EAW Virtural Array KF750P Dimensional Drawing
EAW Virtural Array KF750P Dimensional Drawing

EAW Virtural Array KF750P Dimensional Drawing

Eaw virtural array kf750p: specifications

Advertisement

(8.78)
34.00
15.00
8.19
18.37
30°
TOP
DIMENSIONS APPLY
TO TOP AND BOTTOM
27.00
GRILL PARTIALLY
SHOWN
FRONT
KF750P
A
28.00
9.00
L C
A
1.97
31.00
27.06
1.97

NOTES:

1. SYMBOL
2. SYMBOL
THREADED MOUNTING POINTS.

3. WEIGHT APPROX: 187 LBS.

4. SHIPPING WEIGHT APPROX: 200 LBS.

29.48
9.81
VIEW A-A
DIMENSIONS APPLY
TO BOTH SIDES
PRODUCTION
INDICATES CENTER OF BALANCE.
INDICATES 3/8-16
C L
INPUT

BACK

EASTERN ACOUSTIC WORK
C L
C L
