- Page 1 900 Series Protocol Guide for ZP2 Series Control Panels www.acornfiresecurity.com...
-
Page 2: Table Of Contents
www.acornfiresecurity.com Content Important information ii Limitation of liability ii Advisory messages ii Introduction 1 Intended audience and purpose 1 Firmware compatibility 1 Installation 2 Registering the 2010-2-PAK-900 2 Connecting loop devices 3 Configuration 4 Detector configuration 4 Sounder configuration 5 Wireless configuration 7 Compatibility 8 www.acornfiresecurity.com... -
Page 3: Important Information
www.acornfiresecurity.com Important information Limitation of liability To the maximum extent permitted by applicable law, in no event will UTCFS be liable for any lost profits or business opportunities, loss of use, business interruption, loss of data, or any other indirect, special, incidental, or consequential damages under any theory of liability, whether based in contract, tort, negligence, product liability, or otherwise. -
Page 4: Introduction
This manual is intended for those trained and certified to install, program, and maintain a ZP2 Series control panel. The purpose of this manual is to highlight the features and functions of the control panels that are specific to the 900 Series protocol. -
Page 5: Installation
www.acornfiresecurity.com Installation Registering the 2010-2-PAK-900 A 2010−2-PAK-900 Panel Activation Key (PAK) is required for each control panel that requires the 900 Series protocol. Follow these steps to register or unregister the PAK. Installer level access is required. To register the PAK: 1. -
Page 6: Connecting Loop Devices
www.acornfiresecurity.com To restore the default protocol: 1. Remove the PAK from the USB slot. 2. Insert a jumper onto JP4 on the control panel main board (see figure), and then restart the control panel. When the panel restarts, the System Update menu is displayed. This menu is only available in English. -
Page 7: Configuration
www.acornfiresecurity.com Configuration This section contains information specific to configuring your fire system for the 900 Series protocol. See your control panel installation manual for all other configuration information. Note: Configuration options described here require Installer level access. The default password for the default installer user is 4444. Detector configuration Enabling a mounting base Select the loop device configuration menu to enable a compatible mounting base... -
Page 8: Sounder Configuration
www.acornfiresecurity.com 4. Select T_Grad, and then enter the temperature gradient (in ºC). Possible values 1 to 20 (the default value is 5). 5. Select Aly_Dly, and then enter the configurable delay (in minutes). Possible values 1 to 10 (the default value is 10). 6. - Page 9 www.acornfiresecurity.com 3. Select and check NPollut to automatically silence compatible sounders 20 minutes after activation. 4. Press F4 (Enter), and then press F1 (Back). 5. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit). Remember to apply saved settings from the Main menu. Performing walk tests Select Sounders walk test to perform walk tests for compatible sounders using the optional magnetic wand accessory (not supplied).
-
Page 10: Wireless Configuration
www.acornfiresecurity.com Wireless configuration Enabling wireless communication Select the loop device configuration menu to enable wireless communication for compatible wireless devices. By default this option is disabled. To change the configuration: 1. Select Field setup from the Main menu, and then select Loop device config. 2. -
Page 11: Compatibility
www.acornfiresecurity.com Compatibility This section lists the products compatible with your addressable fire system when using the 900 Series protocol. Note: Compatible products may change without notice. Always contact your local supplier to confirm availability and compatibility. Caution: Products marked with an asterisk (*) are not suitable for installation in fire systems requiring EN 54-13 compliance. - Page 12 www.acornfiresecurity.com Addressable point detectors Model Type MFG code Description DP951 55000-620 950 Series optical detector DP951B 55000-660 950 Series black optical detector DP951T OHDx 55000-885 950 Series optical/heat detector DT952 55000-420 950 Series temperature detector DT953 55000-401 950 Series high temperature detector DI950 55000-520 950 Series ionisation sensor...
- Page 13 www.acornfiresecurity.com Loop isolator Model Type MFG code Description IU955 55000-720 900/950 Series isolator Addressable notification devices Model Type MFG code Description DB952IAS 45681-277 950 Series 85/92 dB integrated base sounder with isolator DB952IAS-DIN SDx 45681-300 950 Series 85/92 dB integrated base sounder with isolator (DIN tone) DB952IAS- 45681-290...
- Page 14 www.acornfiresecurity.com Model Type MFG code Description FHSD8025 ODs, FHSD8025 LaserSense 25 high sensitivity smoke detector ZMUx FHSD8100 ODs, FHSD8100 LaserSense 100 high sensitivity smoke detector ZMUx FHSD8200 ODs, FHSD8200 LaserSense HSSD2 high sensitivity smoke ZMUx detector FHSD8210 ODs, FHSD8210 LaserSense HSSD2 high sensitivity smoke ZMUx detector (without display) FHSD8220...
- Page 15 www.acornfiresecurity.com Intrinsically safe devices Model Type MFG code Description DP971* 55000-640 970 Series addressable IS optical sensor DT972* 55000-440 970 Series addressable IS heat detector DB970* 45681-215 970 Series IS detector base GBX70* 29600-098 950 Series IS galvanic barrier PT971* 55000-855 970 Series IS 1-channel protocol translator PT972*...
