1.800.561.8187
ENGLISH
INSTRUCTION MANUAL
INSTRUCTION MANUAL
INSPECTION KIT
INSPECTION KIT
Infrared
Thermometer
(pg. 2)
• TARGETING LASER
TARGETING LASER
• 10:1 DISTANCE-
TO-SPOT RATIO
• BACKLIT DISPLAY
BACKLIT DISPLAY
• AUTO POWER-OFF
AUTO POWER-OFF
-4° –
752°F
-20° –
400°C
2 m
GFCI Receptacle Tester
(pg. 7)
• FOR STANDARD AND GFCI
RECEPTACLES
• DETECTS OPEN GROUND,
REVERSE POLARITY, OPEN
HOT, OPEN NEUTRAL,
HOT/GROUND REVERSED
CAT II
2 m
300V
www.
information@itm.com
.com
IR1KIT
Advertisement
Table of Contents
Related Manuals for Klein Tools IR1KIT
Summary of Contents for Klein Tools IR1KIT
- Page 1 IR1KIT ENGLISH INSTRUCTION MANUAL INSTRUCTION MANUAL INSPECTION KIT INSPECTION KIT Infrared Thermometer (pg. 2) • TARGETING LASER TARGETING LASER • 10:1 DISTANCE- TO-SPOT RATIO • BACKLIT DISPLAY BACKLIT DISPLAY • AUTO POWER-OFF AUTO POWER-OFF -4° – 752°F -20° – 400°C GFCI Receptacle Tester (pg.
-
Page 2: Measurement Specifications
ENGLISH GENERAL SPECIFICATIONS - IR1 Klein Tools IR1 is an entry-level infrared thermometer with targeting laser. It offers a wide measurement range, a 10:1 distance–to-spot ratio, a targeting laser, and user-selectable from Fahrenheit to Celsius temperature scales. • Environment: Indoor or outdoor •... - Page 3 WARNINGS To ensure safe operation and service of the tester, follow these instructions. Failure to observe these warnings can result in severe injury or death. Retain these instructions for future reference. WARNING: LASER RADIATION. DO NOT STARE INTO BEAM. Class II Laser. •...
-
Page 4: Feature Details
ENGLISH FEATURE DETAILS Front LCD Display Trigger Battery Compartment Door IR Temperature Sensor Targeting Laser °F/°C Switch (Behind Battery Compartment Door) NOTE: There are no user-serviceable parts inside meter. SYMBOLS ON LCD Temperature Reading Targeting laser active Data Hold Battery level indicator Active temperature scale 1.800.561.8187 information@itm.com... -
Page 5: Temperature Measurement
OPERATING INSTRUCTIONS TEMPERATURE MEASUREMENT To measure temperature with the IR1, aim the meter at the object to be measured, pull the trigger and hold it depressed for at least 2 seconds. Releasing the trigger initiates Data Hold, "HOLD" will show on the display, and the measurement will be held on the display. -
Page 6: Maintenance
ENGLISH MAINTENANCE BATTERY REPLACEMENT When indicator is displayed on LCD, battery must be replaced. 1. Loosen the screw in the Battery Compartment Door to open. 2. Remove exhausted 9V battery and dispose of appropriately. 3. Replace 9V battery and return Battery Compartment Door and tighten screw to secure, taking care not to over-tighten. - Page 7 GENERAL SPECIFICATIONS - RT210 Relative Humidity: < 85% non-condensing Operating Temperature: 32° to 140°F (0° to 40°C) Storage Temperature: 14° to 122°F (-10°C to 50°C) Operating Altitude: Up to 6562 ft. (2000 m) Weight: 1.2 oz. (33 g) Nominal Voltage: 110 - 125V AC at 50/60Hz in 3-wire outlet Mains Supply Voltage Fluctuations: ±10% Pollution Degree: 2 Nominal Power: 0.3W...
-
Page 8: Standard Receptacles
ENGLISH OPERATING INSTRUCTIONS WIRING CONFIGURATION TESTING Conditions indicated: wiring correct, open ground, reverse polarity, open hot, open neutral and hot/ground reversed. Conditions NOT indicated: quality of ground, multiple hot wires, combinations of defects, reversal of grounded and grounding conductors. All appliances or equipment on the circuit being tested should be unplugged to help reduce the possibility of erroneous readings.
