Accessing the Sliding Shoes

To do so:
Go behind the packer and, with a grinder or cutting tools, remove the welds from both sliding
1.
shoes (see Figure 3-15).
Figure 3-15 Welds to remove
From the cab, start the engine, engage the hydraulic pump and extend the packer to about
2.
18 inches before the end of the stroke.
Figure 3-16 Packer extended to 18 inches before end of stroke
Danger!
Never enter the hopper while the packer is moving.
Turn off the hydraulic pump and the engine.
3.
Remove all three bolts retaining each sliding shoe.
4.
General Maintenance 33
