Symbols And Annunciators - Extech Instruments EX410A User Manual

Description

Symbols and Annunciators

HOLD
ºF
ºC
Find Quality Products Online at:
1. Rubber holster (must be removed to access battery)
2. 2000 count LCD display
3. °F button for temperature measurements
4. °C button for temperature measurements
5. Function switch
6. mA, uA and A input jacks
7. COM input jack
8. Positive input jack
9. Battery check button
10. Hold button (freezes displayed reading)
11. LCD backlight button
Note: Tilt stand, test lead holders, and battery compartment are on rear of unit.
))) Continuity
Diode test
Battery status
Test lead connection error
Display hold
Degrees Fahrenheit
Degrees Celsius
