FIMI X8 Pro User Manual
Please read the user manual carefully before using and keep the manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X8 Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FIMI X8 Pro

Summary of Contents for FIMI X8 Pro

  • Page 1 FIMI X8 Pro User Manual Please read the user manual carefully before using and keep the manual for future reference.
  • Page 2 V1.0...

  • Page 3: Table Of Contents

    Contents Services & Support ·1 Package List ·2 Product Instruction ·3 Drone ·6 Safety and Protection · 7 Intelligent flight ·9 Visual System and Infrared Sensing System ·16 Assembly and Disassembly ·19 Smart battery ·21 Gimbal and Camera ·24 Remote controller ·26 ·31 ·34...

  • Page 4: Services & Support ·1

    FIMI X8 Pro Disclaimer and Safety Operation Instructions carefully and get image transmission. The APP enriches the remote controller with more features to know the process of using by going through FIMI X8 Pro Quick Start Manual. and fast connection. The remote controller fits iPad Miniat the maximum range.
  • Page 5 Remote controller x 1 Charger x 1 Dustproof plug x 1 FIMI X8 SE 无人机快速入门指南 使 用 产 品 前 请 仔 细 阅 读 本 快 速 入 门 指 南 ， 并 妥 善 保 管 AC cable x 1...
  • Page 6 Product Introduction 1 Drone Landing gear 12-PIN Data interface TOF sensor Fill-in light Downward Positive propeller Power button Battery level lights sensing system Forward Reverse propeller sensing system Integrated gimbal camera Flight status lights Backward Motor sensing system Drone tail light Battery buckle...
  • Page 7 2 Remote controller Flight mode/auto return Stick storage slot Mobile device holder Left dial Record button Shoot button Left stick Right stick Power button USB port Cable slot Five-directional button Antenna Right dial Battery level lights Charging port Auto take-off/land button...
  • Page 8 • The other functions of the five-directional button can be set in the FIMI Navi 3.0 App. • The joystick function is the default mode, which can be set through the FIMI Navi 3.0 App. • The stick mode can be set in FIMI Navi app (the default is American hand).

  • Page 9: Drone ·6

    Drone • At altitudes above 2400 meters, the sport mode will be deactivated. • When flying in sport mode, the visual system will not function, and the drone will be unable to brake or avoid obstacles actively. Flight Mode • When flying in sport mode, the drone's speed will be significantly increased compared to normal mode, resulting in a corresponding increase in braking distance.

  • Page 10: Safety And Protection

    Failsafe Return Hovering on the Edge of No-fly-zone Fimi Navi 3.0 allows setting the behavior of the drone when the remote control The drone will automatically hover in the restricted flight area designated by signal is interrupted to return, land, or hover. When set to return, if the GNSS...
  • Page 11 Otherwise, if the battery is completely depleted, the drone will descend rapidly, leading to • Before takeoff, it is necessary to enter the safety settings interface of Fimi Navi 3.0 and set an appropriate return-to-home altitude (default is 30m).

  • Page 12: Intelligent Flight ·9

    1.2m meters or more, the drone will directly return to the home point . The user can toggle the Auto Return Switch or click the " X " button in the FIMI Navi 3.0 app to exit. GPS Mode VPU Mode Altitude altitude ≥30m...
  • Page 13 Follow flight is only supported in GNSS mode. Users can enter the Smart tracking menu by clicking on the “ ” icon in the FIMI Navi 3.0 App. They can then select "Normal Follow," "Parallel Follow," or "Lock Follow." The drone drone moving direction will track the target selected within the app's frame as the tracking target.
  • Page 14 • • After setting the parameters, click "GO". During Orbit mode, you can set the direction and speed of the Orbit flight in the Fimi If sticks are moved in flight, the flight altitude or radius will be changed. Taking Navi 3.0 app.
  • Page 15 Tap-fly Spiral Mode The user can select Spiral Mode in the App. Set the central point and radius, The user can select Tap-fly in the App. Tap map to choose a destination and the drone will spirally fly upward and shoot a video simultaneously, showing a set flight speed, the drone will fly over there at a default speed in a straight line.
  • Page 16 Dronie Rocket Invert The user can select Dronie,including Rocket and Invert,in the App. In Rocket fly backwards and upwards mode, the drone flies upward with the camera pointing downward at the subject fly vertically upward to shoot a video. In Invert mode, the drone flies backward and upward with the camera locking at the subject to shoot a video.
  • Page 17 Waypoint Choosing points on the map • Tap map to add waypoint Choosing waypoint and drawing route both are available at map. The drone • flies along waypoint route at a default speed. If a point of interest is set, Set waypoint attribute, including flight altitude, action at the destination, rotate direction the camera will be locked at the POI.
  • Page 18 Precise Landing Waypoint In the process of Return to Home, the optical flow sensor will match landing pad features above the home point. Once matched successfully, the drone will land on the landing pad precisely. SAR Mode The user can select SAR Mode in the APP. With real-time GPS coordinates, the drone could help user to search and rescue.

  • Page 19: Visual System And Infrared Sensing System ·16

    Visual System and Infrared Sensing System The automatic calibration of the visual system is already completed during The FIMI X8 Pro is equipped with front, rear, and bottom binocular vision systems the factory assembly, and it can function properly. During the flight, if the...
  • Page 20 ( need to select obstacle with insufficient or excessive light intensity. avoidance behavior as go around or brake stop in FIMI Navi 3.0 App). The forward and backward vision systems are suitable for well-lit environments,...
  • Page 21 d) surfaces with moving objects ( such as above foot traffic, above bushes or grass blown by high winds) e) Scenarios with intense and rapid changes in lighting conditions. j) Tiny obstacles (such as tree branches, wires, etc.). Do not obscure or interfere with the visual system in any way, and make sure the lens is clear and free of smudges.

  • Page 22: Assembly And Disassembly ·19

    • Press the propeller forcefully and rotate the propeller along the unlock direction to remove The FIMI X8 Pro intelligent flight battery has a rated voltage of 15.4V. This battery the propeller. model utilizes high-energy cells for a 40-minute flight time and incorporates an advanced battery management system with charging and discharging management functions.
  • Page 23 Megaphone module Drone Micro SD card • Install the megaphone module as the indicated • When installing SD card to the drone,please unfold the arms of the drone direction，there will be a "click" sound. first and open the protection cover •...
  • Page 24 Intelligent Battery 7. Over-discharge protection: Excessive discharge will damage the battery. When the battery is not used for flight, the battery will be discharged to a certain voltage when Cut off the output. The battery will not enable over-discharge protection during flight. 8.
  • Page 25 Power On and Off Power on/off key To turn on/off the battery, perform a short or long press on the battery button for more than 2 seconds. When the battery is on, the power indicator light will LED 1 display the current battery level. LED 2 LED 3 LED 4...
  • Page 26 • Recharge and discharge the battery every 3 months to maintain battery activity. • Use the official charger provided by FIMI for charging the smart battery. FIMI will not be held responsible for any consequences resulting from the use of non-FIMI chargers.

  • Page 27: Gimbal And Camera ·24

    Gimbal and Camera Gimbal FIMI X8 Pro combines a light weight 3-axis mechanical gimbal FIMI X8 Pro gimbal is an integrated gimbal that utilizes three-axis with the latest professional control algorithms and ±0.005°control mechanical stabilization technology to provide a stable shooting accuracy, which provides a stable shooting platform for camera.
  • Page 28 • Properly turn off the smart flight battery to save camera parameters and prevent video damage. FIMI is not responsible for any damage caused by unreadable videos or photos.

  • Page 29: Remote Controller ·26

    Remote controller Charge • Connect the remote controller to a power adapter as show below With ergonomic design, it is easier and more precise to control. There • When the RC is in charge, the battery level lights are flashing is no complicated operation to connect App, just plug in and it works.
  • Page 30 Press again to stop recording with 4 short sounds. • Connect the drone and update firmware according to instructions in FIMI App. • The pitch angle of the gimbal can be controlled by toggling the left dial up and down.
  • Page 31 Shortcut Buttons • Toggle the auto return button to the right when the drone is in flight, the drone will return to the home point. • In the process of auto return, toggle the auto return button to the left, the drone will hover at place and wait for sticks instructions.
  • Page 32 Sticks Control Remote Controller Pairing Mode 1 When a new remote controller or drone is replaced, please pair the remote controller and the drone again as shown below： Forward • Turn on the drone • Turn on the RC, long press the power button 15 seconds until hearing Counter- Clockwise Left...
  • Page 33 Remote lights Remote lights Remote status Power button's red light are on Weak signal Power button's red light flashes Not connected to the drone Power button's red light flashes RC Pairing or upgrading firmware Power button's white light is on Normal signal Power button's white light flashes Recording videos...

  • Page 34: App ·31

    1. Real-time Flight Parameters After downloading and installing the APP, register the FIMI user account and log in. Click to enter the flight interface, or you can : Tap to return to the home screen. use it without logging in.
  • Page 35 4. Attitude ball 9. Intelligent Flight : Displays the drone head orientation, tilt angle, remote control position and Enter the intelligent flight page, where you can perform one-click auto takeoff, landing, and return to home. It supports waypoint navigation, orbit mode, other information.
  • Page 36 10 Drone gear mode Map Interface ：Display the current aircraft gear mode, click to switch between“Sport” “Normal”“Cine”mode Sport：Max horizontal speed 18m/s, Max ascent speed 5m/s, Max descent speed 4m/s Normal：Max horizontal speed 10m/s, Max ascent speed 4m/s, Max descent speed 3m/s Cine：Max horizontal speed 6m/s, Max ascent speed 1.5m/s, Max descent speed 1.5m/s 11.

  • Page 37: Fly ·34

    • Make sure the front and rear propellers are extended in place is the tail. • Whether the camera and gimbal work normally after powering on • Make sure the FIMI Navi 3.0 is running normally Automatic take off / landing Drone heading...
  • Page 38 Stop propellers in an emergency • Keep both sticks to the bottom inner still over 3 seconds, the propellers start spinning. • Release both sticks once propellers have been spinning, and firmly push the left stick upward to take off the drone. When motors can't properly turn off, please toggle the left stick to the bottom inner in maximum range, and press Auto take-off/landing button for 5 seconds •...
  • Page 39 Flying Condition Requirement 1. The drone is suitable for people above 18 years who have full civil capacity. 2. Make sure to keep some distance from people, animals, trees, vehicles and buildings while using the drone. Please be careful when someone approaches.

  • Page 40: Maintenance And Calibration ·37

    Flight Data The compass may need to be recalibrated when there are changes The FIMI X8 Pro flight control is equipped with a flight logging function, in the magnetic field to ensure proper flight. If the aircraft requires which stores all relevant data after the drone is powered on in the compass calibration, the app will provide corresponding prompts.
  • Page 41 Do not place the battery under the burning sun. Gimbal Maintenance The gimbal of the FIMI X8 Pro is an integrated unit and does not require disassembly. When storing the aircraft, please be careful not to scratch or collide with the camera, and pay attention to keeping the camera clean.
  • Page 42 2. Once the firmware download is complete, the Fimi Navi App will 4. When upgrading the drone, use the provided OTG cable to connect prompt for the upgrade. one end of the USB cable to your phone and the other end to the drone.
  • Page 43 5. After the upgrade is complete, disconnect the data cable connected to the drone, and use a USB cable to connect the remote controller and the mobile phone.. • Make sure to follow the firmware upgrade steps, otherwise, it may result in a failed upgrade. •...

  • Page 44: Basic Specification ·41

    The 40/47 mins flight time refers to the situation where the battery is relatively new and fully charged, and the video recording is turned off during a constant speed flight at 6-8m/s (in a windless environment) without the Megaphone with release-and-drop module. Remote control distance reach to 15km (FCC) in open area and no interference . All above testing and data come from FIMI laboratory, errors may occur in actual use for...
  • Page 45 Intelligent Flight Battery Type：Li-Po 4S Weight：About 280g Capacity：3800mAh Voltage：15.4V Limit voltage：17.6V Energy：58.52Wh Operating temperature：0°C ~ 40°C Intelligent Flight Battery Plus Type：Li-Po 4S Weight：About 330g Capacity：5000mAh Voltage：14.8V Limit voltage：16.8V Energy：74Wh Operating temperature：0°C ~ 40°C...
  • Page 46 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
