FIMI X8 SE 2022 User Manual
Please read the user manual carefully before using and keep the manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X8 SE 2022 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FIMI X8 SE 2022

Summary of Contents for FIMI X8 SE 2022

  • Page 1 FIMI X8 SE 2022 User Manual Please read the user manual carefully before using and keep the manual for future reference.
  • Page 2 V2.0...

  • Page 3: Table Of Contents

    Contents Services & Support ·1 Package List ·2 Product Instruction ·3 Drone ·6 Safety and Protection · 7 Intelligent flight ·8 Assembly and Disassembly ·13 Smart battery ·13 Gimbal and Camera ·16 Remote controller ·18 ·22 ·25 Maintenance and Calibration ·27 Basic Specification ·29...

  • Page 4: Product Instruction

    FIMI X8 SE 2022 Disclaimer and Safety Operation Instructions carefully and get APP enriches the remote controller with more features to know the process of using by going through FIMI X8 SE Quick Start Manual. For more detailed product information, please refer to FIMI X8 SE 2022User Manual.
  • Page 5 Remote controller x 1 Charger x 1 Dustproof plug x 1 FIMI X8 SE 无人机快速入门指南 使 用 产 品 前 请 仔 细 阅 读 本 快 速 入 门 指 南 ， 并 妥 善 保 管 AC cable x 1...
  • Page 6 Product Introduction 1 Drone Positive propeller Power button Battery level lights Landing gear 12-PIN Data interface Fill-in light TOF sensor Optical flow camera Reverse propeller Integrated gimbal camera Flight status lights Motor Drone tail light Battery buckle...
  • Page 7 2 Remote controller Flight mode/auto return Stick storage slot Mobile device holder Left dial Record button Shoot button Left stick Right stick Power button USB port Cable slot Five-directional button Antenna Right dial Battery level lights Charging port Auto take-off/land button...
  • Page 8 The stick mode can be set in FIMI Navi app (the default is American hand). • The other functions of the five-directional button can be set in the FIMI Navi 2020 App. • The joystick function is the default mode, which can be set through the FIMI Navi 2020 App.

  • Page 9: Drone ·6

    Drone Flight Mode Drone Lights GPS Mode Drone lights Drone status To achieve precise hovering, the drone is equipped with a GPS module. All lights are fading in and out Self-checking The intelligent flight function works in GPS mode. Users can enable Sport Drone on the ground: self-check fails All lights are on Mode or Beginner Mode in the flight settings.

  • Page 10: Safety And Protection

    Safety Protection Low-power Protection Failsafe Return Failsafe return is only supported in GPS mode. When the drone and remote In flight, when the battery level is only enough for RTH, App advises users controller signal is interrupted for more than 2 seconds, the flight control to return, and the drone will return automatically after 10 seconds countdown.

  • Page 11: Intelligent Flight

    Intelligent Flight Auto Take-off Auto Return When the conditions are right, press Auto Take-off/Landing button for 2 When the drone is in flight, the user can toggle the auto return switch to seconds to take off. In GPS mode, the drone will take off to an altitude of the right to return the drone.
  • Page 12 Smart Track In Lock mode, the drone will hover at a place if flight speed is 0, following the target 360°. The user can also adjust flight speed, and the drone will fly around Smart Track is supported only in GPS mode. The user can choose Trace, the target at a certain distance.
  • Page 13 Orbit Tap-fly The user can select Orbit mode in the App. when a central point and a radius The user can select Tap-fly in the App. Tap map to choose a destination are set, the drone will fly around the central point at a default speed. If a and set flight speed, the drone will fly over there at a default speed in a point of interest is set, the camera will be locked at the POI.
  • Page 14 Spiral Mode The user can select Spiral Mode in the App. Set the central point and radius, the drone will spirally fly upward and shoot a video simultaneously, Rocket Invert showing a sense of space. fly backwards and upwards Fly to a point to set as the central point fly vertically upward Fly away the central point to set radius Set spiral direction and flight distance to start and shoot a video at the same time...
  • Page 15 Waypoint Precise Landing Choosing waypoint and drawing route both are available at map. The drone In the process of Return to Home, the optical flow sensor will match landing flies along waypoint route at a default speed. If a point of interest is set, pad features above the home point.

  • Page 16: Assembly And Disassembly

    Assembly and Disassembly Battery Propellers The intelligent battery of FIMI X8 SE 2022 has a capacity of 4500mAh, a voltage of 13.05V. This type of battery employs high energy cell, Unfold the front and rear arms of the drone. advanced battery management system, and charge and discharge Attach the gray marked propellers to the motor mounting base with gray marks functionality.
  • Page 17 Drone Micro SD card Megaphone & Release-and-drop module Install the megaphone & Release-and-drop module as the indicated direction，there will be a "click" sound. When installing SD card to the drone,please unfold the arms of the drone After the installation is successful, the corresponding icon will appear on first and open the protection cover the APP, click to set the relevant settings.
  • Page 18 • Recharge and discharge every 3 months or so to ensure battery activity. • The smart battery must be charged with the official Femto charger.FIMI will not take any responsibility for all consequences.

  • Page 19: Gimbal And Camera

    Gimbal and Camera Equip and remove the gimbal protector Equip and remove the gimbal protector as shown Camera The camera, equipped with 1/2.0 inch CMOS and wide-angle lens with 25mm equivalent focal distance, It also comes with various shooting modes, inculding single, burst, time lapse, panorama shot and slow motion, for different scenario.
  • Page 20 Gimbal FIMI X8 SE 2022 combines a light weight 3-axis mechanical gimbal Operating Mode with the latest professional control algorithms and ±0.005° control accuracy, which provides a stable shooting platform for camera. The pitch axis, default to tilt from 0°to -90°, can be Follow Mode: adjusted by left dial of remote controller or App.

  • Page 21: Remote Controller

    Remote controller Charge With ergonomic design, it is easier and more precise to control. There is no complicated operation to connect App, just plug Connect the remote controller to a power adapter as show below in and it works. The remote controller fully charged can work When the RC is in charge, the battery level lights are flashing about 4.5 hours.
  • Page 22 Connect your phone and the RC with a USB cable. The pitch angle of the gimbal can be controlled by toggling the left dial Connect the drone and update firmware according to instructions in Fimi up and down. Navi 2020 app.
  • Page 23 Shortcut Buttons Toggle the auto return button to the right when the drone is in flight, the drone will return to the home point. In the process of auto return, toggle the auto return button to the left, the drone will hover at place and wait for sticks instructions.
  • Page 24 Sticks Control Remote Controller Pairing When a new remote controller or drone is replaced, please pair Mode 1 the remote controller and the drone again as shown below： Turn on the drone Forward Turn on the RC, long press the power button 15 seconds until hearing constant beep sound，and the power button red light flashes Short press the code pairing button on the drone , the yellow light on the drone Counter-...

  • Page 25: App ·22

    28.8m: vertical flight altitude from the home point Download and install Fimi Navi 2020 app, register a FIMI user ：32.8m: horizontal distance from the home point account before login, and select FIMI X8 SE 2020 to enter device VS1.23m/s: vertical speed HS1.80m/s: horizontal speed...
  • Page 26 4. Map Interface 8 Intelligent Flight : Displays the drone head orientation, tilt angle, remote control position and other Tap to enter intelligent flight interface information. Click to switch the map to display the aircraft in real timeLocation ：Auto Take-off 5.
  • Page 27 9 Drone gear mode Map Interface ：Display the current aircraft gear mode, click to switch between“Sport” “Normal”“Cine”mode Sport：Max horizontal speed 18m/s, Max ascent speed 5m/s, Max descent speed 4m/s Normal：Max horizontal speed 10m/s, Max ascent speed 4m/s, Max descent speed 3m/s Cine：Max horizontal speed 6m/s, Max ascent speed 1.5m/s, Max descent speed 1.5m/s 10.Shortcuts...

  • Page 28: Fly ·25

    Whether the camera and gimbal work normally after powering on The red light and the green light indicate the heading,and the yellow light Make sure the FIMI Navi 2020 is running normally is the tail. Manual take off Drone heading...
  • Page 29 Manual take landing Flying Condition Requirement 1. The drone is suitable for people above 18 years who have full civil capacity. Slowly move the left stick downward to 2. Make sure to keep some distance from people, animals, trees, vehicles land the drone and buildings while using the drone.

  • Page 30: Maintenance And Calibration

    Maintenance and Calibration Remote Controller Calibration Gimbal Calibration Please try to calibrate the remote controller when you detect Click "gimbal calibration" and enter the calibration page in the gimbal settings menu. inconsistencies between stick control and drone flying. After the drone is placed smoothly, click to start calibration. Select "RC Calibration"...
  • Page 31 Please check the firmware version regularly, new version will Lithium battery's capacity reduces significantly in low temperature be pushed by Fimi Navi 2020 App to prompt users to update. conditions. Do not use the battery when it is below 5 degrees.

  • Page 32: Basic Specification

    The 35 minutes flight time refers to constant speed at 6-8m/s (no wind) with fully charged and low cyclic battery. Remote control distance reach to 10km (FCC) in open area and no interference . All above testing and data come from FIMI laboratory, errors may occur in actual use for operating and environmental changes.
  • Page 33 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
