Robert Juliat TIBO HE Manual

Led profile spot
Hide thumbs Also See for TIBO HE:

Advertisement

Quick Links

LED PROFILE SPOT
Colour temperature
Standard
North American
COOL WHITE
553 CW
553 CCW
WARM WHITE
553 WW
553 CWW
115W LED PROFILE SPOT
V1
VALIDATION: 19/09/21
DN41205300 (EN)
Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - fax : +33 (0)3 44 26 90 79 - info@robertjuliat.fr
www.robertjuliat.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TIBO HE and is the answer not in the manual?

Questions and answers

Summary of Contents for Robert Juliat TIBO HE

  • Page 1 553 CWW 115W LED PROFILE SPOT VALIDATION: 19/09/21 DN41205300 (EN) Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - fax : +33 (0)3 44 26 90 79 - info@robertjuliat.fr www.robertjuliat.com...
  • Page 2: Table Of Contents

    6.4 Firmware update ..................................................27 6.5 Factory defaults ................................................... 27 6.5.1 Modes ........................................................... 27 6.5.2 Control ..........................................................27 Robert Juliat reserve the right to change or alter any of the items detailed on this page, to increase or improve manufacturing techniques without prior notice.
  • Page 3: User's Instructions

    1 User’s instructions GENERAL INSTRUCTIONS Not for residential use. These fixtures must only be serviced by a qualified technician. In addition to the instructions indicated on this page, relevant health and safety requirements of the appropriate EU Directives must be adhered to at all times. This fixture is in compliance with section 17 - Lighting appliance for theatre stages, television, cinema and photograph studios.
  • Page 4: Presentation

    2 Presentation 2.1 Functions Description Identification plates 11. Fixture rotation locking button Data connector (IN and OUT) 12. Lens tube access Power connector (IN and OUT) 13. Zoom adjustment RJ45 network connector 14. Front slot for accessories and gel frame holder Handle 15.
  • Page 5: Accessories Included

    Accessories included Reference Description DN41202200 Quick Start manual PF100M 135x135 mm metal filter holder Shutter for Tibo series CAL03 Power cable with CEE7/7 type IN connector (standard version) CAL04 UL/CSA Power cable without connector (North American version) Optional accessories Reference Description PCP1716A 16A blue 2P+E 6h IEC60309 power connector...
  • Page 6: Accessories

    2.5 Accessories Reference Description IS500 Drop-in iris (monoplane) with holder SGUT Universal "M" size gobo-holder (metal, glass, frosted glass) Safety cable Ø3mm L= 600mm - SWL: 75Kg DMXcat Bluetooth DMX/RDM Multifunction test tool - City Theatrical DMXcat® Doughty "Twenty clamp" with M10 screw/nut for Ø48 to 51mm pipes Hook clamp 25x6 with M10 L=23mm screw pour tube Ø35 à...
  • Page 7: Instructions For Use

    3.1.3 Instructions for use 5°C 40°C Minimum : Maximum : 40°F 104°F IP20 - Indoor use only 3.1.4 Hanging • Ensure fixture is correctly mounted on an appropriate support Net weight: 10,2 kg (22.4 lbs) 3.1.5 Safety cable • When hung or flown the fixture must be secured by an additional hanging accessory (such as a safety bond or cable) of suitable length.
  • Page 8: Electrical Information

    3.2 Electrical information 3.2.1 LED source Never touch or scratch the LED surface. See 6.1.4 LED cleaning procedure if cleaning is necessary. 3.2.2 Power supply Power supply Voltage Frequency Input power Connectors 0,7 A / 130 W @ 230V Neutrik powerCON TRUE1 TOP 1,15 A / 135 W @ 120V 100 T 264 V 50-60 Hz...
  • Page 9: Data

    3.3 DATA 3.3.1 DMX 512-A / RDM Protocol Input connector Output connector USITT DMX 512-A XLR 5-pin XLR 5-pin DATA connectors PIN # Description Shielding Foil & Braided Shield 1 st conductor of 1 st twisted pair DMX (-) 2 nd conductor of 1 st twisted pair DMX (+) 1 st conductor of 2 nd twisted pair Not used...
  • Page 10: Art-Net / Sacn

    3.3.2 Art-Net / sACN Protocol Input connector Output connector Art-Net RJ45 sACN Daisy chain: Fixture Fixture Fixture Art-Net sACN Network switch* interface (*) A 1000 base-T switch that supports IGMP (Internet Group Management Protocol) is necessary if the unit is connected to a network switch to control multiple devices.
  • Page 11: Accessories

    3.4 Accessories 3.4.1 Front filter holder Step 2 Step 1 For filter dimensions, see section 4.6 The filter holder includes perforations designed for stapling to keep the gel in position. EN - 9 -...
  • Page 12: Iris / Gobo Holder

    3.4.2 Iris / Gobo holder For gobo/Iris dimensions, see section 4.9 To prevent objects from falling when the fixture is used upside-down, secure the iris/gobo with a safety cable (ref# CS5) 3.4.3 Shutters Step 1 Step 2 Step 3 A: Right and left shutters – slot on lamp house side B: Top and bottom shutters –...
  • Page 13: Operations

    4 Operations 4.1 Light intensity 4.1.1 Range 100% 4.1.2 Control compatible device DMX512-A interface Remotely with DMX512-A / Art-Net / sACN protocols. T Set through RDM protocol or web interface 4.1.3 Parameters 4.1.3.1 Dimming resolution - DMX only T Set through RDM protocol or web interface Resolution DMX mode 8 bits –...
  • Page 14: Set Maximum Position

    4.1.3.3 Set maximum position T Set through RDM protocol or web interface 100% ----> Maximum (80%) 100% 4.1.3.4 Dimming mode T Set through RDM protocol or web interface Mode Result Without PWM Flicker-Free, perfect for filming PWM 17 kHz Good dimming quality (Default Value) PWM 3,2 kHz Very good dimming EN - 12 -...
  • Page 15: Strobe

    4.2 Strobe 4.2.1 Range Strobe duration 255 = 20ms 0 = OFF 1 = 1ms Strobe speed 0 = 0.1Hz 255 = 10Hz 4.2.2 Control T Remotely with DMX512-A / Art-Net / sACN protocols. Mode 3 – 4 DMX512-A 4.3 Response time 4.3.1 Range X ms DMX 0 = 0 ms...
  • Page 16: Beam Size Adjustment

    4.4 Beam size adjustment 4.4.1 Range Field angle Model Minimum angle Maximum angle Configuration 1 without additional lens 15° 35° Configuration 2 with additional lens* 30° 45° (*) Standard delivery 4.4.2 Control Configuration 2 configuration 1: Step 3 Step 2 Step 1 EN - 14 -...
  • Page 17: Orientation

    4.5 Orientation 4.5.1 Range Function Range 0 T 360° TILT TD = 0 T 90° 4.5.2 Control TILT Index 4.6 Colour Fixed colour: Type Standard coloured gel filter Ø 10 Dimensions Values are in mm Installation See section: 3.4.1 EN - 15 -...
  • Page 18: Beam Shaping

    4.7 Beam shaping 4.7.1 Range Open 1 shutter 2 shutters 3 shutters 4 shutters 4.7.2 Control EN - 16 -...
  • Page 19: Beam Rotation

    4.8 Beam rotation 4.8.1 Range Function Range Gobo Shutters 4.8.2 Control EN - 17 -...
  • Page 20: Gobo And Iris

    4.9 Gobo and Iris 4.9.1 Gobo Type Standard gobo - M size • Metal 48 mm • Glass Dimensions Maximum image size 66 mm Values are in mm Installation See section: 3.4.2 4.9.2 Iris Type Standard iris Ø42,5 mm Ø10 mm Dimensions Installation See section: 3.4.2...
  • Page 21: Controls And Parameters

    T If IP address unknown (due to a previous modification), a hard reset must be done (see 6.5 Factory defaults). 5.1.3 Network IP of the computer The computer must be on the same network as the TIBO HE fixture. Please refer to your computer Operating System to change IPV4 parameters : •...
  • Page 22: Leds Feedback

    5.2 LEDs Feedback 5.2.1 Trouble shooting: • During unit initialisation (power up) – up to 5 seconds: Description DMX OUT DMX IN Network Unit OFF Unit error Unit has been reset successfully RDM protocol activated • After initialisation - Node mode "OFF": DMX OUT DMX IN Network...
  • Page 23: Dmx512 - A Remote Control

    5.3 DMX512 - A remote control 5.3.1 Protocol: E1.11 – 2008, USITT DMX512-A 5.3.2 Configuration: Set mode through web interface Set mode through RDM protocol compatible device 1 - Set DMX address 2 - Set personality mode (see 5.3.4. DMX chart) 5.3.3 Parameters: 5.3.3.1 DMX Hold T Set through RDM protocol or web interface...
  • Page 24: Dmx Chart

    5.3.4 DMX chart: Mode 1: Mode 2: Mode 3: Mode 4: DMX address Dimmer8B Dimmer16B Profile8B Profile16b Dimmer Dimmer Dimmer Dimmer Dimmer fine Strobe duration Dimmer fine Strobe speed Strobe duration Response time Strobe speed Control mode Response time Control mode 5.3.5 DMX ranges: 5.3.5.1 Strobe duration Range min...
  • Page 25: Rdm Remote Control

    5.4 RDM remote control ANSI E1.20 – 2010 / ANSI E1.37 - 1 5.4.1 Protocol: For more information about RDM protocol: http://www.rdmprotocol.org/ 115W LED PROFILE Function description V2.20 Queued Message Network Management DISCOVERY_UNIQUE_BRANCH DISCOVERY_MUTE DISCOVERY_UNMUTE COMMUNICATION_STATUS Status Collection QUEUED_MESSAGE STATUS_MESSAGES STATUS_ID_DESCRIPTION CLEAR_STATUS_ID RDM Information...
  • Page 26 115W LED PROFILE Function description V2.20 Queued Message Control IDENTIFY_DEVICE RESET_DEVICE PERFORM_SELFTEST SELF_TEST_DESCRIPTION RDMnet Management LIST_INTERFACES INTERFACE_LABEL INTERFACE_HARDWARE_ADRESS_TYPE1 IPV4_DHCP_MODE IPV4_CURRENT_ADDRESS IPV4_STATIC_ADDRESS INTERFACE_RELEASE_DHCP INTERFACE_APPLY_CONFIGURATION IPV4_DEFAULT_ROUTE DNS_IPV4_NAME_SERVER DNS_HOSTNAME PID Manufacturer SELFTEST_RESULT CURRENT_IP_ADDRESS CURRENT_NETMASK CURRENT_DRIVER_STATUS CUSTOM_RESPONSE_TIME_DESCRIPTION CUSTOM_RESPONSE_TIME_VALUE DATA_MODE_DESCRIPTION DATA_MODE_VALUE STANDALONE_VALUE_DESCRIPTION STANDALONE_VALUE SACN_UNIVERSE_VALUE_DESCRIPTION SACN_UNIVERSE_VALUE ARTNET_UNIVERSE_VALUE_DESCRIPTION ARTNET_UNIVERSE_VALUE SERIAL_DESCRIPTION...
  • Page 27: Art-Net Remote Control

    5.5 Art-Net remote control Artistic Licence Art-Net v3. 5.5.1 Protocol: For more information about Art-Net protocol: http://art-net.org.uk/ 5.5.2 Configuration: Set mode through web interface (see 5.1 Web interface) 1 - If necessary, change IP settings 2 - Set Art-Net Universe 3 - Set DMX address 2 - Set personality mode (see 5.3.4.
  • Page 28: Service

    6 Service 6.1 Preventive maintenance 6.1.1 Frequency General maintenance should be performed at least once a year or more frequently if the equipment is operated in adverse conditions (smoke, heat, humidity, touring, etc.). 6.1.2 General cleaning Remove dust from the unit. Front glasses can be cleaned with solutions containing alcohol.
  • Page 29: Analysis

    6.2 Analysis In case of problem, contact RJ distributor with the following information: • Model, version and serial number of the product. • From the menu status: - Software version - LED board IDs - Device hours • Description of the problem. 6.3 Electronic thermal management system In case of overheating, light intensity will be reduced by the system.
