How To Use ATC5200M Mainboard User's Manual
HOW TO USE THIS MANUAL
This manual is written in a user-friendly style. It would be
advisable for users to read it in an orderly sequence :
1. For Hardware Information:
Read COMPONENT LOCATION DIAGRAM, Page B : QUICK JUMPER &
CONNECTOR SETTING, Page C & D : CONNECTORS AND JUMPERS
DESCRIPTION and Page E:List of Packaging.
2. For Mainboard and System Features:
Read "Chapter 1 System Features" , and you will find helpful information
on mainboard and system features. Especially, when you want to do some
feature setup, detailed instructions are provided therein to help you through.
3. For CPU, Memory and Drivers Installation:
Read "Chapter 2 Installation" for your CPU, memory and application drivers
installation. Detailed instructions are provided to guide all kinds of users.
4. For BIOS Update and Setup:
Read "Chapter 3 Award BIOS Setup" for updating your mainboard BIOS and
setting up your BIOS Configuration.
5. For other Technical Support:
See "Appendix A" , fill and send the Request Form to your dealer for other technical
support.
The default settings on a mainboard is not necessarily what user expects. A user-
friendly manual would be the handiest assistant to help change the on-board
configuration or default setting. In case this manual cannot solve all your problems,
please ask your dealer for help and be sure the warranty on your system is still valid.
REMARK: Intel ® is a registered trademark of Intel Corporation.
All other brands and product names are registered trademarks of their respective companies

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATC5200M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for A-Trend ATC5200M

Summary of Contents for A-Trend ATC5200M

  • Page 1 How To Use ATC5200M Mainboard User’s Manual HOW TO USE THIS MANUAL This manual is written in a user-friendly style. It would be advisable for users to read it in an orderly sequence : 1. For Hardware Information: Read COMPONENT LOCATION DIAGRAM, Page B : QUICK JUMPER &...

  • Page 2: Table Of Contents

    CHECKLIST OF PACKAGING..........E HOW TO USE THIS MANUAL TABLE OF CONTENTS: Chapter 1 System Description 1-1 ATC5200M Mainboard Specification ……………………………………………………... 1 1-2 Features Highlight ………………………………………………………………………….. 2 1-2-1 Software Power Off Control …...………………………………………………………… 2 1-2-2 AGP Interface ……………..……………………………………………………………... 2 Chapter 2 Installation 2-1 Mainboard Installation ……………………………………………………………………...
  • Page 3 Contents ATC5200M Mainboard 3-2-6 Integrated Peripherals …………………………………………………………………. 40 3-2-7 IDE HDD Autodetection ……………………………………………………………… 42 3-2-8 Save & Exit Setup ……………………………………………………………………... 43 3-2-9 Load BIOS Defaults …………………………………………………………………... 43 3-2-10 Load Setup Defaults …………………………………………………………………. 43 3-2-11 Supervisor/User Password …………………………………………………………… 43 3-2-12 Exit without Saving ………………………………………………………………….. 43 Control Keys Description for BIOS Setup …………………………..

  • Page 4: Chapter 1 System Description

    CHAPTER 1 System Description ATC5200M Mainboard with Socket 7 on board supports 66~100MHz host clock, and is intended to run Intel Pentium CPUs up to 233MHz, AMD K5/K6/K6-2 CPUs, and Cyrix 6x86/6x86MX / M II CPUs. With VIA MVP3 chipset on board, it also supports AGP and Ultra DMA performance for fast VGA display and data transfer.

  • Page 5: Features Highlight

    Chapter 2 Installation ATC5200M Mainboard  WINBOND W83877TF high-speed Super Multi-I/O chipset.  Infrared transfer (IrDA TX/RX) Support.  One FDD port supports following 2 floppy drives: 1.2MB/1.44MB/ 2.88MB.  Two 16550A fast UARTs compatible serial ports; One DIN connector for KB ...
  • Page 6 ATC5200M Mainboard Chapter 1 System Description  The current PCI bus supports a data transfer rate up to 132 MB/s, while AGP (at 66MHz) supports up to 533 MB/s!

  • Page 7: Atc5200M Mainboard Specification

    Chapter 2 Installation ATC5200M Mainboard CHAPTER 2 INSTALLATION 2-1 MAINBOARD INSTALLATION Before installing the computer, please get ready all components such as CPU, DRAM; peripherals(such as hard drive, keyboard, CD-ROM) and accessories(such as cables, jumper caps, cooling fans, screw driver)etc. Then, install the system as below: 1.

  • Page 8: Agp Interface

    ATC5200M Mainboard Chapter 2 Installation 2-2 CPU CONFIGURATION 5200M Mainboard supports Pentium level CPUs. To install CPU, please notice CPU pin 1 must align with the ZIF socket 7 pin 1 location. To configure your CPU, please follow the CPU Guide provided by CPU manufacturer to configure the CPU voltage setting and then set up DIP Switch &...
  • Page 9 Chapter 2 Installation ATC5200M Mainboard JP4 Setting: For CPU Core voltage The setting for CPU Ccore Voltage Selection Vcore Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 2.2V Open Closed Open Open 2.3V Closed Closed Open Open 2.7V...
  • Page 10 ATC5200M Mainboard Chapter 2 Installation 2-2-1 CPU TYPE vs Jumper Setting Illustrations:  A. INTEL PENTIUM (P54C) ※ P54C VRE : 3.400V~3.600V (CPU Voltage is marked on the back side of the CPU itself. V = VRE, S = standard. ) JP4(3.5V)
  • Page 11 Chapter 2 Installation ATC5200M Mainboard  A-2. Intel Pentium 133MHz Base x Ratio CLOCK 133MHz 66 x 2.0 1 2 3 4 5 6 7 A-3. Intel Pentium  166MHz Base x Ratio CLOCK 166MHz 66 x 2.5 1 2 3 4 5 6 7 A-4.
  • Page 12 ATC5200M Mainboard Chapter 2 Installation INTEL PENTIUM MMX CPU (P55C) JP4 (2.8V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 2.8V Open Open Open Closed JP5 Setting (Dual) Mode JP5 (Pin1-2, 3-4, 5-6) Closed Dual Voltage Mode(Vcore ≠Vi/o)** JP1, JP2 &...
  • Page 13 Chapter 2 Installation ATC5200M Mainboard C. Cyrix 6x86MX CPU JP4 (2.9V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 2.9V Closed Open Open Closed JP5 Setting (Dual) Mode JP5 (Pin1-2, 3-4, 5-6) Closed Dual Voltage Mode(Vcore ≠Vi/o)** JP1, JP2 &...
  • Page 14 ATC5200M Mainboard Chapter 2 Installation C-4. Cyrix 6x86MX PR233 @ 75MHz Bus 2.5x JP4 (2.9V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 2.9V Closed Open Open Closed JP5 Setting (Dual) Mode JP5 (Pin1-2, 3-4, 5-6) Closed Dual Voltage Mode(Vcore ≠Vi/o)**...
  • Page 15 Chapter 2 Installation ATC5200M Mainboard D. Cyrix MII CPU D-1 Cyrix MII 300MHz @ 66MHz Bus 3.5x JP4(2.9V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 2.9V Closed Open Open Closed JP5 Setting (Dual) Mode...
  • Page 16 ATC5200M Mainboard Chapter 2 Installation CPU host clock/DRAM/PCI clock JP1 75MHz/75MHz/30MHz Pin 2-3 Pin 1-2 Pin 1-2 CPU Clock Base x Ratio MII 300MHz 75 x 3.0 1 2 3 4 5 6 7...
  • Page 17 Chapter 2 Installation ATC5200M Mainboard Cyrix 6x86L CPU (dual voltage) JP4 (2.8V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 2.8V Open Open Open Closed JP5 Setting (Dual) Mode JP5 (Pin1-2, 3-4, 5-6) Closed Dual Voltage Mode(Vcore ≠Vi/o)** JP1, JP2 &...
  • Page 18 ATC5200M Mainboard Chapter 2 Installation AMD-K5 CPU Series JP4(3.5V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 3.5V Closed Closed Closed Closed JP5 Setting (Single) Mode JP5 (Pin1-2, 3-4, 5-6) Open Single Voltage Mode(Vcore = Vi/o)* JP1, JP2 &...
  • Page 19 Chapter 2 Installation ATC5200M Mainboard G. AMD-K6 CPU JP1, JP2 & JP3 Settings CPU host clock/DRAM/PCI clock 66MHz/66MHz/33MHz Pin 2-3 Pin 2-3 Pin 2-3 JP5 Setting (Dual) Mode JP5 (Pin1-2, 3-4, 5-6) Closed Dual Voltage Mode(Vcore ≠Vi/o)** G-1. AMD-K6 166MHz JP4(2.9V)
  • Page 20 ATC5200M Mainboard Chapter 2 Installation 200MHz 66 x 3.0 1 2 3 4 5 6 7 G-3a. AMD-K6 233MHz JP4(3.2V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 3.2V Open Open Closed Closed Base x Ratio...
  • Page 21 Chapter 2 Installation ATC5200M Mainboard G-4a. AMD-K6 266 MHz JP4(2.2V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 2.2V Open Closed Open Open CPU Clock Base x Ratio 266MHz 66 x 4.0 1 2 3 4 5 6 7 G-4b.
  • Page 22 ATC5200M Mainboard Chapter 2 Installation JP1, JP2 & JP3 Settings CPU host clock/DRAM/PCI clock 66MHz/66MHz/33MHz Pin 2-3 Pin 2-3 Pin 2-3 Base x Ratio CLOCK 300MHz 66 x 4.5 1 2 3 4 5 6 7...
  • Page 23 Chapter 2 Installation ATC5200M Mainboard G-5b. AMD-K6-2 300MHz JP4(2.2V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore Vcore Open Closed Open Open JP5 Setting (Dual) Mode JP5 (Pin1-2, 3-4, 5-6) Closed Dual Voltage Mode(Vcore ≠Vi/o) SW1(Pin7), JP1, JP2 &...
  • Page 24 ATC5200M Mainboard Chapter 2 Installation CPU host clock/DRAM/PCI clock SW1-pin7 95MHz/95MHz/31.7MHz* Pin 2-3 Pin 1-2 Pin 2-3 95MHz/66MHz/31.7MHz** Pin 1-2 Pin 1-2 Pin 2-3 Please use for PC-100 SDRAM module (SYNC.) Please use non PC-100 SDRAM module or EDO DIMM module (ASYNC.)
  • Page 25 Chapter 2 Installation ATC5200M Mainboard H. IDT Win Chip C6 JP4(3.5V) Pin1 & Pin5 Pin2 & Pin6 Pin3 & Pin7 Pin4 & Pin8 Vcore 3.5V Closed Closed Closed Closed JP5 Setting (Single) Mode JP5 (Pin1-2, 3-4, 5-6) Open Single Voltage Mode(Vcore = Vi/o)* H-1.

  • Page 26: System Memory Installation

    ATC5200M Mainboard Chapter 2 Installation 2-3 SYSTEM MEMORY INSTALLATION The 5200M provides three 168-pin DIMM sockets for system memory expansion from 8MB to 768MB. These three DIMMs are arranged to three banks, please refer to page A. Each bank provides 64-bit wide data path.

  • Page 27: Via Ide Driver Setup

    Chapter 2 Installation ATC5200M Mainboard 2-4 VIA IDE DRIVER SETUP The VIA IDE drivers are enclosed into the VIA Utility CD. Use this CD ROM for installation of the VIA drivers. 2-4-1 Setup for Windows 9x : 1. Starting Windows system.

  • Page 28: Setup For Windows Nt4.0

    ATC5200M Mainboard Chapter 2 Installation 4.To start VIA drivers setup, point to the “VIA Integrated Setup” and click on it. 5.User-friendly Setup screens will appear one by one , guiding you to finish the complete setup. 6. When the “Setup complete” screen appears, click “Finish” to restart your computer so as to put the just installed drivers into effect.

  • Page 29: Chapter 3 Award Bios Setup

    Chapter 3 Award BIOS Setup ATC5200M Mainboard CHAPTER 3 Award BIOS SETUP Award BIOS manufacturer provides access to the system BIOS through the hardware and software on each 5200M mainboard. The hardware consists of a Flash ROM and the software is a group of programs that are installed in the ROMBIOS along with all the other data the BIOS must contain.

  • Page 30: Update Bios Procedure

    ATC5200M Mainboard Chapter 3 Award BIOS Setup 3-1 UPDATE BIOS PROCEDURE 3-1-1 Updating BIOS If the BIOS needs to be updated, you can get a CD or diskette with the updated BIOS utility in the package. The BIOS-update diskette or All-In-One CD includes two files: “awdflash.exe”...

  • Page 31: System Bios Configuration

    Chapter 3 Award BIOS Setup ATC5200M Mainboard 3-2 SYSTEM BIOS CONFIGURATION SETUP The following pages explain how to set up the system configuration (CMOS) under the Award BIOS. The SETUP program is stored in the Read-Only-Memory (ROM) on the mainboard. To do the SETUP procedure, press the <Del> key when the system is booting up.

  • Page 32: Standard Cmos Setup

    ATC5200M Mainboard Chapter 3 Award BIOS Setup 3-2-1 Standard CMOS Setup This screen records some basic hardware information, and sets the system clock and error handling. These records can be lost or corrupted if the on-board battery has failed or is weak.
  • Page 33 Chapter 3 Award BIOS Setup ATC5200M Mainboard <Enter>. If ‘Auto’ selected, the BIOS will detect the HDD & CD-ROM Drive automatically at the POST stage and show the IDE for HDD & CD-ROM Drive. If ‘user’ selected, you will need to know the information listed below. This information should be from your hard disk vender or dealer.
  • Page 34 ATC5200M Mainboard Chapter 3 Award BIOS Setup Halt On This category determines whether the computer will stop if an error is detected during power up. No errors The system boot will not be stopped for any error that may be detected...

  • Page 35: Bios Features Setup

    Chapter 3 Award BIOS Setup ATC5200M Mainboard 3-2-2 BIOS Features Setup This screen is a list of system configuration options. Some of them are defaults required by the mainboard's design, others depend on the features of your system. ROM PCI/ISA BIOS (5200M) BIOS FEATURES SETUP AWARD SOFTWARE, INC.
  • Page 36 ATC5200M Mainboard Chapter 3 Award BIOS Setup Award Software, Inc. Enabled Activates automatically when the system boots up. If anything attempts to access the boot sector or hard disk, partition table will cause a warning message to appear. Disabled No warning message will appear when anything attempts to access the boot sector or hard disk partition table.
  • Page 37 Chapter 3 Award BIOS Setup ATC5200M Mainboard Gate A20 Option The Gate A20 is a device used to address memory above 1MB. While Gate A20 support can be provided through keyboard, it is much faster for system chipset to provide Gate A20 support.
  • Page 38 ATC5200M Mainboard Chapter 3 Award BIOS Setup Report No FDD For WIN 95 Set this item to Yes, BIOS will report FDD to Win95. If in standard CMOS setup, set Drive A to none and set this item to yes. Inside Win95, My Computer and File manager Disk(A:) will show Removable Disk (A:).

  • Page 39: Chipset Features Setup

    Chapter 3 Award BIOS Setup ATC5200M Mainboard 3-2-3 Chipset Features Setup This screen controls the setting for the chipset on the mainboard. ROM PCI/ISA BIOS (5200M) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC. Bank 0/1 DRAM Timing : FP/EDO 70ns OnChip USB...
  • Page 40 ATC5200M Mainboard Chapter 3 Award BIOS Setup DRAM Read Pipeline Enable/Disable DRAM Read Pipeline Cycle. Sustained 3T Write Enabled : set cache to write back mode. Disabled : set cache to write through mode. Cache Rd+CPU Wt Pipeline Enable/Disable Cache Read Write cycle.

  • Page 41: Power Management Setup

    Chapter 3 Award BIOS Setup ATC5200M Mainboard 3-2-4 Power Management Setup This screen controls the 'green' features of this mainboard. ROM PCI/ISA BIOS (5200M) POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. Power Management : User Defined Primary INTR : ON PM Control by APM...
  • Page 42 ATC5200M Mainboard Chapter 3 Award BIOS Setup Power Management This category allows you to select the type (or degree) of power saving and is directly related to the following modes : Doze; Standby; Suspend; HDD Power Down. Min. Power Minimum power management. Doze =1hr.;...
  • Page 43 Chapter 3 Award BIOS Setup ATC5200M Mainboard MODEM Use IRQ This item determines the IRQ in which the MODEM can be used. The choice : 3,4,5,7,9,10,11,NA. Soft-Off by PWR-BTTN Instant-off : When push the power button, the system power will be off immediately. Delay 4 sec : when push the power button, it will enter suspend mode.

  • Page 44: Pnp/Pci Configuration

    ATC5200M Mainboard Chapter 3 Award BIOS Setup 3-2-5 PNP/PCI Configuration This screen configures the PCI Bus slots. ROM PCI/ISA BIOS (5200M) PNP/PCI CONFIGURATION AWARD SOFTWARE, INC. PNP OS Installed : No CPU to PCI Write Buffer : Enabled Resources Controlled by...
  • Page 45 Chapter 3 Award BIOS Setup ATC5200M Mainboard CPU to PCI Write Buffer Enable/Disable CPU to PCI POST Write. PCI Dynamic Bursting Enable/Disable PCI burst operation. PCI Master 0 WS Write Enable : PCI Master 0 wait state mode. Disable : PCI Master 1 wait state mode.

  • Page 46: Integrated Peripherals

    ATC5200M Mainboard Chapter 3 Award BIOS Setup 3-2-6 Integrated Peripherals This section page includes all the items of IDE hard drive and Programmed Input/Output features. See also Section “Chipset Features Setup”. ROM PCI/ISA BIOS (5200M) INTEGRATED PERIPHERALS AWARD SOFTWARE, INC.
  • Page 47 Chapter 3 Award BIOS Setup ATC5200M Mainboard IDE Primary PIO (Programmed Input/Output) allows the BIOS to Master/Slave PIO tell the controller what it wants and then let the controller IDE Secondary and the CPU to complete the task by themselves.

  • Page 48: Ide Hdd Autodetection

    ATC5200M Mainboard Chapter 3 Award BIOS Setup 3-2-7 IDE HDD Auto Detection This allows you to detect the IDE hard disk drivers‘ parameters and enter them into ‘Standard CMOS Setup’ automatically. If the auto-detected parameters displaye on screen do not match the ones that should be used for your hard drive, do not accept them.

  • Page 49: Save & Exit Setup

    Chapter 3 Award BIOS Setup ATC5200M Mainboard 3-2-9 LOAD SETUP DEFAULTS This allows you to load optimal settings which are stored in the BIOS ROM. To load the default values, highlight “Load Setup Defaults” and press “Enter. Then Setup Defaults values will be re-loaded to “BIOS Features Setup”, “Chipset Features Setup”, “Power...
  • Page 50 ATC5200M Mainboard Chapter 3 Award BIOS Setup Control Key Description ※ UP ARROW ↑ Move to previous item DOWN ARROW ↓ Move to next item LEFT ARROW ← Move to the item in the left hand RIGHT ARROW → Move to the item in the right hand...
