- Page 1 AWBP 10 Repair instructions C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 1 of 35 FEIN retains all rights of disposal, such as copying and circulation...
-
Page 2: Table Of Contents
6. Removal 7. Fitting 8. Troubleshooting 9. Connection diagram C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 2 of 35 FEIN retains all rights of disposal, such as copying and circulation... -
Page 3: Models Described
Order number AWBP 10 7 105 04 00 94 0 C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 3 of 35 FEIN retains all rights of disposal, such as copying and circulation... -
Page 4: Technical Data
Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service → Repair Guides). Lubricants The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service → Repair Guides). Lists of spare parts Lists of spare parts and exploded views are available online at www.fein.com... -
Page 5: Notes And Requirements
Outside Germany, the regulations applicable in the relevant country must be observed. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 5 of 35 FEIN retains all rights of disposal, such as copying and circulation... -
Page 6: Tools Required
Inner dia. 15 mm Inner dia. 16 mm Inner dia. ~25 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 6 of 35 FEIN retains all rights of disposal, such as copying and circulation... - Page 7 Circlip pliers Torx T15; T20 Cylinder head screw M8x60 C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 7 of 35 FEIN retains all rights of disposal, such as copying and circulation...
-
Page 8: Lubricants And Auxiliary Substances Required
Grease 0 40 101 0100 4 25 g Housing C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 8 of 35 FEIN retains all rights of disposal, such as copying and circulation... -
Page 9: Removal
- M8x60 cylinder head screw - Drill chuck key C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 9 of 35 FEIN retains all rights of disposal, such as copying and circulation... - Page 10 4. Open the upper part of the motor housing (4). C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 10 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 11 4. Push the stop button out of the motor housing. 5. Remove the spiral spring (5). C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 11 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 12 4. Remove all the connection cables from the plug (4). C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 12 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 13 - Drawing-off socket cap - Chuck cone, dia. 19 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 13 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 14 2. Remove the gearbox (2) from the gearbox housing. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 14 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 15 2. Pull the dowel pin (2) out of the intermediate gear box. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 15 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 16 - Sleeve Inner dia. 16 mm Outer dia. ~20 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 16 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 17 - Sleeve Inner dia. 12 mm Outer dia. ~16 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 17 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 18 3. Remove the disc (3). 4. Remove the shaft (4) from the housing. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 18 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 19 - Chuck cone, dia. 22 mm - Chuck cone, dia. 26 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 19 of 35 FEIN retains all rights of disposal, such as copying and circulation...
-
Page 20: Fitting
- Sleeve Inner dia. 11 mm Outer dia. 26 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 20 of 35 FEIN retains all rights of disposal, such as copying and circulation... - Page 21 - Sleeve Inner dia. 12 mm Outer dia. ~15 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 21 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 22 - Sleeve Inner dia. 5 mm Outer dia. ~15 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 22 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 23 - Sleeve Inner dia. 5 mm Outer dia. ~15 mm C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 23 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 24 When refitting the gearbox housing, always use a new circlip. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 24 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 25 5. Fit the intermediate gear box (4) to the gearbox housing. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 25 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 26 4. Thread the individual wires (4) from the cable into the recess. 5. Connect the plug (5). C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 26 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 27 2. Push the stop button (2) into the recess. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 27 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 28 Make sure that the air guide ring is sitting in both of the recesses (6). 3. Put the terminal (5) in place. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 28 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 29 The red motor cable fixes the thin cables from the speed setting switch in place. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 29 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 30 3. Fit the gearbox housing (3). 4. Screw in the screws (4). C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 30 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 31 3. Tap the key-type drill chuck with a plastic hammer to fix it in place. 4. Slide the battery (2) onto the tool. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 31 of 35 FEIN retains all rights of disposal, such as copying and circulation...
-
Page 32: Troubleshooting
Plug on motor has come loose or is not secure Check cables C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 32 of 35 FEIN retains all rights of disposal, such as copying and circulation... - Page 33 The possible test steps and target values for use with the test board are provided on the next page. C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 33 of 35 FEIN retains all rights of disposal, such as copying and circulation...
- Page 34 Switch not pressed: 0 Ω Switch pressed: 20 kΩ ± 4 kΩ C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 34 of 35 FEIN retains all rights of disposal, such as copying and circulation...
-
Page 35: Connection Diagram
AWBP 10 9. Connection diagram C-SC_CSSM Version 1.0 2015-05-22 All rights reserved by FEIN, especially in case of industrial rights registration. Page 35 of 35 FEIN retains all rights of disposal, such as copying and circulation...
