ZXHN H108N
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Zte ZXHN H108N

Summary of Contents for Zte ZXHN H108N

  • Page 1 ZXHN H108N User Manual...
  • Page 2 ZTE Corporation. ZTE CORPORATION reserves the right to modify this manual for product upgrade or other causes without notifying users in ad- vance.
  • Page 3 Warranty ■ ■ ■ ZTE warrants that, for one year from the date of delivery by ZTE to purchaser's designated carrier, the equipment will remain free from defects in design, ma- terial and workmanship under normal use and service and will conform in all material respects to the applicable specifications set forth in purchase order or agreement.
  • Page 4 OTHERWISE REQUIRED UNDER THE MANDATORY PROVISIONS OF THE CHINESE LAW, AND (2) IS BETWEEN ZTE AND END USER (AS THE ORIG- INAL PURCHASER FOR END USE) AND MAY NOT BE TRANSFERRED OR ASSIGNED, BY OPERATION OF LAW OR OTHERWISE, WITHOUT ZTE’S PRIOR WRITTEN CONSENT.

  • Page 5: Safety Instructions

    Safety Instructions 1.1 Safety Checklistc Check the following items before installing the ZXHN H108N ADSL equipment. Do not place inflammable/conductive/wet objects around the Electrical equipment. Cables should be in good condition. All electrical safety appliances should be placed stably. �...
  • Page 6 Overview The ZXHN H108N is an ADSL access device that has multiple line transmis- sion modes. At the user end, it not only provides four 10/100Base-T Ether- net interfaces but also supports wireless user accesses in compliance with the IEEE802.11b/g/n standard.

  • Page 7: Product Specifications

    Information provided above is for reference only; actual product appearance may vary. 2.4 System Requirements Please check the following items before installing the ZXHN H108N. � ADSL Service Subscription If you have subscribed for the ADSL service, your ADSL operator will provide you at least one valid IP address through static allocation or dialup dynamic allocation.
  • Page 8 � Computer Configuration Please make sure that the system is equipped with a 10M/100M Ethernet adapter and supports the TCP/IP protocol. It is recommended to use a computer with the below configurations: Pen- tium III or a later version, 64M memory, 10G hard disk, graphic accelerating adapter with above 2M display memory, audio adapter, and sound box.
  • Page 9 Identifica- Color Status Description Description tion No signals are detected. DSL line handshaking in Slow Flash progress. Green DSL line training in progress. Flash The modem has been Constantly On activated. The system is under the Bridge mode or the ADSL has not been connected.
  • Page 10 Identifica- Color Status Description Description tion Constantly On The wireless port is enabled. Data is transmitting. The Flashing flashing frequency indicates WLAN Green the WLAN traffic. The equipment is not powered on or the wireless port is disabled. The green indicator is off in the following situations: �...
  • Page 11 Rear panel Item Description RJ-11 connection interface: The equipment is connected to the ADSL line or splitter via the telephone line. RJ-45 connection interface: Connect it to the PC LAN1-LAN4 computer or other network devices by using the network cable. Power interface.

  • Page 12: Hardware Connections

    3.2 Hardware Connections Hardware Connections Introduction Note: If you do not want internet services and telephone voice services to be provided at the same time, connect only the line port of the Gateway with the RJ-11 port (the phone jack) on the wall by using a telephone cord. In this case, the splitter is not necessary.
  • Page 13 FAQs Solution First, make sure that you have inserted the power adapter of the ZXHN H108N into a working power socket and that the ZXHN H108N has been All indicators are off powered on (the switch button is pressed down).
  • Page 14 Solution Modem synchronization and connection are normal. However, sometimes the password fails to be verified. Solution: 1. Be noted that the account and password are case sensitive and some accounts contain a domain name. Password verification 2. Virtual dialup software. It is possible that some- failure.

  • Page 15: Standards Compliance

    Solution On. It is suggested to do check in the following order: 1. Check the quality of the incoming cables and the incoming cable connectors. 2. Install the ADSL Modem correctly by following the user guide. 3. Ensure the telephone cables are normal and are in good contact with ADSL.
  • Page 16 Standard Note Asymmetric digital subscriber line (ADSL) transceivers. ITU G.992.1 Asymmetric digital subscriber line transceivers 2 ITU G.992.3 (ADSL2). Asymmetric Digital Subscriber Line (ADSL) ITU G.992.5 transceivers-Extended bandwidth ADSL2 (ADSL2+). Handshake procedures for Digital Subscriber Line ITU G.994.1 (DSL)Transceivers. Transmission and Multiplexing (TM); Access transmission systems on metallic access cables;...
  • Page 17 Thank you for choosing the ZTE communication product. To obtain our best service, please read the information in this warranty card carefully and retain this card safely. ZTE Corporation warrants that the product will be free from manufacturing defects for one year from the date of purchase. Should there...
  • Page 18 � Service and Maintenance Record Date Maintenance/service Signature Signature of Item of Mainte- Customer nance En- gineer...
  • Page 20 ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen. P.R.China Postcode: 518057 Tel: (86) 755 26771900 Fax: (86) 755 26770801 URL: http://ensupport.zte.com.cn E-mail: support@zte.com.cn...
