- Page 1 SILVER30 SERIES INSTRUCTION MANUAL | ENGLISH SILVER LINE...
- Page 2 SILVER30 Series The SILVER30 Series of stereo microscopes offers three models from which to choose. The SILVER30B features fixed magnifications of 10X and 30X, the SILVER30-S features fixed magnifications of 20X and 40X and the SILVER39Z has a variable zoom magnifica- tion range of 10X~30X, offering extra versatility.
-
Page 3: Microscope Components
DIOPTER ADJUSTMENT Located on the left eyepiece tube of the SILVER30 Series. This adjustment is used to fine focus the optics to compensate for visual differences between the user’s eyes. BOTTOM ILLUMINATOR This is the light source mounted in the base to provide transmitted illumination. - Page 4 The top 6 x 60mW LED light source is fixed in a downward in a vertical position to provide maximum illumination of the specimen. TURRET The round barrel that houses the objective lenses. The SILVER30 Series has magnifications that can be changed by rotating the black turret magnification knob to a different set of objective lenses.
- Page 5 6. Close your right eye and while viewing with the left eye only, adjust the diopter ring on the left eyetube to bring the image of the specimen into sharp focus. The optical system is now adjusted to your particular vision. SILVER30 SERIES | 05 SILVER LINE...
- Page 6 TENSION CONTROL OF FOCUSING MOVEMENT The focus tension is easily adjusted by using the Motic adjustment wrench. This wrench fits the tension collar found on the focusing controls, between the knob and upright support. A TENSION CONTROL...
- Page 7 COMMON PROBLEMS IN MICROSCOPY NEVER DISASSEMBLE MECHANICAL OR OPTICAL COMPONENTS. THIS SERVICING SHOULD ONLY BE DONE BY AN AUTHORIZED MOTIC TECHNICIAN. THE WARRANTY WILL BE NULL AND VOID IF THE MECHANICAL OR OPTICAL COMPO- NENTS ARE DISASSEMBLED BY A NON-MOTIC DEALER.
- Page 8 SILVER LINE Motic assures that the microscope in respect of mechanical and optical parts is guaranteed against defects in material and workmanship for ten years. Electrical and electronical components are covered for two years after purchase. Normal wear, routine maintenance, light bulbs, power supplies, rechargers, batteries, fuses, cords, add-on accessories, damage resulting from repair by unauthorized parties, accident, alteration, shipping, misuse or abuse is not covered.
- Page 9 Motic Incorporation Ltd. 130 - 4611 Viking Way. Richmond, BC V6V 2K9 Canada Motic Incorporation Limited Copyright © 2002-2020. All Rights Reserved. Tel: 1-877-977 4717 | Fax: 1-604-303 9043 Design Change: The manufacturer reserves the right to make changes in instrument design in Motic Deutschland GmbH (Germany) accordance with scientific and mechanical progress, without notice and without obligation.
