  • Page 2 As a proud owner of the TVS Apache RTR 200 4V, you are now part of the 3.5 million strong TVS Racing families. This manual explains the features and operations of your TVS Apache RTR 200 4V. Please read it carefully and follow the instructions to enjoy the ultimate racing experience.
  • Page 3 NOTICE Always keep your Owner‘s Manual in the motorcycle and give it to the new owner if you ever sell your TVS Apache RTR 200 4V. Take time to familiarize yourself with your TVS Apache RTR 200 4V and its performance characteristics.
  • Page 4 SAFETY INFORMATION Operating this vehicle safely is an important responsibility of the rider. To help you make decisions on safety, we have provided necessary operating procedure and other information in this manual. This information alerts you on potential hazards that could hurt you or others. Since it is not possible to warn you about all the hazards associated with operating or maintaining the vehicle, you must use your own judgement.

  • Page 5: Table Of Contents

    CONTENTS Running-in information Antilock braking system Safe riding tips Know your TVS Apache RTR 200 4V Riding your TVS Apache RTR 200 4V Maintenance Service record sheet Technical specifications...

  • Page 7: Running-In Information

    Timely performance of the first service will ensure optimum service life and performance from the engine. Caution Replacing the engine cum transmission oil during first service is most important for better life of engine. Always use TVS TRU4 FULLY SYNTHETIC oil (SAE 10W30 API-SL, JASO MA2) for better performance and life.

  • Page 8: Antilock Braking System

    SINGLE CHANNEL ANTI-LOCK BRAKING SYSTEM ANTI-LOCK BRAKE SYSTEM (ABS) Your motorcycle is fitted with a single channel Anti-Lock Braking System (ABS) in the front brake system which is designed to prevent skidding and help riders to maintain steering control during emergency-stopping situation in dry or wet roads, loose gravels etc.
  • Page 9 SINGLE CHANNEL ANTI-LOCK BRAKING SYSTEM As soon as the actual circumstances arises, the system reacts instantly and adjusts braking force accordingly to achieve optimum braking. Why does brake lever pulsate during brake application? Vehicles fitted with ABS uses the conventional brake system during normal operation.
  • Page 10 Apply continuous brake in ABS mode for better performance. Do not pump. Perform the periodic maintenance as per the schedule. ABS should be serviced only at TVS Motor Company Authorised Distributors or Dealers / Authorised Service Centers. Carefully remove the front wheel during puncture / tyre replacement to prevent toner ring damage / bend.
  • Page 11 (ABS is tuned with tyre specified by the This motorcycle is equipped with ABS and Tubeless TVS Motor Company). tyres. For repair or replacement please contact nearest TVS Motor Company Authorised Distributors Don't’s or Dealers / Authorised Service Centers. Do not use non-standard tyres.

  • Page 12: Safe Riding Tips

    Riding skill and your mechanical knowledge forms the foundation of safe riding practices. We suggest you to practice riding TVS Apache RTR 200 4V in a low-traffic condition until you are thoroughly familiar with your vehicle and its controls. Remember practice makes you perfect.
  • Page 13 SAFE RIDING TIPS Posture Warning Proper vehicle riding starts with proper posture. Do not downshift the gears in the midst of cornering. 1. Keep your elbows relaxed and flexible. Slow down to a safe speed before negotiating a 2. Sit and adjust yourself on seat so that arms and corner.
  • Page 14 SAFE RIDING TIPS Causes for poor braking ACCESSORY INSTALLATION AND SAFETY TIPS 1. If the brake shoes / pads or drum / disc are worn Use extreme caution while selecting and installing the out or if there is water or oil on them, sufficient accessories for your motorcycle.
  • Page 15 SAFE RIDING TIPS EMISSION CONTROL Crankcase emission control system All the TVS motorcycles are tested in the factory for The engine of TVS Apache RTR 200 4V is equipped optimum fuel efficiency and lowest possible CO with a closed crankcase system to prevent levels.

  • Page 16: Know Your Tvs Apache Rtr 200 4V

    KNOW YOUR TVS APACHE RTR 200 4V VEHICLE IDENTIFICATION NUMBER The frame and engine serial numbers are the only means of identifying your vehicle from others of the same model and type. They are also required to assist your Dealer for ordering parts or referring to special information.
  • Page 17 KNOW YOUR TVS APACHE RTR 200 4V LOCATION OF PARTS - HANDLE BAR Connected instrument cluster Ignition cum steering lock Master cylinder (front) Engine cut off switch Rear view mirror R Front brake lever Throttle grip Electric starter switch Fuel tank cap 10.
  • Page 18 KNOW YOUR TVS APACHE RTR 200 4V LOCATION OF PARTS - VEHICLE LEFT SIDE Wheel hugger rear Saree guard Rear wheel axle Pillion foot rest L Rider foot rest L Side stand Centre stand Gear shift lever Front wheel axle...
  • Page 19 KNOW YOUR TVS APACHE RTR 200 4V LOCATION OF PARTS - VEHICLE RIGHT SIDE Disc plate front Cover toner ring Front wheel axle nut Wheel speed sensor front Toner ring front Caliper assembly front Location of spark plug Gauge oil level Rear brake pedal 10.
  • Page 20 KNOW YOUR TVS APACHE RTR 200 4V LOCATION OF PARTS - VEHICLE FRONT AND REAR FRONT Turn signal lamp front L Head lamp assembly Oil cooler Crash guard Position lamps Turn signal lamp front R REAR Turn signal lamp rear R...
  • Page 21 KNOW YOUR TVS APACHE RTR 200 4V CONTROL KEY 2. 'ON' position Your TVS Apache RTR 200 4V comes with a pair of All electrical circuits are activated. The instrument identical control keys. These keys are to operate cluster and warning lights perform the self-diagnostic ignition cum steering lock, fuel tank cap and seat lock.
  • Page 22 1. Speedometer CONNECTED INSTRUMENT CLUSTER Indicates the vehicle speed in kilometer per hour by Your TVS Apache RTR 2004V is provided with a default whenever the ignition is turn ‘ON’. This can be fully digital connected instrument cluster with lots changed to mile per hour.
  • Page 23 This lamp goes ‘OFF’ once the vehicle reaches the speed 6 km/h and above. If this lamp glows continuously then have your vehicle checked at TVS 2. Turn signal indicator right ( Motor Company Authorised Distributor or Dealer / Flashes when the ‘right’...
  • Page 24 KNOW YOUR TVS APACHE RTR 200 4V 8. Turn signal indicator left ( All the eight bars will be displayed when the fuel in the tank reaches above 10.5 liters approximately (full Flashes when the ‘left’ side turn signal indication is tank).
  • Page 25 KNOW YOUR TVS APACHE RTR 200 4V If all the fuel level bars in the speedometer are blinking 11a.Odometer and an error message ‘CHECK FUEL SENSOR’ scrolls Odometer registers the total distance covered by the at bottom, Contact nearest TVS Motor Company vehicle in kilometer or mile as per the user’s preferred...
  • Page 26 KNOW YOUR TVS APACHE RTR 200 4V 11c. Lap timer To start a lap timer again, after stopping it by pressing the ‘Info switch’, the lap timer need to be reset as Lap timer indicates the time taken to complete a explained page No.
  • Page 27 KNOW YOUR TVS APACHE RTR 200 4V 11e. High speed indicator Note High speed indicator records the maximum speed Maximum speed recorded so far will be displayed (top speed) achieved by the rider so far either in km/h whenever the meter is set in ‘HIGH SPEED’ mode.
  • Page 28 KNOW YOUR TVS APACHE RTR 200 4V This last recorded time can be reset as explained in Note page No. 27 and a new time can be recorded if For recording a new time, the last recorded shortest required. The overall best time will be replaced time need to be reset.
  • Page 29 KNOW YOUR TVS APACHE RTR 200 4V 12. Shift RPM indicator 14. Lean angle indicator Shift RPM indicator alerts the user to shift the gears When this mode is selected (refer page no. 29), the when engine reaches the specified RPM. Users can...
  • Page 30 At every ignition ON, ‘TRIP F’ meter will get enabled remainder is reset. Get the vehicle serviced at TVS automatically until fuel level is reached above Motor Company Authorised Distributor or Dealer / minimum safe level (2.5 L).
  • Page 31 18. Low battery indicator The following message will be popped-up after the speedometer’s self diagnostic cycle when the battery charge is too low. Get the battery checked at TVS Motor Company Authorised Distributor or Dealer / Authorised Service Center The mode (A) and set (B) buttons are provided to change between various modes and set the some of the digital display functions of the instrument cluster.
  • Page 32 KNOW YOUR TVS APACHE RTR 200 4V On long pressing the Mode button, the following modes can be accessed. 1. SET mph MODE / SET kmph MODE 2.CLOCK SETTING MODE 3. SHIFT RPM SETTING 4. LEAN ANGLE MODE / RPM MODE 5.
  • Page 33 KNOW YOUR TVS APACHE RTR 200 4V Setting the digital display 3. In ‘TRIP 2’ meter mode, press the ‘Mode’ button twice to enter high speed mode. On entering Every press of the mode button changes the display this mode a message ‘...
  • Page 34 KNOW YOUR TVS APACHE RTR 200 4V MPH and KMPH setting 4. On pressing the Set button, if the clock is in 12 hours format, the hour format ‘AM’ or ‘PM’ blinks. 1. Ensure the display is in ‘ODO’ mode.
  • Page 35 4. Now, press the Mode button to increase the RPM Using the Bluetooth pairing mode the connected (multiples of 1000) in cyclic fashion. Once the user instrument cluster of ‘TVS Apache RTR 2004V’ can be starts updating, the LED stops glowing. connected to your Android™ smart phones and 5.
  • Page 36 KNOW YOUR TVS APACHE RTR 200 4V Steps to “Forget This Device” in iPhone: Note If the user needs to connect multiple iPhones with the In lean angle mode all other features of instrument single instrument cluster, the previous iPhone has to cluster will be accessible except engine rpm.
  • Page 37 KNOW YOUR TVS APACHE RTR 200 4V 1. In the previous connected iPhone, open the First time Bluetooth paring: SETTINGS -> BLUETOOTH. To pair your Android smart phone or iPhone with your TVS Apache RTR 200 4V motorcycle’s connected Select the instrument cluster, which was instrument cluster, via Bluetooth, for the first time,...
  • Page 38 ‘OFF’ and ‘ON’, and the application also need to be restarted. Please remember that, all the smart phones are not compatible for pairing with the TVS Apache RTR 200 4V motorcycle’s connected instrument cluster. On pressing this icon, the app opens a screen where During the search of Bluetooth devices in app, if the you will be asked to grant permission to turn ‘ON’...
  • Page 39 8.0 for App to work seamlessly, any battery the last paired mobile phone. optimisation setting to be removed in the TVS Connect app and GPS shall be allowed to run in If the application unfortunately stops due to unfrossen backround in high accuracy mode.
  • Page 40 This is the default window when the connected Incase multiple SIM cards are used in smart phone, by instrument cluster of your ‘TVS Apache RTR 200 4V’ default, SIM 1’s network provider’s signal strength is is connected with your smart phone using Bluetooth shown in the display of connected instrument cluster.
  • Page 41 The connected instrument cluster displays the total Once the navigation assist is turned ‘ON’, the display number of missed calls from the smart phone via of your TVS Apache RTR 200 4V motorcycle’s Bluetooth. connected instrument cluster enters into navigation...
  • Page 42 KNOW YOUR TVS APACHE RTR 200 4V Low fuel alert The customer also can chose to reject the request (by pressing the ‘Info switch’ on the handle bar for about 1 When the fuel level in the vehicle reached below sec.).
  • Page 43 KNOW YOUR TVS APACHE RTR 200 4V Crash alert If alert is not cancelled within 180 seconds, a message will be sent to Emergency Contacts with location Based the smart phone’s accelerometer data, crash details. alert will be detected by smart phone and the same...
  • Page 44 KNOW YOUR TVS APACHE RTR 200 4V TVS CONNECT APP 9. To locate the last parked location of your TVS Apache RTR 200 4V. 10. To know the signal strength of your mobile Dedicated smart phone app is available in the Google network in connected instrument cluster.
  • Page 45 KNOW YOUR TVS APACHE RTR 200 4V How to login On opening the TVS CONNECT app the following introductory screens will be displayed. You can login using your social media logins like FACEBOOK and GOOGLE+ or using your mobile number which has been registered already.
  • Page 46 After successful verification, the Home screen of the app opens. Note Enter the OTP which is received from TVS Motor Please remember that the Navigation License has Company Limited sent to the registered email id and to be renewed after 5 years of vehicle purchase submit.
  • Page 47 COOLING SYSTEM TVS Apache RTR 200 4V is designed with an external Add vehicle tab allows you to add any of your TVS oil cooler with stone guard arrangement for optimal bikes by selecting the vehicle variant, then press the engine cooling.
  • Page 48 RAM AIR DUCT LED HEAD LAMP TVS Apache RTR 200 4V is designed with a ram air TVS Apache RTR 200 4V comes with a LED head duct on the right side of the fuel tank. This ram air duct...
  • Page 49 KNOW YOUR TVS APACHE RTR 200 4V HANDLE BAR LEFT SIDE Warning 1. Info switch Failure to switch the turn signal lamp ON or OFF at the Info switch ‘ ‘ is used to cancel certain functions right time may lead to an accident.
  • Page 50 KNOW YOUR TVS APACHE RTR 200 4V 5. Head lamp high / low beam switch HANDLE BAR RIGHT SIDE 1. Electric starter switch The head lamp glows automatically once the engine is started. Only the head lamp beam (high/low) can be Ensure the transmission is in neutral or else press the controlled with the beam control switch.
  • Page 51 KNOW YOUR TVS APACHE RTR 200 4V 2. Throttle grip FUEL TANK* CAP Flush type fuel tank cap (1) is provided in TVS Apache It controls the fuel-air mixture supplied to the engine, which regulates the engine speed. Rotate the throttle RTR 200 4V.
  • Page 52 KNOW YOUR TVS APACHE RTR 200 4V Warning Caution Do not smoke while refueling. Do not use cell phones Never fill fuel beyond the fuel tank inlet (1). Filling while refueling. Avoid spilling of fuel on the hot above the inlet may result in improper breathing of engine.
  • Page 53 KNOW YOUR TVS APACHE RTR 200 4V FUEL COCK Note Fuel cock is located on fuel tank at the left side of the Leaving the fuel cock in ON or RESERVE position vehicle. Fuel cock has the following three positions,...
  • Page 54 KNOW YOUR TVS APACHE RTR 200 4V GEAR SHIFT LEVER TVS Apache RTR 200 4V is equipped with a 5 speed constant mesh transmission. Neutral (N) position of the transmission is indicated by the warning light on the speedometer. To shift the transmission from neutral to first gear, push the gear shift lever down.
  • Page 55 KNOW YOUR TVS APACHE RTR 200 4V To change it to the second gear, lift the lever up. Lifting the lever up repeatedly engages all the gears in succession up to the fifth gear. The gear shift indicator on the speedometer dial indicates the current gear position.
  • Page 56 KNOW YOUR TVS APACHE RTR 200 4V STANDS Caution TVS Apache RTR 200 4V is equipped with a centre (1) Do not sit on the vehicle when it is parked on the side and side stand (2). To place the vehicle on the centre...
  • Page 57 KNOW YOUR TVS APACHE RTR 200 4V SEAT Front seat (rider seat) The seat lock is located between the rider and the To remove the front seat (3), remove the rear seat passenger seat assembly. (passenger seat) and take out the key from the lock.
  • Page 58 KNOW YOUR TVS APACHE RTR 200 4V TOOL KIT Caution To assist you in performing certain aspects of periodic It is recommended to use the tool kit in case of any maintenance and emergency repairs, a tool kit is emergency only. It is always advisable to take your supplied along with the vehicle.
  • Page 59 KNOW YOUR TVS APACHE RTR 200 4V COVER FRAME R Caution Removal Make sure that the cover frame is locked securely in Cover frame R is provided to access the battery and position after installation. rear disc brake master cylinder. This cover can be opened in the following manner: 1.

  • Page 60: Riding Your Tvs Apache Rtr 200 4V

    RIDING YOUR TVS APACHE RTR 200 4V INSPECTION BEFORE RIDING Check the following items before riding. ITEM WHAT TO CHECK FOR Engine cum transmission oil Availability of oil upto the level (page no. 68) Fuel Enough fuel for the planned distance of running Tyres Correct pressure (page no.
  • Page 61 RIDING YOUR TVS APACHE RTR 200 4V STARTING THE ENGINE Note As you turn the ignition switch to the ’ON’ position, To start the vehicle first time in the morning or after a the instrument cluster and the warning lights will go long duration of storage, for smooth and quick start, through the self-diagnostic cycle.
  • Page 62 RIDING YOUR TVS APACHE RTR 200 4V 4. Release the clutch lever and open the throttle Warning smoothly. Select the required gears in a similar Reduce speed to a safe limit before turning/cornering. manner. Do not apply brake while turning/cornering. Do not Using the transmission disengage clutch before braking.
  • Page 63 RIDING YOUR TVS APACHE RTR 200 4V FUEL RECOMMENDATION CHECKS AND TIPS FOR IMPROVING FUEL ECONOMY Use BSIV / unleaded petrol only. Regular checks The petrol should be minimum 91 RON. Use Carry out the periodic maintenance checks as recommended fuel additives for longer life of engine specified in this manual (refer page no.
  • Page 64 RIDING YOUR TVS APACHE RTR 200 4V Air cleaner element Engine cum transmission oil Dirty or less engine cum transmission oil increases A dirty air cleaner element restricts airflow and the friction between various parts of the engine and increases fuel consumption. Replace the element reduces the engine life, thereby increases fuel every 12000 kms.
  • Page 65 RIDING YOUR TVS APACHE RTR 200 4V Chain slackness Note Check and ensure drive chain slackness. Excess Please note that the on-road mileage of TVS Apache slackness leads to higher fuel consumption (refer RTR 200 4V is dependent on several factors like road page no. 76).

  • Page 66: Maintenance

    Cylinder head, steering components, suspension, chain and wheel components etc., are key items and require very special and careful servicing. TVS Motor Company Limited strongly recommends that the jobs as per the maintenance schedule be performed by your TVS Motor Company Authorised Distributor or Dealer / Authorised Service Center.
  • Page 67 MAINTENANCE PERIODIC MAINTENANCE SCHEDULE (months or km whichever occurs earlier) Item Service Service Remarks Every Every 500-750 2500-3000 5000-6000 8500-9000 11500-12000 3000 km 6000 km Period from the date of sale 1 month 3 months 6 months 9 months 12 months Engine cum transmission oil I&T I&T...
  • Page 68 MAINTENANCE Item Service Service Remarks Every Every 500-750 2500-3000 5000-6000 8500-9000 11500-12000 3000 km 6000 km Period from the date of sale 1 month 3 months 6 months 9 months 12 months Throttle grip – – – – Lubricate using grease Choke operation –...
  • Page 69 MAINTENANCE Item Service Service Remarks Every Every 500-750 2500-3000 5000-6000 8500-9000 11500-12000 3000 km 6000 km Period from the date of sale 1 month 3 months 6 months 9 months 12 months Brake effectiveness – Brake pedal shaft – Lubricate using TRU4 oil Brake pad wear –...
  • Page 70 RECOMMENDED LUBRICANTS Application Manufacturer Brand Engine cum transmission oil 1200 ml ( TVS Motor Company TVS TRU4 FULLY SYNTHETIC oil during servicing 1400 ml ( (SAE 10W30 API-SL, JASO MA2) during engine overhaul Front fork oil 325 ± 2 cc...
  • Page 71 T V S M o t o r C o m p a n y L i m i t e d recommended battery charger only at TVS Motor The inversion of the battery wires can damage the battery Company Authorised Distributor or Dealer / and the recharging system.
  • Page 72 One 15A fuse is used for single channel 7. Turn ‘ON’ the ignition lock and check for proper ABS system. functioning of the electrical systems. lncase the fuse fails again, consult the nearest TVS Motor Company Authorised Distributor or Dealer / Authorised Service Center. Caution Do not use vehicle by shorting the wires without a fuse.
  • Page 73 MAINTENANCE SPARK PLUG Visually inspect the spark plug gap. The gap should be 0.8 to 0.9 mm. If the gap is found to be more than the 1. Wipe and clean the dust and mud around the limit replace the spark plug with a new one. spark plug mounting to avoid their entry inside the cylinder.
  • Page 74 The gauge oil level is provided at the 8. If the oil level is below the minimum level, top up right-hand side crankcase cover. with TVS TRU4 FULLY SYNTHETIC oil (SAE 10W 30 Maximum upto the maximum level mark. API-SL, JASO MA2) Do not overfill.
  • Page 75 MAINTENANCE CLUTCH ADJUSTMENT 2. Loosen the lock nut (2) while holding the clutch cable adjuster nut (1). Clutch lever free play is one of the most important adjustment which you may need to check in-between 3. Adjust the clutch cable adjusting nut (1) ‘in’ or ‘out’ services for better life of the clutch plates.
  • Page 76 MAINTENANCE Caution After adjusting free play properly, if there is a clutch slip or there is difficulty in shifting gear, visit your TVS Motor Company Authorised Distributor or Dealer / Authorised Service Center for rectification . SOFT HARD REAR SHOCK ABSORBER...
  • Page 77 R along with a wheel speed sensor (3), a disc or ineffective due to air entry, contact TVS Motor (4) and a toner ring along with a cover (5) fitted on the Company Authorised Distributor or Dealer / front wheel.
  • Page 78 You can observe a master cylinder (1) mounted on the or ineffective due to air entry, contact TVS Motor right side rider foot rest, a reservoir (2) below the Company Authorised Distributor or Dealer /...
  • Page 79 If you notice any malfunction in performance and safety of the rider. Check the tyres brake system contact nearest TVS Motor Company frequently for inflation pressure as well as the wear Authorised Distributor or Dealer / Authorised Service pattern on it.
  • Page 80 Tyre puncture Operating the vehicle with excessively worn tyres will TVS Apache RTR 200 4V is fitted with a tubeless tyre decrease riding stability and can lead to loss of control. on both front and rear wheel. lncase of any puncture /...
  • Page 81 (20 ~ 25 mm). user must clean the chain with a dry cloth and 4. If the slackness is found more contact TVS Motor apply TRU SPRAY / TRU4 oil as frequently as Company Authorised Distributor or Dealer / every 500 km for better chain life and smooth Authorised Service Center for adjustment.
  • Page 82 MAINTENANCE FRONT WHEEL REMOVAL AND REASSEMBLY Caution 1. Remove the axle nut (1) along with a washer. Lubricate the drive chain after the motorcycle is 2. Pull out the axle (2) along with a washer and washed with water or riding in rainy / wet condition. remove a spacer from both the sides of the wheel.
  • Page 83 MAINTENANCE Warning Ensure proper seating of disc in the caliper assembly while reassembling the wheel. Ensure to re-fix the right spacers at both the sides of the wheel. Keep the toner ring upwards whenever the wheel is removed in order to avoid damages to the toner ring. Damaged toner ring affects ABS function.
  • Page 84 MAINTENANCE 6. Remove the battery, store it away from direct Note sunlight and freezing temperatures. During removal of rear wheel axle hold the drum 7. Place a suitable support at the bottom of the sprocket assembly with the hand as it may fall. frame so that both the tyres are off the ground.
  • Page 85 1. Complete tool kit / first aid kit required. 2. Recommended spark plug one number. 3. Fill the engine cum transmission oil (TVS TRU4 3. Turn signal lamp bulbs one number each. FULLY SYNTHETIC - SAE 10W30 API-SL, JASO 4. Throttle and clutch cables one number each.
  • Page 86 16. Intactness of EVAP system hoses and canister. 17. Any other job as necessary. 18. Have your vehicle checked at any TVS Motor Company Authorised Distributor or Dealer / Authorised Service Center. Caution Long journey are to be taken only after the running-in...

  • Page 87: Service Record Sheet

    SERVICE RECORD SHEET SERVICE RECORD S.No. Description Odometer Job card no. / Date Servicing Dealer’s reading stamp and sign. 1st service between (a) 500 - 750 km or (b) 1 month from the date of purchase, whichever of the two occurs earlier. 2nd service between (a) 2500 - 3000 km or (b) 3 months from the date of purchase,...
  • Page 88 SERVICE RECORD SHEET SERVICE RECORD S.No. Description Odometer Job card no. / Date Servicing Dealer’s reading stamp and sign. 5th service between (a) 11500 - 12000 km or (b) 12 months from the date of purchase, whichever of the two occurs earlier. 6th service between (a) 14500 - 15000 km or (b) 15 months from the date of purchase,...
  • Page 89 SERVICE RECORD SHEET SERVICE RECORD S.No. Description Odometer Job card no. / Date Servicing Dealer’s reading stamp and sign. 9th service between (a) 23500 - 24000 km or (b) 24 months from the date of purchase, whichever of the two occurs earlier. 10th service between (a) 26500 - 27000 km or (b) 27 months from the date of purchase,...

  • Page 90: Technical Specifications

    TECHNICAL SPECIFICATION MANUFACTURER : TVS MOTOR COMPANY LIMITED P.B. No1, Bythahalli, Kadakola post, Mysore - 571 311, India. ENGINE TRANSMISSION Type : 4 stroke, Oil cooled, single Clutch : Wet - multiplate type cylinder OHC Gear shift pattern : 1 down and 4 up...
  • Page 91 TECHNICAL SPECIFICATION CHASSIS TYRE Tyre size Overall length : 2050 mm Front 90/90 x 17 Tubeless Overall width : 790 mm Overall height : 1105 mm Rear 130/70 x 17 Tubeless Tyre pressure Seat height : 800 mm Ground clearance : 180 mm Front 1.75 kg/cm²...
  • Page 92 CAPACITIES Fuel tank capacity : 12 litres (including reserve)** Reserve : 2.5 litres Engine cum transmission : TVS TRU4 FULLY SYNTHETIC oil oil grade (SAE 10W30 API-SL, JASO MA2) Engine cum transmission : 1200 ml (during servicing) oil and capacity...
