FIMI X8 MINI Drone Quick Start Manual
Please read the quick start manual carefully before using and keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X8 MINI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FIMI X8 MINI

  • Page 1 FIMI X8 MINI Drone Quick Start Manual Please read the quick start manual carefully before using and keep it for future reference.
  • Page 2: Product Introduction

    Product Introduction 1 Drone Clockwise propeller Counterclockwise propeller Landing gear Integrated gimbal camera Motor...
  • Page 3 Power button Battery level light Optical flow camera TOF sensor Charging port Flight status light WIFI/RC switch...
  • Page 4: Remote Controller

    2 Remote controller Battery level lights Power button Mobile holder Stick Stick storage slot Charging port Auto return...
  • Page 5 Antenna Record button Shoot button Dial...
  • Page 6 Description of RC Button Buttons Function description Push stick upward, the drone goes up Pull stick downward, the drone goes down Left stick Toggle stick to left, the drone rotates anticlockwise Toggle stick to right, the drone rotates clockwise Push stick upward, the drone flies forward Pull stick downward, the drone flies backward Right stick Toggle stick to left, the drone flies to left...
  • Page 7 Backward Right Forward Left Drone heading Down Forward Counter Clockwise Left Right clockwise Down Backward Left stick Right stick Note: The stick mode can be set in FIMI Navi Mini app. (The default is Mode 2)
  • Page 8: Drone Specifications

    Drone Specifications Drone Remote controller Product model:FMWRJ04A7 Product model: FMYKQ04A7 Max ascending speed:5m/s Net weight:About 260g Max descending speed:3.5m/s Dimensions: 165x89x47mm Max flight speed:16m/s Operating frequency:5.725-5.850GHz Operating temperature:0~40℃ Type:Rechargeable lithium battery Suitable altitude:≤4000m Battery voltage: 3500mAh FCC ID: 2AYVYFMWRJ04A7 Nominal voltage: 3.7V Operating frequency:5.725-5.850GHz Input: 5V Dimensions:145×85×56mm (folded)
  • Page 9: Gimbal Camera

    6m/s (no wind or breeze environment) after being fully charged *Remote control distance reaches to 8km (FCC) in open area and no interference. All testing and data above come from FIMI laboratory. Errors may occur in actual use because of operating and environmental changes.
  • Page 10: Ready To Fly

    Ready to fly 1 Equip and remove the gimbal protector Equip and remove the gimbal protector as shown Equip the gimbal protector as Remove the gimbal protector as the arrow leading the arrow leading...
  • Page 11 2 Battery Hard push the battery. There will be a “click” sound if the battery is installed in place. To remove the battery, you need to press the bottom battery buckle to pull out. Battery buckle Safety tips: Please take the battery out of the drone and keep it separately when not in use.
  • Page 12 3 Propeller Please install and remove the propellers as the picture shown. The propellers need to be installed according to the marks on the arms and propellers, and distinguished the forward and reverse propellers (the attached picture shows the forward propeller.) Need to use a screwdriver for installation and make sure the screws are locked well.
  • Page 13: Insert Micro Sd Card

    4 Insert Micro SD card When installing Micro SD card, please pull out the battery. Insert the SD card into the SD card slot. When removing SD card, press the SD card to pop out.
  • Page 14 5 Charge Connect the remote controller to a power adapter as shown below. When the RC is in charge, the battery level lights are flashing. When the RC is fully charged, the battery level lights go out. It takes about 2.5 hours to fully charge the RC in the powered off condition.
  • Page 15 The battery status light keeps on when charging. The battery level light off when charging finished. It takes 2.5h to fully charge the batter via 5V/2A, 1.5h via 9V/2A and 1h via 9V/3A.
  • Page 16 6 Remote controller Use USB cable to connect the device as shown. Unfold the RC to place the device.
  • Page 17 7 Distinguish the direction of drone The side of gimbal camera is head of drone. Distinguish the direction of drone through status light. Drone heading Safety tips:User should face to the tail of drone when operating it, in case of accident caused by wrong direction.
  • Page 18 8 urning on/off the drone and the RC Short press+long press power button 2 seconds to power on/off. Short press to check battery level. Confirm the current state of the Wi-Fi / RC switch before powering on (factory default RC position); switch control mode requires restarting the device. Power button Power button...
  • Page 19 Flying 1 Auto take-off/landing Keep both sticks to the bottom inner still over 2 seconds, the propellers start spinning. Release both sticks once propellers have been spinning, and firmly push the left stick upward to take off the drone. During flight, release both sticks to hover. Left stick Right stick Left stick...
  • Page 20 2 Stop propellers in emergency When motors can’t be properly turned off, please toggle the left stick to the bottom inner maximum range, and press auto take-off in/landing button for 5 seconds simultaneously, then motors will stop. Safety tips: Do not do the operation above during normal flight to avoid motors being stopped in the air.
  • Page 21 3 Shooting and recording Press the shoot button to take a photo. A photo is taken when you hear 2 short sounds. Press the record button to record video. Recording starts when you hear 2 short sounds. Press again to stop recording with 4 short sounds. The pitch angle of the gimbal can be controlled by toggling the left dial up and down.
  • Page 22 Light Recognition 1 Drone light Drone status Light status The yellow light is fading in and out Self-checking Drone on the ground: self-check fails Red light on Drone is flying: internal error Red and yellow lights flash alternately Calibrate the compass Red light flashing twice Ready to fly/in flight Red light flashing twice...
  • Page 23 Safety Flight In visual range Good GPS signal Open and unobstructed environment Safety tips: Fly only in open area, and avoid people, animals, trees vehicles and buildings. Keep away from airports, railways, highways, high-rises, electric wires and areas where drones are restricted. Keep away from telecommunication base stations, high-power antennas and areas with complex electromagnetic signals.
  • Page 24 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 25 The FIMI X8 Mini Drone should be installed and operated with minimum distance 20cm between the radiator & your body. Scan the QR code to download FIMI Navi Mini APP...
