GEIST™ LEAK DETECTION KIT
Quick Installation Guide
Part Number:
WSCK
Description
Water-sensing cable kits feature
detection cables that recognize the
presence of water along the entire
cable length.
Kit includes:
• LD310 control box
• +5 V power supply
• 15 ft (3 m) leader cable
• 50 ft (16.7 m) 4-conductor
alarm wire
• Orange Leak Detection
Cable(s)
• Accessory hardware - Hex key,
wall mounting hardware and
self-adhesive J-clips
• Terminator plug
(NOTE: Some kits contain a
permanently terminated,
orange Leak Detection Cable
and do not require a separate
terminator plug)
Mounting the LD310
Control Box
Determine the location where the
control box is to be mounted. Take
into consideration power
accessibility and the wire route to
your environmental monitoring unit.
With the provided hex key, loosen
the two set screws on the bottom
end of the control box and remove
the cover. Then locate the two
mounting screw holes on the base.
Hold the bottom of the control box
in place and mark the holes. After
drilling the mounting holes, fasten
the control box in place with the
appropriate hardware.
Before replacing the cover, attach
the Leader Cable, 4-conductor
alarm wires and 5 V power supply
into the terminal block near the
bottom of the control box circuit
board. You may also want to
Power Failure Sensor Power Failure Sensor Power Failure Sensor Power Failure Sensor
Geist Geist Geist Geist LD310 Cable Configuration LD310 Cable Configuration LD310 Cable Configuration LD310 Cable Configuration
TM TM TM TM
LD310 Control Box LD310 Control Box
Leader Cable Leader Cable
Non-Sensing Cable Non-Sensing Cable
Leak Detection Cable Leak Detection Cable
activate the audible alarm before
replacing the LD310's cover. When
you are ready to replace the cover,
assemble it to the base and use the
hex key to tighten the screws to
secure it.
See the Geist LD310 Control Box
Wiring Diagram on the following
page for details.
Connecting the Leader Cable
The Leader Cable is a 15-ft (4.57 m)
white cable with a twist-lock
connector on one end and four
bare, stripped and tinned wires on
the other end.
To connect the Leader Cable,
make sure the four colored wires
Leak Detection Cable Leak Detection Cable
Leak Detection Cable Leak Detection Cable
Terminator Terminator
Leak Detection Cable Leak Detection Cable
Power Failure Sensor
LD310 Mounting Hole Locations
Mounting
screw
hole
1
