remove the loose mirror. Removing the loose mirror will prevent any internal damage during
shipping when returning the unit for service. The mirror can now be packed separately and both
units sent back to the factory for service.
Required Tools:
Small Phillips head screwdriver
Medium Phillips head screwdriver (magnetic preferred)
Work in a dust free environment
1. Remove the Mantis viewing head from its support by removing the Yaw bolt.
2. Rest the viewing head upside down (turret facing "UP").
3. Remove the two screws on the rear of the viewing head.
4. Remove both filter trays providing access to the lamps. Be careful not to let the diffuser lens
drop when removing the filter trays.
5. Remove the single screw in each lamp socket.
6. The lower viewing head assembly (lower black section) can now be removed.
7. Without Touching the Mirror, remove the mirror or reattach if required.
8. Reassemble by reversing the disassembly steps.
