Alber Universal Xplorer Industrial
Monitor (UXIMe) Battery Monitor
Installation Guide
Vertiv Corporation
1050 Dearborn Drive
Columbus, OH 43085
Tel: (954) 377-7101
www.vertivco.com
590-2172-501A/SL-29241/4200-136
