Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo with in-dash six CD AM/FM stereo cassette with CD Navigation system Climate Controls Electronic automatic temperature control Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control...
Page 3
Table of Contents Maintenance and Specifications Engine compartment Engine oil Battery Fuel information Air filter(s) Tire Information Part numbers Refill capacities Lubricant specifications Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5
(miles) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 6
In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 7
By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this Owner’s Guide for all other required information and warnings. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 8
Brake Fluid - Anti-Lock Brake System Non-Petroleum Based Traction Control AdvanceTrac Master Lighting Switch Hazard Warning Flasher Fog Lamps-Front Fuse Compartment Fuel Pump Reset Windshield Wash/Wipe Windshield Rear Window Defrost/Demist Defrost/Demist 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 9
Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System Engine Air Filter Passenger Compartment Jack Air Filter Check fuel cap Low tire warning 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Continued driving with this light on may cause the Check engine warning light to come on. Refer to Fuel filler cap in the Maintenance and Specifications chapter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 11
Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt. Charging system: Illuminates when the battery is not charging properly. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 12
If the light stays on the vehicle will not start, make sure the key is the correct key, refer to Securilock in the Locks and Security chapter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 13
Electronic throttle control (if equipped): Illuminates when the engine has defaulted to a ’limp-home’ operation. Report the fault to a dealer at the earliest opportunity. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 14
Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Never remove the coolant reservoir cap while the engine is running or hot. Odometer: Registers the total kilometers (miles) of the vehicle. • Standard instrument cluster 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 16
ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. Refer to Filling the tank in the Maintenance and Specifications chapter for more information. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
TEXT: TEXT is only available when equipped with Satellite radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Lincoln dealer. Detailed Satellite instructions are included with the dealer installed kit.
Page 18
RDS-equipped FM stations. Traffic: In FM mode with RDS ON, this feature allows you to hear traffic broadcasts. With the feature ON, press SEEK or SCAN to find a station 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 19
11. SAT (if equipped): Your Audiophile radio comes equipped with Satellite Ready capability. The kit to enable the Satellite reception is available through your Lincoln dealer. Detailed satellite instructions are included with the dealer installed kit. 12. AM/FM: Press to select AM/FM1/FM2 frequency band.
Page 20
CAT: CAT is only available when equipped with Satellite Radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Lincoln dealer. Detailed Satellite instructions are included with the dealer installed kit.
Treble: Allows you to increase or decrease the audio system’s treble output. Press TREB then press SEL to decrease or increase the treble levels. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 22
CD modes. In the tape mode, tape direction automatically reverses when the end of the tape is reached. In CD mode, FF advances the CD within the current track. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 23
CD modes. Press to access the previous or next listenable radio station, tape selection or CD track. 13. Tune: Works in radio mode. Press to manually advance up or down the frequency band. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 24
AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
LINCOLN NAVIGATION SYSTEM (IF EQUIPPED) Your vehicle may be equipped with a Lincoln Navigation System which allows you to listen to the radio, play CDs and also navigate the vehicle using a navigation DVD.
Page 26
The system offers an advanced speaker system, amplifier, subwoofer and equalizer. Your Lincoln Navigation System has a large range of features, yet is easy to use. Guidance is shown on the display screen and is supplemented with voice prompts. The display screen provides full information for operating the system through use of menus, text screens and map displays.
Page 27
(if equipped). Quick Start — How to get going To play a radio station: 1. Ensure that the vehicle ignition is on. 2. Press AUDIO. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 28
Push CD OPEN CLOSE to close the screen. Once closed, the CD will begin to play. 3. Use the touch controls to advance tracks, scan, pause, etc. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 29
5. Choose the desired route by pressing the NEXT button (if it appears). There can be up to three alternative routes. 6. Press START to begin the navigation guidance. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 30
Voice activated commands (if equipped) Your Lincoln Navigation System (LNS) may be equipped with a voice activated feature which allows you to “speak” certain commands to the system. Speaking clearly will help to ensure that the system correctly responds to your commands.
Page 31
• Auto service • Gas station • Gas • Parking garage • Parking lot • ATM • Bank • City hall • Civic center • Community center • Convention center 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 32
• Park and ride • Rental car agency • Rest area • Rest stop • Tourist information • Train station • Business facility • City center • POI off • Commuter rail station 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 33
Navigation help commands you may speak at any time: • Help • Map • Destination • Guidance • Radio • Disc • Map help • Destination help • Guidance help • Radio help • Disc help 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 34
Entertainment Systems Audio mode Your Lincoln Navigation Audio System has many features including a full range of audio functions. To access these functions, press AUDIO on the main bezel. This will take you into audio mode. Volume/power control Press knob to turn the audio system on/off.
Page 35
The recommended level for the speed compensated volume is from level 1 through level 3. When activated, level 1 is the minimum setting and level 7 is the maximum setting. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 36
CD. Tune adjust Press TUNE to manually move down/up ( ) the frequency band. In CD mode, press TRACK to select the previous/next ( 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 37
87.9 89.9 98.1 98.5 106.3 107.9 2. Press AUTO SET. 3. When the first six strong stations are filled, the station stored in memory preset control 1 will start playing. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 38
PTY category of the SEEK TUNE selected FM station. SCAN PRESET SCAN AUTO SET TRAFFIC INFO SET PTY 87.9 98.1 98.5 106.3 107.9 89.9 Note: Not all stations support INFO function. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 39
SET PTY following program types: 87.9 89.9 98.1 98.5 106.3 107.9 • All • Classical • Country • Information • Jazz • Religious • Rock • Soft • Top 40 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 40
87.9 89.9 98.1 98.5 106.3 107.9 MENU CD OPEN • CLOSE 1. Press AUDIO. 2. Press SOUND. 3. Select from Bass/Treb; Bal/Fade; DSP/SCV. 4. Press +/— to increase/decrease the levels. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 41
1. Select the frequency band with the AM/FM1/FM2 touch controls. 2. Select a station. 3. Press and hold a memory preset until the sound returns. The frequency will appear in the preset. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 42
Entertainment Systems Satellite ready capability Your Lincoln navigation system comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Lincoln dealer. Detailed Satellite instructions are included with the dealer installed kit. CD mode CD units are designed to play commercially pressed 12 cm (4.75 in) audio compact discs only.
Page 43
After an allotted time, the screen will close automatically or you may press CD OPEN CLOSE on the bezel again. 6. Once the screen closes, the system will start playing the last CD loaded. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 44
(SHUFFLE TRACK) on the current CD or between all tracks on all CDs (SHUFFLE DISC). All tracks will be played in random order. Press again to disengage (SHUFFLE OFF). 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 45
Press again to continue playing. Map mode Map display information VOL PUSH AUDIO DEST MENU CD OPEN • CLOSE To access the map display, press MAP on the bezel. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 46
(house) will appear on the screen and is able to be selected as a destination. To delete POI icons from the map, touch the map again and press the POI off button. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 47
• Use Toll Roads • Use Ferries Information function INFO will appear on the screen when you have calculated a destination. Press INFO for more information about the current destination, if available. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 48
The position of the pointer indicates the direction of north on the map. Press to toggle between “North up” and “Heading up” map display states. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 49
Speaker icon symbol— Press to turn voice guidance on/off. Navigation menu To access the Navigation Menu, press NAV MENU at the bottom of the map screen. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 50
Use voice guidance as much as possible, and only view the display when driving conditions permit. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 51
Average speed settings Allows you to set approximate speeds you drive. These speeds enable the navigation system to aid in calculating timing for routes. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 52
It is recommended to activate this function after every tire replacement. When the button is highlighted, calibration is in process and will turn off automatically when complete. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 53
You can choose from: • Map Mode (Dual or Full) • Guidance Mode (Arrows or Turn list) • Guidance Display (On or Off) • Time to destination (Show or Hide) 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 54
Voice guidance/volume Allows you to turn the voice guidance option on/off and to determine the volume level of the guidance voice prompts. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 55
To set home for the first time: VOL PUSH AUDIO DEST MENU CD OPEN • CLOSE 1. Press MAP. 2. Press “Nav. Menu”. 3. Press “Stored Locations”. 4. Press “Home”. 5. Press “Add”. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 56
Memory Point, Point of Interest, Previous Destination). 7. Enter the required details. 8. Press OK to set the home position. To view home, press the home icon (house) on the Destination Entry screen. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 57
To view the set home position VOL PUSH AUDIO DEST MENU CD OPEN • CLOSE 1. Press MAP. 2. Press “Nav. Menu”. 3. Press “Stored Locations”. 4. Press “Home”. 5. Press “List”. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 58
Deleting a home location VOL PUSH AUDIO DEST MENU CD OPEN • CLOSE 1. Press MAP. 2. Press “Nav. Menu”. 3. Press “Stored Locations”. 4. Press “Home”. 5. Press “Delete”. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 59
To set a memory point: VOL PUSH AUDIO DEST MENU CD OPEN • CLOSE 1. Press the MAP hard key. 2. Press “Nav. Menu”. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 60
“Full”. You must delete points before more can be added. To delete a memory point: VOL PUSH AUDIO DEST MENU CD OPEN • CLOSE 1. Press the MAP hard key. 2. Press “Nav. Menu”. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 61
Press DETOUR to confirm the selection and to activate the detour around the specified areas. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 62
To select the area to avoid: • From the MAP screen, press Nav Menu. • Select Route Options, then Display Whole Route • Press Turn List 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 63
• From the stored locations menu, select “Avoid area”. • Press DELETE • Select the desired area to be deleted. • Press DEL. ALL to delete all stored areas. • Press YES to confirm. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 64
— audible feedback, navigation units, language and clock (if equipped). Note: There may be a slight time delay between the soft key and the hard key functions. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 65
For example, if you are unable to make a U-turn, continue on your journey. The navigation system will recalculate your route to get you back to an appropriate road to your destination. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 66
Your navigation system uses a regional search area. This area is the area from which navigational directions will be used. To check your area or reset, press CHANGE under the search area listing. The 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 67
• By Category — Press “Category”. Scroll down the list to select the category, then sub-category desired. Once you have selected a category, your entry of the POI will be restricted to that category. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 68
To delete any of these stored locations: VOL PUSH AUDIO DEST MENU CD OPEN • CLOSE 1. Press the MAP hard key. 2. Press “Nav Menu” in the bottom left hand corner of the screen. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 69
7. Select (touch) the entry to be deleted. The item details will be listed. 8. Press YES to confirm the deletion. 9. Press DELETE ALL to delete all stored locations. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 70
STORE will appear on the screen. 2. Press STORE to add the location to the memory point list. You may also add a memory point via the Navigation menu. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 71
7. Enter/select any required details. The new point will be added to the stored list of memory points. 8. Press OK. The new point will be added to the list of stored memory points. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 72
AUDIO DEST MENU CD OPEN • CLOSE 1. Press the MAP hard key. 2. Press “Nav Menu” in the bottom left hand corner of the screen. 3. Press “Stored locations”. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 73
When sorted by distance, the points are ordered by distance from the current vehicle location. When sorting by icon, the icons are listed in the order they appear on the icon selection screen. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 74
• In the Memory Point Menu, press DELETE ALL. • The system will ask you to confirm deletion. Press YES to confirm. The screen will briefly show “All Memory Points Deleted”. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 75
(from the current vehicle location), by pressing the “Dist” button or alphabetically by pressing the “A-Z” button. Select the desired entrance or exit. The destination details are displayed for confirmation. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 76
On the map, location details for the entry are displayed at the top of the screen. To adjust the position of the way point (or destination), scroll the map as required. Press OK. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 77
Selecting route criteria Once you have selected a destination, you may change the routing criteria by pressing “Change” in the route preferences screen. Refer to Route preferences for further information. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 78
After the destination has been calculated, it will appear on the map screen. Press NEXT in the upper right hand corner to scroll through other possible routes to the same destination. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 79
Menu mode allows you to access: • System Set-up • Information — Gives you the Lincoln Customer Assistance Center information. • Brightness/Contrast — Allows you to adjust the brightness and contrast on the screen. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 80
Metric/English units. • Language — Press to toggle between English, French, or Spanish. • Clock Setting the clock Once in Menu mode, press CLOCK to set the hours/minutes. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 81
To use the system as effectively and safely as possible, obtain an up-to-date map database DVD whenever they become available. Set the volume level so that you can hear directions clearly. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 82
Ford or Lincoln Dealer. Federal Communication Commission (FCC) Compliance Changes or modifications not approved by Ford Lincoln Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 83
Do not spray cleaning fluid directly onto the unit. Instead, spray onto a soft cloth and gently wipe the unit. Only recommended products should be used. • Recommended products- Rubbing alcohol based cleaner (i.e., methyl alcohol) or a damp clean cloth. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 84
If you need help operating your navigation/audio system, want to report a map database error or want to obtain a map DVD, please call 1 (888) 628–6277 (NAV-MAPS) or log onto www.navtech.com. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Allows the passenger to choose and control a different temperature than the driver, if desired. 4. Rear defrost: Press to defrost the rear window. Refer to Rear Window Defrost for more information. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 86
AUTO. 14. Driver’s side temperature control: Controls the temperature on the driver side of the vehicle in dual zone and controls the temperature of the entire vehicle in single zone. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 87
This feature operates automatically when the outside temperature is near or below freezing. DUAL ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (DEATC) SYSTEM WITH HEATED AND COOLED SEATS (IF EQUIPPED) 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 88
(Defrost): Distributes outside air through the windshield defroster ducts and the demister outlets. Can be used to clear ice or fog from the windshield. The system will automatically provide outside air to reduce window fogging. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 89
Automatic heated/cooled driver seat: To engage, press the driver side heat and cool seat controls simultaneously. The center light above the driver side heated and cooled controls will illuminate and the display will 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 90
OFF position when the vehicle is parked. • Do not put objects under the front seats that will interfere with the airflow. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 91
Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
The filter is located just in front of the windshield under the cowl grille on the passenger side of the vehicle. For more information, or to replace the filter, see your Ford, Lincoln or Mercury Dealer. 2004 Lincoln LS (dew)
7. Turn the autolamps off after the desired delay time is reached. (The maximum programmable delay is 3 minutes. The lights that turned on in step 6 will turn off.) 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 94
Failure to activate your headlamps under these conditions may result in a collision. High beams Pull toward you until control stops to activate. Repeat to deactivate. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
• (1) Eight feet • (2) VOL - subtract 50 mm (2.1 in) from the measurement of the center of the low beam lamp to the ground. • (3) Twenty five feet 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
7. Close the hood and turn off the lamps. TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Park and turn lamp (front) 3457 A/K (amber) Side marker lamp (front) LED* Foglamp 9145 Tail lamp, brakelamp, side lamp 3157K Rear turn lamp 3157 A/K (amber) Backup lamp License plate lamp 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 98
2. Lift the hood and remove the upper and lower sight shields by removing the seven plastic retaining pins. 3. On the headlamp assembly, remove the three headlamp attaching bolts (8mm socket). 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 99
Install the new bulb in reverse order, while also replacing the seal on the bulb retaining cover. The kits for replacement seals are available at Lincoln or Ford dealers. Replacing HID headlamp bulb (if equipped) The low beam headlamps on your vehicle use a “high intensity discharge”...
Page 100
Install the new assembly in reverse order, while also replacing the seal on the bulb retaining cover. The kits for replacement seals are available at Lincoln or Ford dealers. Replacing front parking lamp/turn signal lamp bulbs 1. Remove the headlamp assembly as described under the Replacing exterior bulb header.
Page 101
Install the new stop lamp in reverse order. Replacing tail lamp/backup bulbs For bulb replacement, see a dealer or qualified technician. Replacing license plate lamp bulbs For bulb replacement, see a dealer or qualified technician. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
To replace the wiper blades: 1. Pull the passenger side wiper arm away from the windshield into the service position. Turn the blade at an angle from the wiper arm. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
The telescope function is adjusted by moving the control toward the driver to telescope out and toward the instrument panel to telescope The tilt function is adjusted by moving the control up or down. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 104
STEERING COLUMN LOCK (IF EQUIPPED) The steering column will automatically lock when the key is removed from the ignition. When the vehicle key is inserted into the ignition, the steering column will automatically unlock. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 105
Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Press the rocker switches to open and close windows. • Press the bottom portion of the rocker switch to open. • Press the top portion of the rocker switch to close. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 107
Bounce Back (Front Windows Only) When an obstacle has been detected in the window opening as the window is moving upward, the window will automatically move down and stop at a prescribed position. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Ensure the mirror is pulled down low enough to prevent visibility interference with the overhead console. The mirror support arm has two pivot points which lets you adjust the mirror UP or DOWN and from SIDE to SIDE. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 109
Most geographic areas (zones) have a magnetic north compass point that varies slightly from the northerly direction on maps. A correct zone setting will eliminate this error. Refer to Compass zone adjustment. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 110
2. Press and hold the COMP side of the control until “C” appears in the mirror display. 3. Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until the display reads a direction. 4. The compass is now calibrated. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 111
These actions could cause damage to the glass and mirrors. Fold-away mirrors (if equipped) Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Speed control does not work at speeds below 48 km/h (30 mph). Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 113
• If the vehicle speed decreases more than 16 km/h (10 mph) below your set speed on an uphill, your speed control will disengage. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 114
You can also use the CANCEL or SET - control to operate the Tap-Down function. Press and release this control to decrease the vehicle set speed in small amounts by 1.6 km/h (1 mph). 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 115
STEERING WHEEL CONTROLS These controls allow you to operate some audio control features. Audio control features Press MEDIA to select AM, FM1, FM2, CD, or TAPE (if equipped). MUTE MEDIA 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 116
MEDIA Navigation steering wheel controls (if equipped) These controls allow you to operate some audio and navigation control features when the vehicle is equipped with the navigation feature. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 117
• Press NEXT to select preset stations within the selected radio band. In CD mode: • Press NEXT to select the next selection on the CD. In any mode: • Press VOL to adjust volume. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 118
• Press the rear portion of the control forward to close the moon roof. • Press the rear portion of the control past the first detent to activate the Auto close feature. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 119
April 1, 1982). A garage door which cannot detect an object, signaling the door to stop and reverse, does not meet current U.S. federal safety standards. For more information, contact HomeLink at: www.homelink.com or 1–800–355–3515. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 120
4. The red light will flash slowly and then rapidly. Release both buttons when the red light flashes rapidly. (The rapid flashing light indicates acceptance of the hand-held transmitters’ radio frequency signals.) 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 121
3 with the following: Note: If programming a garage door opener or gate operator, it is advised to unplug the device during the “cycling” process to prevent overheating. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 122
Reprogramming a single HomeLink button To program a device to HomeLink using a HomeLink button previously trained, follow these steps: 1. Press and hold the desired HomeLink button. Do NOT release the button. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Operator selectable features These features are controlled by the message center controls located above the radio. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 124
PLEASE CLOSE DOOR will be displayed. • trunk status • exterior lamps (front and rear turn, brake, tail and side repeater lamp (if equipped) status) • Traction Control or AdvanceTrac (if equipped) 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 125
Since this procedure requires the vehicle speed control system to be set to highway speeds, it must be run only on suitable roadways where long distance speed control can be safely maintained. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 126
English to Metric. Autolocks 1. Select this function from the SETUP control for the current display mode. 2. Press the RESET control to turn the autolocks ON or OFF. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 127
2. Pressing the RESET control cycles the message center through each of the language choices. 3. Press and hold the RESET control to set the language choice. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 128
Park brake on & need service Park brake on Check engine temp Warning returns after 10 minutes Check charging system Transmission overheated Check transmission Low fuel level Check fuel cap ETC-engine failsafe mode 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 129
DRIVER’S DOOR AJAR. Displayed when the driver’s door is not completely closed. PASSENGER DOOR AJAR. Displayed when the passenger side door is not completely closed. DRIVER’S REAR DOOR AJAR. Displayed when the driver’s rear door is not completely closed. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 130
ETC-ENGINE FAILSAFE MODE. Displayed when the engine has defaulted to a ’limp-home’ operation. If the warning stays on or continues to come on, contact your dealer as soon as possible. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 131
LOW WASHER FLUID. Indicates the washer fluid reservoir is less than one quarter full. Check the washer fluid level. Refer to Checking and adding washer fluid in the Maintenance and specifications chapter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 132
To reset the oil monitoring system to 100% after each oil change [approximately 8,000 km (5,000 miles) or 180 days] perform the following: 1. Press the STATUS control to access the System Check function. Press RESET to reset oil %. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 133
If the warning stays on or continues to come on, contact your dealer as soon as possible. DATA ERROR. These messages indicate improper operation of the vehicle network communication between electronic modules. • Fuel computer • Engine sensor • Gear selection 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 134
Refer to Perimeter Alarm System in the Locks and Security chapter. FUEL DOOR RELEASE Press the remote fuel door release control on the instrument panel to open the fuel door. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 135
1. Place the ashtray insert into the ashtray drawer. 2. Push the ashtray drawer in to close. CENTER CONSOLE Your vehicle may be equipped with a variety of console features. These include: 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 136
Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. To remove the floor mat, reverse the installation procedure. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 137
• Repeat steps 1 and 2 for the other side. LUGGAGE RACK (IF EQUIPPED) The luggage rack is dealer installed only. See your local Lincoln Mercury dealership. The maximum load is 75 kg (165 lb) on the luggage rack structure. The vehicle’s roof panel is not designed to carry a load.
Press and hold the control on the remote entry transmitter, or turn the key toward the front of the vehicle and hold it for more than two 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 139
Note: The turn lamps will flash twice to confirm that a change to the feature has occurred. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 140
The “T” shaped handle will be located either on the luggage compartment door (lid) or inside the luggage compartment near the tail lamps. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 141
• structures around the vehicle, or • other vehicles parked next to your vehicle. The remote entry system allows you to perform the following tasks using the remote entry transmitter: 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
2. Press and release again within five seconds to unlock all the doors. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 143
(if equipped). Refer to Message center in the Driver Controls chapter for more information. Sounding a panic alarm Press on the remote transmitter to activate the alarm. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 144
FRONT HOUSING OF THE REMOTE ENTRY TRANSMITTER. 2. Do not wipe off any grease on the battery terminals on the back surface of the circuit board. 3. Remove the old battery. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 145
6. Within 20 seconds press any button on the remote entry transmitter. Note: If more than 20 seconds have passed you will need to start the procedure over again. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 146
Your vehicle comes with the autolock feature activated; in order to deactivate the feature, take your vehicle to an authorized dealer, or use the message center (if equipped). Refer to Message center in the Driver Controls chapter for more information. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 147
7 8 9 0 keypad to: • lock or unlock the doors without using a key. • open the trunk. • recall memory seat/mirrors/steering column/adjustable pedals positions 1 or 2. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 148
3. Press and hold the 1 • 2 for two seconds to erase the customer programmed codes. All personal codes are now erased and only the factory set 5–digit code will work. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 149
This system is designed to prevent the engine from being started unless a coded key programmed to your vehicle is used. The use of the wrong type of coded key may lead to a “no-start” condition. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 150
Programming spare keys A maximum of eight keys can be coded to your vehicle. Only Securilock keys can be used. To program a coded key yourself, you 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 151
5. If failure repeats, take your vehicle to your authorized dealer in order to have new spare key(s) programmed. PERIMETER ALARM SYSTEM The perimeter anti-theft system will warn you in the event of an unauthorized entry to your vehicle. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 152
Triggering the anti-theft system The armed system will be triggered if any door, the trunk or the hood is opened without using the key, the remote entry transmitter or valid keypad code. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Adjust your head restraint so that it is located directly or as close as possible behind your head. The head restraints can be moved up and down. Push control to lower head restraint. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 154
Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 155
The seat will move 5 cm (2 inches) forward (to the original position) when the key is placed in the ignition cylinder. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 156
Climate controlled seats operation The controls for the climate controlled seats are located on the dual electronic automatic temperature control (DEATC) system. Refer to Climate controls for more information. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 157
To remove an air filter: • Remove key from ignition. • Push up on the outside rigid edge of the filter and rotate toward the front of the vehicle once tabs are released. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 158
Head restraints help to limit head motion in the event of a rear collision. Adjust your head restraint so that it is located directly or as close as possible behind your head. The head restraints can be moved up and down. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 159
OFF position. The indicator lights will illuminate when each heated seat has been activated. Split-folding rear seatbacks One or both rear seatbacks can be folded down to provide additional cargo space. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
• Driver and front passenger side air bags • Driver and passenger side air curtains (if equipped) • Front safety belts with pretensioners, energy management retractors, and safety belt usage sensors 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 161
This allows your Personal safety system to distinguish between different levels of crash severity and modify the deployment strategy of the dual-stage air bags and safety belt pretensioners. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 162
Refer to the Warning light section in the Instrument cluster chapter. Routine maintenance of the Personal safety system is not required. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 163
Be sure everyone in your vehicle is in a seat and using a safety belt properly. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 164
(the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 165
The front outboard and rear safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat safety belts have two types of locking modes. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 166
Children 12 years old and under should be properly restrained in the rear seat whenever possible. Refer to Safety restraints for children or Safety seats for children later in this chapter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 167
Safety belt maintenance section in this chapter. Failure to replace the safety belt assembly under the above conditions could result in severe personal injuries in the event of a collision. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 168
The driver’s safety belt is buckled The safety belt warning light and before the ignition switch is turned indicator chime remain off. to the RUN position... 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 169
1 in 4 of us will be seriously injured in a crash during our lifetime. “I’m not going far” 3 of 4 fatal crashes occur within 25 miles of home. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 170
“I’d rather be thrown clear” Not a good idea. People who are ejected are 40 times more likely to DIE. Safety belts help prevent ejection, WE CAN’T “PICK OUR CRASH”. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 171
3. Buckle then unbuckle the safety belt three times, ending with the safety belt unbuckled. This can be done before or during BeltMinder warning activation. 4. Turn on the parklamps/headlamps, turn off the parklamps/headlamps. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 172
(if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Air bags DO NOT inflate slowly; there is a risk of injury from a deploying air bag. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 174
(including frame, bumper, front end body structure and tow hooks) may affect the performance of the air bag system, increasing the risk of injury. Do not modify the front end of the vehicle. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 175
Front air bags and pretensioners are designed to activate in frontal and near-frontal collisions, not rollover, side-impact, or rear-impacts unless the collision causes sufficient longitudinal deceleration. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 176
• side air bags. Refer to Side air bag system later in this chapter • safety belt pretensioners • one or more impact and safing sensors • a readiness light and tone 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 177
Do not use accessory seat covers. The use of accessory seat covers may prevent the deployment of the side air bags and increase the risk of injury in an accident. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 178
Do not attempt to service, repair, or modify the air bag SRS, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle should always wear their safety belts even when an air bag SRS is provided.
Page 179
If any of these things happen, even intermittently, have the SRS serviced at your dealership or by a qualified technician immediately. Unless serviced, the system may not function properly in the event of a collision. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 180
Do not lean your head on the door. The side airbag could injure you as it deploys from the seat. Do not lean your head on the door. The side air curtain could injure you as it deploys from the headliner. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 181
Do not attempt to service, repair, or modify the side air curtain system, its fuses, the A, B, or C pillar trim, or the headliner on a vehicle containing a side air curtain. See your Ford or Lincoln Mercury dealer.
Page 182
Several air bag system components get hot after inflation. Do not touch them after inflation. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 183
Disposal of air bags and air bag equipped vehicles (including pretensioners) See your local dealership or qualified technician. Air bags MUST BE disposed of by qualified personnel. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Moving the child closer to the center of the vehicle may help provide a good shoulder belt fit. Do not leave children, unreliable adults, or pets unattended in your vehicle. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 185
• Does the lap belt rest low across the hips? • Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 186
It is best to use a booster seat with lap/shoulder belts in the back seat- the safest place for children to ride. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 187
• Place seat back in upright position. • Put the safety belt in the automatic locking mode. Refer to Automatic locking mode. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 188
Children 12 and under should be properly restrained in the rear seat whenever possible. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 189
3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 190
7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 191
Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor. 1. Position the child safety seat on the seat cushion. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 192
7. Tighten the child safety seat tether strap according to the manufacturer’s instructions. If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 193
Never attach two LATCH child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 194
LATCH attachments. Two plastic LATCH guides can be obtained at no charge from any Ford or Lincoln-Mercury dealer. They snap onto the LATCH lower anchors in the seat to help attach a child seat with rigid attachments.
Page 195
Also try to tug the seat forward. Check to see if the anchors hold the seat in place. If the safety seat is not anchored properly, the risk of a child being injured in a crash greatly increases. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Starting the engine in this chapter. Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 197
Safety Restraints chapter. 2. Make sure the headlamps and electrical accessories are off. • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 198
2. When the engine starts, release the key, then release the accelerator pedal gradually as the engine speeds up. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an Anti-lock Braking System (ABS). This system helps you maintain steering control during emergency stops by 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 200
To set the parking brake, pull the lever up. To release the parking brake, make sure the ignition is turned to ON, depress the brake pedal, then gently push the parking brake lever down. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 201
• loose or worn suspension components • loose or worn steering components • improper steering alignment A high crown in the road or high crosswinds may also make the steering seem to wander/pull. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Excessive wheel spin is controlled by momentarily reducing engine power and rapidly applying the anti-lock 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 203
However, the system does not function when the vehicle is traveling in R (Reverse); the ABS and traction enhancement features will continue to function. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 204
• If the driving condition is severe and your foot is not on the brake, the brake pedal will move to apply higher brake forces. You may also hear a whoosh of air from under the instrument panel during this severe condition. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
If it is necessary to use the above procedure to move the gearshift lever, it is possible that a fuse has blown or the vehicle’s brakelamps are not operating properly. Refer to Fuses and relays in the Roadside Emergencies chapter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 206
After this learning process, normal shift feel and shift scheduling will resume. P (Park) This position locks the transmission and prevents the rear wheels from turning. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 207
• To return to D5 (overdrive mode), move the transmission shift lever into the D5 position. • Select D4 at higher speeds will cause the transmission to downshift into fourth gear. 3 (Third) This position allows for third gear only. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 208
Shift Transmission (SST) shifter (if equipped) Understanding gearshift positions The Select Shift Transmission (SST) shifter allows the driver to select between the transmission’s automatic shift mode or the manually selected shift mode. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 209
• Transmission will not upshift or downshift unless the selector lever is moved forward or rearward. • One tap forward (+) will command the transmission to upshift one gear range. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 210
Do not rock the vehicle for more than a minute or damage to the transmission and tires may occur, or the engine may overheat. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 211
10 km/h (6 mph). The system is not effective at speeds greater than 10 km/h (6 mph) and may not detect certain angular or moving objects. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 212
Always keep the sensors (located on the rear bumper/fascia) free from snow, ice and large accumulations of dirt (do not clean the sensors with sharp objects). These elements may cause the system to operate inaccurately. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Overloading or improperly loading your vehicle can contribute to loss of vehicle control and vehicle rollover. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 214
Note: For trailer towing information refer to Trailer towing found in this chapter or the RV and Trailer Towing Guide provided by your dealership. GVW (Gross Vehicle Weight) – is the Vehicle Curb Weight + cargo + passengers. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 215
GCW of the towing vehicle plus the trailer exceed the GVWR of the towing vehicle. The GCW must never exceed the GCWR. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. TRAILER TOWING Your vehicle is not equipped to tow. No towing packages are available through Ford or Lincoln/Mercury dealers. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Ford recommends the driveshaft be removed/installed only by a qualified technician. Improper removal/installation of the driveshaft may cause damage to the driveshaft and internal transmission components. See your local dealer for driveshaft removal/installation. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Owner Information Guide in the glove compartment.
If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who need to obtain reimbursement information, call 1–800–665–2006.
Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 221
The fuse panel is located on the right-hand side kick panel. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 222
Restraints Control Module (RCM) OBD II DDM, DSM, Anti-theft LED, Power mirror switch, Electric Park Brake switch, PCM Right front turn, Right front sidemarker, Right front park lamps Right front low beam/HID 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 223
Wiper module Radio, Navigation unit Not Used (spare) FEM, Reverse park assist FEM, Passenger power mirror — Not used Cigar lighter Switch backlighting, FEM Not used (spare) Stop lamp signal 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 224
Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and specifications chapter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 225
Fuel injectors, Electric cooling fan, Mass Air Flow (MAF) sensor 15A* Transmission solenoid, EGR — Not used – Not used — Not used — Not used 15A* HEGOs 15A* Coil-on-plug 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 226
Relay 11 — Not used Relay 12 — Heated wiper park Relay 13 — Horn Relay 14 — PCM power Relay 15 — Starter motor Diode — *Mini fuses **Cartridge fuses 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 227
Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and specifications chapter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 228
Center high-mounted stop lamp Heated mirror 20A* Power point - console 20A* Rear heated seats 20A* Power point - ashtray — Not used 10A* Navigation unit Alternator sense 20A* Moonroof 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 229
Relay 005 — SSP2 Relay 006 — Not used Relay 007 — Fuel pump motor Diode 01 — Not used Diode 02 — Fuel pump motor *Mini fuses **Maxi fuses 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
• Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 231
• Driving vehicles equipped with a camper body • Driving vehicles with a load on the cargo rack Drive cautiously when using a dissimilar spare tire/wheel and seek service as soon as possible. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 232
2. Place gearshift lever in P (Park) , turn engine OFF, and block the diagonally opposite wheel. 3. Lift the trunk cargo cover and remove the spare tire, jack and lug wrench. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 233
5. Put the jack in the jack notch next to the tire you are changing. Turn the jack handle clockwise until the wheel is completely off the ground. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 234
10. Put flat tire, jack and lug wrench away. Make sure jack is fastened so it does not rattle when you drive. 11. Unblock the wheels. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
This operation is considered normal and will not affect function or durability of the transmission. Over time, the adaptive learning process will fully update transmission operation to its optimum shift feel. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 236
1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 237
2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 238
2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 239
Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the spare tire tie-down stud. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 240
After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
GETTING THE SERVICES YOU NEED At home You must take your Lincoln or Mercury vehicle to an authorized Lincoln Mercury dealer for warranty repairs. While any Ford, Lincoln or Mercury dealership handling your vehicle line will provide warranty service, we recommend you return to your selling dealer who wants to ensure your continued satisfaction.
Page 243
Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) www.ford.ca If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 244
• Protection against covered repair costs after your Bumper-to-Bumper Warranty expires. You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs.
Page 245
What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...
Page 246
Customer Assistance from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs To have your case reviewed you must complete the application in the DSB brochure and mail it to the address provided on the application form.
Page 247
This procedure is without cost to you and is designed to eliminate the need for lengthy and expensive legal proceedings. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 248
If you buy your vehicle in North America and then relocate outside of the U.S. or Canada, register your vehicle identification number (VIN) and new address with Ford Motor Company Worldwide Direct Market Operations. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 249
OR 2. Four or more repair attempts are made on the same nonconformity (a defect or condition that substantially impairs the use, value or safety of the vehicle) OR 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
1–800–424–9393 (or 366–0123 in the Washington D.C. area) or write NHTSA 400 Seventh Street U.S. Department of Transportation Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from the Hotline. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Your dealer has touch-up paint and sprays to match your vehicle’s color. Take your color code (printed on a sticker in the driver’s door jam) to your dealer to ensure you get the correct color. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 252
• Spray Motorcraft Engine Shampoo and Degreaser (ZC-20) on all parts that require cleaning and pressure rinse clean. • Cover the highlighted areas to prevent water damage when cleaning the engine. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 253
PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3–A). 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 254
INTERIOR TRIM • Clean the interior trim areas with a damp cloth, then dry by wiping with a dry, soft, clean cloth. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 255
Note: In some instances, color or dye transfer can occur when wet clothing comes in contact with leather upholstery. If this occurs, the leather should be cleaned immediately to avoid permanent staining. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 256
FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
• Do not work on a vehicle with the engine running in an enclosed space, unless you are sure you have enough ventilation. • Keep all open flames and other lit material away from the battery and all fuel related parts. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 258
3. Lift the hood until the lift cylinders hold it open. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
2. Engine oil dipstick 3. Brake fluid reservoir 4. Engine coolant reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Windshield washer fluid reservoir 8. Power distribution box 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 260
2. Engine oil dipstick 3. Brake fluid reservoir 4. Engine coolant reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Windshield washer fluid reservoir 8. Power distribution box 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan. 3. Set the parking brake and ensure the gearshift is securely latched in P (Park). 4. Open the hood. Protect yourself from engine heat. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 262
2. If the engine oil level is not within the normal range, add only certified engine oil of the recommended viscosity. Remove the engine oil filler cap and use a funnel to pour the engine oil into the opening. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 263
Ford material and design specifications, start-up engine noises of knock may be experienced. It is recommended you use the appropriate Motorcraft oil filter (or another brand meeting Ford specifications) for your engine application. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Lift the battery with a battery carrier or with your hands on opposite corners. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 265
If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 266
• Freeze protection down to -36° C (-34° F). • Boiling protection up to 129° C (265° F). • Protection against rust and other forms of corrosion. • Enables calibrated gauges to work properly. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 267
When adding coolant, make sure it is a 50/50 mixture of engine coolant and distilled water. Add the mixture to the coolant reservoir, when the engine is cool, until the appropriate fill level is obtained. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 268
Add the proper mixture of coolant and water to the “cold full” level. For all other vehicles, which have a coolant degas system with a pressurized cap, or if it is necessary to remove the 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 269
Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 270
Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 271
1. Pull off the road as soon as safely possible and turn off the engine. 2. Arrange for the vehicle to be taken to a service facility. 3. If this is not possible, wait a short period for the engine to cool. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Automotive fuels can cause serious injury or death if misused or mishandled. Gasoline may contain benzene, which is a cancer-causing agent. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 273
Care should be taken to avoid inhaling excess fumes. The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 274
If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 275
Gasolines that meet the World-wide Fuel Charter should be used when available. Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 276
Refill capacities section of this chapter. The advertised capacity is the amount of the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 277
Calculation 2: Divide total miles traveled by total gallons used. Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 278
• Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy. • Use recommended engine oil. Refer to Lubricant specifications in this chapter. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 279
To make sure that the catalytic converter and other emission control components continue to work properly: • Use only the specified fuel listed. • Avoid running out of fuel. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 280
This system is commonly known as the On Board Diagnostics System (OBD-II). This OBD-II system protects the environment by ensuring that your vehicle continues to meet government emission standards. The OBD-II system also assists the 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 281
Then, start the engine and complete the above driving cycle. The engine must warm up to its normal operating temperature. Once started, do not turn off the engine until the above driving cycle is complete. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 282
If the fluid levels are outside of the normal operating range, the performance of your brake system could be compromised, seek service from your dealer immediately. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Refer to Motorcraft part numbers in this chapter. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 284
5. Install a new air filter element. Be careful not to crimp the filter element edges between the air filter housing and cover. This could cause filter damage and allow unmetered air to enter the engine if not properly seated. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 285
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 286
The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
This information identifies and describes the fundamental characteristics of the tire and also provides a U.S. DOT Tire Identification Number for safety standard certification and in case of a recall. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 288
These speed ratings may need to be adjusted for the difference in conditions. The ratings range from 159 km/h (99 mph) to 299 km/h (186 mph). These ratings are listed in the following chart. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 289
Refer to the tire label or the safety certification label, located on the B-Pillar or the driver’s door, for the correct tire pressure for your vehicle 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 290
Note: You may not find this information on all tires because it is not required by federal law. The tire suppliers may have additional markings, notes or warnings such as standard load, radial tubeless, etc. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 291
4. Maximum Load Single kg (lbs.) at kPa (psi) cold: Indicates the maximum load and tire pressure when the tire is used as a single; a single is defined as when two tires (total) are put on the rear axle. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 292
Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 293
Note: Some spare tires require higher inflation pressure than the other tires. Check the tire label on the B pillar or the driver’s door for the recommended spare tire pressure. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 294
Wheel misalignment in the front or the rear can cause uneven and rapid treadwear of your tires and should be corrected by a qualified technician at a Ford or Lincoln/Mercury dealer. Front wheel drive (FWD) vehicles, and those with an independent rear suspension require alignment of all four wheels.
Page 295
Maintenance and Specifications • Front Wheel Drive (FWD) vehicles (front tires at top of diagram) • Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD) vehicles (front tires at top of diagram) 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 296
Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Ford or Lincoln/Mercury dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 297
If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires; spinning the tires can tear the tire and cause an explosion. A tire can explode in as little as three to five seconds. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 298
• Drive cautiously. If you hear the chains rub or bang against your vehicle, stop and re-tighten the chains. If this does not work, remove the chains to prevent damage to your vehicle. • If possible, avoid fully loading your vehicle. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
The customer warranty may be void for any damage to the engine if such spark plugs are not used. Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Use only brake fluids certified to meet Ford specifications. Refer to Lubricant Specifications in this chapter. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Silicone XL-6 ESR-M13P4-A weatherstrips Lubricant Door latch, Multi-Purpose XG-4 or XL-5 ESR-M1C159-A hood latch, Grease auxiliary hood ESB-M1C93–B latch, door hinges, striker plates, seat tracks and fuel filler door hinge 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 302
Windshield Washer Concentrate Use only brake fluids certified to meet Ford specifications. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 303
1859 mm (73.2 in) (3) Overall height 1424 mm (56.0 in) (4) Wheelbase 2909 mm (114.5 in) (5) Tread - Front 1540 mm (60.6 in) (5) Tread - Rear 1543 mm (60.7 in) 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 304
Maintenance and Specifications 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 305
8. Production sequence number Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped). 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 306
Automatic 4–speed overdrive (CD4E) Automatic 4–speed overdrive (4R70W) Automatic 4–speed overdrive (4R44E) Automatic 4–speed overdrive (4R100) Automatic 5–speed overdrive (5R55E) Electric One speed electric Automatic 5–speed overdrive (5R44E) Automatic 5–speed overdrive (5R55S) 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Not all accessories are available for all models. Following is a list of several Lincoln Genuine Accessory products. Not all accessories are available for all models. To find out what accessories are available for your vehicle, please contact your dealer or visit our online store at: www.lincolnaccessories.com.
Page 309
• Mobile communications systems may harm the operation of your vehicle, particularly if they are not properly designed for automotive use. 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
....252 Axle instrument panel ....254 lubricant specifications ..301, 303 interior ........255 refill capacities ......300 interior trim ......254 plastic parts ......253 washing ........251 waxing ........251 Battery ........264 wheels ........252 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 311
.........249 Engine oil ........261 The Dispute Settlement checking and adding ....261 Board ........244 dipstick ........261 Utilizing the filter, specifications ..263, 299 Mediation/Arbitration recommendations ....263 Program ........247 refill capacities ......300 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 312
Gas cap (see Fuel cap) ....274 Jack ..........230 positioning .......230 Gas mileage storage ........230 (see Fuel economy) ....276 Gauges .........15 Jump-starting your vehicle ..235 Hazard flashers ......219 Keyless entry system ....147 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 313
....300 Message center ....123, 125 fluid, specifications ..301, 303 select button ......123 Power Windows ......106 warning messages ....128 Mirrors .......105, 108 automatic dimming rearview mirror ........108 Radio ........17, 21 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 314
........241 Setting the clock Traction control ......202 AM/FM/In-dash 6 CD ....19 Transmission ......205 AM/FM/Tape/CD .......23 brake-shift interlock (BSI) ..205 Spark plugs, fluid, checking and adding specifications .....299, 303 (automatic) ......283 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Page 315
Windshield washer fluid and Vehicle Identification Number wipers ........102 (VIN) ..........305 checking and adding fluid ..261 replacing wiper blades ...102 Vehicle loading ......213 Wrecker towing ......241 Ventilating your vehicle ...199 2004 Lincoln LS (dew) Owners Guide (post-2002-fmt) USA English (fus)
Need help?
Do you have a question about the 2004 LS and is the answer not in the manual?
Questions and answers
