Alemlube HR90000 Series Owner Technical Manual
Dual pedestal spring rewind hose reels
Hide thumbs
Also See for HR90000 Series:
- Owner technical manual (10 pages) ,
- Owner technical manual (5 pages)
Table of Contents
Advertisement
Quick Links
OWNER'S TECHNICAL MANUAL
TECHNICAL DETAILS
Part No.
Inlet/Outlet
HR90085
1/2" BSPT
HR90090
1/2" BSPT
HR90095
1/4" BSPT
HR90096
3/8" BSPT
DESCRIPTION
1. These series of hose reels are professional spring-driven models.
2. These series of hose reels are equipped with a slow retracting function
3. These series of hose reels can be pulled and stopped at any point
during usage.
TIPS
1. Read the following precautions and instructions before
you begin assembly or using.
2. Failure to comply with these instructions could result
in personal injury or property damage.
3. Keep these instructions in a convenient location
for future reference.
