- Page 1 飞米 MINI 3无人机快速入门指南 使用产品前请仔细阅读本快速指南并妥善保管 FIMI MINI 3 Drone Quick Start Manual Please read the quick start manual carefully before using and keep it for future reference.
-
Page 2: Product Introduction
Product Introduction 1 Drone Clockwise propeller Counterclockwise propeller Landing gear Integrated gimbal camera Motor... - Page 3 Power button Battery level light Optical flow camera TOF sensor Charging port Flight status light...
-
Page 4: Remote Controller
2 Remote controller Battery level lights Power button Mobile holder Stick Stick storage slot Charging port Auto return... - Page 5 Antenna Record button Shoot button Dial...
- Page 6 Description of RC Button Buttons Function description Push stick upward, the drone goes up Pull stick downward, the drone goes down Left stick Toggle stick to left, the drone rotates anticlockwise Toggle stick to right, the drone rotates clockwise Push stick upward, the drone flies forward Pull stick downward, the drone flies backward Right stick Toggle stick to left, the drone flies to left...
- Page 7 Right stick Down Move backward Sideways Flight Left stick Right stick Left Fly to the left Left stick Right stick Right Fly to the Right Note: The stick mode can be set in FIMI Navi app (the default is American hand).
- Page 8 Remote Controller Communication Range When operating an aircraft, it is necessary to timely adjust the orientation and distance between the remote controller and the aircraft, as well as adjust the antenna position to ensure that the aircraft always remains within the optimal communication range.
- Page 9 Backward Right Forward Left Drone heading Down Forward Counter Clockwise Left Right clockwise Down Backward Left stick Right stick Note: The stick mode can be set in FIMI Navi Mini app. (The default is Mode 2)
-
Page 10: Ready To Fly
Ready to fly 1 Equip and remove the gimbal protector Equip and remove the gimbal protector as shown Equip the gimbal protector as Remove the gimbal protector as the arrow leading the arrow leading... - Page 11 2 Battery Hard push the battery. There will be a “click” sound if the battery is installed in place. To remove the battery, you need to press the bottom battery buckle to pull out. Battery buckle Safety tips: Please take the battery out of the drone and keep it separately when not in use.
- Page 12 3 Propeller Please install and remove the propellers as the picture shown. The propellers need to be installed according to the marks on the arms and propellers, and distinguished the forward and reverse propellers (the attached picture shows the forward propeller.) Need to use a screwdriver for installation and make sure the screws are locked well.
-
Page 13: Insert Micro Sd Card
4 Insert Micro SD card When installing Micro SD card, please pull out the battery. Insert the SD card into the SD card slot. When removing SD card, press the SD card to pop out. - Page 14 5 Charge Connect the remote controller to a power adapter as shown below. When the RC is in charge, the battery level lights are flashing. When the RC is fully charged, the battery level lights go out. It takes about 2.5 hours to fully charge the RC in the powered off condition. After fully charged, the endurance time when connected to a device is approximately 4 hours.
- Page 15 The battery status light keeps on when charging. The battery level light off when charging finished. It takes 2.5h to fully charge the batter via 5V/2A, 1.5h via 9V/2A and 1h via 9V/3A. After fully charged, the flight endurance time during hover is approximately 29 minutes.
- Page 16 6 Remote controller Use USB cable to connect the device as shown. Unfold the RC to place the device.
- Page 17 7 Distinguish the direction of drone The side of gimbal camera is head of drone. Distinguish the direction of drone through status light. Drone heading Safety tips：User should face to the tail of drone when operating it, in case of accident caused by wrong direction.
- Page 18 8 urning on/off the drone and the RC Short press+long press power button 2 seconds to power on/off. Short press to check battery level. Confirm the current state of the Wi-Fi / RC switch before powering on (factory default RC position); switch control mode requires restarting the device. Power button Power button...
-
Page 19: Remote Controller Pairing
Remote Controller Pairing When a new remote controller or drone is replaced, please pair the remote controller and the drone again as shown below： Turn on the drone and remote controller. Wait for 20 seconds, then long press the power button of controller until hearing the beep sound, and the light will be flashing. - Page 20 Light Recognition 1 Drone light Drone status Light status The yellow light is fading in and out Self-checking Drone on the ground: Self-check fails Red light on Drone is flying: Attitude Mode Red and yellow lights flash alternately Calibrate the compass Red light flashing twice Ready to fly/in flight Red light flashing twice...
- Page 21 Flying 1 Auto take-off/landing Keep both sticks to the bottom inner still over 2 seconds, the propellers start spinning. Release both sticks once propellers have been spinning, and firmly push the left stick upward to take off the drone. During flight, release both sticks to hover. Left stick Right stick Left stick...
- Page 22 2 Stop propellers in emergency When motors can’t be properly turned off, please toggle the left stick to the bottom inner maximum range, and press auto take-off in/landing button for 5 seconds simultaneously, then motors will stop. Safety tips： Do not do the operation above during normal flight to avoid motors being stopped in the air.
- Page 23 3 Shooting and recording Press the shoot button to take a photo. A photo is taken when you hear 2 short sounds. Press the record button to record video. Press again to stop recording with 4 short sounds. The pitch angle of the gimbal can be controlled by toggling the left dial up and down. Record button Shoot button Dial...
- Page 24 Safety Flight In visual range Good GPS signal Open and unobstructed environment Safety tips： Fly only in open area, and avoid people, animals, trees vehicles and buildings. Keep away from airports, railways, highways, high-rises, electric wires and areas where drones are restricted. Keep away from telecommunication base stations, high-power antennas and areas with complex electromagnetic signals.
- Page 25 FIMI MINI 3 Drone FCC ID: 2AYVYFMWRJ04A3 Remote Controller FCC ID: 2AYVYFMYKQ04A3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 26 Drone: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Scan the QR code to download FIMI Navi Mini App...
