  • Page 1 User Manual FIMI X8 Tele Please read the user manual carefully before using and keep the manual for future reference.
  • Page 2 V3.0...
  • Page 3 · 7 Intelligent flight ·9 Cruise control ·16 ZOOM ·18 Assembly and Disassembly ·19 Intelligent battery ·21 Dual main gimbal Camera ·24 Remote controller ·27 ·32 ·35 Maintenance and Calibration ·38 FIMI Enhanced Video Transmission Module ·40 Basic Specification ·44...
  • Page 4 ISP processor and high-definition real-time transmission. to know the process of using by going through FIMI X8 Tele Quick Start Manual. The FIMI Navi 3.0 App adopts a minimalist UI design, offering a larger image For more detailed product information, please refer to FIMI X8 Tele User Manual.
  • Page 5 Remote controller x 1 Smart Charging Case x 1 Charger x 1 FIMI X8 SE 无人机快速入门指南 使 用 产 品 前 请 仔 细 阅 读 本 快 速 入 门 指 南 ， 并 妥 善 保 管 Dustproof plug x 1...
  • Page 6 Product Introduction 1 Drone Landing gear 12-PIN Data interface TOF sensor Fill-in light Downward Positive propeller Power button Battery level lights sensing system Reverse propeller Integrated gimbal camera Flight status lights Motor Drone tail light Battery buckle...
  • Page 7 2 Remote controller Flight mode/auto return Stick storage slot Mobile device holder Left dial Record button Shoot button Left stick Right stick Power button USB port Cable slot Five-directional button Antenna Right dial Battery level lights Charging port Auto take-off/land button...
  • Page 8 • The other functions of the five-directional button can be set in the FIMI Navi 3.0 App. • The joystick function is the default mode, which can be set through the FIMI Navi 3.0 App. • The stick mode can be set in FIMI Navi app (the default is American hand).
  • Page 9 Drone • At altitudes above 2400 meters, the sport mode will be deactivated. • When flying in sport mode, the visual system will not function, and the drone will be unable to brake or avoid obstacles actively. Flight Mode • When flying in sport mode, the drone's speed will be significantly increased compared to normal mode, resulting in a corresponding increase in braking distance.
  • Page 10 Failsafe Return Hovering on the Edge of No-fly-zone Fimi Navi 3.0 allows setting the behavior of the drone when the remote control The drone will automatically hover in the restricted flight area designated by signal is interrupted to return, land, or hover. When set to return, if the GNSS...
  • Page 11 Otherwise, if the battery is completely depleted, the drone will descend rapidly, leading to • Before takeoff, it is necessary to enter the safety settings interface of Fimi Navi 3.0 and set an appropriate return-to-home altitude (default is 30m).
  • Page 12 1.2m meters or more, the drone will directly return to the home point . The user can toggle the Auto Return Switch or click the " X " button in the FIMI Navi 3.0 app to exit. GPS Mode VPU Mode Altitude altitude ≥30m...
  • Page 13 Follow flight is only supported in GNSS mode. Users can enter the Smart tracking menu by clicking on the “ ” icon in the FIMI Navi 3.0 App. They can then select "Normal Follow," "Parallel Follow," or "Lock Follow." The drone drone moving direction will track the target selected within the app's frame as the tracking target.
  • Page 14 • • After setting the parameters, click "GO". During Orbit mode, you can set the direction and speed of the Orbit flight in the Fimi If sticks are moved in flight, the flight altitude or radius will be changed. Taking Navi 3.0 app.
  • Page 15 Tap-fly Spiral Mode The user can select Spiral Mode in the App. Set the central point and radius, The user can select Tap-fly in the App. Tap map to choose a destination and the drone will spirally fly upward and shoot a video simultaneously, showing a set flight speed, the drone will fly over there at a default speed in a straight line.
  • Page 16 Dronie Rocket Invert The user can select Dronie,including Rocket and Invert,in the App. In Rocket fly backwards and upwards mode, the drone flies upward with the camera pointing downward at the subject fly vertically upward to shoot a video. In Invert mode, the drone flies backward and upward with the camera locking at the subject to shoot a video.
  • Page 17 Waypoint Choosing points on the map • Tap map to add waypoint Choosing waypoint and drawing route both are available at map. The drone • flies along waypoint route at a default speed. If a point of interest is set, Set waypoint attribute, including flight altitude, action at the destination, rotate direction the camera will be locked at the POI.
  • Page 18 Precise Landing Waypoint In the process of Return to Home, the optical flow sensor will match landing pad features above the home point. Once matched successfully, the drone will land on the landing pad precisely. SAR Mode The user can select SAR Mode in the APP. With real-time GPS coordinates, the drone could help user to search and rescue.
  • Page 19 The aircraft will respond to these stick inputs for directional adjustments. Once the sticks are centered, the aircraft will resume cruising at the preset speed. 1. Cruise Control Switch Users can open the cruise control switch in the Fimi Navi 3.0 preview main interface - System Settings - Aircraft - Cruise Control.
  • Page 20 3. Exit Cruise Control • During cruise control, obstacle avoidance status follows the current flight mode's obstacle avoidance settings. Speed will be restricted to the speed set by the obstacle avoidance mode. Please pay attention to flight safety. Press the intelligent flight button on the remote control or tap the "X" button on the screen.
  • Page 21 zoom • Modes that support 1X to 30X zoom: 4K/30/25/24, 8M, 12M To safely view distant scenes using a telephoto camera, suitable for landscape • Modes that support 1X and 5X zoom: 2.7K/60/50/30/25/24, 1080P/60/50/30/25/24 surveying or pathfinding, click on "5X" to switch to the telephoto camera. Click •...
  • Page 22 • Press the propeller forcefully and rotate the propeller along the unlock direction to remove the propeller. The FIMI X8 Tele intelligent flight battery has a rated voltage of 11.55V. This battery uses high-energy cells and an advanced battery management system with charge and discharge management functions.
  • Page 23 Drone Micro SD card When installing SD card to the drone,please unfold the arms of the drone • first and open the protection cover Insert the SD card with the head side facing upward into the SD card slot • When removing SD card, press the SD card to pop it out •...
  • Page 24 Intelligent Battery 7. Over-discharge protection: Excessive discharge will damage the battery. When the battery is not used for flight, the battery will be discharged to a certain voltage when Cut off the output. The battery will not enable over-discharge protection during flight. 8.
  • Page 25 Power On and Off Power on/off key To turn on/off the battery, perform a short or long press on the battery button for more than 2 seconds. When the battery is on, the power indicator light will LED 1 display the current battery level. LED 2 LED 3 LED 4...
  • Page 26 • Use the official charger provided by FIMI for charging the smart battery. FIMI will not be held responsible for any consequences resulting from the use of non-FIMI chargers. • For safety reasons, during long-distance or prolonged transportation, it is advisable to keep 100V ~ 240V the smart battery at a low level, such as below 50%.
  • Page 27 Dual main gimbal camera Gimbal FIMI X8 Tele gimbal is an integrated gimbal system that utilizes FIMI X8 Tele gimbal is an integrated gimbal system that utilizes three-axis mechanical stabilization technology. It provides a three-axis mechanical stabilization technology, providing a stable stable shooting platform for the camera, with angular jitter of shooting platform for the camera.
  • Page 28 Operating Mode Camera Overview The X8 Tele is equipped with the first dual-camera system, featuring a 1/2-inch CMOS wide-angle camera and a 5x telephoto camera. The wide-angle camera has an aperture Follow Mode: of F/1.79 and an equivalent focal length of 24mm, while the telephoto camera has an The roll axis does not move with the drone aperture of F/3.0 and an equivalent focal length of 120mm.
  • Page 29 Storage: may enter a protected state. FIMI X8 Tele is equipped with a microSD card slot for expanding storage space. • Do not attach additional objects to the camera head, as this can affect its performance and High-quality video and photo shooting require storage devices that support fast potentially damage the motor.
  • Page 30 Remote controller Charge • Connect the remote controller to a power adapter as show below With ergonomic design, it is easier and more precise to control. There • When the RC is in charge, the battery level lights are flashing is no complicated operation to connect App, just plug in and it works.
  • Page 31 Press again to stop recording with 4 short sounds. • Connect the drone and update firmware according to instructions in FIMI App. • The pitch angle of the gimbal can be controlled by toggling the left dial up and down.
  • Page 32 Shortcut Buttons • Toggle the auto return button to the right when the drone is in flight, the drone will return to the home point. • In the process of auto return, toggle the auto return button to the left, the drone will hover at place and wait for sticks instructions.
  • Page 33 Sticks Control Remote Controller Pairing When a new remote controller or drone is replaced, please pair the remote Mode 1 controller and the drone again as shown below： • Forward Turn on the drone • Turn on the RC, long press the power button 15 seconds until hearing constant beep sound，and the power button red light flashes Counter- Clockwise...
  • Page 34 Left stick Right stick Left Fly to the left Left stick Right stick Right Fly to the Right Note: The stick mode can be set in FIMI Navi app (the default is American hand).
  • Page 35 1. Real-time Flight Parameters After downloading and installing the APP, register the FIMI user account and log in. Click to enter the flight interface, or you can use it without logging in. : Tap to return to the home screen.
  • Page 36 4. Attitude ball 9. Intelligent Flight : Displays the drone head orientation, tilt angle, remote control position and Enter the intelligent flight page, where you can perform one-click auto takeoff, landing, and return to home. It supports waypoint navigation, orbit mode, other information.
  • Page 37 10 Drone gear mode Map Interface ：Display the current aircraft gear mode, click to switch between“Sport” “Normal”“Cine”mode Sport：Max horizontal speed 18m/s, Max ascent speed 5m/s, Max descent speed 4m/s Normal：Max horizontal speed 10m/s, Max ascent speed 4m/s, Max descent speed 3m/s Cine：Max horizontal speed 6m/s, Max ascent speed 1.5m/s, Max descent speed 1.5m/s 11.
  • Page 38 • Make sure the front and rear propellers are extended in place is the tail. • Whether the camera and gimbal work normally after powering on • Make sure the FIMI Navi 3.0 is running normally Automatic take off / landing Drone heading...
  • Page 39 Stop propellers in an emergency • Keep both sticks to the bottom inner still over 3 seconds, the propellers start spinning. • Release both sticks once propellers have been spinning, and firmly push the left stick upward to take off the drone. When motors can't properly turn off, please toggle the left stick to the bottom inner in maximum range, and press Auto take-off/landing button for 5 seconds •...
  • Page 40 Flying Condition Requirement 1. The drone is suitable for people above 18 years who have full civil capacity. 2. Make sure to keep some distance from people, animals, trees, vehicles and buildings while using the drone. Please be careful when someone approaches.
  • Page 41 Flight Data The compass may need to be recalibrated when there are changes The FIMI X8 Pro flight control is equipped with a flight logging function, in the magnetic field to ensure proper flight. If the aircraft requires which stores all relevant data after the drone is powered on in the compass calibration, the app will provide corresponding prompts.
  • Page 42 • The entire upgrade process will take approximately 10 minutes. • During the upgrade process, the aircraft may exhibit the following conditions: gimbal The gimbal of the FIMI X8 Tele is an integrated unit and does not limpness, abnormal blinking of status indicator lights, or self-rebooting. These are all normal occurrences, so please be patient and wait for the firmware upgrade to complete.
  • Page 43 FIMI Technology will not assume any responsibility. influence of drugs, or other physical or mental impairments. 5. FIMI Technology shall not be liable for any actions directly or indirectly violating applicable 17. The final interpretation right of this product-related disclaimer and explanatory laws and regulations carried out by users when using this product.
  • Page 44 Overview • After installation, the status should be as follows: The FIMI Enhanced Video Transmission Module can be installed as an expansion module on FIMI drones (please refer to official website information for specific supported models). In cases where the remote control signal exceeds the operating range or is obstructed, the drone can still be controlled via a 4G connection.
  • Page 45 • It is recommended to use the phone's native cellular network for a better experience. • When replacing or installing a physical nano SIM card, there is no need to remove the FIMI enhanced transmission module from the drone. After replacing the nano SIM card, you need to unplug and reinsert the micro USB connection.
  • Page 46 Specifications • Enhanced transmission uses the phone's 4G network for data transfer. During use, it is advisable to turn off the phone's Wi-Fi to reduce interference and avoid affecting transmission delay and stability. Technical standard TDD-LTE/FDD-LTE/WCDMA • Due to limitations of Android/iOS systems, phone calls may restrict background operations TDD-LTE：Band 38/39/40/41 FDD-LTE：Band 1/3/5/8 Working frequency...
  • Page 47 Basic Specification Drone Remote controller Dimensions：Folded (without propellers): 204×106×72.6mm Product weight：Approx. 373g Unfolded (without propellers): 242×334×72.6mm Dimensions：204x91x47mm Takeoff weight: Approx. 780 g Operating frequency：2.400-2.4835GHz Diagonal size：372mm 5.725-5.850 GHz Max ascending speed：5m/s Max battery life: Without charging mobile devices: 8 hours Max descending speed：4m/s Charging mobile devices: 4 hours *Tested with mobile device battery level...
  • Page 48 Camera Gimbal Three-axis mechanical gimbal (Pitch, Roll, Yaw) Wide-angle camera Telephoto camera Structural design range: Pitch: -115° to 40° Image sensor：1/2.5-inch CMOS Image sensor: 1/2-inch CMOS Roll: -40° to 40° Lens: FOV 79° Lens: FOV 21.5° Yaw: -40° to 40° Aperture: F/3.0 Aperture: F/1.6 Controllable rotation range: 10°...
  • Page 49 12.0 or later，Android 9.0 or later Operating Temperature: 5℃-40℃ • This manual may be updated without further notice. Please visit the Fimi official website for the latest version: https://www.fimi.com • This manual introduces the high-performance version of the battery and charging kit.
  • Page 50 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
