Page 4: Introduction
Introduction CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Introduction...
Page 6 Failure to follow the specific warnings and instructions could result in personal injury. WARNING: Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger airbag. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 7 Certain versions or updates to 911 Assist may also be capable of electronically or verbally disclosing to 911 operators the vehicle location, 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 8 The driver’s primary responsibility is the safe operation of their vehicle. Only use cell phones and other devices not essential to the driving task when it is safe to do so. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 9 Owner’s Guide is written primarily for the U.S. and Canadian Markets. Features or equipment listed as standard may be different on units built for Export. Refer to this Owner’s Guide for all other required information and warnings. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 10 Brake Fluid - Non-Petroleum Based Stability Control System Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) See Owner’s Guide Airbag - Front Child Seat Lower Anchor Brake System Parking Brake System...
Page 11 Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Service Engine Soon Passenger Compartment Air Filter Check Fuel Cap 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Introduction Power Window Lockout Interior Luggage Compartment Release Engine Oil Engine Coolant...
Page 12: Instrument Cluster
If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately by your authorized dealer. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 13 Normal braking is still functional unless the brake warning light also is illuminated. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Instrument Cluster BRAKE...
Page 14 (RTT): Displays when the engine coolant temperature is high. Stop the vehicle as soon as safely possible, switch off the engine and let it cool. Refer to Engine coolant in the Maintenance and Specifications chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 15 Tow/Haul feature has been activated. Refer to the Driving chapter for transmission function and operation. If the light flashes steadily, have the system serviced immediately, damage to the transmission could occur. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Instrument Cluster...
Page 16 High beams: Illuminates when the high beam headlamps are turned on. Key-in-ignition warning chime: Sounds when the key is left in the ignition in the off or accessory position and the driver’s door is opened. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 17: Gauges
Reverse warning chime (if equipped): Sounds when the vehicle is in R (Reverse). Refer to the Driving chapter for more information. GAUGES Speedometer: Indicates the current vehicle speed. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 18 Trip B. Press and hold the RESET button for two seconds to reset. Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 19 Add oil if needed. If the oil level is correct, have your vehicle checked by your authorized dealer. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 20: Entertainment Systems
(if equipped) may be used for up to ten minutes after the ignition is turned off or until either front door is opened. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 21 Satellite radio is available only with a valid SIRIUS subscription. Check with your authorized dealer for availability. (Phone): Press to access SYNC phone features. For further information, please refer to the SYNC supplement. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 22 ALL DELETED. Note: If there are no songs presently saved, the display will read NO SONGS. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) to cycle through the saved...
Page 23 Press OK to close and return to the main menu. Bass: Press to adjust the bass setting. Press OK to close and return to the main menu. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Entertainment Systems to turn RBDS ON or OFF.
Page 24 In satellite radio mode, press SEEK to seek to the next channel. Press and hold SEEK to fast seek through the next channels. In CATEGORY MODE, press to select a category. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 25 SEEK to view the previous display text when “<” is active in the display. Satellite radio is available only with a valid SIRIUS subscription. Check with your authorized dealer for availability. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Entertainment Systems...
Page 26: Auxiliary Input Jack (Line In)
The driver’s primary responsibility is the safe operation of their vehicle. Only use cell phones and other devices not essential to the driving task when it is safe to do so. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 27 6. Press AUX on the vehicle radio repeatedly until LINE, LINE IN or SYNC LINE IN appears in the display. You should hear audio from your portable music player although it may be low. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 28: Usb Port
The driver’s primary responsibility is the safe operation of their vehicle. Only use cell phones and other devices not essential to the driving task when it is safe to do so. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 29: Rear Seat Controls
DVD (if equipped) and *SYNC (if equipped). If in Dual Play mode, SHARED illuminates in the radio display when the front and rear modes are set to the same media. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 30 “enable” them again by simultaneously pressing the 3 and 5 preset controls. The settings of the front seat controls will always override those of the rear seat controls. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) to decrease the volume level...
Page 31 The words DUAL PLAY will illuminate on the radio display, sound will no longer be heard from the rear speakers and the fade control will be disabled, signaling that Dual Play has been activated. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Entertainment Systems...
Page 32 CD/CD player care • Handle discs by their edges only. (Never touch the playing surface). • Inspect discs before playing. • Clean only with an approved CD cleaner. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 33: Satellite Radio Information
If service is necessary, see your dealer or qualified technician. Satellite radio information Satellite radio channels: SIRIUS broadcasts a variety of music, news, sports, weather, traffic and entertainment satellite radio channels. For 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 34 Ford Motor Company shall not be responsible for any such programming changes. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 35 NO TEXT Artist information not available. NO TEXT Song title information not available. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Entertainment Systems Action Required No action required. This message should disappear shortly. If this message does not clear...
Page 36: Family Entertainment System
CD-R/W, CD-R and certain CD-ROM media. Please review this material to become familiar with the FES features and controls as well as the very important safety information. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Action Required...
Page 37 The indicator light will turn off indicating the system is off. Note: The audio from the DVD system will play over all vehicle speakers and can be adjusted by the radio volume control. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 38 DVD system. It will load and automatically begin to play. If there is already a disc in the system, press PLAY on the DVD player. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 39 DVD-AUX. If your source is properly plugged in, it will appear on the LCD (Liquid Crystal Display) screen. If your auxiliary source does not have a video signal, or if the DVD system does not detect a video signal 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 40 Refer to Using the infrared wireless headphones and Using wired headphones for further information. • Black (4) — wired headphone output (wired headphones not included) 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) button on the DVD player or...
Page 41 A will listen to Channel A and headphones plugged into jack B will listen to Channel B. 2. Adjust the volume levels using the volume controls on the DVD system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Entertainment Systems A or...
Page 42 Note: Headphone A can access any possible media (AM, FM1, FM2, SAT (if equipped), CD, DVD, DVD-AUX). Headphone B can only access DVD and DVD-AUX. For further information, refer to Single play/Dual play later in this section. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) VIDEO...
Page 43 9. LCD screen: The eight inch diagonal screen rotates down to view and up into housing to store when not in use. Ensure that the screen is latched into the housing when being stored. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 44 From the set-up menu, you may select from Angle, Aspect Ratio, Language, Subtitles, Disc resume, Compression, Restore Defaults and Back. For more detailed information, refer to Menu mode. 15. ENTER: Press to select/confirm the current selection. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 45 When not in a Menu, the left and right cursor controls decrease and increase the display brightness. 3. DISPLAY: Press to access the on-screen display of the FES functions and adjustments. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 46 Channel B can only access DVD and AUX sources. 16. VIDEO: Press to cycle through video states: DVD-DISC, DVD-AUX, NON-DVD, Off. 17. EJECT: Press to eject a disc from the FES. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 47 Battery replacement Batteries are supplied with the remote control unit. Since all batteries have a limited shelf life, replace them when the unit fails to control the DVD player. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 48 Also, wired headphones may be purchased and plugged in where indicated on the left and right hand sides of the system. Refer to Wired Headphones following. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 49 Then, lightly press down on top and slide the cover off. When replacing the batteries, use two new batteries (alkaline recommended) and install them with the correct orientation as indicated in the battery housing. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 50 They will also turn off after two hours of continuous use as a power save feature. If this happens, simply turn the headphones on again and continue use. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 51 Channel B source. Adjust the headphone volume using the volume control on the DVD system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Entertainment Systems A. Headphones plugged into this...
Page 52 These are called Channel A and Channel B. Both Channel A and Channel B can be listened to on the wired headphones (not included) or on the infrared (IR) wireless headphones. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 53 These are called Channel A and Channel B. Both Channel A and Channel B can be listened to on the wired headphones (not included) or on the infrared (IR) wireless headphones. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 54 DVD-AUX, regardless of headphone channel (A or B). • When a disc is inserted into the FES while in Headphone Only Mode, both headphone channels (A&B) will be connected to FES-DISC. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 55 ENTER to confirm. The system default is Angle 1. Aspect ratio Select ASPECT RATIO to select the viewing size and shape of the video displayed on the LCD screen. This is disc dependent. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 56 Once you have made your selection, press ENTER to confirm. The system default is English. Subtitles Select SUBTITLES to turn the subtitle option on or off. The system default is OFF. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 57 1. Ensure that the vehicle is on or the ignition is in accessory mode. 2. Ensure that the DVD system is on. 3. Insert the MP3 disc into the DVD system, label side up. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 58 Follow the PC configuration recommendations of the encoder software vendor. We recommend that you avoid running other software applications on your PC during MP3 encoding to avoid undesirable noise and distortion. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 59 1. Ensure that the vehicle is on or the ignition is in accessory mode. 2. Ensure that the navigation system is on. 3. Insert a DVD label-side up into the system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 60 1/4 and 1/2. These will display on the status bar on top of the screen as the screens cycle through at this rate. Frame by frame 1. With a DVD playing, press pause. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 61 DVD system. Plug in wired headphones (not included) here. Note: The B headphones can only access DVD and AUX modes. They cannot access radio sources. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 62 The radio will ignore button presses that affect the primary (speaker) audio source. LOCKED (disabled): The FES buttons are locked and all FES button presses are ignored by the radio and the FES except for load and eject. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 63 An independent license for such use is required. For details, please visit http:// www.mp3licensing.com. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 64 Ultraviolet rays deteriorate the liquid crystal. Be sure to review User Manuals for video games and video game equipment when used as auxiliary inputs for your Family Entertainment System (FES). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 65 Federal Communication Commission (FCC) Compliance Changes or modifications not approved by Ford Lincoln-Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 66 Overspray from these fluids could drip down into the internal electronics of the screen and cause damage. Do not apply excessive pressure while cleaning the screen. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 67: Navigation System
For more information, please refer to the SYNC supplement or to the SYNC section in the Navigation system supplement (if equipped). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Entertainment Systems...
Page 68: Climate Controls
Rear defroster: Press to activate/deactivate the rear window defroster. Refer to Rear window defroster later in this chapter for more information. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 69 The system will automatically determine fan speed, airflow location, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 70 When the rear temperature button is pressed, the display will show only the rear cabin settings. After the rear setting changes are completed on the front control, the display will automatically show all climate settings. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 71 : Distributes air through the instrument panel and the floor vents. : Distributes air through the floor vents. : Distributes air through the windshield defroster vents, demister vents and the floor vents. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Climate Controls...
Page 72 Recirculated air can be engaged manually in any airflow selection except . Recirculated air may turn off automatically in all airflow selections. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 73 5. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Climate Controls position.
Page 74: Rear Window Defroster
This may cause damage to the heated grid lines and will not be covered by your warranty. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 75: Lights
See Message center in the Driver Controls chapter. • To turn autolamps on, rotate the control counterclockwise. • To turn autolamps off, rotate the control to the off position. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 76 Turns the fog lamps on at full intensity output. To activate: • the ignition must be in the on position and • the headlamp control must be in the off, parking lamps or autolamp position. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 77 Before aim adjustment, disable the air suspension system. Refer to Message center in the Driver Controls chapter. 1. Park the vehicle directly in front of a wall or screen on a level surface, approximately 25 feet (7.6 meters) away. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Lights...
Page 78 6. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE. 7. Repeat Steps 3–5 for the other headlamp. 8. Close the hood and turn off the lamps. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 79: Turn Signal Control
• any of the remote entry controls are pressed and the ignition is off. The map lamps are activated by pressing the controls on either side of the lens. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Lights...
Page 80 The battery saver will shut off the exterior lamps and interior lamps, except the hazard warning lamps if activated, 10 minutes after the ignition control has been turned off. The system will not turn off the parking lamps if they are on. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 81: Bulb Replacement
Headlamps (low and high-beam) Front park lamps Front turn lamps Front sidemarker Fog lamps Front row map lamps 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Number of bulbs Trade number *See your dealer 3157K or 4157K 3157A (amber)
Page 82 The front parking lamp/turn signal/sidemarker bulbs are located in the headlamp assembly. Follow the same steps to replace either bulb. 1. Make sure the headlamp control is in the off position. 2. Open the hood. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Number of bulbs...
Page 83 Replacing tail/stop/turn/backup lamp bulbs The tail/stop/turn/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 84 7. Install the bulb socket into the lamp assembly and rotate clockwise. 8. Install the lamp assembly on the vehicle and secure with four nuts. 9. Install the interior trim panel. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 85 5. Install the bulb socket in the lamp assembly by turning it clockwise. 6. Install the lamp assembly and secure it with the retaining screw. Replacing approach lamp/mirror turn signal bulbs For bulb replacement, see your authorized dealer. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 86: Driver Controls
Before operating the wiper on a dry windshield, always use the windshield washer. In freezing weather, be sure the wiper blades are not frozen to the windshield before operating the wipers. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 87: Steering Wheel Adjustment
Hold the control to adjust. The tilt function is adjusted by depressing the control up or down. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 88 • Continue pressing the control until it reaches the end of the column position. • Continue pressing the control for approximately two seconds. You will feel the steering column bounce back slightly. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 89 Press the release area on the rear edge of the bin door to open the storage compartment. The door will open to full open position. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 90 WARNING: When closing the power rear quarter windows, you should verify that it is free of obstructions and ensure that children and/or pets are not in the proximity of the window opening. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 91 CLOCK Press the right (+) control to move the time display forwards. Press the left (-) control to move the time display backwards. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 92 Always keep the power point caps closed when not being used. A second auxiliary power point is located on the rear side of the center console. The power point is accessible from the rear seats. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 93: Power Windows
WARNING: When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 94 To operate one touch up: Pull the switch completely up to the second detent and release quickly. The window will close fully. Momentarily press the switch to any position to stop the window operation. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 95 The interior rear view mirror has two pivot points on the support arm which lets you adjust the mirror up or down and from side to side. WARNING: Do not adjust the mirror while the vehicle is in motion. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 96 Note: If your vehicle is equipped with a reverse camera system, a video image will display in the mirror or the navigation system display (if equipped) when the vehicle is put in R (Reverse). Refer to Reverse camera system in the Driving chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 97: Mirrors
After that, the mirrors will operate to their normal positions until they are again moved manually. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 98 Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum-based cleaning products. Signal indicator mirrors When the turn signal is activated, the lower portion of the mirror housing will blink. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 99 • When running boards are manually set in the deployed position <OUT>, the boards will return to the stowed position and enter automatic mode when the vehicle speed exceeds 5 mph (8 km/h). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 100: Speed Control
A moving running board may cause injury. SPEED CONTROL With speed control set, you can maintain a set speed without keeping your foot on the accelerator pedal. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 101 Disengaging speed control To disengage the speed control: • Depress the brake pedal. Disengaging the speed control will not erase previous set speed. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 102 1 mph (1.6 km/h). • Depress the brake pedal until the desired vehicle speed is reached and press the SET + control. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 103 In CD mode: • Press to listen to the next track on the disc. In Satellite radio mode: • Press to advance through preset channels. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 104 Press to activate phone mode or answer a phone call. Press VOL + or − to adjust volume. Press and hold to exit phone mode or end a call. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 105: Moon Roof
Press the switch again to stop the moon roof. Pull and hold the TILT control to close the moon roof. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 106 It is also recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for quicker training and accurate transmission of the radio-frequency signal. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 107 HomeLink should now activate your rolling code equipped device. To program additional HomeLink buttons begin with Step 1 in this section. For questions or comments, please contact HomeLink at www.homelink.com or 1–800–355–3515. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 108 For convenience, the hand-held transmitter of the device may also be used at any time. In the event that there are still programming difficulties, contact HomeLink at www.homelink.com or 1–800–355–3515. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 109: Message Center
The system will also notify you of potential vehicle problems with a display of system warnings followed by a long indicator chime. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 110 To switch the temperature display to compass display, hold the INFO button again for two seconds until the compass heading is seen in the display 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 111 It is important to press the RESET control (press and hold RESET for two seconds in order to reset the function) after setting the speed control to get accurate highway fuel economy readings. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 112 • Autolock • Autounlock • Air Suspension (if equipped) • Running Boards (if equipped) • Power Liftgate • Rear park aid (if equipped) • Front park aid (if equipped) • Language 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 113 Oil life is set to 100% and “OIL LIFE SET TO 100%” is displayed. Easy entry This feature automatically moves the drivers seat backwards for easy exit from the vehicle. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 114 ON or OFF. 3. Press the RESET control switch for the next SETUP MENU item or wait for more than four seconds to return to the INFO MENU. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 115 ON or OFF. If disabled, the outside release handle and the rear cargo area control button are off. The instrument panel button will continue to function the liftgate in power mode. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 116 SETUP menu for the current language to be displayed. 2. Waiting four seconds or pressing the RESET control cycles the message center through each of the language choices. Selectable languages are English, Spanish, or French. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 117 6. Press and release the RESET control until the message center display changes to show the current zone setting (XX). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls 7 8 9 1011...
Page 118 Note: If the RESET control is pressed or three minutes has expired, the display will go back to the INFO menu and will show CAL instead of the compass heading until the compass is calibrated. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 119 • They cannot be cleared until the condition is corrected. • They will reappear on the display 10 minutes from the reset. • They will not reappear until an ignition off-on cycle has been completed. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 120 Check air suspension Check brake system XXX miles to E fuel level low Park brake engaged Press reset to clear 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Status Warning can be reset. Will return if reset and warning is cleared and set again within the same ignition cycle.
Page 121 Control Trac four-wheel drive (4x4) operation in the Driving chapter. CHECK FUEL FILL INLET — Displayed when the fuel fill inlet may not be properly closed. Refer to Easy Fuel™ “no cap” fuel system in the Maintenance and Specifications chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 122 0%, the OIL CHANGE REQUIRED message will be displayed. An oil change is required whenever indicated by the message center and according to the recommended maintenance schedule. USE ONLY RECOMMENDED ENGINE OILS. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 123 WARNING: Make sure all persons are clear of the power liftgate area before using the power liftgate control. WARNING: Keep keys out of reach of children. Do not allow children to play near an open or moving power liftgate. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 124 The liftgate can be fully opened by pushing it upward to the maximum open position. To open the liftgate from the Instrument panel: Press the button once to open the liftgate, press it again to close. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 125 Note: The rear cargo area control button is disabled when the liftgate is latched (fully closed). WARNING: Keep clear of the liftgate when activating the rear switch. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 126 The power liftgate is still operational through the use of the remote entry transmitter and instrument panel button when the power liftgate is turned off in the message center. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 127 If the liftgate glass is raised and the liftgate is also opened, both liftgate and glass could be damaged against a low ceiling. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 128 1. To open, lift up on the handle and cover. 2. To close, lower the cover and press down on the handle until the latch clicks. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 129 WARNING: Do not place people or pets on or under the parcel shelf. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driver Controls...
Page 130 Always ensure that the load is secure before traveling. Ford Motor Company recommends loading the roof rack only when equipped with (optional) cross-bars, to avoid unintended damage to the roof panel. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 131: Locks And Security
Note: Your vehicle’s IKTs were issued with a security tag that provides important vehicle key cut information. It is recommended that you keep the tag in a safe place for future reference. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 132 Likewise, when rotating the IKT to the off position in the ignition lock cylinder, the bottom edge of the IKT adjacent to the control can be utilized. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 133: Locks
• the ignition is in the on position, • you shift into any gear putting the vehicle in motion, and • the vehicle attains a speed greater than 12 mph (20 km/h). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 134 (one short and one long chirp) if autolock was activated. 7. Turn the ignition to the off position. The horn will chirp once to confirm the procedure is complete. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 135 • by using the instrument cluster message center (if equipped). Refer to Message center in the Driver Controls chapter. Note: The autounlock feature can be activated/deactivated independently of the autolock feature. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Locks and Security...
Page 136 5. Release the 3 • 4. The user should receive a horn chirp to indicate the system has been disabled or a chirp followed by a honk to indicate the system has been enabled. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 137 (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 138 The remote entry system activates the illuminated entry feature; this feature turns on the lamps for 25 seconds or until the ignition is turned to the on position. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 139 This will also prevent passengers and cargo from falling out. If you must drive with the liftgate open, keep the vents open so outside air comes into the vehicle. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Locks and Security...
Page 140 3. Within three seconds press the transmitter. 4. A tone will be heard when the activation is complete. 5. Repeat this procedure for another remote entry transmitter if desired. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) control on the remote entry...
Page 141 5. Snap the battery cover back onto the key. Note: Replacement of the battery will not cause the IKT to become deprogrammed from your vehicle. The IKT should operate normally after battery replacement. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 142 • if the ignition switch is turned to the on position, or • the Integrated Keyhead Transmitter lock control is pressed, or • the vehicle is locked using the keyless entry keypad, or • after 25 seconds of illumination. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 143 The lights will turn off if all the doors remain closed and • 25 seconds elapse, or • the key is inserted in the ignition. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Locks and Security...
Page 144 • Pressing 1 • 2 assigns driver 1 settings. • Pressing 3 • 4 assigns driver 2 settings. • Pressing 5 • 6, 7 • 8, or 9 • 0 assigns Driver 3 settings. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 145 Note: The driver’s door must be closed. You do not need to enter the keypad code first. To open the liftglass, press the 5 • 6 after entering the factory set 5-digit code or your personal code. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 146: Anti-Theft System
IKT and restart the engine. Note: Do not leave a duplicate coded key in the vehicle. Always take your keys and lock all doors when leaving the vehicle. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 147 Note: Your vehicle comes equipped with two Integrated Keyhead Transmitters (IKTs). The IKT functions as both a programmed ignition key that operates all the locks and starts the vehicle, as well as a remote 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 148 3 (on) position for at least three seconds, but no more than 10 seconds. 3. Turn the ignition to the 1 (off) position and remove the first coded key from the ignition. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 149 The perimeter anti-theft system will help protect your vehicle from unauthorized entry. If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL Integrated Keyhead Transmitters are brought to the authorized dealer to aid in troubleshooting. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 150 20 second countdown. The turn signal lamps will flash once when all doors, the hood and the liftgate are closed indicating the vehicle is locked and entering the 20 second countdown. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 151 • Any door, the hood or the liftgate is opened without using the keypad or the remote entry transmitter portion of your IKT. • The ignition is turned to the on position with an invalid unprogrammed SecuriLock™ key or IKT. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Locks and Security...
Page 152: Seating And Safety Restraints
(4). To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 153 Whenever possible it should be installed and properly adjusted when the seat is occupied. To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 154 For occupants of extremely tall stature, adjust the head restraint to its full up position. WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 155 The control is located on the outboard side of the seat cushion. Move the switch in the direction of the arrows to raise or lower the front portion of the seat cushion. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 156 • Continue pressing the control until it reaches the end of the seat track. • Continue pressing the control for approximately two seconds. You will feel the seat bounce back slightly. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 157 (back and cushion) to stabilize. The controls for the climate controlled seats are located on the dual electronic automatic temperature control (DEATC) system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 158 (two indicator lights), low cool (one indicator light) or off. If the engine falls below 350 RPMs while the cooled seats are on, the feature will turn itself off and will need to be reactivated. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 159 1. Remove key from ignition. 2. Push up on the outside rigid edge of the filter and rotate toward the front of the vehicle once tabs are released. 3. Remove filter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 160 Move the front passenger seat forward so that the second row seat headrest clears the front seat. For assistance, refer to the label located on the side of the seat cushion. 1. Lower the head restraints by pulling on the strap. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 161 After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 162 2. Pull the cargo mode lever up to release the seat into a kneel down load floor position. A moderate force may be required to move the seat forward and down. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 163 WARNING: Always latch the vehicle seat to the floor, whether the seat is occupied or empty. If not latched, the seat may cause injury during a sudden stop. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 164 After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 165 Folding the 2nd row center 20% seat system (if equipped) 1. Locate the release handle located in the upper left seat back, and pull the handle to release the folding seat latch. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 166 After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 167 Note: Do not do the following: • Place heavy objects on the seat • Operate the seat heater if water or any other liquid is spilled on the seat. Allow the seat to dry thoroughly. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 168 Ensure that the head restraints are lowered. Ensure that the second row seats are not reclined. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 169 After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched. An unlatched seat may become dangerous in the event of a sudden stop or collision. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 170 3rd row seat will be disabled 10 minutes after turning the vehicle off. If the power 3rd row seat is disabled after 10 minutes, the seat can be enabled by 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 171: Safety Restraints
(crash severity, belt usage, etc.) were not appropriate to activate these safety devices. Front airbags are designed to activate only in frontal and near-frontal collisions, not rollovers, side-impacts, or rear-impacts unless the collision causes sufficient longitudinal deceleration. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 172 This helps reduce the risk of force-related injuries to the occupant’s chest by limiting the load on the occupant. Refer to Safety restraints section in this chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 173 WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 174 Check seat covers and buckles before you place a child anywhere near them. WARNING: Front and rear seat occupants, including pregnant women, should wear safety belts for optimum protection in an accident. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 175 5 mph (8 km/h) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 176 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 177 Safety Canopy and safety belt pretensioners. Refer to the Safety belt maintenance section in this chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 178 This guide is attached to the quarter trim panel and is used to adjust the comfort of the shoulder belt for smaller occupants in the outboard second row seats. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 179 Also, use the safety belt extension only if the safety belt is too short for you when fully extended. WARNING: Do not use extensions to change the fit of the shoulder belt across the torso. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 180 The Belt-Minder feature uses two different warning chimes. During the first minute of activation, the warning chime will sound once every second. The remaining warning chimes will sound twice every second while the system is activated. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Then...
Page 181 The following are reasons most often given for not wearing safety belts: (All statistics based on U.S. data) Reasons given... “Crashes are rare events” “I’m not going far” 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Then... The Belt-Minder feature is activated...
Page 182 “Belts wrinkle my clothes” “The people I’m with don’t wear belts” “I have an airbag” “I’d rather be thrown clear” 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Consider... We design our safety belts to enhance comfort. If you are uncomfortable -...
Page 183 Step 3 must be completed within 50 seconds after the safety belt warning light turns off. • After Step 3, the safety belt warning light will be turned on for three seconds. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 184: Airbags
Airbags DO NOT inflate slowly; there is a risk of injury from a deploying airbag. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 185 (including frame, bumper, front end body structure and tow hooks) may affect the performance of the airbag system, increasing the risk of injury. Do not modify the front end of the vehicle. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 186 The driver and passenger airbags are designed to inflate in frontal and near-frontal collisions, not rollover, side-impact, or rear-impacts unless the collision causes sufficient longitudinal deceleration. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 187 • driver and passenger airbag modules (which include the inflators and airbags), • seat-mounted side airbags. Refer to Seat-mounted side airbag system later in this chapter • Safety Canopy system. Refer to Safety Canopy system later in this chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 188 WARNING: Do not lean your head on the door. The side airbag could injure you as it deploys from the side of the seatback. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 189 The airbag SRS is designed to activate when the vehicle sustains lateral deceleration sufficient to cause the sensors to close an electrical circuit that initiates airbag inflation. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 190 WARNING: Do not lean your head on the door. The Safety Canopy could injure you as it deploys from the headliner. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 191 (one on each side of vehicle). • A headliner designed to flex open above the side doors to allow Safety Canopy deployment. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 192 The Safety Canopy is designed to inflate in certain side impact collisions or rollover events, not in rear impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration or rollover. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 193 S.O.S. Post Crash Alert The S.O.S Post Crash Alert automatically flashes the turn signal lamps and sounds the horn three times at four second intervals in the event of 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 194: Child Restraints
Failure to properly restrain children in safety seats made especially for their height, age, and weight may result in an increased risk of serious injury or death to your child. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 195 Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in a front seating position. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 196 A safety seat that is improperly installed or utilized, is inappropriate for your child’s height, age, or weight or does not properly fit the child may increase the risk of serious injury or death. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) below by “X”...
Page 197 Follow all the safety restraint and airbag precautions that apply to adult passengers in your vehicle. If the child is the proper height, age, and weight (as specified by your child safety seat or booster manufacturer), fits the restraint and can be 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 198 Installing child safety seats with combination lap and shoulder belts Check to make sure the child seat is properly secured before each use. Children 12 and under should be properly restrained in a rear seating 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 199 Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat. 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 200 Make sure the tongue is latched securely by pulling on it. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 201 9. Attach the tether strap (if the child seat is equipped). Refer to Attaching child safety seats with tether straps later in this chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 202 Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching safety restraints for children in this chapter for more information. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 203 Follow the instructions on attaching child safety seats with tether straps. Refer to Attaching child safety seats with tether straps later in this chapter. Attach LATCH lower attachments of the child seat only to the anchors shown. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 204 Some of the rear seats of your vehicle are equipped with built-in tether strap anchors located behind the seats as described below. In the third row center seating position, the tether anchor is a loop at the bottom of the seatback. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 205 If the top of the safety seat hits the head restraint, raise the head restraint to let the child seat fit further rearward. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 206 (if equipped) 3. Grasp the tether strap and position it to the seat frame. 4. Rotate the tether strap, and clip the tether strap to the anchor on the seat frame. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 207 2. Locate the anchor webbing loop for the seating position. • You may need to pull back the top of the hinged panel along the bottom of the seat back to access the tether anchor. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 208 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 209 • Does the lap belt rest low across the hips? • Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 210 • High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 211 For this reason, you should never use a booster seat with a lap belt only. It is generally best to use a booster seat with lap/shoulder belts in the back seat. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 212 WARNING: Failure to inspect and if necessary replace the safety belt assembly or child restraint system under the above conditions could result in severe personal injuries in the event of a collision. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 213: Tires, Wheels And Loading
This increases traction which may enable you to safely drive over terrain and road conditions that a conventional two-wheel drive vehicle cannot. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 214 All other things held equal, a shorter wheelbase may make your vehicle quicker to respond to steering inputs than a vehicle with a longer wheelbase. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 215: Tire Information
Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 216 Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 217: Tire Inflation
Every day before you drive, check your tires. If one looks lower than the others, use a tire gauge to check pressure of all tires and adjust if required. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 218 1 psi (7 kPa) in inflation pressure. Check your tire pressures frequently and adjust them to the proper pressure which can be found on the Safety Compliance Certification Label or Tire Label. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 219 Check for holes or cuts that may permit air leakage from the tire and make necessary repairs. Also inspect the tire sidewalls for 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 220 You should replace your spare tire when you replace the road tires or after six years due to aging even if it has not been used. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 221 If you have questions regarding tire replacement, contact your authorized dealer as soon as possible. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 222 Tire Pressure Monitoring System. If the TPMS indicator is flashing, your TPMS is malfunctioning. Your replacement tire might be incompatible with your TPMS, or some component of the TPMS may be damaged. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 223 Front wheel drive (FWD) vehicles and those with an independent rear suspension (if equipped) may require alignment of all four wheels. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 224 Note: After having your tires rotated, inflation pressure must be checked and adjusted to the vehicle requirements. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 225 You may find this information in your Owner’s Guide. If not, contact a local tire dealer. Note: You may not find this information on all tires because it is not required by federal law. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 226 9. M+S or M/S: Mud and Snow, or AT: All Terrain, or AS: All Season. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Speed rating - mph (km/h)
Page 227 The cold inflation pressure should never be set lower than the recommended pressure on the vehicle label. The tire suppliers may have additional markings, notes or warnings such as standard load, radial tubeless, etc. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading ⁄...
Page 228 4. Maximum Load Single lb. (kg) at psi (kPa) cold: Indicates the maximum load and tire pressure when the tire is used as a single; defined as two tires (total) on the rear axle. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 229 B-Pillar or the edge of the driver’s door. Refer to the payload description and graphic in the Vehicle loading — with and without a trailer section. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 230: Tire Pressure Monitoring System (Tpms)
TPMS to continue to function properly. The Tire Pressure Monitoring System complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 231 Even if the light turns ON and a short time later turns OFF, your tire pressure still needs to be checked. Visit www.checkmytires.org for additional information. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 232 Spare tire in use TPMS malfunc- tion 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Customer Action Required 1. Check your tire pressure to ensure tires are properly inflated; refer to In- flating your tires in this chapter.
Page 233 Inflate all the tires to the recommended inflation pressure. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading Customer Action Required Your temporary spare tire is in use.
Page 234: Vehicle Loading
VEHICLE LOADING – WITH AND WITHOUT A TRAILER This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 235 Overloading or improperly loading your vehicle can contribute to loss of vehicle control and vehicle rollover. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 236 GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) – including vehicle curb weight and all payload. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 237 The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The GVW must never exceed the GVWR. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 238 0.15 and 0.25 to obtain a proper king pin load range of 1,725 to 2,875 lb. (782 to 1,304 kg) WARNING: Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 239 In metric units, the calculation would be: 635 kg - (5 x 99 kg) - (5 x 13.5 kg) = 635 - 495 - 67.5 = 72.5 kg. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 240: Trailer Towing
Trailer towing puts additional loads on your vehicle’s engine, transmission, axle, brakes, tires, and suspension. For your safety and to maximize vehicle performance, be sure to use the proper equipment while towing. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 241 Electronic trailer brakes (if equipped) refer to the instructions provided by the aftermarket electronic brake controller manufacture for determining trailer brake functionality. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 242 Note: For vehicles equipped with the optional trailer tow package, the maximum frontal area of trailer should not exceed 60 square feet (5.6 square meters). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Trailer weight Maximum range (0 - maximum) - lb.
Page 243 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 244 Pull the cover downward to remove it; the fasteners will remain attached to the cover. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Maximum Tongue Weight - lb. (kg)
Page 245 2. Turn the air suspension (if equipped) control to off. 3. Measure the height of a reference point on the front and rear bumpers at the center of the vehicle. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading ⁄...
Page 246 Trailer lamps are required on most towed vehicles. Make sure all running lights, brake lights, turn signals and hazard lights are working. Contact your authorized dealer or trailer rental agency for proper instructions and equipment for hooking up trailer lamps. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) ⁄...
Page 247 • If you are driving down a long or steep hill, shift to a lower gear. Do not apply the brakes continuously, as they may overheat and become less effective. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Tires, Wheels and Loading...
Page 248 Replace the rear axle lubricant any time the axle has been submerged in water. Rear axle lubricant quantities are not to be checked or changed unless a leak is suspected or repair required. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 249: Recreational Towing
Control Trac four-wheel drive system. In case of a roadside emergency with a disabled vehicle, see Wrecker towing in the Roadside Emergencies chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 250: Driving
WARNING: Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 251 Seating and Safety Restraints chapter. 2. Make sure the headlamps and vehicle accessories are off. 3. Make sure the gearshift is in P (Park). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving...
Page 252 4 (start) position, the engine may continue cranking for up to 10 seconds or until the vehicle starts. Note: Cranking may be stopped at any time by turning the key to the off position. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 253 2. When the engine starts, release the key, then gradually release the accelerator pedal as the engine speeds up. If the engine still fails to start, repeat Step 1. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 254 For flexible fuel vehicles, if operating with E heater must be used if ambient temperature is below 0°F (-18°C). See Cold weather starting in the Driving chapter for more information on starting with ethanol. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) ethanol, an engine block...
Page 255 Be sure to check for heat anywhere in the electrical hookup once the system has been operating for approximately a half hour. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 256: Brakes
WARNING: If you are driving down a long or steep hill, shift to a lower gear. Do not apply your brakes continuously, as they may overheat and become less effective. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) BRAKE...
Page 257 If your brake warning lamp illuminates, have your vehicle serviced immediately. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving BRAKE...
Page 258 Since the parking brake applies only the rear brakes, the vehicle’s stopping distance will increase greatly and the handling of your vehicle will be adversely affected. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 259: Advancetrac
If your AdvanceTrac with RSC system activates, SLOW DOWN. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving...
Page 260 The message center will also indicate a failure with the AdvanceTrac with RSC system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Off button located on the center of the...
Page 261 The Engine Traction Control and Brake Traction Control system may be deactivated in certain situations. See the Switching Off AdvanceTrac with RSC section following. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving in the...
Page 262 Certain adverse driving maneuvers may activate the Roll Stability Control system, which include: • Emergency lane-change • Taking a turn too fast • Quick maneuvering to avoid an accident, pedestrian or obstacle 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) in the...
Page 263 (40 km/h) seconds STEERING Your vehicle is equipped with power steering. Power steering uses energy from the engine to decrease the driver’s effort in steering the vehicle. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving will Off button...
Page 264: Air Suspension
RPM, have the power steering system checked by your authorized dealer. AIR SUSPENSION SYSTEM The air suspension system is designed to improve ride, handling and general vehicle performance during: • Certain road conditions 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 265 Avoid sharp turns, excessive speed or abrupt maneuvers in these vehicles. Failure to drive cautiously could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving...
Page 266: Transmission Operation
P (Park) position and into the N (Neutral) position. 4. Remove tool and reinstall the protective cover. 5. Start the vehicle and release the parking brake. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 267 (TCM). If the battery is disconnected for any reason, the stored information from the last time the key was turned to OFF will be read. This way, no information will be lost with any battery removal or battery disconnect. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving...
Page 268 Transmission operates in gears one through six. D (Overdrive) with Tow/Haul On The Tow/Haul feature improves transmission operation when towing a trailer or a heavy load. All transmission gear ranges are available when using Tow/Haul. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 269 WARNING: Do not use the Tow/Haul feature when driving in icy or slippery conditions as the increased engine braking can cause the rear wheels to slide and the vehicle to swing around with the possible loss of vehicle control. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving...
Page 270: Forward And Reverse Sensing System
P (Park) or N (Neutral) and the vehicle speed is below 8 mph (13 km/h). The rear sensors will only be active when the gearshift is in R (Reverse). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 271 While receiving a rear detection warning, the radio volume will be reduced to a predetermined level. After the warning goes away, the radio will return to the previous value. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 272 The reverse sensing portion of the system will assist the driver in detecting certain objects while: • the vehicle is in R (Reverse) and moving toward a stationary object at a speed of 3 mph (5 km/h) or less. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 273: Reverse Camera
(if equipped). The area displayed on the screen may vary according to the vehicle orientation and/or road condition. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 274 Note: If the camera system image is not clear or seems distorted, it may be covered with water droplets, snow, mud or any other substance. If this occurs, clean the camera lens before using the reverse camera system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 275 CONTROL TRAC FOUR-WHEEL DRIVE (4X4) OPERATION (IF EQUIPPED) WARNING: For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving...
Page 276 “4X4” when this position is selected. This position is not recommended for use on dry pavement. This position is only intended for severe winter or off-road conditions, such as deep snow, ice or shallow sand. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) AUTO...
Page 277 Maintain steering wheel control at all times, especially in rough terrain. Since sudden changes in terrain can result in abrupt steering wheel motion, make sure you grip the steering wheel from the outside. Do not grip the spokes. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving...
Page 278 Avoid sharp turns, excessive speed and abrupt maneuvers in these vehicles. Failure to drive cautiously could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 279 Use all available road surface to return the vehicle to a safe direction of travel. • In the event of an emergency stop, avoid skidding the tires and do not attempt any sharp steering wheel movements. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Driving...
Page 280 This is the front drivetrain coming up to speed and engaging the front wheels, and is not cause for concern. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 281 If the transmission, transfer case, front axle or rear axle are submerged in water, their fluids should be checked and changed, if necessary. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 282 Apply just enough power to the wheels to climb the hill. Too much power will cause the tires to slip, spin or lose traction, resulting in loss of vehicle control. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 283 In emergency stopping situations, apply the brake forcefully and steadily. Do not “pump” the brakes. Refer to the Brakes section of this chapter for additional information on the operation of the anti-lock brake system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 284 Once through the water, always dry the brakes by moving your vehicle slowly while applying light pressure on the brake pedal. Wet brakes do not stop the vehicle as quickly as dry brakes. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 285: Roadside Emergencies
• winch out – available within 100 feet (30.5 meters) of a paved or county maintained road, no recoveries. • towing – Ford/Mercury/Lincoln eligible vehicle towed to an authorized dealer within 35 miles (56.3 km) of the disablement location or to the nearest authorized dealer.
Page 286: Hazard Flasher Control
Owner Guide portfolio in the glove compartment. In Canada, the card is found in the Customer Information Guide in the glove compartment. U.S. Ford, Mercury and Lincoln vehicle customers who require Roadside Assistance, call 1-800-241-3673. Canadian customers who require roadside assistance, call 1-800-665-2006.
Page 287: Fuel Pump Shut-Off Switch
4. Turn the ignition to the on position. Pause for a few seconds and return the key to the off position. 5. Make a further check for leaks in the fuel system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 288: Fuses And Relays
Yellow Yellow Natural Natural Green Green — — — — — — — — — — 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) COLOR Cartridge Maxi Fuse link maxi fuses cartridge fuses — — — — — —...
Page 289 To reinstall the fuse box cover, place the top part of the cover on the fuse panel, then push the bottom part of the cover until you hear it click shut. Gently pull on the cover to make sure it is seated properly. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 290 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating 7.5A 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Protective Circuits Smart window #1 Driver side power seat memory FES, Audio rear seat controls, SDARS, SYNC...
Page 291 Fuse/Relay Fuse Amp Location Rating 7.5A 30A Circuit Breaker — 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Roadside Emergencies Protective Circuits Demand lamps, Glovebox, Visor Instrument panel cluster Ignition switch Radio Instrument panel cluster Not used (Spare) Not used (Spare)
Page 292 Battery section of the Maintenance and Specifications chapter. The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating — — — 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Protected Circuits Powertrain Control Module power relay Starter relay Not used...
Page 293 — — — 15A* 20A* 25A* 20A* 10A* — 40A** 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Roadside Emergencies Protected Circuits Trailer tow relay Fuel pump relay Trailer tow park lamp relay Heated backlite/Mirror relay Not used Run/Start (R/S) relay...
Page 294 — 30A** 40A** 10A* 10A* 30A* 10A* 15A* 15A* — 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Protected Circuits Not used Auxiliary blower motor PCM relay Power liftgate Trailer tow left hand stop/turn relay Trailer tow right hand stop/turn...
Page 295 — 20A* — — — — — — * Mini Fuses ** Cartridge Fuses 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Roadside Emergencies Protected Circuits Fuel pump diode LT HID lamp relay Not used Moon roof Auxiliary power point...
Page 296: Changing Tires
1. T-type mini-spare: This spare tire begins with the letter “T” for tire size and may have “Temporary Use Only” molded in the sidewall 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 297 The usage of a full-size dissimilar spare tire/wheel can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Roadside Emergencies...
Page 298 The spare tire and tools for your vehicle are stowed in the following locations: Item Spare tire Jack tools and jacking instructions Under the access panel located in 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Location Under the vehicle, just forward of...
Page 299 4. To remove the spare tire, turn the handle counterclockwise until the tire is lowered to the ground and the cable is slightly slack. 5. Slide the retainer through the center of the spare tire wheel. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 300 Refer to the instruction sheet (located in the rear floor compartment behind the 3rd row seat with the jack tray tools assembly kit) for detailed tire change instructions. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 301 Note: Use the frame rail as the jacking point, NOT the control arm. 6. Lift the vehicle so the tire is no further than 1 inch (2.5 cm) off the ground when installing the spare tire. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 302 WARNING: Turn off the running boards (if equipped) before jacking or placing any object under the vehicle. Never place your hand between the extended running board and the vehicle. A moving running board may cause injury. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 303 13. Turn on the air suspension system (if equipped). Refer to Message center in the Driver Controls chapter for instructions on turning the air suspension system on. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Roadside Emergencies...
Page 304 Close the access hole with the rubber plug. Reinstall the tray into the vehicle and secure it with the wing nut (turn clockwise until tight). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 305: Wheel Lug Nut Torque
(1 square cm) sized glob of grease around the wheel pilot surface (1) with end of finger. DO NOT apply grease to lugnut/stud holes or wheel-to-brake surfaces. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Roadside Emergencies Wheel lug nut torque* lb.ft.
Page 306: Jump Starting
Do not attempt to push-start your automatic transmission vehicle. Automatic transmissions do not have push-start capability. Attempting to push-start a vehicle with an automatic transmission may cause transmission damage. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 307 Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 308 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 309 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 310 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 311 (boosting) battery. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 312 After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 313: Wrecker Towing
Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Also, wrecker towing the vehicle by the front frame-mounted tow hooks is not recommended or advised. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 314 Driving chapter for specific instructions if you cannot move the gear shift lever into N (Neutral). • Maximum speed is not to exceed 35 mph (56 km/h). • Maximum distance is 50 miles (80 km). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 315: Customer Assistance
GETTING THE SERVICES YOU NEED Warranty repairs to your vehicle must be performed by an authorized Ford, Lincoln, or Mercury dealer. While any authorized dealer handling your vehicle line will provide warranty service, we recommend you return to your selling authorized dealer who wants to ensure your continued satisfaction.
Page 316 Ford Motor Company of Canada, Limited P.O. Box 2000 Oakville, Ontario L6J 5E4 Telephone 1-800-565-3673 (FORD) Online www.ford.ca Mailing address (Lincoln vehicles) Lincoln Centre Ford Motor Company of Canada, Limited P.O. Box 2000 Oakville, Ontario L6J 5E4 Telephone 1-800-387-9333 Online www.lincolncanada.com...
Page 317 THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 318 Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 319 Before exporting your vehicle to a foreign country, contact the appropriate foreign embassy or consulate. These officials can inform you of local vehicle registration regulations and where to find unleaded fuel. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 320 Monday-Friday 8:00 a.m. - 6:00 p.m. EST Helm, Incorporated can also be reached by their website: www.helminc.com. (Items in this catalog may be purchased by credit card, check or money order.) 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 321: Reporting Safety Defects (U.s. Only)
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform Transport Canada, using their toll-free number: 1–800–333–0510. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 322: Cleaning
• Wash the vehicle first, using cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A). • Use Custom Bright Metal Cleaner (ZC-15), available from your authorized dealer. Apply the product as you would a wax to clean 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 323 • Never apply any cleaning chemical to hot or warm wheel rims or covers. • Some automatic car washes may cause damage to the finish on your wheel rims or covers. Chemical-strength cleaners, or cleaning 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Cleaning...
Page 324 • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 325 INSTRUMENT PANEL/INTERIOR TRIM AND CLUSTER LENS Clean the instrument panel, interior trim areas and cluster lens with a clean and damp white cotton cloth, then with a clean and dry white 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 326 Carpet & Upholstery Cleaner (ZC-54). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14). In Canada, use Motorcraft Multi-Purpose Cleaner (CXC-101). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 327 If this occurs, the leather should be cleaned immediately to avoid permanent staining. UNDERBODY Flush the complete underside of your vehicle frequently. Keep body and door drain holes free from packed dirt. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Cleaning...
Page 328 Cleaning FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 329: Maintenance And Specifications
Never place your hand between the extended running board and the vehicle. A moving running board may cause injury. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 330 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood. 3. Lift the hood until the lift cylinders hold it open. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 331: Engine Compartment
2. Engine oil dipstick 3. Brake fluid reservoir 4. Engine coolant reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Power distribution box 8. Engine oil filler cap 9. Battery 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 332 Checking and adding washer fluid for the liftgate Washer fluid for the liftgate is supplied by the same reservoir as the windshield. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 333 2. Grasp the wiper blade and rotate it away from the wiper arm using moderate force until it disengages from the wiper arm. 3. Once the wiper blade is loose, slide it away form the wiper arm. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 334: Engine Oil
6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is within this range, the oil level is acceptable. DO NOT ADD OIL. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 335 1/4 of a turn until the cap is fully seated. To avoid possible oil loss, DO NOT operate the vehicle with the engine oil level dipstick and/or the engine oil filler cap removed. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 336 Ford material and design specifications, start-up engine noises or knock may be experienced. It is recommended you use the appropriate Motorcraft oil filter or another with equivalent performance for your engine application. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 337: Battery
Lift the battery with a battery carrier or with your hands on opposite corners. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 338 • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 339: Engine Coolant
50/50 mixture of coolant and water provides the following: • Freeze protection down to -34°F (-36°C). • Boiling protection up to 265°F (129°C). • Protection against rust and other forms of corrosion. • Proper function of calibrated gauges. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) RECYCLE...
Page 340 Also, you can be burned if you spill coolant on hot engine parts. WARNING: Do not put engine coolant in the windshield washer fluid container. If sprayed on the windshield, engine coolant could make it difficult to see through the windshield. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 341 WARNING: To reduce the risk of personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 342 Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 343 If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 344 5. Restart the engine and take your vehicle to an authorized dealer. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to an authorized dealer as soon as possible. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) symbol will illuminate.
Page 345: Fuel Information
• Automotive fuels can be harmful or fatal if swallowed. Fuels such as gasoline and ethanol are highly toxic and if swallowed can cause death or permanent injury. If fuel is 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 346 Ethanol is more chemically active than gasoline. It corrodes some metals and causes some plastic and rubber components to swell, break down or 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 347 Use the following guidelines to avoid electrostatic charge build-up when filling an ungrounded fuel container: • Place approved fuel container on the ground. • DO NOT fill a fuel container while it is in the vehicle (including the cargo area). 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 348 Continuing to drive with the Check Fuel Fill Inlet lamp or Check Fuel Fill Inlet message on may cause the Service Engine Soon lamp to turn on as well. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 349 Fuel quality Do not add aftermarket fuel additive products to your fuel tank. It should not be necessary to add any aftermarket products to your fuel 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) (R+M)/2 METHOD...
Page 350 Choosing the right fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 351 2. Slowly insert the funnel into the Easy Fuel™ system. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) indicator may come on. For more...
Page 352 • Use the same filling rate setting (low — medium — high) each time the tank is filled. • Allow no more than two automatic click-offs when filling. • Always use fuel with the recommended octane rating. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 353 • Steady speeds without stopping will usually give the best fuel economy. • Idling for long periods of time (greater than one minute) may waste fuel. • Anticipate stopping; slowing down may eliminate the need to stop. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 354 • Fuel economy may decrease with lower temperatures during the first 8–10 miles (12–16 km) of driving. • Driving on flat terrain offers improved fuel economy as compared to driving on hilly terrain. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 355 The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the service engine soon warning light or the temperature warning light, fluid leaks, strange odors, 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) indicator, charging system...
Page 356 After three driving cycles without these or any other temporary malfunctions present, the service engine soon 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 357 Allow the vehicle to sit for at least eight hours without starting the engine. Then, start the engine and complete the above driving cycle. The 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) indicator remains on, have your vehicle...
Page 358 If the fluid levels are outside of the normal operating range the performance of the system could be compromised; seek service from your authorized dealer immediately. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 359: Air Filter(S)
Changing the air filter element 1. Locate the mass air flow sensor electrical connector on the air outlet tube. This connector will need to be unplugged. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 360 5. Release the three clamps that secure the cover to the air filter housing. Push the air filter cover toward the center of the vehicle and up slightly to release it. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 361 9. Slip the air tube onto the air filter housing and tighten the air-tube clamp bolt snugly, but do not overtighten it. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 362: Part Numbers
Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) 5.4L 3V V8 engine...
Page 363: Maintenance Product Specifications And Capacities
Maintenance and Specifications 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 364 Maintenance and Specifications 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 365 Maintenance and Specifications 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 366: Engine Data
ENGINE DATA Engine Cubic inches Fuel Firing order Ignition system Spark plug gap Compression ratio 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) 5.4L V8 engine 87 octane or (E-85) 1-3-7-2-6-5-4-8 Coil on plug 0.039–0.043 inch (1.05 +/– 0.05mm)
Page 367 Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s door or the edge of the driver’s door. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 368 2. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint System 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6. Model year 7. Assembly plant 8. Production sequence number 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus)
Page 369 Maintenance and Specifications TRANSMISSION CODE DESIGNATIONS You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Six-speed automatic (6R80) 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Code...
Page 370: Accessories
Accessories GENUINE LINCOLN ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Lincoln Accessories are available for your vehicle through your local Lincoln or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 371 • Electrical or electronic accessories or components that are added to the vehicle by the authorized dealer or the owner may adversely affect battery performance and durability. 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Accessories...
Page 372: Index
...359 fluid, checking ...359 fluid, refill capacities ...363 fluid, specification ...363 Auxiliary input jack (Line in) ...26 Auxiliary power point ...92 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Axle lubricant specifications ...363 refill capacities ...363 Battery ...337 acid, treating emergencies ...337...
Page 373 Getting roadside assistance ...285 Getting the service you need ...315 Ordering additional owner’s literature ...320 Utilizing the Mediation/Arbitration Program ...318 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Index Daytime running lamps (see Lamps) ...76 Dipstick automatic transmission fluid ...359 engine oil ...334...
Page 374 ...352 octane rating ...349, 366–367 quality ...349–350 running out of fuel ...306, 350 safety information relating to automotive fuels ...345 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Fuel - flex fuel vehicle (FFV) ...345, 349 Fuses ...288–289 Gas cap (see Fuel cap) ...348...
Page 375 (ABS) ...257 Load limits ...234 Loading instructions ...240 Locks autolock ...133 childproof ...137 doors ...133 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Index Lubricant specifications ...363 Lug nuts ...305 Luggage rack ...130 Lumbar support, seats ...155 Message center ...109–110...
Page 376 ...142 replacing the batteries ...141 Reverse camera ...273 Reverse sensing system ...270 Roadside assistance ...285 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Roll stability control ...259 Roof rack ...130 Safety Belt Maintenance ...212 Safety belts (see Safety restraints) ...171, 173, 175–178...
Page 377 ...223 sidewall information ...225 snow tires and chains ...234 spare tire ...296 terminology ...216 tire grades ...216 treadwear ...215, 220 2009 Navigator (nav) Owners Guide, 2nd Printing USA (fus) Index Towing ...240 recreational towing ...249 trailer towing ...240 wrecker ...313...

Lincoln 2009 Navigator Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Index

Quick Links

Table of Contents

Related Manuals for Lincoln 2009 Navigator

Summary of Contents for Lincoln 2009 Navigator

Table of Contents
