Page 1: Iso-16.Pci User Manual
ISO-16.PCI User Manual Sealevel Systems, Inc. Sealevel.com Phone 864.843.4343 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm... -
Page 2: Table Of Contents
Contents ISO-16.PCI User Manual ............................1 Contents ..................................2 Before You Get Started ............................. 4 What’s Included ..............................4 Advisory Conventions ............................4 Product Description ..............................5 Features ................................. 5 Optional Items ............................... 6 Electrical Specifications ............................7 Features ................................. 7 Input Ports ................................ - Page 3 Register Description ............................15 Example Circuits ..............................16 Software Installation ............................... 17 Where to Get Sealevel Software .......................... 17 Windows Installation ............................17 Guided Software Installation ..........................18 Manual Software Installation ..........................20 Linux Installation..............................21 Appendix A - Handling Instructions ........................23 ESD Warnings ...............................
-
Page 4: Before You Get Started
DB78 Male to DB37 Female cable (Item# CA489) Sealevel Software CD – SeaI/O Classic Software and User Manual Warning - The highest level of importance used to stress a condition where damage could result to the product or the user could suffer serious injury. -
Page 5: Product Description
Includes 72” cable with DB78 Male connector to DB37 Female connectors (Item# CA489) SeaI/O Classic software supports Windows 7, Vista, and XP operating systems Software support for Linux available ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm... -
Page 6: Optional Items
Break out serial and digital connectors to screw terminals for easy field connection. The TB02 terminal block is designed with both DB37 male and female connectors for interfacing the inputs or outputs. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm... -
Page 7: Electrical Specifications
10 to 90% R.H. Non-Condensing 10 to 90% R.H. Non-Condensing All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These printed circuit boards are solder mask over bare copper or solder mask over tin nickel. -
Page 8: Hardware Installation
To access Device Manager, follow the steps below: 1. Right click on the ‘Computer’ icon on your desktop or in the Start menu. 2. Click ‘Manage’ in the fly out menu to launch the ‘Computer Management’ console window. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013... - Page 9 5. You should see the card assignment listed as ‘SeaI/O 8006e’ with the card number in parentheses. The card number will increment for each additional SeaI/O device installed. The ISO-16.PCIe is now ready for use. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013...
-
Page 10: Programming The Iso-32.Pcie
Sealevel’s SeaI/O Classic software is provided to assist in the development of reliable applications for the Sealevel Systems family of PCI and PCI Express digital I/O adapters. The SeaI/O Classic software is included on the CD that shipped with the board. The software contains driver functions for use in accessing the I/O as well as helpful samples and utilities. -
Page 11: Input Ports
Turn on Voltage = diode drop + (turn on current) x (resistance) [Ex: 1.1 + (.003) x R] Input Current = ((input voltage)-1.1V) / (resistor value) Maximum voltage = 1.1 + square root of (.25(resistor value)) ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013... - Page 12 Increasing the input resistor accordingly can increase the maximum input voltage. Because socketed DIP resistors are utilized, they can easily be replaced with a different value. Sealevel can do this, if necessary. The input circuits are not intended for monitoring 120-volt AC circuits. In addition to being too high a voltage for the circuits, it is dangerous to have that high a voltage on the card.
-
Page 13: Input Ports Pin Assignments (Db-37 Female)
8,27 Part B Bit 3 7,26 Part B Bit 4 6,25 Part B Bit 5 5,24 Part B Bit 6 4,23 Part B Bit 7 3,22 Ground 2,20,21 +5 Volts +12 Volts ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm... -
Page 14: Female Pin Assignments (Card Edge Connector)
Port A Pins Port B Pins 55,74 47,66 54,73 46,65 53,72 45,64 52,71 44,63 51,70 43,62 50,69 42,61 49,68 41,60 48,67 40,59 39,57,58 18,36,37 +12V ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm... -
Page 15: Direct Hardware Control
All ports are set to input after reset or power up. Address Mode Base+0 Input Port A PAD7 PAD6 PAD5 PAD4 PAD3 PAD2 PAD1 PAD0 Base+1 Input Port B PBD7 PBD6 PBD5 PBD4 PBD3 PBD2 PBD1 PBD0 ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm... -
Page 16: Example Circuits
Input Pair Pins from the table labeled Input Ports Pin Assignments. Common is the other pin listed in the Input Pair Pins entry. The polarity of the pair does not matter. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013... -
Page 17: Software Installation
All Sealevel products are shipped with media containing the installers for each software package available. If the media is otherwise unavailable or if desired, the current versions of Sealevel software packages can be obtained from the Sealevel website (see following instructions). If you already have the Sealevel software, proceed to the Windows or Linux installation section. -
Page 18: Guided Software Installation
1. Insert the Sealevel media into your PC. 2. If the ‘AutoRun’ feature is enabled for this media the software will automatically launch. 3. Otherwise, navigate to the root directory of the media and double-click the ‘autorun.exe’ application to launch the installation window. - Page 19 Click on the “Allow” button to continue installation of your Sealevel software. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm...
-
Page 20: Manual Software Installation
6. Refer to the Physical Installation section to connect and install your hardware. 1. To install a software package from the Sealevel media, browse the Sealevel Systems media ’Software’ directory. For example: Software\SeaIO\Windows\SeaIO Installer.exe 2. -
Page 21: Linux Installation
Most Sealevel Linux software is distributed as source code. To use the software, it must be compiled. Refer to the README file in each package for system prerequisites. You must have administrative privileges to install the software. It is not necessary to have administrative privileges to build or use the software. - Page 22 At this point, the driver has enabled the hardware and it is ready to use. You now have the option to run a test utility on it. Test utilities were compiled in step 8, and they are located in the package’s folder named seaio/utilities/ /usr/bin. and installed globally in step 10 to: ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm...
-
Page 23: Appendix A - Handling Instructions
6. Keep work area free of non-conductive materials such as ordinary plastic assembly aids and Styrofoam. 7. Use field service tools such as cutters, screwdrivers, and vacuum cleaners that are conductive. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm... -
Page 24: Appendix B - Troubleshooting
5. Use the VCTest to verify the basic I/O functionality of your digital I/O board. The source code is included to simplify application development in the programming language C. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013... - Page 25 1. VBTest is another utility included with SeaI/O Classic software. The source code is included to aid with Visual Basic application development. 2. SeaIOTST is a command line utility that allows you to test the function calls from the SeaI/O Classic API. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm...
- Page 26 Programmers Interface section. If these steps do not solve your problem, please call Sealevel’s Technical Support at (864) 843-4343. Our technical support is free and available from 8:00AM-5:00PM EST Monday through Friday. For email support contact support@sealevel.com.
-
Page 27: Appendix C - How To Get Assistance
The Sealevel website is an excellent resource located at www.sealevel.com. The most current software updates and user manuals are available via our homepage by clicking on the '' or ' links located under ‘Technical Support.’... -
Page 28: Appendix D - Drawing
Appendix D – Drawing ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013 https://www.impulse-embedded.co.uk/products/8006e--Isolated-PCI-Express-Card.htm... -
Page 29: Appendix E - Compliance
Always use cabling provided with this product if possible. If no cable is provided or if an alternate cable is required, use high quality shielded cabling to maintain compliance with FCC/EMC directives. ©Sealevel Systems, Inc. 8006e Manual SL9236 03/2013... -
Page 30: Warranty
In the event of failure, Sealevel will repair or replace the product at Sealevel's sole discretion. Failures resulting from misapplication or misuse of the Product, failure to adhere to any specifications or instructions, or failure resulting from neglect, abuse, accidents, or acts of nature are not covered under this warranty.
