Quick Setup - Tekmar Mixing Control 356 Manual

Quick Setup

The quick setup can be used for both outdoor reset and setpoint operation. To enter the installer programming mode, set the Advanced /
Installer DIP switch to Installer .
OUTDOOR RESET
Access the ADJUST menu by pressing and holding simultaneously for 1 second, the Item ,
the word ADJUST in the top right corner.
ADJUST
° F
ROOM
OUTDR DSGN ADJUST
° F
ADJUST
Terminal Unit
High Mass Radiant
Terminal Unit
MIX DSGN 120°F (49°C)
MIX MAX 140°F (60°C)
ADJUST
° F
ADJUST
SETPOINT CONTROL
Access the ADJUST menu by pressing and holding simultaneously for 1 second, the Item ,
the word ADJUST in the top right corner.
OUTDR DSGN ADJUST
ADJUST
° F
TARGET
MIX
ADJUST
° F
ADJUST
The ROOM adjustment is the first item displayed. Use the
ROOM setting is set to the desired room air temperature.
Note: To increase or decrease space temperature, only adjust the ROOM setting.
Press and release the Item button to advance to the OUTDR DSGN adjustment. Use the
set the outdoor design temperature. The OUTDR DSGN setting is set to the typical coldest temperature of
the year.
Press and release the Item button to advance to the Terminal Unit adjustment. Use the or button to select
the desired terminal unit. The terminal unit number corresponds to the type of terminal that is being used.
The table below lists the terminal units and their default values.
Low Mass Radiant
(1) (2)
140°F (60°C)
160°F (71°C)
Press and release the Item button to advance to the units adjustment. Use the
to °F or °C.
To exit the ADJUST menu, press and release the Item button to advance to the ESC item. Then either press
the or button, or leave the buttons alone for 20 seconds.
Press and release the Item button to advance to the OUTDR DSGN adjustment. Press and hold the button
until OFF is displayed.
Press and release the Item button to advance to the MIX TARGET adjustment. Use the or button to select
the desired temperature. The MIX TARGET setting is set to the desired setpoint supply temperature.
Press and release the Item button to advance to the units adjustment. Use the
to °F or °C.
To exit the ADJUST menu, press and release the Item button to advance to the ESC item. Then either press
the or button, or leave the buttons alone for 20 seconds..
or
Fancoil Fin-tube Convector
(3) (4)
190°F (88°C) 180°F (82°C)
210°F (99°C) 200°F (93°C)
11 of 16
and buttons. The display will now show
button to set the ROOM temperature. The
Radiator Baseboard
(5)
160°F (71°C) 150°F (66°C)
180°F (82°C) 170°F (77°C)
or button to set the scale
and buttons. The display will now show
or button to set the scale
Copyright © D 356 -05/00
or button to
(6)
