Operation; Flow Display; Device Connection - Task Force Tips SHO-FLOW 1 Instruction For Operation And Maintenance

5.0

OPERATION

A smartphone app is required to view the flow rate of the SHO-FLOW.
Please download the app from either the Google Play Store or the Apple
App Store before proceeding. Search SHO-FLOW in either store.
1. Create a flow greater than or equal to the minimum rated flow rate
through the SHO-FLOW to turn on the device and start transmitting
the Bluetooth signal.
2. If the app is not already open, find and press the SHO-FLOW app
icon from your list of apps, which will launch the app. (The TFT logo
is displayed while opening and the app will bring you to the main
Flow Display screen.)
3. Allow app to use location if prompted. (This is required for use)
4. If a Bluetooth connection has not already been set up refer to
section 5.2.
5. Once a connection is established, the flow rate and SHO-FLOW
pressure loss will be displayed on the Flow Display screen. (Section
5.1)
5.1

FLOW DISPLAY

The Flow Display screen is used to notify the user of the
current flow rate in the hose line in real time when a
SHO-FLOW is connected. Whenever the app is opened
this screen will open as default.
5.2

DEVICE CONNECTION

The Device Connection screen is used to connect to a SHO-FLOW. The app will remember the device it was connected to and attempt
to connect to that unit. (App will only connect to one SHO-FLOW at a time).
If you wish to connect to a different SHO-FLOW, press the UNPAIR button and find the device you wish to connect to in the device list.
The Bluetooth connection can be released for another user to connect to the SHO-FLOW by one of the following methods:
• Press the UNPAIR button on the Wireless Connection page
• Completely close the app
1. To access this screen, press the MENU button.
2. Then, press the BLUETOOTH CONNECTION button.
©Copyright Task Force Tips LLC 2019-2021
Figure 5.1
7
Figure 5.0
LIE-100 January 29, 2021 Rev06
