Control Settings; View Menu; Adjust Menu - Tekmar Mixing Control 356 Manual

View Menu (1 of 1)
Display
OUTDR
VIEW
° F
VIEW
° F
MIX
B3
VIEW
B1
° F
TARGET
MIX
B2
B3
VIEW
° F
BOIL
Adjust Menu (1 of 2)
Display
ADJUST
° F
B2
ROOM
ADJUST
° F
TARGET
MIX
B2
OUTDR DSGN ADJUST
° F
B2
ADJUST
B2
Terminal Unit
ADJUST
° F
MIX
B3
INDR
DSGN ADJUST
° F
MIX
B3
Copyright © D 356 -05/00
Description
Current outdoor air temperature as measured by the outdoor
sensor. This is also the default display for the control.
≠
(OUTDR DSGN OFF)
Current mixed supply water temperature as measured by the
mixing sensor.
Target mixed supply is the temperature the control is currently
trying to maintain at the mixing sensor.
Current boiler temperature as measured by the boiler sensor.
(Boiler sensor is present)
Description
The desired room air temperature.
≠
(OUTDR DSGN OFF)
Mixing setpoint temperature.
(OUTDR DSGN = OFF)
The design outdoor air temperature used in the
heat loss calculation for the heating system. For
setpoint operation, set the OUTDR DSGN to OFF.
The type of terminal units that are being used in the
heating system.
≠
(OUTDR DSGN OFF)
The design indoor air temperature used in the heat
loss calculation for the heating system.
≠
(OUTDR DSGN OFF)
The design supply water temperature used in the
heat loss calculation for the heating system.
≠
(OUTDR DSGN OFF)
12 of 16
Range
-67 to 149°F
(-55 to 65°C)
14 to 266°F
(-10 to 130°C)
---, 14 to 266°F
(---, -10 to 130°C)
14 to 266°F
(-10 to 130°C)
Actual
Range
Setting
35 to 100°F
(2 to 38°C)
OFF, 60 to 200°F
(OFF, 16 to 93°C)
-60 to 32°F, OFF
(51 to 0°C, OFF)
1 (High Mass Radi-
ant), 2 (Low Mass
Radiant), 3 (Fancoil),
4 (Fin-tube Convec-
tor), 5 (Radiator),
6 (Baseboard)
35 to 100°F
(2 to 38°C)
70 to 220°F
(21 to 104°C)
