicle should be turned off for about 30 minutes to allow fluid to cool before checking.
  • Page 176 Maintenance and care High fluid level Fluid levels above the safe range may result in transaxle failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
  • Page 177 Maintenance and care BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the Scheduled Maintenance Guide for the service interval schedules.
  • Page 178 Maintenance and care Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.

  • Page 179: Cabin Air Filter

    If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned. If the battery has been disconnected or a new battery has been installed, the clock must be reset once the battery is reconnected.
  • Page 180 Maintenance and care 2. Release and open the hood. HOOD 3. Pull the rubber cowl seal (number 1 in figure) away from the cowl vent screen. Remove the right half of the cowl vent screen (number 2 in figure) by placing your hand underneath the cowl vent screen and lifting straight up to release the four spring clips.

  • Page 181: Windshield Wiper Blades

    Maintenance and care Be careful when installing the new filter. Avoid bending or tearing the filter and make sure it is fully seated in its mounting location after installation. WINDSHIELD WIPER BLADES Check the wiper blades at least twice a year or when they seem less effective.
  • Page 182 If the warning remains on after you have adjusted the tires to the recommended air pressure levels, take your vehicle to an authorized Lincoln/Mercury dealer for service. LOW TIRE PRESSURE ROOF...

  • Page 183: Information About Uniform Tire Quality Grading

    Maintenance and care Flat tire warning If the sensors detect a tire pressure lower than 68 kPa (10 psi), the LOW TIRE PRESSURE warning will appear in the overhead console and the message WARNING LOW TIRE PRESSURE will be displayed in the message center, indicating an impending flat tire.
  • Page 184 Maintenance and care Tire Quality Grades apply to new pneumatic tires for use on passenger cars. They do not apply to deep tread, winter-type snow tires, space-saver or temporary use spare tires, tires with nominal rim diameters of 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2).
  • Page 185 The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge.

  • Page 186: Snow Tires And Chains

    Maintenance and care Replacing the tires Replace the tires when the wear band is visible through the tire treads. When replacing full size tires, never mix radial bias-belted, or bias-type tires. Use only the tire sizes that are listed on the Certification Label.

  • Page 187: What You Should Know About Automotive Fuels

    Snow tires must be the same size and grade as the tires you currently have on your vehicle. Do not use any type of tire chains on this vehicle. This includes both conventional and cable-type chains. The tires on your vehicle have all-weather treads that provide traction in rain or snow.
  • Page 188 Maintenance and care Observe the following guidelines when handling automotive fuel: Extinguish all smoking materials and any open flames before fueling your vehicle. Always turn off the vehicle before fueling. Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
  • Page 189 The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container. Use the following guidelines to avoid static build-up when filling an ungrounded fuel container: Place approved fuel container on the ground.
  • Page 190 Maintenance and care The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out and injure you or others. If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel system to work improperly in a collision, which may result in...
  • Page 191 unleaded gasoline. If the problems persist, see your dealer or a qualified service technician. It should not be necessary to add any aftermarket products to your fuel tank if you continue to use high quality fuel of the recommended octane rating.

  • Page 192: Essentials Of Good Fuel Economy

    Maintenance and care ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver. You must gather information as accurately and consistently as possible. Fuel expense, frequency of fillups or fuel gauge readings are NOT accurate as a measure of fuel economy.
  • Page 193 Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in kilometers or miles). 2. Each time you fill the tank, record the amount of fuel added (in liters or gallons). 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading.
  • Page 194 Maintenance and care Using the air conditioner or defroster may reduce fuel economy. You may want to turn off the speed control in hilly terrain if unnecessary shifting between third and fourth gear occurs. Unnecessary shifting of this type could result in reduced fuel economy.

  • Page 195: Emission Control System

    EPA window sticker Every new vehicle should have the EPA window sticker. Contact your dealer if the window sticker is not supplied with your vehicle. The EPA window sticker should be your guide for the fuel economy comparisons with other vehicles. It is important to note the box in the lower left corner of the window sticker.
  • Page 196 Maintenance and care Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
  • Page 197 Brakelamps High-mount brakelamp Turn signals Backup lamps License plate lamp Do not remove lamp bulbs unless they will be replaced immediately. If a bulb is removed for an extended period of time, contaminants may enter the lamp housings and affect performance. Replacing headlamp bulbs To remove the headlamp bulb: 1.
  • Page 198 Maintenance and care 5. Disconnect the electrical connector from the bulb by pulling rearward. 6. Remove the bulb retaining ring by rotating it counterclockwise. 7. Remove the old bulb from the lamp assembly by pulling it straight out of the lamp assembly. To install the new bulb: Handle a halogen headlamp bulb carefully and keep out of children’s reach.
  • Page 199 Maintenance and care 2. Install the bulb retaining ring over the plastic base and lock the ring by rotating clockwise until it snaps into place. 3. Connect the electrical connector to the bulb. 4. Install the protective dust shield and lock the shield by rotating it clockwise until it locks into position.
  • Page 200 Maintenance and care 4. Rotate the bulb socket counterclockwise and remove from lamp assembly. 5. Carefully pull bulb straight out of the socket and push in the new bulb. 6. To complete installation, follow the removal procedure in reverse order. Replacing license plate lamp bulbs 1.

  • Page 201: Aiming The Headlamps

    Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
  • Page 202 Maintenance and care A bubble (vertical indicator) that is not centered between the two red lines does not necessarily indicate out-of-aim headlamps. If your vehicle is not positioned on a level surface, the slope will be included in the vertical indication. Therefore, vertical and horizontal headlamp adjustment should be performed only when the beam direction appears to be incorrect.
  • Page 203 Maintenance and care Turning the horizontal adjusting screw in the direction of the arrow changes the horizontal aim as shown. Vertical aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, remove the protective cover, then locate the bubble level and the vertical adjustment screw.

  • Page 204: Cleaning And Caring For Your Vehicle

    Maintenance and care CLEANING AND CARING FOR YOUR VEHICLE Refer to the Customer Assistance chapter for a list of Ford-approved cleaners, polishes and waxes. Washing your vehicle Wash your vehicle regularly with cold or lukewarm water. Never use strong detergents or soap. If your vehicle is particularly dirty, use a quality car wash detergent.
  • Page 205 Maintenance and care recommended that you clean the wiper blades and windshield as described in Cleaning the wiper blades and windshield. Repairing paint chips Minor scratches or paint damage from road debris may be repaired with the Ultra Touch Prep and Finishing Kit (#F7AZ-19K507–BA), Lacquer Touch-up Paint (#ALBZ-19500–XXXXA), or Exterior Acrylic Spray Lacquer (#ALAZ-19500–XXXXA) from the Ford Car Care Chemicals line.
  • Page 206 Maintenance and care Cleaning the exterior lamps Wash with the same detergent as the exterior of your vehicle. If necessary, use a tar remover such as Ford Extra Strength Tar and Road Oil Remover (B7A-19520–AA). To avoid scratching the lamps, do not use a dry paper towel, chemical solvents or abrasive cleaners.
  • Page 207 Cover the highlighted areas to prevent water damage when cleaning the engine. Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning the instrument panel Clean with a damp cloth, then dry with a dry cloth. Avoid cleaner or polish that increases the gloss of the upper portion of the instrument panel.
  • Page 208 Maintenance and care Do not use chemical solvents or strong detergents when cleaning the seat mounted side air bag. Such products could contaminate the side air bag system and affect performance of the side air bag in a collision. Woodtone trim Wipe stains with a soft cloth and a multi-purpose cleaning solution.

  • Page 209: Motorcraft Part Numbers

    MOTORCRAFT PART NUMBERS Component Engine air filter element Cabin Air filter element Fuel filter Battery Oil filter PCV valve Spark plugs* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. REFILL CAPACITIES Fluid Ford Part Name Engine oil Motorcraft SAE...

  • Page 210: Lubricant Specifications

    Capacities and specifications Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter. Use only brake fluids certified to meet Ford specifications. Refer to Lubricant Specifications in this chapter.

  • Page 211: Engine Data

    Ford Part Item Name or equivalent Windshield Ultra-clear washer fluid Windshield Washer Concentrate Use only brake fluids certified to meet Ford specifications. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used. ENGINE DATA Engine Cubic inches...
  • Page 212 Capacities and specifications...

  • Page 213: Certification Label

    IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification Label be affixed to a vehicle and prescribe where the Certification Label may be located. The Certification Label is located on the front door latch pillar on the driver’s side.

  • Page 214: Customer Assistance

    Bumper to Bumper Warranty expires You may purchase Ford ESP from any participating Ford and Lincoln/ Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs.
  • Page 215 Customer assistance If you have questions or concerns, or are unsatisfied with the service you are receiving, follow these steps: 1. Contact your Sales Representative or Service Advisor at your selling/servicing dealership. 2. If your inquiry or concern remains unresolved, contact the Sales Manager or Service Manager at the dealership.
  • Page 216 Customer assistance If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Assistance Center to find an authorized dealership to help you.

  • Page 217: The Dispute Settlement Board (U.s. Only)

    What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance as designed concerns on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written...
  • Page 218 Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...
  • Page 219 a brief summary of the action taken by the dealer(s) and Ford Motor Company the names (if known) of all the people you contacted at the dealership(s) a description of the action you expect to resolve your concern You will receive a letter of explanation if your application does not qualify for Board review.

  • Page 220: Getting Assistance Outside The U.s. And Canada

    Customer assistance You may also contact the North American Customer Assistance Center at 1-800-392-3673 (Ford), TDD for the hearing impaired: 1-800-232-5952 or by writing to the Center at the following address: Ford Motor Company Customer Assistance Center 16800 Executive Plaza Drive P.O.
  • Page 221 Customer assistance The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
  • Page 222 FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Ford accessories are available for your vehicle through your local authorized Ford, Lincoln Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
  • Page 223 Comfort and convenience Cargo nets Cargo organizers Engine block heaters Luggage presenter Travel equipment Heavy-duty battery Inside mirror, electrochromic with compass (with and without temperature display) Protection and appearance equipment Air bag anti-theft locks Carpet floor mats (standard and premium) Cleaners, waxes and polishes Flat splash guards Lubricants and oils...

  • Page 224: Ordering Additional Owner's Literature

    Customer assistance Mobile communications systems may harm the operation of your vehicle, particularly if they are not properly designed for automotive use or are not properly installed. When operated, such systems may cause the engine to stumble or stall. In addition, such systems may be damaged or their performance may be affected by operating your vehicle.

  • Page 225: Reporting Safety Defects

    Reporting safety defects REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect that could cause a crash, or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company.

  • Page 226: Index

    Index Accessory delay ...76 Air bag supplemental restraint system ...104,105,109 and child safety seats ...106 description ...105,109 disposal ...112 driver air bag ...107,110 indicator light ...9,108,111 operation ...107,110 passenger air bag ...107,110 side air bag ...109 Air cleaner filter ...209 Air conditioning ...24 automatic temperature control system ...24...
  • Page 227 set zone adjustment ...70,72 Console ...78 overhead ...54 Controls power seat ...92 steering column ...48 Coolant checking and adding ...169 refill capacities ...173,209 specifications ...210,211 Cruise control (see Speed control) ...49 Customer Assistance ...141 Ford accessories for your vehicle ...221 Ford Extended Service Plan ...214 Getting assistance outside...
  • Page 228 Index gauge ...12 improving fuel economy ...192 octane rating ...190,211 quality ...190 running out of fuel ...191 safety information relating to automotive fuels ...187 Fuses ...143,144 Garage door opener ...65 Gas cap (see Fuel cap) ...189 Gas mileage (see Fuel economy) ...192 Gauges ...12 engine coolant temperature gauge ...13...
  • Page 229 charging system ...11 high beam ...10 oil pressure ...11 safety belt ...9 service engine soon ...8 traction control active ...11 turn signal indicator ...10 Load limits ...135 GAWR ...135 GVWR ...135 trailer towing ...135 Locks autolock ...88 childproof ...77 doors ...74 Lubricant specifications ...210,211 Lug nuts, anti-theft ...155 Lumbar support, seats ...94...
  • Page 230 Index SecuriLock passive anti-theft system ...88,89,90 Servicing your vehicle ...162 Spark plugs, specifications ...209,211 Specification chart, lubricants ...210,211 Speed control ...49 Speedometer ...13 Starting your vehicle ...120,122 jump starting ...156 Steering speed sensitive ...129 Steering wheel controls ...48 tilting ...53 Tachometer ...13 Tilt steering wheel ...53 Tires ...152,181,182,183,184,185...

  • Page 232: Filling Station Information

    Filling station information Item Required fuel Fuel tank capacity Engine oil capacity (includes filter change) Automatic transaxle fluid capacity Tire size and pressure Hood release Coolant capacity Power steering fluid capacity Windshield washer fluid Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.

Table of Contents
