- Page 1 SILVER150 SERIES INSTRUCTION MANUAL | ENGLISH SILVERLINE...
-
Page 2: General Safety Instructions
Operation Instructions. INSTRUMENT SAFETY The SILVER150 Series biological microscope has been designed, manufactured and inspected according to the EN 61010-1:2001 Safety Requirements for Electrical Equipment for Measurement, Control and Laboratory Use. -
Page 3: Quality Warranty
If there is any electrical failure (of the fuse system, ground protection or transformer), turn off and unplug the unit immediately. Make sure the microscope is set aside so it will not be used again and contact the Motic service department or a Motic microscope repair agency to have it repaired. - Page 4 SILVER150 SERIES The SILVER150 Series stands out for its innovation, quality, and student-proof features, offering a wide range of microscopes for educational purposes in high schools up to advanced high school biology. This range of microscopes has cordless LED illumination that provides white light with virtually no heat and a built-in carrying handle.
-
Page 5: Microscope Components
FINE FOCUS CONTROL The fine focusing knobs, located on either side of the microscope, are used for precise focusing adjustments once the specimen has been brought into view with the coarse focus controls. SILVER150 SERIES | 05 SILVER LINE... - Page 6 ILLUMINATOR The built-in light source which provides the optical system with light. SILVER150 Series uses an energy efficient LED which can last up to 50,000 hours of use before replacement. SILVER150 SERIES...
-
Page 7: On/Off Switch
The housing and platform of the instrument to which the arm is attached. The base stands on rubber feet and contains the illuminator assembly. The bulb replacement part number is printed on the underside of the base. SILVER150 SERIES | 07 SILVER LINE... - Page 8 1.00 are "Dry" objectives. Values of 1.00 or greater require oil as a medium. Please note that condensers are part of the optical system and are also assigned an N.A. value. That value must be at least as high as that of the highest objective used. SILVER150 SERIES | 08 SILVER LINE...
- Page 9 The DIN objectives on SILVER150 Series Microscope are parfocaled at the factory to a standard 45mm distance, so that only a slight turn of the fine adjustment is required when a change is made from a lower to higher power.
-
Page 10: First Time Use
The microscope can then be quickly reset to the correct distance. Setting bright field illumination The SILVER150 Series biological microscope has been set already before delivery and can be adjusted as follows: 1. Put the specimen on the stage and fix it with the slide clips. - Page 11 MICROSCOPIC OPERATION OPERATION OF THE BIOLOGICAL MICROSCOPE The SILVER150 Series biological microscope with adjustable condenser can do as follow: 1. Raise the stage by turning the coarse focus knob. 2. Completely lower the condenser carrier by turning the condenser focus knob.
- Page 12 MICROSCOPIC OPERATION USING YOUR MOTIC MICROSCOPE 8. Set the diopter adjustment which is designed to help compensate for the difference between the user’s eyes. To adjust, first bring the specimen into perfect focus by using the coaxial focusing knobs while looking through the eyepiece with the right eye only (close your left eye).
- Page 13 The 100XRD oil immersion lens on Motic microscopes has a spring-loaded end to prevent cracking the cover slip upon its initial contact. Once this zone of safety is exceeded by moving the slide further toward the lens, a point can be reached where damage will occur.
-
Page 14: Care And Cleaning
Tension of the focusing movement is controlled by a tension system found on the pinion of the coarse focus control. This can be adjusted by using the wrench included with the microscope. TIGHTENING DIRECTION SILVER150 SERIES | 14 SILVER LINE... -
Page 15: Led Replacement
The SILVER150 Series is outfitted with a tension collar on the coarse focusing shaft to allow tension on the slip-clutch system to be increased or decreased. - Page 16 SILVER LINE Motic assures that the microscope in respect of mechanical and optical parts is guaranteed against defects in material and workmanship for ten years. Electrical and electronical components are covered for two years after purchase. Normal wear, routine maintenance, light bulbs, power supplies, rechargers, batteries, fuses, cords, add-on accessories, damage resulting from repair by unauthorized parties, accident, alteration, shipping, misuse or abuse is not covered.
- Page 17 Motic Incorporation Ltd. 130 - 4611 Viking Way. Richmond, BC V6V 2K9 Canada Motic Incorporation Limited Copyright © 2002-2020. All Rights Reserved. Tel: 1-877-977 4717 | Fax: 1-604-303 9043 Design Change: The manufacturer reserves the right to make changes in instrument design in Motic Deutschland GmbH (Germany) accordance with scientific and mechanical progress, without notice and without obligation.
