USB-231 User's Guide
When connected for the first time, a
the device. When the dialog closes, the installation is complete. The LED turns on after the device is
successfully installed.
If the LED turns off or blinks
If the LED turns off, the device is either not fully connected or is in suspend mode.
If the LED blinks, the device has encountered an error. Wait 10 seconds to allow the device to attempt to
recover from the error. If the LED continues blinking, disconnect and reconnect the device. Contact
Measurement Computing if the error persists.

Calibrating the hardware

The Measurement Computing Manufacturing Test department performs the initial factory calibration. Return
the device to Measurement Computing Corporation when calibration is required. The recommended calibration
interval is one year.
1 Screw terminal connector plugs
Figure 2. Setting up a USB-231
Found New Hardware
2 Hi-Speed Micro -USB cable
dialog box opens when the operating system detects
9
Installing the USB-231
