General Specifications
Find Quality Products Online at:
Diode Test
Test current of 1mA maximum, open circuit voltage 2.8V DC typical
Continuity Check
Audible signal when resistance is less than approximately 150
Input Impedance
10M
AC Response
Average responding
ACV Bandwidth
50Hz to 1kHz
DCA voltage drop
200mV
Display
3 ½ digit, 2000 count LCD, 0.9 digits
Auto-Power Off
Meter switches OFF after 15 minutes (approximately) of inactivity
Overrange indication
1 is displayed
Polarity
Automatic (no indication for positive polarity); Minus (-) sign for negative
polarity.
Measurement Rate
2 times per second, nominal
Low Battery Indication
Battery
One 9 volt (NEDA 1604) battery
Fuses
mA, µA ranges; 0.2A/600V fast blow
A range; 10A/600V ceramic fast blow
Operating Temperature 5ºC to 40ºC (41ºF to 104ºF)
Storage Temperature
-20ºC to 60ºC (-4ºF to 140ºF)
Operating Humidity
Max 80% up to 31ºC (87ºF) decreasing linearly to 50% at 40ºC (104ºF)
Storage Humidity
<80%
Operating Altitude
2000 meters (7000ft.) maximum
Weight
342g (0.753lb) (includes holster)
Size
187 x 81 x 50mm (7.36 x 3.2 x 2.0 ) (includes holster)
Safety
For indoor use and in accordance with the requirements for double
insulation to: EN61010-1 (2010) 3rd edition Overvoltage Category III
600V, Pollution Degree 2.
GlobalTestSupply
www.
is displayed if battery voltage drops below operating voltage
11
EX410A-en-GB_V6.0 6/16
